In the interests of user-safety (Required by safety regulations in some countries) the set should be re-

stored to its original condition and only parts identical to those specified should be used.

The LC-13SH1E, LC-15SH1E Service Manual (SY4C2LC13SH1E) has typo on page 11.

This Supplement has been issued to make corrections.

Note also the partial modification on page 13. This modification is also related to Model LC-15SH2E.

You are kindly requested to take care of this change too.

SERVICE MANUAL

SUPPLEMENT

LCD COLOUR TELEVISION

MODELS

OUTLINE

SHARP CORPORATION

LC-13SH1E

LC-15SH1E

LC-13SH1E

LC-15SH1E

SUPPLEMENT

S25F9LC13SH1E

Page 1 OUTLINE The LC-13SH1E, LC-15SH1E Service Manual (SY4C2LC13SH1E) has typo on page 11. This Supplement has been issued to make corrections. Note also the partial modification on page 13. This modification is also related to Model LC-15SH2E.
Page 2 LC-13SH1E LC-15SH1E SUPPLEMENT » Precautions at the time of the side B(back) service of main and sub unit. 1. Remove only SC1203 of the FFC for connection between Main unit (SC1203) and LCD panel, and connect the extended cable (QCNW-A553WJZZ) for service.
Page 3 LC-13SH1E LC-15SH1E SUPPLEMENT 5. Adjustment 5-1. RF AGC adjustment 1) Feed the colour bar signal. 2) In Adjustment Mode, select the RF AGC AUTO ("OFF") and press the " RIGHT" cursor key to start the adjustment. 3) Automatic adjustment is complete when it display "OK" is displayed.
Page 4 LC-13SH1E LC-15SH1E SUPPLEMENT COPYRIGHT © 2005 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
