NETGEAR Orbi RBKWM Quick Start Manual

Install the wall mount with the cradle
You must prepare the wall mount before
following these instructions. For more
information, see Prepare the wall mount on
the other side of this quick start guide.
If you need to use the cradle but your Orbi
product is too small for the cradle, see Install
the wall mount with the cradle for smaller Orbi
products.
Note: These instructions show the Orbi
AC3000 Tri‑band WiFi System (model RBK50).
1
2
3
4 5
Install the wall mount with the cradle for
smaller Orbi products
You can adjust the cradle to fit smaller Orbi
products.
You must prepare the wall mount before
following these instructions. For more
information, see Prepare the wall mount on
the other side of this quick start guide.
Note: These instructions show the Orbi
Tri‑band WiFi System (model RBK20).
1
2
3
4 5
Orbi Wall-Mounting Kit
Quick Start Guide
Model RBKWM
