U-Line H-7799 Quick Start Manual

H-7799
OUTDOOR BLUETOOTH
PADLOCK
UNLOCK WITH KEYPAD
1. Enter Primary Code by pressing
the corresponding directions
on lock keypad.
NOTE: Do not pull on the
shackle when entering
code.
2. When lock lights green, open
within five seconds or it will relock.
UNLOCK WITH MOBILE DEVICE
1. On mobile device, visit app store and download the
free Master Lock Vault eLocks app.
2. Follow prompts to log into, or create, a Master Lock
Vault account.
3. In Master Lock Vault eLocks app, press Add a Lock (+).
4. Enter Activation Code to register lock and follow
instructions to connect mobile device to lock.
5. Press any button on lock keypad to wake up
lock and prompt it to communicate with your mobile
device.
NOTE: Lock is now in Touch Unlock mode.
Recalibrate the phone-to-lock communication
range in the app settings.
LED KEYPAD INDICATORS
BLUE GREEN
Open or
Locked,
unlocked and
communicating,
waiting to be
or keypad entry
opened
PAGE 1 OF 3
1-800-295-5510
uline.com
USAGE
YELLOW RED
Invalid
Low battery
keypad entry
HOW TO UNLOCK WITH EXTERNAL BATTERY
1. If battery dies in locked position,
remove bottom cover. (See Figure 1)
2. Hold a 9V battery to jump contacts on
bottom of lock. (See Figure 2)
3. If in Touch Unlock mode, hold the
battery in place with authorized
mobile device within range and press
any keypad button on the lock. If it
does not unlock, enter primary code on
lock keypad.
4. When unlocked, open battery door
and install a new CR2 battery.
(See Figure 3)
BATTERY REPLACEMENT
1. Lock will light yellow to indicate a
low battery.
2. Unlock and open the lock.
3. Remove bottom cover. (See Figure 4)
4. Use a coin to turn battery door slot
90 degrees counter clockwise. Open
battery door and remove old battery.
(See Figure 5)
5. Install a new CR2 battery with positive
(+) side facing right.
6. Close battery door, turn slot back
90 degrees clockwise and replace
bottom cover. (See Figure 6)
Para Español, vea página 2.
Pour le français, consulter la page 3.
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
0521 IH-7799
