- Page 1 AHIP6+ Advanced High Integration Platform ® with Pentium II Processor P/N 133172-001B Ó Ó Ó Ó 1998 XYCOM, INC. Printed in the United States of America...
- Page 2 Windows is a registered trademark of Microsoft Corp. in the United States and other countries. Copyright Information This document is copyrighted by Xycom Incorporated (Xycom) and shall not be reproduced or copied without ex- pressed written authorization from Xycom. The information contained within this document is subject to change without notice. Xycom does not guarantee the accuracy of the information and makes no commitment toward keeping it up to date.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction..........................1-1 Product Overview ...........................1-1 Module Features.............................1-1 Architecture.............................1-2 PCI Local Bus Interface..........................1-3 XGA Graphics Controller........................1-3 Fast IDE controller..........................1-3 Expansion Options ..........................1-4 On-board Memory...........................1-4 DRAM ..............................1-4 Flash BIOS ............................1-4 Non-volatile SRAM ..........................1-4 DiskOnChip 2000 ..........................1-5 Serial and Parallel Ports .........................1-5 Keyboard Interface ..........................1-5 Hard and Floppy Drives..........................1-5 Environmental Specifications .........................1-6... - Page 4 Power Connector (PWR1) ........................2-12 Touch Control Connector (TCTRL1) ....................2-12 Touch Connector (TCH1) ........................2-12 Flat Panel Connector (FPNL1 and FPNL2)..................2-12 Backlight Inverter Connector (DCINV1) ....................2-13 Chapter 3 – BIOS Setup Menus ......................3-1 Moving through the Menus ........................3-1 BIOS Main Setup Menu..........................3-2 IDE Submenu ............................3-3 Cache Submenu .............................3-4 Advanced Menu............................3-5...
-
Page 5: Chapter 1 Introduction
Product Overview The Xycom Advanced High-Integration Platform (AHIP6+) board is designed ex- pressly for use in Xycom’s line of flat panel industrial personal computers. The AHIP6+ is optimized in design, layout, and features for use with flat panel computer systems. This integrated design approach allows Xycom industrial PC/ATs to incor- porate “Big PC”... -
Page 6: Architecture
· 32Kx8 and 128Kx8 non- volatile RAM supported · LED interface · Designed specifically for Xycom industrial PC/ATs. Architecture Figure Chapter 1 -1. AHIP6+ Block diagram... -
Page 7: Pci Local Bus Interface
PCI Local Bus Interface The Pentium design uses the 440BX chip set. The 440BX integrates a high perform- ance interface from PCI to IDE. This interface is capable of accelerated data transfers. The 440BX chipset provides an accelerated PCI-to-ISA interface that includes ·... -
Page 8: Expansion Options
ID command. If you experience problems, change the PIO to standard. Expansion Options The AHIP6+ offers expansion when used in conjunction with a Xycom Plug-in Ex- pansion Backplane. This gives the user a total of six full length slots: ·... -
Page 9: Diskonchip 2000
POST (Power On Self Test). The enhanced IDE (EIDE) interface supports up to 2 hard drives. Hard drive inter- face is via the Xycom plug-in backplane or the on-board IDE controller. -
Page 10: Environmental Specifications
Caution The higher the PIO mode, the shorter the cycle time. As the IDE cable length increases, this reduced cycle time can lead to erratic operation. The total IDE cable length must not exceed 18 inches. If two IDE drives are connected, they must not be more than six inches apart. -
Page 11: Hardware Specifications
Hardware Specifications Table Chapter 1 -2. Hardware Specifications Characteristic Specification Power Specifications Typical Maximum +12V 90mA 112.5mA -12V 30mA 37.5mA CPU speed 266 MHz, 333 MHz, 350 MHz, and 400 MHZ PCI Super VGA Graphics Controller 640x480, 800x600, and 1024x768, 64K colors maximum resolution 2 MB video DRAM Serial Ports (2) COM1 is RS-232 or RS-485... -
Page 13: Chapter 2 - Installation
Chapter 2 – Installation This chapter provides information on configuring the AHIP6+ Processor Module. Pinouts for the connectors are located in Appendix C. Figure 2-1 illustrates the jumper and connector locations on the AHIP6+. BACKLIGHT FPGA INTERNAL LED IN INVERTER KEYPAD TOUCH KEYPAD... -
Page 14: Configuration Options
AHIP6+ Manual Configuration Options Jumpers The following tables list AHIP6+ jumpers, their default positions and their functions. The jumpers marked “Access” are placed at the top of the board for easy customer access. Table 2- 1. AHIP6+ Jumpers Jumper Position Function Push button reset switch DISABLED (Access) Push button reset switch ENABLED... -
Page 15: System Interrupts
Chapter 2 – Installation System Interrupts The following table describes the interrupts used on the AHIP6+. Table 2- 3. System Interrupts Interrupt Function IRQ0 System Timer IRQ1 Keyboard IRQ2 Cascade IRQ3 Serial Port* IRQ4 Serial Port* IRQ5 Parallel Port* IRQ6 Floppy Controller IRQ7 Parallel Port*... -
Page 16: Dma Mapping
AHIP6+ Manual DMA Mapping Table 2- 4. DMA Channels Function DMA0 Unused (Could be used for EPP/ECP parallel port option) DMA1 Unused DMA2 Floppy Controller DMA3 Unused (Could be used for EPP/ECP parallel port option) DMA5 Unused DMA6 Unused DMA7 Unused DMA channels 0-3 are 8-bit and DMA channels 5-7 are 16-bit. -
Page 17: I/O Map
SRAM control register (May be remapped based on I/O port 234h) 182-1EF Available 1F0-1F7 IDE Controller (AT Drive) 1F8-22F Available Xycom LED port Xycom Flash control register Xycom IO port control register 278-27F Parallel Port 2 (see Note 1) 280-2F7 Available 2F8-2FF Serial Port 2 (see Note 1) 300-36F Available 370-377 Alt. - Page 18 AHIP6+ Manual Hex Range Device 3B0-3BB mono mode video 3BC-3BF reserved for parallel port 3C0-3CF VGA registers (see Note 2) 3D0-3DF CHIPS flat panel & color mode registers 3E0-3EF Available 3F0-3F7 Primary Floppy disk controller 3F8-3FF Serial port 1 (see Note 1) PCI configuration address register (see Note 4) PCI configuration data register (see Note 4) Note 1...
-
Page 19: Registers
Chapter 2 – Installation Registers The AHIP6+ contains five I/O ports: 231h, 233h, 234h, and a user-definable port (port 180/1h, 2E0/1h, 3E0/1h, or 300/1h). These ports are compatible with AHIP4+ and AHIP 6+. Register 231h – CPU LED Port Register 231h controls the LEDs and signals shown in the following table. Table 2- 7. -
Page 20: Register 234H - I/O Port Location
AHIP6+ Manual Register 234h - I/O Port Location Register 234h controls the I/O port location register shown in the following table. Table 2- 9. Register 234h - I/O Port Location Register Signal Result Reserved Reserved Reserved Reserved I/O range select I/O range select bit 0 I/O range select I/O range select bit 1... -
Page 21: Offset Registers
Chapter 2 – Installation Offset Registers The following registers are located starting at the I/O location defined by register 234h. Table 2- 11. I/O Port Selection (Port Address) I/O port selection Port address 180h 2E0h 3E0h 300h Offset 0 Page Register for Programming (Port Address) Offset 0 is a read-only register that checks the battery status Table 2- 12. -
Page 22: Offset 1 Page Register For Programming (Port Address +1)
AHIP6+ Manual Offset 1 Page Register for Programming (Port Address +1) Offset 1 controls the paging bits for the ROM. This feature is needed for program- ming flash. Table 2- 13. Offset 1 Page Register for Programming (Port Address +1) Signal Result Control ROM/RAM15... -
Page 23: Ps/2 Keyboard/Mouse Connector (Kbms1)
Chapter 2 – Installation · LPT1/COM2 RS-232 connector The BIOS setup determines whether the COM2 is used for the RS-232 connector or the IR interface. Jumpers on the touchscreen controller select the COM2 port or the auxiliary port. If a touchscreen controller is jumpered for COM2, this COM port is not available. -
Page 24: Fpga Program Connector (J15)
AHIP6+ Manual FPGA Program Connector (J15) This eight-pin connector is used to program the lattice FPGA. This pinout matches the standard lattice pinout. ISA/IDE Backplane Connector (ATIDE1) The ISA/IDE Backplane connector is a 120-pin connector. This connector provides both ISA and IDE signals to the backplane. IDE Connector (HDD1) IDE hard drive connector is a 40-pin header. -
Page 25: Backlight Inverter Connector (Dcinv1)
Chapter 2 – Installation Backlight Inverter Connector (DCINV1) This 8-pin connector provides power for the backlight inverter. 2-13... -
Page 27: Chapter 3 - Bios Setup Menus
Chapter 3 – BIOS Setup Menus board’s The AHIP6+ customized BIOS has been designed to surpass the functionality provided for normal PC/ATs. This custom BIOS allows you to access the value-added features on the AHIP6+ module without inter- facing to the hardware directly. Moving through the Menus General instructions for navigating through the screens are described below: Result... -
Page 28: Bios Main Setup Menu
If the setup prompt is enabled on your sys- tem, the BIOS will display the following message: “Press F2 to enter Setup.” Xycom BIOS Setup Utility Main Advanced Security... -
Page 29: Ide Submenu
Cache RAM Displays the amount of cache detected and allows entry into the cache submenu. Shadow RAM Enables or disables the Shadow RAM access. IDE Submenu Xycom BIOS Setup Utility Main IDE Primary Master (C: 1082 Mb) Item Specific Help Type:... -
Page 30: Cache Submenu
2 = Editable only when Type is “User” 3 = Not visible when Type is set to “None” 4 = Not editable when Type is set to “Auto” Cache Submenu Xycom BIOS Setup Utility Main Memory Cache Item Specific Help... - Page 31 BIOS or AT-bus memory. Enabling cache may increase system performance, depending on how the extended BIOS is accessed. The default is disabled. Shadow RAM Submenu Xycom BIOS Setup Utility Main Item Specific Help Shadow RAM [384 KB]* Disabled – This block is not shadowed.
-
Page 32: Advanced Menu
AHIP6+ Manual Advanced Menu Xycom BIOS Setup Utility Main Advanced Security Exit Item Specific Help ?I/O Device Configuration ?Advanced Chipset Control ?PCI Configuration If the item you are viewing has specific Installed O/S: [other] help, it will Reset Configuration Data: [No] be listed here. -
Page 33: I/O Device Configuration Submenu
Chapter 3 – BIOS Setup Menus I/O Device Configuration Submenu Xycom BIOS Setup Utility Advanced I/O Device Configuration Item Specific Help COM A: [Auto] * Base I/O Address [3F8] If the item you * Interrupt [IRQ4] are viewing has specific help, it will... -
Page 34: Advanced Chipset Control Submenu
AHIP6+ Manual Advanced Chipset Control Submenu Xycom BIOS Setup Utility Advanced Advanced Chipset Control Item Specific Help Enable Memory Gap [Disabled] If the item you ECC Config: [Disabled] are viewing has SERR Signal Condition: [Multiple bit] specific help, it will 8-bit I/O Recovery: [3.5]... - Page 35 Chapter 3 – BIOS Setup Menus PCI Configuration Submenu Xycom BIOS Setup Utility Advanced PCI Configuration Item Specific Help ?PCI Device, Slot #1 If the item you ?PCI Device, Slot #2 are viewing has ?PCI/PNP ISA UMB Region Exclusion specific help, it ?PCI/PNP ISA IRQ Resource Exclusion will be listed here.
- Page 36 Setup Defaults ¬® Select Menu Exit Enter Select » Submenu F10 Save & Exit PCI Device, Slot #2 Submenu Xycom BIOS Setup Utility Advanced PCI Configuration, Slot #2 Item Specific Help Option ROM Scan [Enabled] If the item you are viewing has...
- Page 37 Chapter 3 – BIOS Setup Menus PCI/PNP ISA UMB Region Exclusion Submenu Xycom BIOS Setup Utility Advanced PCI/PNP ISA UMB Region Exclusion Item Specific Help CC00-CFFF [Available] If the item you are viewing has D000-D3FF [Available] specific help, it will be listed here.
-
Page 38: On-Board Socket Site Submenu
Change Values Setup Defaults ¬® Select Menu Exit Enter Select » Submenu F10 Save & Exit On-board Socket Site Submenu Xycom BIOS Setup Utility Advanced On-board Socket Site Item Specific Help 32-pin Socket Site Address [Disabled] If the item you... -
Page 39: Flat Panel Submenu
Chapter 3 – BIOS Setup Menus Flat Panel Submenu Xycom BIOS Setup Utility Advanced Flat Panel Item Specific Help Default Panel Type 640 x 480 STN If the item you Video Screen Expansion [ON] are viewing has Simultaneous Video [Disabled] specific help, it will be listed here. -
Page 40: Security Menu
AHIP6+ Manual Security Menu PhoenixBIOS Setup–Copyright 1985-95 Phoenix Technologies Ltd. Main Advanced Security Power Exit Item Specific Help Supervisor Password is: Clear User Password is: Clear Set Supervisor Password: [Enter] If the item you Set User Password: [Enter] are viewing has specific help, it will Password on boot: [Disabled]... -
Page 41: Power Menu
Chapter 3 – BIOS Setup Menus Option Description Diskette Access Restricts access to floppy drives to the supervisor when set to “Supervisor.” Requires setting the Supervisor password. User Mode Defines “User” access as [Normal] or [Restricted]. In normal mode you can access the data/time, user password, power, 32-pin socket, flat panel, boot order, and disk setup settings. -
Page 42: Device Monitoring Submenu
AHIP6+ Manual Device Monitoring Submenu Xycom BIOS Setup Utility Power Device Monitoring Item Specific Help IDE Primary Master [Disabled] If the item you IDE Primary Slave [Disabled] are viewing has IDE Secondary Master [Disabled] specific help, it will IDE Secondary Slave [Disabled] be listed here. -
Page 43: Boot
Chapter 3 – BIOS Setup Menus Boot PhoenixBIOS Setup–Copyright 1985-95 Phoenix Technologies Ltd. Boot Item Specific Help +Removable Devices +Hard Drive If the item you ATAPI CD-ROM Drive are viewing has Network Boot specific help, it will be listed here. ¯... -
Page 44: Exit Menu
AHIP6+ Manual Exit Menu PhoenixBIOS Setup–Copyright 1985-95 Phoenix Technologies Ltd. Main Advanced Security Power Exit Item Specific Help Exit Saving Changes Exit Discarding Changes If the item you Load Setup Defaults are viewing has Discard Changes specific help, it will Save Changes be listed here. -
Page 45: Appendix A- Dram Installation
Part Number Manufacturer 100 MHz SFRAM PC100 Micron MT16LSDT464AG-10BC4 Toshiba THMY6440FIBEG-80H Simple Tech STI644106UD2-10DVG Celestica CLAG052QLBC000 Xycom 128668 Table Chapter 3 –21. 8M x 64 Part Numbers (64 Meg) Part Number Manufacturer SDRAM PC100 Toshiba THMY6480FIBEG-80H Micron MT8LSDT864AG-10BD2 Simple Tech... - Page 46 AHIP6+ Manual DIMM MEMORY LOCKING MECHANISM Insert memory vertically DIMM SOCKET Memory inserted Figure A-1. SDRAM Installation...
-
Page 47: Appendix B- Video Modes
Appendix B– Video Modes Introduction Appendix B defines the video modes and the panels the AHIP6+ supports. Video Modes The Chips & Technologies 69000 VGA controller supports many standard, VESA, and extended modes. The following tables list the standard and extended video modes and whether they passed, failed or are not supported with the CRT, TFT active color, or STN passive color displays. -
Page 48: Extended Modes
AHIP6+ Manual Extended Modes Mode VESA Number Pixels Display C&T Mode of colors mode 640x400 graphics 640x480 graphics 640x480 graphics 640x480 graphics 640x480 graphics 800x600 graphics 800x600 graphics 800x600 graphics 800x600 graphics 1024x768 graphics 1024x768 graphics 1024x768 graphics 1024,768 graphics = Execute VESA.EXE device driver to initiate VESA modes... -
Page 49: Windows 3.1
Appendix B – Video Modes Windows 3.1 Windows 3.1 driver (version 1.1.8) C&T 69000 1024x768x16 1024x768x256 1024x768x32K 1024x768x64K 1280x1024x16 1280x1024x256 640x480x16 640x480x256 640x480x32k 640x480x64k 640x480x16M 800x600x16 800x600x256 800x600x32k 800x600x64k 800x600x16M = All windows' drivers were tested on a NEC multisync 5FG monitor... -
Page 50: Windows '95
AHIP6+ Manual Windows ‘95 Windows 95 driver (version 1.3.2 - included with Windows 95) C&T 65554 PCI 1024x768x16 1024X768X256 1024X768X16bit 1024x768x24bit 640x480x16 640x480x256 640x480x16bit 640x480x24bit 800x600x16 800x600x256 800x600x16bit 800x600x24bit... -
Page 51: Appendix C- Pinouts
Appendix C– Pinouts This appendix describes the pinouts for the AHIP6+ connectors defined in Chapter 2. VGA Connector (VGA1) Signal GREEN BLUE ORB_GND ORB_GND ORB_GND ORB_GND Fused VCC ORB_GND DDCDAT HSYNC VSYNC DDCCLK NC = no connect... -
Page 52: Com1 Connector Rs-232/Rs-485 (Com1_4
AHIP6+ Manual COM1 Connector RS-232/RS-485 (COM1_4) Signal Siganl DCD1 TXD- RXD1 TXD+ TXD1 TXD TERM - DTR1 TXD TERM + DSR1 RXD- RTS1 RXD+ CTS1 RXD TERM + RXD TERM - Note ‘A’ denotes the lower connector (RS-232) and ‘B’ denotes the upper connector (RS-485). - Page 53 Appendix C – Pinouts Signal Signal INIT SELIN DTR2 Note ‘A’ denotes the lower connector (LPT1) and ‘B’ denotes the upper con- nector (COM2, RS-232). This connector also contains the remote system reset option The reset jumper (J1) must be in position B for this option to work.
-
Page 54: Fpga Program Connector (J15
AHIP6+ Manual FPGA Program Connector (J15) Signal SDO* SDI* ISPEN* MODE* SCLK* DCIN1 Power Connector (PWR1) Signal Note -5V is not provided by the power supplies and will have to be created on the backplane board. -
Page 55: Touch Control Connector (Tctrl1
Appendix C – Pinouts Touch Control Connector (TCTRL1) Signal Signal KB_AIN0 +12V KB_AIN1 -12V RESET TXD2 TCH_RXD2 KB_P14 KB_P15 KB_P16 AUX_DATA KB_P17 AUX_CLK SENSE TCH_LED*... -
Page 56: Touch Connector (Tch1
AHIP6+ Manual Touch Connector (TCH1) Signal SENSE Internal Mouse Connector (MS2) Signal 5VFUSE AUX_CLK AUX_DATA... -
Page 57: Internal Led Connector (Ledmsc1
Appendix C – Pinouts Internal LED Connector (LEDMSC1) Signal Signal 5VFUSE KSI(6) 5VFUSE IR_RXD2 COM_LED TXD2 ALPHA_LED IR_MODE USER_LED KSO(12) IDEACTP_LED KSI(7) LED In_Keypad Connector (LEDKB1) Signal Signal IDEACTP_LED USER_LED ALPHA_LED IR_MODE COM_LED TXD2 IR_RXD2 +5V (thru 330W res) -
Page 58: Flat Panel Connector (Fpnl1 And Fpnl2
AHIP6+ Manual Flat Panel Connector (FPNL1 and FPNL2) Signal Signal SHFCLK P(4) P(5) P(6) P(7) P(16) P(17) VCCSW P(18) VCCSW P(19) P(20) PANEL_LOGIC P(21) PANEL_LOGIC P(22) +3.3V_CPU P(23) +3.3V_CPU P(8) FPSEL(0) P(9) FPSEL(1) P(10) FPSEL(2) P(11) FPSEL(3) +12V P(12) NC(Note 1) P(13) ENAVEE P(14) -
Page 59: Internal Keyboard Connector (Kybd1
Appendix C – Pinouts Internal Keyboard Connector (KYBD1) Signal KB_CLK KB_DATA 5VFUSE SPEAKER PS/2 Keyboard/Mouse Connector (KBMS1) Note If the touchscreen controller is using the mouse port, this interface will not be available. Signal Signal KB_DATA AUX_DATA 5VFUSE 5VFUSE KB_CLK AUX_CLK Internal Floppy Connector (FDD1) Signal... -
Page 60: External Floppy Connector (Fdd2
AHIP6+ Manual External Floppy Connector (FDD2) Signal Signal FSTEP* IDX* FDS1* FWD* FWE* DCHG* FTK0* FWP* MO1* FRDD* FDIRC* FHS* C-10... -
Page 61: Ide Connector (Hdd1
Appendix C – Pinouts IDE Connector (HDD1) Signal Signal IDERESET* HDRQ0 HDD7 HDIOW* HDD8 HDD6 HDIOR* HDD9 HDD5 HDIORDY HDD10 ALE (pullup) HDD4 HDAK0 HDD11 HDD3 IRQ14 HDD12 HDIOCS16* HDD2 HDA1 HDD13 HDD1 HDA0 HDD14 HDA2 HDD0 HDCS0* HDD15 HDCS1* IDEACTP* C-11... -
Page 62: Isa/Ide Backplane Connector (Atide1
AHIP6+ Manual ISA/IDE Backplane Connector (ATIDE1) Signal Signal SD(7) IOCHK* SD(6) RESETDRV SD(5) IRQ9 SD(4) -5V (nc) SD(3) DRQ2 SD(2) 0WS* SD(1) IOCHRDY SD(0) SA(19) SMEMW* SA(18) SMEMR* SA(17) IOW* SA(16) IOR* SA(15) DACK3* SA(14) DRQ3 SA(13) DACK1* SA(12) DRQ1 SA(11) REF* SA(10) - Page 63 Appendix C – Pinouts Signal Signal HDDACK0* DACK7* HDDRQ0 DRQ7 RESERVED MASTER16* HDD(7) IDERST* HDD(6) HDD(8) HDD(5) HDD(9) HDD(4) HDD(10) HDD(3) HDD(11) HDD(2) HDD(12) HDD(1) HDD(13) HDD(0) HDD(14) HDIOW* HDD(15) HDIORDY HDIOR* IDE_IRQ HDIOCS16* HDA0 HDA1 HDCS0* HDA2 IDEACTP* HDCS1* C-13...
-
Page 64: Pci Backplane Connector (Pcimg1
AHIP6+ Manual PCI Backplane Connector (PCIMG1) Signal Signal -12V +12V PIRQA* PIRQC* PIRQB* PIRQD* PCLKS3 REQ3* REQ1* GNT3* GNT1* PCLKS2 PCIRST* PCLKS0 GNT0* REQ0* REQ2* AD(30) PAD(31) +3.3V_CPU PAD(29) PAD(28) PAD(26) PAD(27) PAD(25) PAD(24) +3.3V_CPU GNT2* C_BE*(3) +3.3V_CPU PAD(23) PAD(22) PAD(20) PAD(21) PAD(19) - Page 65 Appendix C – Pinouts Signal Signal PAD(15) C_BE*(1) +3.3V_CPU PAD(14) PAD(13) PAD(11) PAD(12) PAD(10) PAD(9) C_BE*(0) PAD(8) +3.3V_CPU PAD(7) PAD(6) +3.3V_CPU PAD(4) PAD(5) PAD(3) PAD(2) PAD(0) PAD(1) REQ64* (pullup) ACK64* (pullup) C-15...
-
Page 66: Keypad Connector (Keypad1
AHIP6+ Manual Keypad connector (KEYPAD1) Signal Signal KSI(7) KSO(9) KSO(0) KSO(10) KSO(1) KSI(0) KSO(2) KSI(1) KSO(3) KSI(2) KSO(4) KSI(3) KSO(5) KSI(4) KSO(6) KSI(5) KSO(7) KSI(6) KSO(8) USB Connector Description Description 5V Fuse USBP0+ USBP1+ USBP0- USBP1- C-16... - Page 67 Index Advanced Menu, BIOS setup........3-6 DRAM A-1 BIOS compatibility ..........3-18 Interrupts 2-3 BIOS menus BIOS controlled..........2-3 Advanced Menu ..........3-6 defaults 2-3 Advanced Chipset Control Sub-menu ..3-8 jumpers Integrated Peripherals Sub-menu3-7, 3-12, 3-13, location 2-1 3-16 Jumpers Exit Menu..........
