5.1 - 6
9. Configure the parameters for the "Base Service".
10. You have now completed all the important configurations using the configuration

Configuration of the IFR 2968 System Setup

The setup depends on the firmware version of the IFR 2968, the firmware version of the
terminal and the customer programming of the terminal.
Perform the following steps to configure the IFR 2968 System Setup with the terminal
settings:
1. Turn ON the IFR.
2. Press the "Systems" Mode Key (wait until the digital system is initialised).
3. Press the "Tetra Mobile" soft key.
4. Press the "Setup" soft key and enter the System Parameters Screen.
5. Press the "Channel Plan" or "System Type" soft key.
6. Press the "TETRA 380+0MS" soft key for 380
b. Enter the parameters outlined below:
Broadcast:
Broadcast Interval:
Neighbour Cell Channel:
Neighbour Cell Location Area:
Neighbour Cell Identifier:
Slow Re-select Threshold Above Fast:
Fast Re-select Threshold:
Slow Re-select Hysteresis:
Fast Re-select Hysteresis:
a. Press the "Config" soft key twice, then go to "Configure", followed by "Base Serv-
ice", and press the "Select" soft key.
b. Use the default parameters outlined below:
POWER ON REGISTRATION:
POWER OFF DE-REGISTRATION:
PRIORITY CELL:
MINIMUM MODE SERVICE:
MIGRATION:
SYSTEM WIDE SERVICE:
TETRA VOICE SERVICE:
CIRCUIT MODE DATA SERVICE:
(RESERVED):
TETRA PACKET DATA SERVICE:
AIR INTERFACE ENCRYPTION:
ADVANCED LINK:
menu.
Note: Please store these setting in the IFR to be recalled for future use.
Test Setup & Testing for 380–430 MHz
Not supported
5s
3500
1
1
10dB
10dB
10dB
10dB
REQUIRED
REQUIRED
YES
NEVER USED
SUPPORTED
NORMAL MODE
SUPPORTED
NOT SUPPORTED
NOT AVAILABLE
NOT AVAILABLE
NOT AVAILABLE
NOT SUPPORTED
430 MHz.
–
