Halsey Taylor MPW100 Instructions

Mounting Plate Instructions
Installer
To assure you install this model easily and correctly, PLEASE READ THESE
SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK
YOUR INSTALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL
AND OTHER APPLICABLE CODES. After installation, keep these instructions
for future reference.
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
Parts List
Refer to the illustration to make sure you receive all mounting plate parts. If any parts are missing, please
call our Customer Care at 1.800.476.4106.
Halsey Taylor - www.halseytaylor.com
Model MPW100
This Mounting Plate System is designed for use
with the single OVL II™ Series.
ITEM NO. QTY.
1 1
2 16
3 16
4 4
2
MPW100
IMPORTANT
PART NO. DESCRIPTION
28791C Mounting Plate
70020C Hex Nut 5/16-18
75541C Flat Washer .339/.359ID
75708C Threaded Rod 5/16-18 x 6 In.
1
3
PAGE 1
4
98371C (Rev. B - 08/16)
