- Page 1 148MM MODEL: EIR047 NAME: 16 IN 1 LIGHTNING ARCADE BASKETBALL GAME ASSEMBLY INSTRUCTIONS WE ENCOURAGE OUR CUSTOMERS TO LEAVE REVIEWS OF OUR PRODUCTS ON THE RETAILER'S WEBSITE WHERE THE PRODUCT WAS PURCHASED.
-
Page 2: Assembly Tips
ASSEMBLY TIPS: 1 - Please read the instructions carefully, and follow all assembly, operation or safety instructions properly in order to avoid damage or injury. 2 - Some figures or drawings may not look exactly like your product. Please read and understand the text before beginning each assembly step. -
Page 3: Parts List
PARTS LIST Triangle Frame Triangle Frame Cross Bar Rear Support (1pc) (1pc) (4pcs) (1pc) Rear Support Middle Support Middle Support Top Poles (1pc) (1pc) (1pc) (2pcs) Basketball Rim Front Legs Front Handrail "T" Style Connector (2pcs) (2pcs) (1pc) (2pcs) Scoreboard Backboard Score Trigger (1pc) - Page 4 ASSEMBLY INSTRUCTIONS FIG.1 Assemble the scoreboard #16 on the backboard #15 as shown in FIG.1. Front Back FIG.2 Slide the trigger #14 into the metal track. And please make sure the trigger is reached Connect the wire of the trigger #14 to the bottom.
- Page 5 FIG.3 Plug wires of both triggers into the scoreboard #16. Back FIG.4 Front Fix the rim by screw set #20. Slide the rim #12 into the metal track. And please make sue the rim is on top Noted: Please ensure that washers are used of trigger.
- Page 6 FIG.5 Attach the net #13 on the rim as shown. HOW TO ASSEMBLE THE FRAME FIG.6 Back Back...
- Page 7 FIG.7 Back Back FIG.8 Front Front...
- Page 8 FIG.9 Connect the backboard #15 with base frame. This step requires 2 people to assemble it together. Back Back FIG.10 Insert tubes #8 with #15 backboard Back Front...
- Page 9 FIG.11 Front Front...
- Page 10 FIG.12 Follow the below steps to assemble the ball return net with frame. Back Slide in the elastic straps onto Tube #8, then slide the sleeves of ball return net #17 onto tubes at the top Fasten the return net velcro strap through the hook Fasten the return net velcro around the tube.
- Page 11 FIG.13 Please connect cross bar #3 with connectors #11 on both ends. FIG.14 FIG.14-1 Slide in the return net #17 onto front handrail #10 FIG.14-2 FIG.14-3 Please circle the Velcro strap on the handrail to make sure the return net is tight.
- Page 12 FIG.15 Please place the controller #22 on the right corner of handrail by fasten screw #24. Shown in FIG 15-A Connect bigger connector of wire #23 through the net sleeve on controller #22 and the other connector to scoreboard #16 in FIG 15-B and 15-C YOU ARE NOW READY TO PLAY!
- Page 13 ELECTRONIC SCORER OPERATION START ON/OFF button. To turn on/turn off the power. Once you turn it on, you will see timmer show (01) which mean 1st game and push the buttom to start playing. GAME button. To select the game you like to play. you can see the number of game you select on the timmer. VOLUME button.
-
Page 14: Game Options
GAME OPTIONS 1. BEAT THE TIME CLOCK - 30S Player 1P or 2P ● Select playing time 30 seconds ● Select the basket you want to play ● All shots are worth 2 points until the final 10 seconds or award time when each shot is ●... - Page 15 6. TRAINING Player 1P or 2P. ● Playing Time: No Limit. ● All shots are worth 2 points. ● Choose the 2-player mode and the player with most points scored wins. ● 7. TEAM Player 2P or 4P. ● Playing Time: 30 seconds. ●...
- Page 16 13. SCORING STREAK Player 1P or 2P. ● Playing time: no limit. ● Select the basket you want to play. ● When you hear "Ready 3,2,1 go, then you have to pay attention the 3,2,1 counted down on the ● screen, then shoot the ball to selected basket in 3S, if ball in, game will keep going, if not, game over.
- Page 17 HOW TO FOLD UP STEP 1 Remove the locking pin #21. Repeat the step on the other side. STEP 2 Push the front handrail # 10 upwards to fold up. STEP 3 Put the locking pin #21 back. Repeat the step on the other side.
