Owner's Manual
Tripp Lite по адресу: tripplite.com
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
Dual Flex-Arm
Desk Clamp,
Aluminum
Model: DDR1732DAL
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR
PROPERTY DAMAGE MAY OCCUR!
32"
75 x 75
MAX
100 x 100
®
1
19.8 lb. x2
19.8 lb. x2
(9 kg x2)
(9 kg x2)
MAX
MAX
11/6/2020 9:11:15 AM
11/6/2020 9:11:15 AM
