Innovative Hygiene.
XIBU Tips and Tricks
eng
January 2018
www.hagleitner.com

Advertisement

Table of Contents
loading

Related Manuals for Hagleitner XIBU

Summary of Contents for Hagleitner XIBU

  • Page 1 Innovative Hygiene. XIBU Tips and Tricks January 2018 www.hagleitner.com...

  • Page 2: Table Of Contents

    XIBU TISSUEPAPER Technical package ..................................Replacing the cover assembly ..............................Change the lid clip ..................................XIBU senseFOAM / XIBU senseDISINFECT / XIBU senseDISHES / senseSEATCLEANER Technical package ................................... Replacing the cover assembly ..............................Replacing the potentiometer axis ............................Battery tray assembly ..................................
  • Page 3 Year Month Pers. The batch number is printed on the respective dispenser here Batch-number XIBU senseSEAT CLEANER XIBU touchMULTIFOLD Since 14.9.2016 printed on all dispensers. XIBU senseMOISTCARE The batch number is formed as follows: For example the date 17.09.2019. Year Month Pers.

  • Page 4: Xibu Tissuepaper

    XIBU TISSUEPAPER XIBU touchTISSUEPAPER Article no. 411010065000 Abb. 1: XIBU touchTISSUEPAPER Technical package Abb. 2: XIBU touchTISSUEPAPER Technical package  Spare part name: XIBU touchTISSUEPAPER techn. package Article no. 492011730000 4 | Tips & Tricks | January 2018...

  • Page 5: Replacing The Cover Assembly

    XIBU TISSUEPAPER Replacing the cover assembly Replacing the cover assembly Open the dispenser with the XIBU key. Press the red (grey) locking lever on the left side wall (Fig. 2) and slide it upwards (Fig. 3). Press the right side of the cover lightly to the outside so that the cover can be turned to the side wall via the latch (Fig.

  • Page 6: Change The Lid Clip

    Twist the lid clip counterclockwise until it strikes and remove it. (Fig. 1 + 2) The insert of the lid happens in the opposite order. Spare part name: XIBU WC lid clip Artikel number: 492011830000 Fig. 1 Fig. 2 6 | Tips & Tricks | January 2018...

  • Page 7: Xibu Sensefoam / Xibu Sensedisinfect / Xibu Sensedishes / Senseseatcleaner Technical Package

    XIBU senseFOAM / XIBU senseDISINFECT / XIBU senseDISHES XIBU senseFOAM XIBU senseFOAM Technical package Article no. 411020105000 Fig. 2 Spare part name: XIBU senseFOAM techn. package Article no. 492011650000 Fig. 1 XIBU senseDISINFECT Technical package XIBU senseDISHES Technical package Fig. 3 Fig.

  • Page 8: Replacing The Cover Assembly

    XIBU senseFOAM / XIBU senseDISINFECT / XIBU touchFOAM / XIBU senseDISHES Replacing the cover assembly Tools used: Phillips screwdriver size PH1 Replacing the cover: Open the dispenser with the XIBU key  Loosen the screws on the left and the right side of the cover, (Fig.

  • Page 9: Replacing The Potentiometer Axis

    XIBU senseFOAM / XIBU senseDISINFECT / XIBU senseDISHES / XIBU senseSEATCLEANER / XIBU senseMOISTCARE Replacing the potentiometer axis Tools used: Pin punch (Fig. 6) Needle nose pliers XIBU key Requem: Broken potentiometer axis Fig. 1 Solution: Replace the potentiometer axis Fig.

  • Page 10: Changing The Soap/Disinfect Tank

    XIBU senseFOAM / XIBU senseDISINFECT / XIBU senseDISHES / XIBU senseSEATCLEANER / XIBU senseMOISTCARE Changing the soap/disinfect tank Request: intake bag broken fill level display does not work third party product was filled in technical package has to be replaced Fig.

  • Page 11: Technical Package

    XIBU senseSEATCLEANER / XIBU senseMOISTCARE XIBU senseSEATCLEANER Article no.: 411010145000  XIBU senseMOISTCARE Article no.: 411010165000  Technical package Spare part name: XIBU senseSEATCLEANER TP Article no.: 492012110000  Spare part name: XIBU MOISTCARE TP Article no.: 492012130000  Fig. 1: senseSEATCLEANER technology package Fig.

  • Page 12: Replacing The Cover Assembly

    XIBU senseSEATCLEANER / XIBU touchSEATCLEANER / XIBU senseMOISTCARE Replacing the cover assembly Fig. 1 Fig. 2 Fig. 3 XIBU senseSEATCLEANER lid XIBU touchSEATCLEANER lid XIBU senseMOISTCARE lid Tools used: Phillips screwdriver size PH1  Lid replacement: Open the dispenser with the XIBU key.

  • Page 13: Xibu Touchfoam

    XIBU touchFOAM XIBU touchFOAM wl Article no. 411020145000 Technical package Spare part name: XIBU touchFOAM white techn.p. Article no. 492011740000 Spare part name: XIBU touchFOAM black techn.p. Article no. 492011750000 Fig. 1: touchFOAM technical package January 2018 | Tips & Tricks | 13...

  • Page 14: Replacing The Technical Package Assembly

    XIBU touchFOAM Replacing the technical package assembly Tools used: Slot screwdriver, size 2 XIBU key Replacing the technical package: Loosen the push piece from both latches. (Fig. 1) Fig. 1 Loosen the lock on the bottom of the rear side by using the screwdriver.

  • Page 15: Xibu Touchseatcleaner

    XIBU touchSEATCLEANER XIBU touchSEATCLEANER Article no.: 411010155000 Technical package Spare part name: XIBU touchSEATCLEANER TP bl Article no.: 492012105000 Spare part name: XIBU touchSEATCLEANER TP dl Article no.: 492012106700 Fig. 1: touchSEATCLEANER TP dl January 2018 | Tips & Tricks | 15...

  • Page 16: Replacing The Technical Package Assembly

    XIBU touchSEATCLEANER Replacing the technical package assembly Tools used: Slot screwdriver, size 2 XIBU key Replacing the technical package: Loosen the push piece from both latches. (Fig. 1) Fig. 1 Open the lock at the bottom using a screwdriver (Fig. 2).

  • Page 17: Xibu Sensetowel

    411020115000 Fig. 1: XIBU senseTOWEL Technical package Spare part compatible with batch no. 110115XX and higher Fig. 2: XIBU senseTOWEL Technical package Spare part name: XIBU senseTOWEL techn. package Article no. 492011660000 January 2018 | Tips & Tricks | 17...

  • Page 18: Replacing The Cover Assembly

    Replacing the cover assembly Tools used: REPLACING THE COVER Phillips screwdriver size PH1 XIBU key Use the XIBU key to Open the cover  remove the paper roll   Remove screw on the left and the right side of the cover swivel joint using the Phillips screwdriver.
  • Page 19 Fig. 3 Then twist the cover swivel joint back to its original position and tighten both screws again (Fig. 4) Spare part name: HT cover white XIBU Article no. 492011525000 Fig. 4 January 2018 | Tips & Tricks | 19...

  • Page 20: Cover Microswitch

    XIBU senseTOWEL Cover microswitch Tools used: Phillips screwdriver size PH1 Long nose pliers Request: No paper is dispensed despite a green blin- king LED (no difference whether the cover is open or closed). Possible cause: Microswitch (cover) is not working! Analysis: Fig.

  • Page 21: Replacing The Battery Tray

    Remove the batteries from the holder and re- place them (Fig. 5) The installation of the battery tray takes place in the reverse order. Spare part name: BG HT battery case XIBU Article no. 492011530000 Fig. 5 January 2018 | Tips & Tricks | 21...

  • Page 22: Tensioning Roller Spring

    Fig. 1 roller spring Open the cover  hook in the spring left and/or right (Fig. 2 and 3). Fig. 3 Spare part name: XIBU HTR tension.roller.spring Article no. 492011680000 Fig. 2 22 | Tips & Tricks | January 2018...

  • Page 23: Replacing The Cutting Unit Assembly

    Fig. 1: cutting unit Open the cover  remove the paper roll  press the hand button back and insert the XIBU key (Fig. 2). Loosen both screws on the cutting unit (Fig. 3) Press down the catches on the left and the right side with a slot screwdriver to loosen the cutting unit.
  • Page 24 Fig. 2 Tighten the 2 screws again and remove the XIBU key from its anchoring position. Spare part name: BG. HT cutting unit XIBU w. Replace the paper roll, turn the switch to „on“...

  • Page 25: Replacing The Lower Counter Roller / Esd Film Installation

    Remove the cutting unit  Fig. 2 The lower counter roller is now visible (Fig. 1). Spare part compatible with batch no. 110115XX and higher Spare part name: XIBU senseTOWEL counter roller Article no. 492011690000 Fig. 3 lower counter roller Fig. 2: XIBU senseTOWEL...
  • Page 26 Fig. 1 rocker has to be checked for ease movement and correct positioning. (Fig. 3) Fig. 3 ESD Film installation Spare part name: XIBU HTR ESD Film Article no: 492012120000 Request: Fig. 4: Film Dispenser automatically dispenses paper or dispenses paper.

  • Page 27: Replacing The Top Counter Roller

    XIBU senseTOWEL/touchTOWEL Replacing the top counter roller This error appear only with dispensers showing a batch.-no. before 141027XX. Tool used: Remove central reinforcement. For this pur- Flat screw driver pose, lever out the latch mechanism on the left and right-hand sides by means of a flat screwdriver, (Fig.
  • Page 28 XIBU senseTOWEL/touchTOWEL Replacing the top counter roller Insert spare part (Fig. 1) – hook in both springs again. Re-insert central reinforcement from above. Please make sure that the component is in- Fig. 1 serted into the vertical guide slots (Fig. 2).

  • Page 29: Xibu Touchtowel

    XIBU touchTOWEL XIBU touchTOWEL Article no. 411020125000 Fig. 1: XIBU touchTOWEL Technical package Fig. 2: XIBU touchTOWEL Technical package Spare part name: XIBU touchTOWEL techn.package Article no. 492011700000 January 2018 | Tips & Tricks | 29...

  • Page 30: Replacing The Cover Assembly

    Replacing the cover assembly Tools used: Phillips screwdriver size PH1 XIBU key Replacing the cover Use the XIBU key to Open the cover  remove the paper roll   Remove screw on the left and the right side of the cover swivel joint using the Phillips screwdriver.
  • Page 31 Then twist the cover of the swivel joint back to its original position and tighten both screws again (Fig. 4) Spare part name: HT cover white XIBU touch Article no. 492011715000 Fig. 4 January 2018 | Tips & Tricks | 31...

  • Page 32: Tensioning Roller Spring

    Fig. 1 roller spring Open the cover  hook the spring left and/ or right (Fig. 1 and 2). Fig. 3 Spare part name: XIBU HTR tension.roller.spring Article no. 492011680000 Fig. 2 32 | Tips & Tricks | January 2018...

  • Page 33: Insert Spring

    Insert the spring at the mounting points (see Fig. 2). Spare part compatible from batch no. Ch.-No. 150113XX Spare part name: XIBU HTR-T Spring Nachförderer Fig. 1 Artikel number: 492011840000 Fig. 2 January 2018 | Tips & Tricks | 33...

  • Page 34: Replacing The Cutting Unit Assembly

    Fig. 1: cutting unit Open lid  Remove paper roll  Press the hand button back and insert the XIBU key (Fig. 2). Undo the two screws at the cutting unit (Fig. 3). Push down the latches at the left and right with a flat-tip screwdriver to remove the cut-...
  • Page 35 XIBU touchTOWEL Replacing the cutting unit assembly Fig. 1 Fig. 2 Fig. 3 Setting the position of the supply cogwheel Careful! using a screwdriver (Fig. 1 + Fig. 2). The position of the blade must not be chan- ged when putting the cutting unit back in! Bring the blade of the cutting unit into exactly the same position as shown in Fig.

  • Page 36: Exchange The Spring Time Interval

    XIBU touchTOWEL Exchange the spring time interval Spare part name: XIBU HTR-T D-Feder Zeitverz. Article no.: 492012140000 Fig. 1 Tools used: XIBU key Request: Time delay is too short or too long. Solution: Change the spring time interval. Open the dispenser  press handle time in- terval and remove upwards (Fig.

  • Page 37: Xibu Sensefreshair

    Article no. 411020135000 Fig. 1 XIBU senseFRESHAIR Replacing the AF adjustment pin Tools used: Pin punch (Fig. 2 Needle nose pliers, XIBU key Fig. 2 Request: The adjustment pin is broken Solution: Replace the adjustment pin Push out the remainder of the adjustment pin by using the pin punch (Fig.

  • Page 38: Replacing The Technical Package Assembly / Battery Tray Assembly

    XIBU senseFRESHAIR Replacing the technical package assembly Tools used: XIBU key Open the dispenser with the XIBU key. Remove the battery tray from the technical package. (Fig. 1) Remove the technical package by pressing on the lock. (Fig. 2 and 3)
  • Page 39 XIBU XL senseFLUID XIBU senseFRESHAIR XIBU XL senseFLUID Article no. 411030107000 Fig. 1 XIBU xl senseFLUID Technical package Spare part name: XIBU XL technikal package Article no. 492012180000 Fig. 2 XIBU XL technical package January 2018 | Tips & Tricks | 39...

  • Page 40: Xibu Xl Sensefluid

    XIBU XL senseFLUID Replacing the technical package assembly Open the dispenser with the XIBU key. Tools used: XIBU key Remove the battery compartment from the dispenser (Fig. 1). Request: Remove the technical package by applying Spender ist ohne Funktion pressure to the lock. (Fig. 2 + 3)

  • Page 41: Installation Of Various Xibu Dispensers Using Two-Sided Adhesive Tape

    Installation of various XIBU dispensers using two-sided adhesive tape Process: 1.) Clean the mounting areas (back wall and/or mounting panel in the area where the two-sided adhesive tape is to be applied and area it is to be glued to) with SPSE cleaning cloth for dis- pensers.

  • Page 42: Freshair, Multifold, Xibu Xl Sensefluid

    Installation of various XIBU dispensers using two-sided adhesive tape Adhesive solution for XIBU dispensers freshAIR multiFOLD Adhesive tape, two-sided, 1.6 mm x 20 mm Article number: Adhesive tape, two-sided, Article number: 492020150000 1,6mmx20mm 492020150000 Required tape length 400 mm Required tape length 600 mm...
  • Page 43 Installation of various XIBU dispensers using two-sided adhesive tape Adhesive solution for XIBU dispensers XIBU XL senseFLUID Adhesive tape, two-sided, Article number: 1,6mmx20mm 492020150000 Required tape length 495 mm January 2018 | Tips & Tricks | 43...

  • Page 44: Installation Of Various Xibu Dispenser On Mirrors

    Installation of various XIBU dispenser on mirrors Screw mounting of XIBU dispensers on mirrors When screw mounting a XIBU dispenser onto a mirror, the customer has to provide the neces- sary spacers and recesses in the mirror. Hagleitner does not give any warranty for the installation!
  • Page 45 NOTES 12033150 January 2018 | Tips & Tricks | 45...
