20201006171709_32K1BF000_eng_BOOK Page 1 Tuesday, October 06 2020 17:20:39 JST
This manual should be considered a permanent part of the vehicle
and should remain with the vehicle when it is resold.
This publication includes the latest production information available
before printing. Honda Motor Co., Ltd. reserves the right to make
changes at any time without notice and without incurring any
obligation.
No part of this publication may be reproduced without written
permission.
The vehicle pictured in this owner's manual may not match your
actual vehicle.
© 2020 Honda Motor Co., Ltd.

Advertisement

Table of Contents
loading

Related Manuals for Honda NSS350A E 2020

Summary of Contents for Honda NSS350A E 2020

  • Page 1 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 2 Welcome Congratulations on your purchase of a new The illustrations here in are based on the ● Honda vehicle. Your selection of a Honda NSS350A ED type. makes you part of a worldwide family of satisfied customers who appreciate Honda's...
  • Page 3 20201006171709_32K1BF000_eng_BOOK Page 3 Tuesday, October 06 2020 17:20:39 JST A Few Words About Safety Your safety, and the safety of others, is very DANGER important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about WARNING safety, we have provided operating...

  • Page 4: Table Of Contents

    20201006171709_32K1BF000_eng_BOOK Page 4 Tuesday, October 06 2020 17:20:39 JST Contents Vehicle Safety P. 2 Operation Guide P. 20 Maintenance P. 77 Troubleshooting P. 110 Information P. 133 Specifications P. 149 Index P. 152...

  • Page 5: Vehicle Safety

    20201006171709_32K1BF000_eng_BOOK Page 5 Tuesday, October 06 2020 17:20:39 JST Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Image Labels............P. 6 Safety Precautions..........P. 11 Riding Precautions ..........

  • Page 6: Safety Guidelines

    20201006171709_32K1BF000_eng_BOOK Page 6 Tuesday, October 06 2020 17:20:39 JST Safety Guidelines Safety Guidelines Instruct your passenger on holding onto the grab rails or your waist, leaning with you in Follow these guidelines to enhance your safety: turns, and keeping their feet on the footpegs, Perform all routine and regular inspections even when the vehicle is stopped.
  • Page 7 20201006171709_32K1BF000_eng_BOOK Page 7 Tuesday, October 06 2020 17:20:39 JST Safety Guidelines Make Yourself Easy to See Keep Your Honda in Safe Condition Make yourself more visible, especially at night, It's important to keep your vehicle properly by wearing bright reflective clothing, positioning maintained and in safe riding condition.
  • Page 8 20201006171709_32K1BF000_eng_BOOK Page 8 Tuesday, October 06 2020 17:20:39 JST Safety Guidelines If you decide to continue riding, first turn the Never run your vehicle inside a garage or other ignition switch to the (Off) position, and enclosure. evaluate the condition of your vehicle. Inspect WARNING for fluid leaks, check the tightness of critical nuts Running the engine of your vehicle...

  • Page 9: Image Labels

    20201006171709_32K1BF000_eng_BOOK Page 9 Tuesday, October 06 2020 17:20:39 JST Image Labels Image Labels The following pages describe the label Read instructions contained in Owner's meanings. Some labels warn you of Manual carefully. potential hazards that could cause serious injury. Others provide important safety Read instructions contained in Shop Manual information.
  • Page 10 20201006171709_32K1BF000_eng_BOOK Page 10 Tuesday, October 06 2020 17:20:39 JST Image Labels BATTERY LABEL DANGER • Keep flame and spark away from the battery. Battery produce explosive gas that can cause explosion. • Wear the eye protection and rubber gloves when handling the battery, or you can get burned or lose your eyesight by the battery electrolyte.
  • Page 11 20201006171709_32K1BF000_eng_BOOK Page 11 Tuesday, October 06 2020 17:20:39 JST Image Labels RADIATOR CAP LABEL DANGER NEVER OPEN WHEN HOT. Hot coolant will scald you. Relief pressure valve begins to open at 1.1 kgf/cm ACCESSORIES AND LOADING WARNING LABEL WARNING ACCESSORIES AND LOADING •...
  • Page 12 20201006171709_32K1BF000_eng_BOOK Page 12 Tuesday, October 06 2020 17:20:39 JST Image Labels TYRE INFORMATION LABEL Cold tyre pressure: [Driver only] Front 200 kPa (2.00 kgf/cm , 29 psi) Rear 225 kPa (2.25 kgf/cm , 33 psi) [Driver and passenger] Front 200 kPa (2.00 kgf/cm , 29 psi) Rear 225 kPa (2.25 kgf/cm...
  • Page 13 20201006171709_32K1BF000_eng_BOOK Page 13 Tuesday, October 06 2020 17:20:39 JST Image Labels CARGO LIMIT LABEL Do not exceed 10 kg (22 lb). CARGO LIMIT LABEL Ⅲ E, Ⅶ E, Ⅱ ED, Ⅵ ED type only Do not exceed 5.0 kg (11.0 lb). CARGO LIMIT LABEL Do not exceed 1.5 kg (3.3 lb).

  • Page 14: Safety Precautions

    20201006171709_32K1BF000_eng_BOOK Page 14 Tuesday, October 06 2020 17:20:39 JST Safety Precautions Safety Precautions Face shield with unobstructed field of vision ● or other approved eye protection Ride cautiously and keep your hands on the WARNING ● handlebar and feet on the step board. Not wearing a helmet increases the Keep passenger's hands onto the grab rails ●...

  • Page 15: Riding Precautions

    20201006171709_32K1BF000_eng_BOOK Page 15 Tuesday, October 06 2020 17:20:39 JST Riding Precautions Riding Precautions Brakes Observe the following guidelines: Running-in Period Avoid excessively hard braking. ● Sudden braking can reduce the vehicle's During the first 500 km (300 miles) of running, stability.
  • Page 16 ABS operation. the handlebar, lock the ignition switch P. 53) and leave your vehicle while taking the Honda SMART Key with you. Deactivate Wet or Rainy Conditions the Honda SMART Key system if necessary. Road surfaces are slippery when wet, and wet P.
  • Page 17 20201006171709_32K1BF000_eng_BOOK Page 17 Tuesday, October 06 2020 17:20:39 JST Riding Precautions Parking with the Side Stand or Centre Left handle grip Stand Centre stand Left grab rail Stop the engine. Using the side stand Push the side stand down. Slowly lean the vehicle to the left until its weight rests on the side stand.
  • Page 18 20201006171709_32K1BF000_eng_BOOK Page 18 Tuesday, October 06 2020 17:20:39 JST Riding Precautions Refuelling and Fuel Guidelines Follow these guidelines to protect the engine, fuel system and catalytic converter: Use only unleaded petrol. ● Use recommended octane number. Using ● lower octane petrol will result in decreased engine performance.
  • Page 19 Always use the recommended tyres and the Honda Genuine Parts for drive system such as the drive belt and weight rollers, to ensure correct Torque Control operation.

  • Page 20: Accessories & Modifications

    We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed for your vehicle by Honda or make Follow all instructions in this owner's modifications to your vehicle from its original manual regarding accessories and design.

  • Page 21: Loading

    20201006171709_32K1BF000_eng_BOOK Page 21 Tuesday, October 06 2020 17:20:39 JST Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your vehicle's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed for the load you are carrying.
  • Page 22 20201006171709_32K1BF000_eng_BOOK Page 22 Tuesday, October 06 2020 17:20:39 JST...

  • Page 23: Operation Guide

    20201006171709_32K1BF000_eng_BOOK Page 23 Tuesday, October 06 2020 17:20:39 JST Parts Location Seat (P.72) Document bag (P.75) Throttle grip (P.104) Front brake fluid reservoir (P.101) Front brake lever Emergency seat opener (P.120) Luggage box (P.74) Battery (P.93) Main fuse (P.130) Fuse boxes (P.129) Coolant reserve tank (P.98)
  • Page 24 20201006171709_32K1BF000_eng_BOOK Page 24 Tuesday, October 06 2020 17:20:39 JST Windscreen (P.106) Rear brake fluid reservoir (P.101) Rear brake lever Glove box (P.76) USB socket (P.70) Helmet holder (P.73) Tool kit (P.92) Fuel fill cap (P.68) EM mode connector (P.122) Rear suspension spring preload adjuster (P.105) Centre stand...
  • Page 25 20201006171709_32K1BF000_eng_BOOK Page 25 Tuesday, October 06 2020 17:20:39 JST Instruments Tachometer NOTICE Do not operate the engine in the tachometer red zone. Excessive engine speed can adversely affect engine life. Speedometer Tachometer red zone (excessive engine rpm range) button INFO A button INFO B Display Check...
  • Page 26 20201006171709_32K1BF000_eng_BOOK Page 26 Tuesday, October 06 2020 17:20:39 JST Clock Fuel gauge Clock setting: (P.30) (P.35) Status icon Ⅴ E, Ⅶ E, Ⅳ ED, Ⅵ ED type Displays the status of the voice control system. Oil change indicator (P.57) (P.31) Maintenance indicator (P.32)
  • Page 27 20201006171709_32K1BF000_eng_BOOK Page 27 Tuesday, October 06 2020 17:20:39 JST Instruments (Continued) Switching the Display button switches between the tripmeter A and tripmeter B. Also button INFO A INFO A switches between the average fuel mileage and elapsed time. Tripmeter A Tripmeter A Tripmeter B Tripmeter B...
  • Page 28 20201006171709_32K1BF000_eng_BOOK Page 28 Tuesday, October 06 2020 17:20:39 JST Current fuel mileage E, Ⅲ E, Ⅴ E, Ⅶ E type ● If the calculated value is less than 0.1 Displays the current or instant fuel mileage. mile/gal (mile/L, L/100km or km/L): “0.0” is Display range: displayed.
  • Page 29 20201006171709_32K1BF000_eng_BOOK Page 29 Tuesday, October 06 2020 17:20:39 JST Instruments (Continued) Average fuel mileage ED, Ⅱ ED, Ⅳ ED, Ⅵ ED type ● If the calculated value is less than 0.1 L/ Displays the average fuel mileage since the 100km (km/L): “0.0” is displayed. selected tripmeter was reset.
  • Page 30 20201006171709_32K1BF000_eng_BOOK Page 30 Tuesday, October 06 2020 17:20:39 JST fuel is below 1.0 L (0.26 US gal, 0.22 Imp Available driving distance gal): “---” is displayed. Displays the estimated distance you can travel on the remaining fuel. The indicated When “---” is displayed except for the above- available driving distance is calculated based mentioned cases, go to your dealer for on the driving conditions, and the indicated...
  • Page 31 20201006171709_32K1BF000_eng_BOOK Page 31 Tuesday, October 06 2020 17:20:39 JST Instruments (Continued) Elapsed time To reset the tripmeter, average fuel mileage and elapsed time Displays the elapsed time during the engine running since the selected tripmeter was To reset tripmeter A, average fuel mileage reset.
  • Page 32 20201006171709_32K1BF000_eng_BOOK Page 32 Tuesday, October 06 2020 17:20:39 JST To reset tripmeter B, average fuel mileage Coolant temperature gauge and elapsed time (these are based on When the coolant is over specified tripmeter B) together, press and hold the temperature, the segment H flashes and high button while tripmeter B is displayed.
  • Page 33 20201006171709_32K1BF000_eng_BOOK Page 33 Tuesday, October 06 2020 17:20:39 JST Instruments (Continued) Fuel gauge Air temperature gauge Remaining fuel when there is only 1st (E) Shows ambient temperature. segment: approximately 2.32 L (0.613 US gal, Display range: −10 to 50°C 0.510 Imp gal). Below −10°C: “---”...
  • Page 34 20201006171709_32K1BF000_eng_BOOK Page 34 Tuesday, October 06 2020 17:20:39 JST The indicator does not go off until it is reset. Oil change indicator The indicator is turned on whenever the running distance reaches the programmed oil Oil change indicator change interval. When the oil change indicator is appeared, reset the indicator after changing the engine oil.
  • Page 35 20201006171709_32K1BF000_eng_BOOK Page 35 Tuesday, October 06 2020 17:20:39 JST Instruments (Continued) The maintenance indicator is appeared when Maintenance indicator the running distance reaches every 8,000 mile The indicator is turned on whenever the (12,800 km) after first indication was reset. running distance reaches the programmed The indicator does not go off until it is reset.
  • Page 36 20201006171709_32K1BF000_eng_BOOK Page 36 Tuesday, October 06 2020 17:20:39 JST To check the remaining distance To reset the oil change indicator and maintenance indicator You can check the remaining distance to next interval of the oil change and maintenance. Press and hold the button and INFO A When the...
  • Page 37 20201006171709_32K1BF000_eng_BOOK Page 37 Tuesday, October 06 2020 17:20:39 JST Instruments (Continued) Press the button. Press the button. INFO B INFO B The oil change indicator and remaining The maintenance indicator and remaining distance are reset, then the maintenance distance are reset, then the display will indicator and remaining distance start return to the ordinary display after next flashing after next interval of the oil...
  • Page 38 20201006171709_32K1BF000_eng_BOOK Page 38 Tuesday, October 06 2020 17:20:39 JST Display Setting Ordinary display Following items to change sequentially. • Time format setting • Clock setting Time format setting • Backlight brightness adjustment • E, Ⅲ E, Ⅴ E, Ⅶ E type only Clock setting Changing of mileage unit •...
  • Page 39 20201006171709_32K1BF000_eng_BOOK Page 39 Tuesday, October 06 2020 17:20:39 JST Instruments (Continued) 1 Time format setting: 2 Clock setting: You can switch the time format between 12 Press the button until the desired INFO A hour format or 24 hour format. hour is displayed.
  • Page 40 20201006171709_32K1BF000_eng_BOOK Page 40 Tuesday, October 06 2020 17:20:39 JST Press the button. The clock is set, INFO B E, Ⅲ E, Ⅴ E, Ⅶ E type and then the display moves to the backlight Press the button. The backlight is INFO B brightness adjustment.
  • Page 41 20201006171709_32K1BF000_eng_BOOK Page 41 Tuesday, October 06 2020 17:20:39 JST Instruments (Continued) 4 Changing of mileage unit: 5 Changing of fuel mileage meter unit: Press the button to select “L/100km” E, Ⅲ E, Ⅴ E, Ⅶ E type only INFO A or “km/L”.
  • Page 42 20201006171709_32K1BF000_eng_BOOK Page 42 Tuesday, October 06 2020 17:20:39 JST Bluetooth pairing setting ® Except Ⅴ E, Ⅶ E, Ⅳ ED, Ⅵ ED type Press the button. The fuel mileage INFO B Ⅴ E, Ⅶ E, Ⅳ ED, Ⅵ ED type only meter unit is set, and then the display will You can reset the Bluetooth pairing...
  • Page 43 20201006171709_32K1BF000_eng_BOOK Page 43 Tuesday, October 06 2020 17:20:39 JST Instruments (Continued) Press the button. the display will return to ordinary INFO B Bluetooth pairing setting is set. display. ® Select "no" Return to and follow the Display will return to the ordinary display. procedure again.
  • Page 44 If one of these indicators does not come on when it should, have your dealer check for problems. Honda SMART Key Indicator Comes on when vehicle and Honda SMART Key verification is complete, and the ignition switch can be operated.
  • Page 45 20201006171709_32K1BF000_eng_BOOK Page 45 Tuesday, October 06 2020 17:20:39 JST Indicators (Continued) Left turn signal Torque Control indicator Comes on when the ignition switch is turned to the (On) indicator ● position. Goes off when your speed reaches approximately 3 km/h (2 mph) to indicate Torque Control is ready to work. Blinks when Torque Control is operating.
  • Page 46 20201006171709_32K1BF000_eng_BOOK Page 46 Tuesday, October 06 2020 17:20:39 JST...
  • Page 47 Used to switching the display. Also used to operate and set the display. (P.35) (P.24) Multi switch Also used to operate and set the display. Ⅴ E, Ⅶ E, Ⅳ ED, Ⅵ ED type (P.35) Operate the Honda Smartphone Voice Control system. (P.57)
  • Page 48 20201006171709_32K1BF000_eng_BOOK Page 48 Tuesday, October 06 2020 17:20:39 JST Windscreen adjusting switch Push up or down to adjust the windscreen height. (P.106) Ignition switch (On) Switches the electrical system on/off, locks Turns electrical system on the steering and glove box, and operates for starting/riding.
  • Page 49 20201006171709_32K1BF000_eng_BOOK Page 49 Tuesday, October 06 2020 17:20:39 JST Switches (Continued) Steering Lock Locking Turn the handlebar all the way to the left or Lock the steering when parking to help right. prevent theft. Push the ignition switch down, and turn it to A U-shaped wheel lock or similar device is (Lock) position.
  • Page 50 The system runs a two-way authentication between the vehicle and the Honda SMART Key to verify if it is the registered Honda SMART Key. The Honda SMART Key system uses low- intensity radio waves. It may affect medical equipment such as a cardiac pacemaker.
  • Page 51 (Continued) Switching the Honda SMART Key System To switch the Honda SMART Key system to activation or deactivation Press the ON/OFF button until the Honda SMART Key LED changes colour. To check the Honda SMART Key ON/OFF button system status Lightly press the ON/OFF button.
  • Page 52 The Honda SMART Key system uses low- intensity radio waves. Therefore, the operating range may be wider or narrower, or the Honda SMART Key system may not work properly in the following situations: When the Honda SMART Key battery is ●...
  • Page 53 (Continued) Anyone can unlock the ignition switch and When the ignition switch is locked: start the engine if your Honda SMART Key is The system can be operated within the within operating range of your vehicle, even shaded area shown in the illustration.
  • Page 54 ● You should always keep the Honda SMART Key on your person after you get on and off the vehicle or while riding. Do not place the Honda SMART Key in any compartment. Continued...
  • Page 55 If someone without the Honda SMART Key tries to turn the ignition switch, the ignition To Unlock the Ignition Switch switch rotates freely. If you notice the ignition Make sure that the Honda SMART Key is switch is in a different position, turn the activated. (P.48)
  • Page 56 (Off) or (Lock). Switch the Honda SMART Key system ● to inactive. (P.48) Make sure that the Honda SMART Key indicator and ignition switch ring go off, the turn signals flash once. This indicates that the ignition switch is locked. Continued...
  • Page 57 20201006171709_32K1BF000_eng_BOOK Page 57 Tuesday, October 06 2020 17:20:39 JST Honda SMART Key System (Continued) Always make sure the ignition switch position is in the (Off) or (Lock) position when you leave your vehicle. When the ignition switch is locked in the...
  • Page 58 Answer back you that the immobilizer function of the button Honda SMART key system is activated. When the immobilizer is active and you press the answer back button on the Honda SMART Key with the ignition switch in the...
  • Page 59 20201006171709_32K1BF000_eng_BOOK Page 59 Tuesday, October 06 2020 17:20:39 JST Answer Back System (Continued) Operation Press the answer back button on the Honda SMART Key. The answer back system will not function when the ignition switch is (On) position. If the ignition switch is left the...
  • Page 60 Bluetooth to install/operate the dedicated application, SIG, Inc., and any use of such marks by see the following URL: Honda Motors Co., Ltd., is under license. https://global.honda/voice-control-system/ Other trademarks and trade names are those of their respective owners.
  • Page 61 20201006171709_32K1BF000_eng_BOOK Page 61 Tuesday, October 06 2020 17:20:39 JST Honda Smartphone Voice Control system (Continued) Costs of network communication and The system itself has certain limitations. ● communication equipment necessary for Therefore, you must verify the voice the use of this feature shall be borne by guidance and information in the meter the user himself/herself.
  • Page 62 Voice Control system functionality and services. Bluetooth indicator ® Honda cannot and does not provide any For operation of the application, follow warranty or guarantee of future Honda the instruction of the application. Smartphone Voice Control system performance or functionality.
  • Page 63 20201006171709_32K1BF000_eng_BOOK Page 63 Tuesday, October 06 2020 17:20:39 JST Honda selectable torque control Torque Control (engine power control) can Torque Control on and off be turned on/off. Torque Control can be turned on and off by pressing and holding the Torque Control Do not operate the Torque Control switch while riding.
  • Page 64 If you lower the side stand with the engine • The engine will not start if the throttle is fully open. running, it will automatically shut off. This vehicle is equipped with a Honda SMART Key system. Always keep Honda SMART Key on you when you ride the vehicle.
  • Page 65 20201006171709_32K1BF000_eng_BOOK Page 65 Tuesday, October 06 2020 17:20:39 JST Starting the Engine (Continued) Place the vehicle on its centre stand. Squeeze the rear brake lever. Make sure the engine stop switch is in the The starter motor will only work when (Run) position.
  • Page 66 20201006171709_32K1BF000_eng_BOOK Page 66 Tuesday, October 06 2020 17:20:39 JST If you cannot start the engine: If the engine does not start: Place the vehicle on its centre stand and Open the throttle fully and press the start squeeze the rear brake lever. button for 5 seconds.
  • Page 67 20201006171709_32K1BF000_eng_BOOK Page 67 Tuesday, October 06 2020 17:20:39 JST Riding Starting the Vehicle Acceleration and deceleration To accelerate: Open the throttle slowly. Push the vehicle forward off the centre To decelerate: Close the throttle. stand. Squeeze the rear brake lever. Open (Accelerate) Keep throttle closed.
  • Page 68 20201006171709_32K1BF000_eng_BOOK Page 68 Tuesday, October 06 2020 17:20:39 JST Braking Close the throttle and apply the front and rear brake levers together. Rear brake lever Front brake lever...
  • Page 69 20201006171709_32K1BF000_eng_BOOK Page 69 Tuesday, October 06 2020 17:20:39 JST Emergency Stop Signal Emergency stop signal activates when the The emergency stop signal stops operating system detects hard braking about 50 km/h when: (30 mph) or above to alert drivers behind You release the brakes.
  • Page 70 20201006171709_32K1BF000_eng_BOOK Page 70 Tuesday, October 06 2020 17:20:39 JST The emergency stop signal is not a system that can prevent a possible rear-end collision caused by your hard braking. It is always recommended to avoid hard braking unless it is absolutely necessary. The emergency stop signal does not activate with the hazard switch pressed in.
  • Page 71 20201006171709_32K1BF000_eng_BOOK Page 71 Tuesday, October 06 2020 17:20:39 JST Refuelling Fuel type: Unleaded petrol only Opening the Fuel Fill Cap Turn the ignition switch to the position of Fuel octane number: Your vehicle is SEAT FUEL. To unlock the ignition switch designed to use Research Octane Number (P.52) Push the FUEL side of the fuel lid and seat...
  • Page 72 20201006171709_32K1BF000_eng_BOOK Page 72 Tuesday, October 06 2020 17:20:39 JST Turn the fuel fill cap counterclockwise and Closing the Fuel Fill Cap remove the fuel fill cap. Install and tighten the fuel fill cap firmly by turning it clockwise. Fuel fill Arrow marks Make sure that the arrow marks on the fuel fill cap and fuel tank are aligned.
  • Page 73 Use USB devices at your own risk. In no event Open the glove box lid. (P.76) shall Honda be liable for any damage to your Open the cover to access the USB socket. USB device when in use. USB socket...
  • Page 74 20201006171709_32K1BF000_eng_BOOK Page 74 Tuesday, October 06 2020 17:20:39 JST To prevent the battery from becoming weak NOTICE (or dead), keep the engine running while • Using any heat-generating USB devices or drawing current from the USB socket. improperly rated USB devices can damage the USB socket.
  • Page 75 20201006171709_32K1BF000_eng_BOOK Page 75 Tuesday, October 06 2020 17:20:39 JST Storage Equipment Seat Open Seat Turn the handlebar pointed straight ahead. Turn the ignition switch to the position of SEAT FUEL. To unlock the ignition switch (P.52) Push the SEAT side of the fuel lid and seat opener switch.
  • Page 76 20201006171709_32K1BF000_eng_BOOK Page 76 Tuesday, October 06 2020 17:20:39 JST Helmet Holder Use the helmet holder only when parked. The helmet holder is located under the seat. Opening the seat A helmet set wire is in the tool kit. (P.72) Helmet holder WARNING Riding with a helmet attached to the holder can interfere with your ability to...
  • Page 77 20201006171709_32K1BF000_eng_BOOK Page 77 Tuesday, October 06 2020 17:20:39 JST Storage Equipment (Continued) Luggage Box Depending on the position of the partition The position of the partition board can be board, one or two helmets can be stored. changed according to the cargo in stored. Position of the partition board can be changed into four places as shown.
  • Page 78 20201006171709_32K1BF000_eng_BOOK Page 78 Tuesday, October 06 2020 17:20:39 JST Tool Kit/Document Bag Rear Carrier The tool kit is located in the left side of the Ⅲ E, Ⅶ E, Ⅱ ED, Ⅵ ED type only luggage box. Never exceed the maximum weight limit. Maximum Weight: 5.0 kg (11.0 lb) The document bag is located in the Rear carrier...
  • Page 79 20201006171709_32K1BF000_eng_BOOK Page 79 Tuesday, October 06 2020 17:20:39 JST Storage Equipment (Continued) Glove Box Open The glove box will be locked in conjunction Push the upper of the lid, then open the with the steering lock. glove box lid when the steering is unlocked. If you do not lock the steering, the glove To unlock the steering.

  • Page 80: Maintenance

    Adjusting the Windscreen Height ....P. 106 Maintenance Schedule........P. 79 Other Replacement......... P. 107 Maintenance Fundamentals ......P. 82 Replacing the Honda SMART Key Battery .. P. 107 Tool ............... P. 92 Removing & Installing Body Components.. P. 93 Battery ..............P. 93 Battery Lid .............

  • Page 81: Importance Of Maintenance

    20201006171709_32K1BF000_eng_BOOK Page 81 Tuesday, October 06 2020 17:20:39 JST Importance of Maintenance Importance of Maintenance Maintenance Safety Keeping your vehicle well-maintained is Always read the maintenance instructions absolutely essential to your safety and to before you begin each task, and make sure that protect your investment, obtain maximum you have the tools, parts, and skills required.

  • Page 82: Maintenance Schedule

    Maintenance work should be performed in new owner. accordance with Honda's standards and specifications by properly trained and equipped Honda recommends that your dealer should technicians. Your dealer meets all of these road test your vehicle after each periodic requirements. Keep an accurate record of maintenance is carried out.
  • Page 83 Inspect (clean, adjust, lubricate, or replace, if necessary) dealer, unless you have the necessary tools and are Replace mechanically skilled. Clean Procedures are provided in an official Honda Shop Manual. : Technical. In the interest of safety, have your vehicle serviced by your dealer.
  • Page 84 20201006171709_32K1BF000_eng_BOOK Page 84 Tuesday, October 06 2020 17:20:39 JST Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 82 × 1,000 mi Drive Belt – Belt Case Air Cleaner – Final Drive Oil 2 Years –...

  • Page 85: Maintenance Fundamentals

    20201006171709_32K1BF000_eng_BOOK Page 85 Tuesday, October 06 2020 17:20:39 JST Maintenance Fundamentals Brakes - Check operation; Pre-ride Inspection ● Front and Rear: check brake fluid level and To ensure safety, it is your responsibility to pads wear. P. 101, P. 102 perform a pre-ride inspection and make sure Lights and horn - Check that lights, ●...
  • Page 86 20201006171709_32K1BF000_eng_BOOK Page 86 Tuesday, October 06 2020 17:20:39 JST Maintenance Fundamentals WARNING Replacing Parts Always use Honda Genuine Parts or their Installing non-Honda parts may make equivalents to ensure reliability and safety. your vehicle unsafe and cause a crash in...
  • Page 87 20201006171709_32K1BF000_eng_BOOK Page 87 Tuesday, October 06 2020 17:20:39 JST Maintenance Fundamentals Battery NOTICE Your battery is a maintenance-free type and can be Your vehicle has a maintenance-free type battery. permanently damaged if the cap strip is removed. You do not have to check the battery electrolyte level or add distilled water.
  • Page 88 20201006171709_32K1BF000_eng_BOOK Page 88 Tuesday, October 06 2020 17:20:39 JST Maintenance Fundamentals What to do in an emergency WARNING If any of the following occur, immediately see The battery gives off explosive your doctor. hydrogen gas during normal operation. Electrolyte splashes into your eyes: ●...
  • Page 89 Always replace the battery with another maintenance-free battery of the same type. NOTICE Installing non-Honda electrical accessories can NOTICE overload the electrical system, discharging the Replacing a fuse with one that has a higher battery and possibly damaging the system.
  • Page 90 Selecting the Engine Oil circular API service symbol. For recommended engine oil, see “Specifications.” P. 150 If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: JASO T 903 standard : MB ●...
  • Page 91 Brake Fluid Recommended Coolant Do not add or replace brake fluid, except in an Pro Honda HP Coolant is a pre-mixed solution emergency. Use only fresh brake fluid from a of antifreeze and distilled water. sealed container. If you do add fluid, have the...
  • Page 92 20201006171709_32K1BF000_eng_BOOK Page 92 Tuesday, October 06 2020 17:20:39 JST Maintenance Fundamentals Crankcase Breather Tyres (Inspecting/Replacing) Checking the Air Pressure Service more frequently when riding in rain, at Visually inspect your tyres and use an air full throttle, or after the vehicle is washed or pressure gauge to measure the air pressure at overturned.
  • Page 93 20201006171709_32K1BF000_eng_BOOK Page 93 Tuesday, October 06 2020 17:20:39 JST Maintenance Fundamentals Inspecting for Abnormal Wear WARNING Inspect the tyres for Riding on tyres that are excessively signs of abnormal wear worn or improperly inflated can cause a on the contact surface. crash in which you can be seriously hurt or killed.
  • Page 94 ● of the same size, construction, speed rating, and load range. Always use the size and type of tyres Have the wheel balanced with Honda ● recommended in this owner's manual. Genuine balance weights or equivalent after the tyre is installed.

  • Page 95: Tool

    20201006171709_32K1BF000_eng_BOOK Page 95 Tuesday, October 06 2020 17:20:39 JST Tool The tool kit is stored in the compartment in the luggage box. P. 75 You can perform some roadside repairs, minor adjustments and parts replacement with the provided tools. 10 x 14 mm Open end wrench ●...

  • Page 96: Removing & Installing Body Components

    20201006171709_32K1BF000_eng_BOOK Page 96 Tuesday, October 06 2020 17:20:39 JST Removing & Installing Body Components Battery Removal Make sure the ignition switch is in the Negative Positive (Off) position. terminal terminal Remove the battery lid. P. 95 Disconnect the negative - terminal from the battery.
  • Page 97 20201006171709_32K1BF000_eng_BOOK Page 97 Tuesday, October 06 2020 17:20:39 JST Removing & Installing Body Components Battery Installation Install the parts in the reverse order of removal. Always connect the positive + terminal first. Make sure that bolts and nuts are tight. Make sure the clock information is correct after the battery is reconnected.

  • Page 98: Battery Lid

    20201006171709_32K1BF000_eng_BOOK Page 98 Tuesday, October 06 2020 17:20:39 JST Removing & Installing Body Components Battery Lid Battery Lid Removal Open the seat. P. 72 Remove the screws. Remove the battery lid. Installation Install the parts in the reverse order of removal.

  • Page 99: Engine Oil

    20201006171709_32K1BF000_eng_BOOK Page 99 Tuesday, October 06 2020 17:20:39 JST Engine Oil Checking the Engine Oil Oil fill cap/dipstick If the engine is cold, idle the engine for 3 to 5 minutes. Upper level Turn the ignition switch to the (Off) position and wait for 2 to 3 minutes.
  • Page 100 20201006171709_32K1BF000_eng_BOOK Page 100 Tuesday, October 06 2020 17:20:39 JST Engine Oil Adding Engine Oil Adding Engine Oil For the recommended oil and oil selection guidelines, see “Maintenance Fundamentals.” If the engine oil is below or near the lower P. 87 level mark, add the recommended engine oil.

  • Page 101: Coolant

    20201006171709_32K1BF000_eng_BOOK Page 101 Tuesday, October 06 2020 17:20:39 JST Coolant Checking the Coolant Check the coolant level in the reserve tank while the engine is cold. Place your vehicle on a firm, level surface. Hold your vehicle in an upright position. Check that the coolant level is between UPPER level mark the UPPER level and LOWER level marks...
  • Page 102 20201006171709_32K1BF000_eng_BOOK Page 102 Tuesday, October 06 2020 17:20:39 JST Coolant Adding Coolant Adding Coolant Floor mat If the coolant level is below the LOWER level mark, add the recommended coolant P. 88) until the level reaches the UPPER Screwdriver level mark. Add fluid only from the reserve tank cap and do not remove the radiator cap.
  • Page 103 20201006171709_32K1BF000_eng_BOOK Page 103 Tuesday, October 06 2020 17:20:39 JST Coolant Adding Coolant Remove the reserve tank cap and add fluid while monitoring the coolant level. Do not overfill above the UPPER level mark. Make sure no foreign objects enter the reserve tank opening.

  • Page 104: Brakes

    20201006171709_32K1BF000_eng_BOOK Page 104 Tuesday, October 06 2020 17:20:39 JST Brakes Checking Brake Fluid Front Place your vehicle in an upright position on a firm, level surface. Check that the brake fluid reservoir is horizontal and that the fluid level is above the LOWER level mark.
  • Page 105 20201006171709_32K1BF000_eng_BOOK Page 105 Tuesday, October 06 2020 17:20:39 JST Brakes Inspecting the Brake Pads Inspecting the Brake Pads Front Wear Check the condition of the brake pad wear indicators indicators. The pads need to be replaced if a brake pad is worn to the indicator.

  • Page 106: Side Stand

    20201006171709_32K1BF000_eng_BOOK Page 106 Tuesday, October 06 2020 17:20:39 JST Side Stand Checking the Side Stand Check the spring for damage or loss of tension. Sit on the vehicle and raise the side stand. Side stand spring Start the engine. Lower the side stand all the way. The engine should stop as you lower the side stand.

  • Page 107: Throttle

    20201006171709_32K1BF000_eng_BOOK Page 107 Tuesday, October 06 2020 17:20:39 JST Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open in all steering positions and throttle freeplay is correct. If the throttle does not move smoothly, close automatically, or if the cable is damaged, have the vehicle inspected by your dealer.

  • Page 108: Other Adjustments

    20201006171709_32K1BF000_eng_BOOK Page 108 Tuesday, October 06 2020 17:20:39 JST Other Adjustments Adjusting the Rear Suspension Pin spanner 2 3 4 Spring Preload You can adjust the spring preload by the adjuster to suit the load or the road surface. Use the pin spanner and extension bar provided in the tool kit ( P.

  • Page 109: Adjusting The Windscreen Height

    20201006171709_32K1BF000_eng_BOOK Page 109 Tuesday, October 06 2020 17:20:39 JST Other Adjustments Adjusting the Windscreen Height Adjusting the Windscreen Check the windscreen adjustment for smooth operation and check the sliding area for Height looseness. If the windscreen is significantly loose or you You can adjust your windscreen height notice that the windscreen is loose while higher or lower according to your...

  • Page 110: Other Replacement

    Honda SMART Key Battery protective cloth into the slit. Wrap a coin or a screwdriver with a If the Honda SMART Key indicator flashes 5 protective cloth to prevent scratching times when the ignition switch is turned (On) the Honda SMART Key.
  • Page 111 20201006171709_32K1BF000_eng_BOOK Page 111 Tuesday, October 06 2020 17:20:39 JST Other Replacement Replacing the Honda SMART Key Battery WARNING Upper case Battery Chemical Burn Hazard: do not swallow battery. If swallowed, the battery can cause severe Protective internal burns and even death.
  • Page 112 20201006171709_32K1BF000_eng_BOOK Page 112 Tuesday, October 06 2020 17:20:39 JST Other Replacement Replacing the Honda SMART Key Battery CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. CAUTION: Do not exposed to excessive heat...

  • Page 113: Troubleshooting

    Blown Fuse............P. 129 Honda SMART Key Indicator......P. 116 Unstable Engine Operation Occurs Other Warning Indications ......P. 117 Intermittently ..........P. 132 Fuel Gauge Failure Indication......P. 117 When the Honda SMART Key System Does Not Operate Properly........... P. 118...

  • Page 114: Engine Will Not Start

    20201006171709_32K1BF000_eng_BOOK Page 114 Tuesday, October 06 2020 17:20:39 JST Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ●...

  • Page 115: Overheating (High Coolant Temperature Indicator Is On)

    20201006171709_32K1BF000_eng_BOOK Page 115 Tuesday, October 06 2020 17:20:39 JST Overheating (High coolant temperature indicator is on) The engine is overheating when the following Check that the radiator fan is operating, and then turn the ignition switch to the occurs: (Off) position. High coolant temperature indicator ●...

  • Page 116: Warning Indicators On Or Flashing

    20201006171709_32K1BF000_eng_BOOK Page 116 Tuesday, October 06 2020 17:20:39 JST Warning Indicators On or Flashing Low Oil Pressure Indicator If the engine oil level goes down rapidly, your vehicle may have a leak or another serious If the low oil pressure indicator comes on, problem.

  • Page 117: Abs (Anti-Lock Brake System) Indicator

    20201006171709_32K1BF000_eng_BOOK Page 117 Tuesday, October 06 2020 17:20:39 JST Warning Indicators On or Flashing ABS (Anti-lock Brake System) Indicator ABS (Anti-lock Brake System) If the ABS indicator stays on, your brakes will continue to work as a conventional system, Indicator but without the anti-locking function.

  • Page 118: Torque Control Indicator

    20201006171709_32K1BF000_eng_BOOK Page 118 Tuesday, October 06 2020 17:20:39 JST Warning Indicators On or Flashing Torque Control Indicator Torque Control Indicator Even when the Torque Control indicator is on, your vehicle will have normal riding ability If the indicator operates in one of the without Torque Control function.

  • Page 119: Honda Smart Key Indicator

    Honda SMART Key stops after turning the ignition switch to the (On) position. If you do not have the Honda SMART Key, It is probably caused by the following: the ignition switch can be unlocked in Strong radio waves or noise are affecting ●...

  • Page 120: Other Warning Indications

    20201006171709_32K1BF000_eng_BOOK Page 120 Tuesday, October 06 2020 17:20:39 JST Other Warning Indications Fuel Gauge Failure Indication If the fuel system has an error, the fuel gauge indicators will be displayed as shown in the illustration. If this occurs, see your dealer as soon as possible.

  • Page 121: When The Honda Smart Key System Does Not Operate Properly

    20201006171709_32K1BF000_eng_BOOK Page 121 Tuesday, October 06 2020 17:20:39 JST When the Honda SMART Key System Does Not Operate Properly When the Honda SMART Key system does Check that there is no communication ● not work properly, perform the following. failure in the Honda SMART Key system.
  • Page 122 20201006171709_32K1BF000_eng_BOOK Page 122 Tuesday, October 06 2020 17:20:39 JST When the Honda SMART Key System Does Not Operate Properly Check that a registered Honda SMART Check the battery condition and battery ● ● Key is used. lead in your vehicle.

  • Page 123: Unlock The Seat In An Emergency

    20201006171709_32K1BF000_eng_BOOK Page 123 Tuesday, October 06 2020 17:20:39 JST Unlock the Seat in an Emergency The seat lock can be unlocked by using the Prong A emergency key. Open Pull the neck guard cover upward to release the prongs A. Prong A Pull the neck guard cover backward to release the prongs B and remove the...
  • Page 124 20201006171709_32K1BF000_eng_BOOK Page 124 Tuesday, October 06 2020 17:20:39 JST Unlock the Seat in an Emergency Align the projection of the emergency key Emergency seat with the slot of the emergency seat opener opener, and turn the emergency key counterclockwise. Open the seat and turn the emergency key clockwise Close Close and push down on the rear of the...

  • Page 125: Unlock The Ignition Switch In An Emergency

    20201006171709_32K1BF000_eng_BOOK Page 125 Tuesday, October 06 2020 17:20:39 JST Unlock the Ignition Switch in an Emergency Set up to ID number input mode EM mode coupler Hook Use the emergency key to open the seat. P. 120 Remove the battery lid. P.
  • Page 126 20201006171709_32K1BF000_eng_BOOK Page 126 Tuesday, October 06 2020 17:20:39 JST Unlock the Ignition Switch in an Emergency ID number input Example: To input “0”, wait for 5 seconds without ● You can input your ID number by pressing the pushing the ignition switch when the ignition switch when the ignition switch is ignition switch ring comes on.
  • Page 127 After the last ID number is inputted, through, After the last ID number is inputted, the the ignition switch ring and Honda SMART Key ignition switch ring and Honda SMART Key Indicator will flash every 2 seconds until the EM Indicator will flash every second until the EM mode coupler is removed.

  • Page 128: Tyre Puncture

    20201006171709_32K1BF000_eng_BOOK Page 128 Tuesday, October 06 2020 17:20:39 JST Tyre Puncture Repairing a puncture or removing a wheel WARNING requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tyre repair can be risky. If the temporary performed by your dealer.

  • Page 129: Smartphone Pairing Trouble

    20201006171709_32K1BF000_eng_BOOK Page 129 Tuesday, October 06 2020 17:20:39 JST Smartphone Pairing Trouble Symptom Cause/remedy Some smartphones you use may be incompatible with the vehicle and/or the operable functions may be limited. Check that the vehicle and smartphone are both in pairing mode. P.
  • Page 130 20201006171709_32K1BF000_eng_BOOK Page 130 Tuesday, October 06 2020 17:20:39 JST Smartphone Pairing Trouble Symptom Cause/remedy Depending on the smartphone you use, it may take some time for the vehicle to connect to a smartphone and to start using a dedicated application. The connection may be temporarily disconnected when starting the engine, which is normal and not a malfunction.

  • Page 131: Electrical Trouble

    20201006171709_32K1BF000_eng_BOOK Page 131 Tuesday, October 06 2020 17:20:39 JST Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle All light bulbs on the vehicle are LEDs. If battery charger. there is an LED which is not turned on, see Remove the battery from the vehicle before your dealer for servicing.

  • Page 132: Blown Fuse

    20201006171709_32K1BF000_eng_BOOK Page 132 Tuesday, October 06 2020 17:20:39 JST Electrical Trouble Blown Fuse Blown Fuse Before handling fuses, see “Inspecting and Replacing Fuses.” P. 86 Fuse Box Fuses Remove the battery lid. P. 95 Open the fuse box covers. Pull the fuses out one by one with the Fuse box Fuse box Fuse box...
  • Page 133 20201006171709_32K1BF000_eng_BOOK Page 133 Tuesday, October 06 2020 17:20:39 JST Electrical Trouble Blown Fuse Main Fuse Starter magnetic switch Remove the battery lid. P. 95 Remove the starter magnetic switch from the stay. Stays...
  • Page 134 20201006171709_32K1BF000_eng_BOOK Page 134 Tuesday, October 06 2020 17:20:39 JST Electrical Trouble Blown Fuse Remove the starter magnetic switch Starter magnetic switch cover. Pull the main fuse out and check for a blown fuse. Always replace a blown fuse with a spare fuse of the same rating. Spare main fuse is provided in the starter magnetic switch.

  • Page 135: Unstable Engine Operation Occurs Intermittently

    20201006171709_32K1BF000_eng_BOOK Page 135 Tuesday, October 06 2020 17:20:39 JST Unstable Engine Operation Occurs Intermittently If the fuel pump filter is clogged, unstable engine operation will occur intermittently while riding. Even if this symptom occurs, you can continue to ride your vehicle. If unstable engine operation occurs even if sufficient fuel is available, have your vehicle inspected by your dealer as soon as possible.

  • Page 136: Information

    20201006171709_32K1BF000_eng_BOOK Page 136 Tuesday, October 06 2020 17:20:39 JST Information Service Diagnostic Recorders....... P. 134 Keys..............P. 134 Instruments, Controls, & Other Features... P. 138 Caring for Your Vehicle........P. 139 Storing Your Vehicle........P. 143 Transporting Your Vehicle ......P. 144 You &...

  • Page 137: Service Diagnostic Recorders

    However this data may be accessed by Honda, its authorised dealers and authorised repairers, employees, representatives and contractors only for the purpose of the technical diagnosis, research and development of the vehicle.
  • Page 138 Locking or unlocking the steering ● sunlight, high temperature, and high humidity. The ID number of the Honda SMART Key is on Do not scratch or puncture. ● the ID tag. You can also unlock the ignition Do not store near any magnetized products ●...
  • Page 139 20201006171709_32K1BF000_eng_BOOK Page 139 Tuesday, October 06 2020 17:20:39 JST Keys If fuel, wax, or grease adhere to the Honda The battery in the Honda SMART Key system ● SMART Key, wipe it off immediately to avoid normally lasts about 2 years.
  • Page 140 20201006171709_32K1BF000_eng_BOOK Page 140 Tuesday, October 06 2020 17:20:39 JST Keys EU Directive South Africa only Singapore only This Honda SMART Key system complies with the RE (Radio Equipment) Directive (2014/53/ EU). Morocco only The declaration of conformity to RE Directive is provided to the owner at the time of purchase.

  • Page 141: Instruments, Controls, & Other Features

    20201006171709_32K1BF000_eng_BOOK Page 141 Tuesday, October 06 2020 17:20:39 JST Instruments, Controls, & Other Features Instruments, Controls, & Tripmeter Other Features The tripmeters return to 0.0 when each read- out exceeds 9,999.9. Ignition Switch Leaving the ignition switch in the (On) position Document Bag with the engine stopped will drain the battery.

  • Page 142: Caring For Your Vehicle

    Frequent cleaning and polishing is important to After the vehicle dries, lubricate any moving ensure the life of your Honda. A clean vehicle parts. makes it easier to spot potential problems.
  • Page 143 20201006171709_32K1BF000_eng_BOOK Page 143 Tuesday, October 06 2020 17:20:39 JST Caring for Your Vehicle Washing Precautions Do not direct water at the air cleaner: ● Water in the air cleaner can prevent the Follow these guidelines when washing: engine from starting. Do not use high-pressure washers: ●...
  • Page 144 20201006171709_32K1BF000_eng_BOOK Page 144 Tuesday, October 06 2020 17:20:39 JST Caring for Your Vehicle Aluminium Components Windscreen Aluminium will corrode from contact with dirt, Using plenty of water, clean the windscreen with a soft cloth or sponge. (Avoid using detergents mud, or road salt. Clean aluminium parts or any kind of chemical cleaner on the regularly and follow these guidelines to avoid windscreen.) Dry with a soft, clean cloth.
  • Page 145 20201006171709_32K1BF000_eng_BOOK Page 145 Tuesday, October 06 2020 17:20:39 JST Caring for Your Vehicle When the exhaust pipe and muffler are painted, Exhaust Pipe and Muffler do not use a commercially available abrasive The exhaust pipe and muffler are stainless steel kitchen cleaning compound.

  • Page 146: Storing Your Vehicle

    20201006171709_32K1BF000_eng_BOOK Page 146 Tuesday, October 06 2020 17:20:39 JST Storing Your Vehicle Storing Your Vehicle After removing your vehicle from storage, inspect all maintenance items required by the If you store your vehicle outdoors, you should Maintenance Schedule. consider using a full-body cover. If you won't be riding for an extended period, follow these guidelines: Wash your vehicle and wax all painted...

  • Page 147: Transporting Your Vehicle

    20201006171709_32K1BF000_eng_BOOK Page 147 Tuesday, October 06 2020 17:20:39 JST Transporting Your Vehicle Transporting Your Vehicle If your vehicle needs to be transported, it should be carried on a motorcycle trailer or a flatbed truck or trailer that has a loading ramp or lifting platform, and motorcycle tie-down straps.

  • Page 148: You & The Environment

    20201006171709_32K1BF000_eng_BOOK Page 148 Tuesday, October 06 2020 17:20:39 JST You & the Environment You & the Environment Recycle Wastes Put oil and other toxic wastes in approved Owning and riding a vehicle can be enjoyable, containers and take them to a recycling centre. but you must do your part to protect the Call your local or state office of public works or environment.

  • Page 149: Serial Numbers

    20201006171709_32K1BF000_eng_BOOK Page 149 Tuesday, October 06 2020 17:20:39 JST Serial Numbers Serial Numbers The frame and engine serial numbers uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. You should record these numbers and keep them in a safe place.

  • Page 150: Fuels Containing Alcohol

    20201006171709_32K1BF000_eng_BOOK Page 150 Tuesday, October 06 2020 17:20:39 JST Fuels Containing Alcohol Fuels Containing Alcohol NOTICE Use of blended fuels containing higher than Some conventional fuels blended with alcohol approved percentages can damage metal, are available in some locales to help reduce rubber, plastic parts of your fuel system.

  • Page 151: Catalytic Converter

    A defective catalytic converter contributes to air pollution and can impair your engine's performance. A replacement unit must be an original Honda part or equivalent.

  • Page 152: Specifications

    20201006171709_32K1BF000_eng_BOOK Page 152 Tuesday, October 06 2020 17:20:39 JST Specifications Main Components ■ Minimum 2.40 m (7.9 ft) turning radius E, Ⅴ E, ED, Ⅳ ED 2,145 mm (84.4 in) Displacement 330 cm (20.1 cu-in) type Overall length Ⅲ E, Ⅶ E, Ⅱ ED, Bore x stroke 77.0 x 70.8 mm (3.03 x 2.79 in) 2,170 mm (85.4 in)
  • Page 153 Spark plug gap 0.80 - 0.90 mm (0.031 - 0.035 in) 120/70-15 M/C 56P Idle speed 1,500 ± 100 rpm Tyre size PIRELLI: Honda 4-stroke motorcycle oil API Service Classification SG or higher, excluding oils 140/70-14 M/C 68S Recommended marked as “Energy Conserving” or REINFORCED...
  • Page 154 20201006171709_32K1BF000_eng_BOOK Page 154 Tuesday, October 06 2020 17:20:39 JST Specifications Bulbs ■ Headlight Brakelight/Taillight Front turn signal/Position light Rear turn signal License plate light Position light Fuses ■ Main fuse 30 A Other fuse 30 A, 15 A, 10 A, 7.5 A, 5 A...

  • Page 155: Index
