Orientation of the Document and the Paper Loading

When you load or place a document in the ADF or on the platen glass, the
orientation of the document and the orientation of the paper in the cassette or in the
multi-purpose tray are as shown below.
Document
Specifying the Paper Size and Type (Common for Cassette and Multi-Purpose Tray)
ADF
Cassette
Paper
Multi-
purpose
Copy
tray
Platen glass
Document
