Panasonic NR-B420M Service Manual

Hide thumbs

Advertisement

Quick Links

Service Manual
MODELS:
CFCs have been used in refrigerator as refrigerant and the insulation materials for many years.
But it is now known that these compounds which once seemed so ideal for use as cleaning
agents and in refrigeration systems, destroy the earth's ozone layer. As a result, an
international body decided on a total worldwide ban of harmful CFCs by the end 1995.
EXPLANATION OF COLOUR CODE
The suffix of model number shows the colour
of that unit as in the following table.
Suffix
S
TITANIUM SILVER
W
NR-B420M/MS/MW, B480M/MS/MW, B570M/MS/MW/D, B53D2,
B643M/MS/MW/D, B703M/MS/MW, C603D, C703M/MS/MW/D
Colour
WHITE
NR-B570D
