Page 9: Introduction
Introduction Purpose of this manual This SIRIUS 3RA6 Compact Starter Manual describes the compact starter and its functions. It contains information about configuration, commissioning and servicing. As well as providing information about the compact starter itself, the manual also deals with compatible infeed systems.
Page 10 Introduction 1.1 Siemens Industry Online Support Topics The manual consists of instructive chapters, which are intended for reference purposes. The following table provides an overview of the topics covered: Table 1- 1 Chapter overview Chapter Contents Introduction Provides an overview of the manual's contents...
Page 11 Introduction 1.1 Siemens Industry Online Support Required basic knowledge Knowledge of the following areas is needed in order to understand the manual: ● Low-voltage switchgear ● Automation engineering and STEP 7 software ● AS-Interface ● IO-Link Symbols used in the text...
Page 12: Siemens Industry Online Support
Siemens Industry Online Support Information and service At Siemens Industry Online Support you can obtain up-to-date information from our global support database quickly and simply. To accompany our products and systems, we offer a wealth of information and services that provide support in every phase of the lifecycle of your machine or plant –...
Page 13 Introduction 1.1 Siemens Industry Online Support mySupport With "mySupport", your personal work area, you get the very best out of your Industry Online Support experience. Everything enables you to find the right information - every time. The following functions are now available: ●...
Page 14: Technical Assistance
Siemens Industry Online Support app Siemens Industry Online Support app You can use the Siemens Industry Online Support app to access all the device-specific information available on the Siemens Industry Online Support portal for a particular article number, including operating instructions, manuals, datasheets, FAQs etc.
Page 15: Safety Instructions
In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept. Siemens’ products and solutions only form one element of such a concept. Customer is responsible to prevent unauthorized access to its plants, systems, machines and networks.
Page 16: Standards/Regulations/Approvals
For environmentally friendly recycling and disposal of your old device, please contact a company certified for the disposal of old electrical and/or electronic devices and dispose of the device in accordance with the regulations in your country. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 17: System Description
3RA61/3RA62 compact starter without optional Communication via auxiliary contacts AS-i mounting module and signaling contacts 3RA61/3RA62 compact starter (24 V) with optional Communication via AS-Interface AS-i mounting module 3RA64/3RA65 compact starter with IO-Link Communication via IO-Link SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 18 Door-coupling rotary operating Door-coupling rotary operating Door-coupling rotary operating mechanism mechanisms enable compact mechanism (Page 207) starters to be operated with the control cabinet doors closed. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 19: System Configuration
3RA64/3RA65 compact starter with IO-Link IO-Link Note There are capacitors in the control circuit of the 3RA6 compact starter. As a result, high charging currents can arise briefly upon activation of the control supply voltage. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 20 Examples of how the compact starter can be integrated into the automation environment ① 3RA61/3RA62 compact starter without AS-i mounting module ② 3RA61/3RA62 compact starter with AS-i mounting module ③ 3RA64/3RA65 compact starter with IO-Link Figure 3-1 Integration into the automation environment SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 21: 3Ra61/3Ra62 Compact Starter Without Optional As-I Mounting Module
View of parallel wiring ① 3RA61 compact starter (direct starter) ② 3RA62 compact starter (reversing starter) ③ Connection to control system (e.g. PLC) Figure 3-2 System configuration with 3RA61/3RA62 compact starter without AS-i mounting module SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 22: 3Ra61/3Ra62 Compact Starter With Optional As-I Mounting Module
3RA61 compact starter (direct starter) with AS-i mounting module ② 3RA62 compact starter (reversing starter) with AS-i mounting module ③ AS-i ④ External voltage supply (AUX PWR) Figure 3-3 System configuration 3RA61/3RA62 compact starter with AS-i mounting module SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 23: 3Ra64/3Ra65 Compact Starter With Io-Link
① 3RA64 compact starter with IO-Link (direct starter) ② 3RA65 compact starter with IO-Link (reversing starter) ③ IO-Link ④ Auxiliary voltage V Figure 3-4 System configuration with 3RA64/3RA65 compact starter with IO-Link SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 24 System description 3.2 System configuration SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 25: Application Planning
(that is, on a vertically installed rail). Operating conditions SIRIUS 3RA6 compact starters are suitable for use in any climate. They are intended for use in enclosed rooms in which no severe operating conditions (such as dust, caustic vapors, hazardous gases) prevail.
Page 26 80 % of I 60 % of I 3RA6 infeed system side- by-side without clearance Mounting on vertical 3RA6 100% of I 80 % of I 60 % of I infeed system side-by-side without clearance SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 27 You will find further information on the compact starters' terminals in "Technical data (Page 251)". Distance from neighboring components For additional information on clearances to the neighboring components, please refer to "Minimum distances from neighboring components (dimensions in mm) (Page 256)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 28: Safe Isolation
External ..NO/..NC 300 V 250 V 250 V 250 V — 400 V auxiliary switch Main circuit 1L1/3L2/5L3 400 V 400 V 400 V 400 V 400 V — 2T1/4T2/6T3 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 29 The kinds of fault to be taken into account include twisted or loose conductive parts, twisted solder pins, broken winding wire, missing screws or broken barriers within a device. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 30: Supply Options (Main Circuit)
63 A three slots, outgoing terminals with spring- loaded connection technology, incl. PE bar Left or right infeed, 25/35 mm², with spring- 3RA6830-5AC 63 A loaded connection technology Extension connector 3RA6890-1AB 63 A SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 31 Permissible operating current of the compact starter + 40 °C 100% of I + 60 °C 80 % of I Mounting position The infeed system for 3RA6 can be installed horizontally or vertically. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 32 ① Main conductors (L1, L2, L3) ② Connection from the top ③ Connection from the bottom Figure 4-1 Multi-tier configuration of the infeed system for 3RA6 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 33 Short-circuit protection for terminal block (3RV2917-5D) 1.5 mm < 7.5 kA d,max 2.5 mm < 9.5 kA d,max 4 mm < 9.5 kA d,max 6 mm < 12.5 kA d,max SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 34 They shall be rated at least in accordance with the information concerning the short-circuit withstand strength (IEC 61439-1 Section 8.6.1) and designed to withstand at least the short-circuit stresses limited by the protective device on the supply side of the infeed system. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 35 Application planning 4.3 Supply options (main circuit) Options for combining the equipment with other products from the SIRIUS modular system SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 36 SIRIUS size S0 3RV2.2 circuit breakers using the 45 mm adapter for the infeed system for 3RA6 (3RA6890-0BA). ③ Three-phase or single-phase protective devices of other sizes using the terminal block (3RV2917-5D). Figure 4-2 Combination with other sizes (SIRIUS infeed system for 3RA6) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 37: 3Rv19 3-Phase Busbar
The compact starters can be combined with size S0 circuit breakers using the 3RV19 3- phase busbar (3RV1915-1.B) as well as with size S00 circuit breakers using the connection piece (3RV1915-5DB). Figure 4-3 Combination with other sizes (3RV19 3-phase busbar) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 38: 8Us Busbar Adapter
You can find more information on the technical data in "Technical data (Page 251)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 39: Infeed In Accordance With Ul 508 (Type E)
This means that it provides all 4 sub-functions and is, therefore, a member of the Type E category. It differs from the devices in the Type F category in that they switch the motors via a contactor which is connected separately. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 40 3RV19 3-phase infeed terminal for installing Type E starters, UL 508 3RV2925-5EB Figure 4-5 Terminals for infeed in accordance with UL 508 (Type E) Note According to C22.2-14, terminal blocks are not required for installation in accordance with CSA requirements. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 41: 3Ra61/3Ra62 Compact Starter
3RA6 ① 0 - ②③④⑤ The variables can be selected from the following table, depending on the required compact starter options: Variable Options Character string SIRIUS 3RA6 compact starter ① Compact starter 3RA61 direct starter • 3RA62 reversing starter •...
Page 42 3RA61/3RA62 compact starter 5.1 Scope of supply Variable Options Character string SIRIUS 3RA6 compact starter ④ Control supply voltage range (AC/DC) 24 V • 42 to 70 V • 110 to 240 V • ⑤ Terminal configuration No terminals •...
Page 43: Scope Of Supply
The equipment of the supplied 3RA61/3RA62 compact starter depends on the version ordered. Scope of supply of the 3RA61/3RA62 compact starter System component Article number Figure 3RA61 compact starter (direct 3RA61. starter) 3RA62 compact starter (reversing 3RA62. starter) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 44: Description Of The Hardware
– 1 to 4 A – 3 to 12 A – 8 to 32 A ● Control supply voltage range (AC/DC): – 24 V – 42 to 70 V – 110 to 240 V SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 45: 3Ra61 Compact Starter (Direct Starter)
Control is either via the control supply voltage connection at terminals "A1+" and "A2-" or via the AS-i mounting module. For additional information on the AS-i mounting module, please refer to "AS-i mounting module for 3RA61/3RA62 compact starter (Page 212)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 46 "Reset overload trip" button RESET Press this button to reset the compact starter following an overload. "Manual/auto reset" selector switch RESET M/A For selecting manual or auto reset following an overload. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 47 • White display: Malfunctions detected. Device must • be replaced. (15) "Control supply voltage" connection A1+, A2- — You can find detailed information on the precise device statuses in "Diagnostics (Page 87)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 48: 3Ra62 Compact Starter (Reversing Starter)
When switching several 3RA62 reversing starters in parallel, the operating mechanism must be switched via a separate auxiliary contact. You can find a connection example in "Control circuit of the 3RA61/3RA62 compact starter (Page 270)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 49 • "Reset overload trip" button RESET Press this button to reset the compact starter following an overload. "Manual/auto reset" selector switch RESET M/A For selecting manual or auto reset following an overload. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 50 Green: Control supply voltage is present. • display B1/B2 Off: Control supply voltage not present. • (13) "Short-circuit protection function" test TEST I>> Press this button to test the short-circuit protection button function. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 51 Even if the polarity is reversed, the LED "Control supply voltage present" lights up, but the compact starter does not switch on. You can find detailed information on the precise device statuses in "Diagnostics (Page 87)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 52: Configuring
Internet to assist you with configuration. Here, you can gather together all necessary products before the actual configuration process and you can realize complete projects virtually. You can find the configurator on the Internet (http://www.siemens.com/sirius/configurators). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 53: Functions
The main contacts are open. • Compact starter is switched off: The circuit breaker mechanism is switched off. • GREEN Control supply voltage is present. • The main contacts are open. • SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 54 READY, the machine will start up immediately. People may be injured if they stay in the danger area of the machine. Make sure that the danger area of the machine is kept clear of people. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 55 There is a fault. "Overload trip" display white: Overload tripped. • GREEN "Overload trip" display not white: Control supply • voltage is outside the working range. The main contacts are open. • SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 56 Control supply voltage is outside the working range. – Control supply voltages for both directions of rotation were applied simultaneously. – Polarities are reversed in the case of DC connection. All main contacts are open. • SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 57 For additional information on eliminating malfunctions, please refer to "Shutdown on malfunction (Page 62)". For additional information on eliminating short circuits, please refer to "Short-circuit protection function (Page 60)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 58: Overload Protection Function
The "Overload tripped" status is indicated by the following elements: Table 5- 6 Overload trip display elements (direct starter/reversing starter) Actuator Mech. display Compact starter status TRIP READY Overload tripped White display SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 59 3 minutes. If you carry out a manual reset within 3 minutes although the motor model has not yet sufficiently discharged, another overload trip can occur when the compact starter is switched SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 60: Short-Circuit Protection Function
The "Short circuit tripped" status is indicated by the following elements: Table 5- 7 Short circuit trip display elements (direct starter/reversing starter) Actuator Mech. display Compact starter status RLT 0% TRIPPED Short circuit tripped No display SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 61 TRIPPED position. The "Fault" signaling contact (terminals 77/78) opens. The test can be terminated by turning the actuator first to the OFF position and then to the READY position. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 62: Shutdown On Malfunction
A compact starter malfunction will cause the compact starter to shut down. Continuing to operate the compact starter is extremely risky, as it can no longer be considered reliable. Following a shutdown caused by a malfunction, you will need to replace the compact starter. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 63: Disabling The Actuator
(shackle diameter 3.5 - 4.5 mm). Before you can do this, the actuator must be set to OFF position and the actuator eye must be pulled out. Step Instructions Image Pull out the eye on the actuator. Hang the padlock into the eye and close SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 64: Installing/Removal
5.5 Installing/removal Installing/removal 5.5.1 Installing the 3RA61/3RA62 compact starter The sections below explain how to install the SIRIUS 3RA6 compact starter on: ● A standard mounting rail ● A level surface (screw fastening) ● The infeed system for 3RA6 5.5.1.1...
Page 65: Installing The Compact Starter On A Level Surface (Screw Fastening)
● 4 M4 screws for mounting the direct starter on the level surface. 6 M4 screws for mounting the reversing starter on the level surface. ● Observe the information on minimum clearances in "Dimension drawings (Page 253)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 66 Insert each screw through the relevant holes in the mounting lugs. ⑤ Screw the device onto the level surface so that it is secure. ⑥ Release the actuator. ⑦ Remove the transport lock from the compact starter toward the front. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 67 However, in this case 2 additional adapters just need to be snapped onto the reversing starter and a single lug is used for surface mounting. Figure 5-1 Installing a 3RA62 compact starter (reversing starter) on a level surface (screw fastening) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 68: Installing The Compact Starter On An Infeed System For 3Ra6
Push the compact starter straight onto the infeed system for 3RA6 until you hear it engage. ④ Release the actuator. ⑤ Remove the transport lock from the compact starter toward the front. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 69: Removing The 3Ra61/3Ra62 Compact Starter
3RA61/3RA62 compact starter 5.5 Installing/removal 5.5.2 Removing the 3RA61/3RA62 compact starter The sections below explain how to remove the SIRIUS 3RA6 compact starter from: ● A standard munting rail ● A level surface (screw fastening) ● The infeed system for 3RA6 5.5.2.1...
Page 70: Removing The Compact Starter From A Level Surface (Screw Fastening)
Before starting work, disconnect the system and the device from the power supply. Procedure Note The compact starter can be removed from the wall with the wiring still in place (permanent wiring), i.e. there is no need to disconnect the main circuit terminals. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 71 Use a screwdriver to release the bottom main circuit terminal. Tilt the compact starter upwards and pull it forwards in order to remove it from the main circuit terminals. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 72: Removing The Compact Starter From An Infeed System For 3Ra6
(see arrow on enclosure lid) so that you can push the compact starter forwards by approx. 5 mm. Move the compact starter forwards to remove it from the screw-type infeed or extension block. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 73 (see arrow on enclosure lid) so that you can push the reversing starter forwards by approx. 5 mm. Move the reversing starter forwards to remove it from the screw-type infeed or extension block. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 74: Connection
The terminals are marked to make it easier to determine the stripping length. The correct stripping length can be achieved by lining the conductor up with this marking. Figure 5-2 Representation of stripping lengths on terminals SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 75 On the compact starter with spring-loaded connection technology, all terminals are equipped with special test probe openings. Openings for test probes on ① the main circuit terminals. ② the control circuit terminals. Figure 5-3 Test probe openings on the 3RA6 compact starter SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 76 2 x (14 to 10) 2 x (16 to 10) 2 x (14 to 10) 2 x (14 to 10) — — — 1 x 8 1 x 8 1 x 8 1 x 8 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 77 2 x (0.5 to 1.5) mm — 2 x (20 to 14) 2 x (24 to 16) Note A cross-section (2 x 1.5) mm with end sleeve to DIN 46228-4 is not possible (plastic collar). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 78: Connecting Terminal Blocks
Insert the relevant cable as far as it will go into the screw terminal opening and hold it in place. Tighten the relevant screw. Pull on the cable to ensure it is completely secure. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 79 Insert the cable as far as it will go into the oval opening and hold it in place. Remove the screwdriver and pull on the cable to ensure it is completely secure. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 80: Connecting The Compact Starter Without Optional As-I Mounting Module
21, 22 Auxiliary NC contact for querying the position of the main contacts - mirror contacts to main contacts 2T1, 4T2, 6T3 Main contacts (on the outgoing side) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 81 A mirror contact is an NC contact that cannot be closed simultaneously with the main NO contact. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 82 21-22 (normally closed) and 13-14 (normally open). In addition, external auxiliary switch 3RA6913-1A or 3RA6913-2A provides positively driven contact elements with one NC contact and one NO contact each. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 83: Disconnecting Terminal Blocks
Before starting work, disconnect the system and the device from the power supply. Procedure for screw terminals Step Instructions Image Undo the screw of the screw terminal. Remove the cable from the unscrewed screw terminal. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 84 Please observe a 10° horizontal angular deviation of the screwdriver to the oval opening. Remove the cable from the oval opening. Remove the screwdriver. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 85: Commissioning
< 20 s (for heavy starting) You can use a slide switch to set the trip class to CLASS 10E or CLASS 20E. Figure 5-4 Setting CLASS 10E/20E on the compact starter SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 86 3 minutes. However, a manual reset can still be performed if you have selected this setting. Figure 5-6 Setting RESET M/A on the compact starter For additional information on the manual and auto reset functions, please refer to "Overload protection function (Page 58)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 87: Diagnostics
95/96: Closed 77/78: Open 95/98: Open 21/22: Closed — — Malfunction (e.g. end of service life reached) Malfunction tripped TRIPPED Open 13/14: Open 95/96: Closed 77/78: Open 95/98: Open 21/22: Closed — — SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 88 77/78: Open 95/98: Open 43/44: Open — — Malfunction (e.g. end of service life reached) Malfunction tripped TRIPPED Open Open 13/14: Open 95/96: Closed 77/78: Open 95/98: Open 43/44: Open — — SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 89: Diagnostics Via Display Elements
Depends on whether control supply voltage is present at the same time or whether no control supply voltage is present LED: Not illuminated Mechanical display: No display LED: Illuminated green Mechanical display: White display SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 90 Depends on whether control supply voltage is present at the same time or whether no control supply voltage is present LED: Not illuminated Mechanical display: No display LED: Illuminated green Mechanical display: White display SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 91: 3Ra64/3Ra65 Compact Starter With Io-Link
The variables can be selected from the following table, depending on the required compact starter options: Variable Options Character string SIRIUS 3RA6 compact starter ① Compact starter 3RA64 compact starter with IO-Link (direct starter) • 3RA65 compact starter with IO-Link (reversing starter) •...
Page 92 Current setting range ③ 1 to 4 A ➜ C Terminal configuration ④ With main circuit terminals and control circuit ➜ 2 terminals for attachment to a standard mounting rail. Article number: ➜ 3RA6 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 93: Scope Of Supply
8 mm) Further accessories for the 3RA64/3RA65 compact starter: ● Connecting cable (Chapter "Connecting cable for IO-Link (Page 238)") ● Operator panel (Chapter "Operator panel for 3RA64/3RA65 compact starter with IO-Link (Page 240)") SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 94: Description Of The Hardware
● One 6-pole control circuit terminal (L+, C/Q, L-, A2-, A1+/Y1, Y2) ● Slot for an optional external auxiliary switch block (2 NO contacts, 2 NC contacts or 1 NC contact + 1 NO contact) Control takes place via IO-Link. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 95 For selecting the current setting I depending on the article number: 0.1 - 0.4 A • 0.32 - 1.25 A • 1 - 4 A • 3 - 12 A • 8 - 32 A • SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 96 3RA64/3RA65 compact starter with IO-Link (Page 134)". You can find information on the external auxiliary switch block in "External auxiliary switch block (Page 156)". Reference to "Parameter "Operation at Preset <> Actual Configuration" (Page 115)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 97: 3Ra65 Compact Starter With Io-Link (Reversing Starter)
(against incorrect activation). Note If direction of rotation 1 and direction of rotation 2 are triggered simultaneously, the compact starter signals a group error and switches off. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 98 For selecting the current setting I depending on the article number: 0.1 - 0.4 A • 0.32 - 1.25 A • 1 - 4 A • 3 - 12 A • 8 - 32 A • SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 99 3RA64/3RA65 compact starter with IO-Link (Page 134)". You can find information on the external auxiliary switch block in "External auxiliary switch block (Page 156)". Reference to "Parameter "Operation at Preset <> Actual Configuration" (Page 115)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 100: Configuring
Internet to assist you with configuration. Here, you can gather together all necessary products before the actual configuration process and you can realize complete projects virtually. You can find the configurator on the Internet (http://www.siemens.com/sirius/configurators). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 101: Combinations
– V1.1: 0x01 ● Parameter server functionality: – V1.0: not available – V1.1: available The 3RA64 and 3RA65 compact starters are designed as an IO-Link device according to IO- Link communication specification V1.0. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 102: Configuring With Step 7 And The S7-Pct Port Configuration Tool
● The GSD files of the IO-Link masters are already installed in . You can download all current GSD files for the Siemens IO-Link masters from the Internet (http://www.siemens.com/comdec). ● Optional: Install the IO_LINK_MASTER and IO_LINK_DEVICE function blocks for backing up / restoring IO-Link master parameters, IO-Link device parameters, parameterization of IO-Link devices during operation, and readout of IO-Link port functions.
Page 103: Configuration
4. Drag the IO-Link device out of the component catalog to the required port of the IO-Link master. 5. Start by parameterizing the IO-Link device. S7-PCT Additional information is available in the online help. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 104: Configuring With The S7-Pct Port Configuration Tool (Stand-Alone)
IO-Link device according to the IO-Link communication specification V1.1. You may need IODD files according to the communication specification V1.0 when replacing devices in existing installations. Note Configuring with S7-PCT stand-alone is not possible for the CPU versions of the ET 200. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 105: Configuration
To be able to access the IO-Link master or an IO-Link device online, communication between the ET 200 and the higher-level controller must be active (BF-LED on ET 200 interface module is off). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 106: Acyclic Data Exchange With The Io_Link_Device Function Block
2. Use the IO_LINK_DEVICE function block as described in the documentation. 3. You can find an application example of how to use the IO-Link devices with the IO_LINK_DEVICE function block on the Internet (https://support.industry.siemens.com/cs/ww/en/view/90529409). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 107: Acyclic Data Exchange With The Io_Link_Master Function Block
2. Use the IO_LINK_MASTER function block as described in the documentation. 3. You can find an application example of how to use the IO-Link masters with the IO_LINK_MASTER function block on the Internet (https://support.industry.siemens.com/cs/ww/en/view/90529409). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 108: Replacing An Io-Link Device
In the event of a replacement, a PG/PC is available with the SIMATIC project of the plant. S7-PCT With the data stored in the SIMATIC project, and the port configuration tool, you transfer the parameters belonging to the replaced IO-Link-Device to the new IO-Link-Device. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 109 "SIRIUS 3RA2711 function modules", where group formations of up to four starters are possible, the above information refers to the replacement of the first load feeder. Replacement of load feeders 2 to 4 of a group of four does not require any supplementary measures. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 110: Integration Into The Simatic Environment
A block library is designed to make it easier for end users to connect the IO-Link devices, and to demonstrate use of the library using actual examples You can download the library from the Internet (https://support.industry.siemens.com/cs/ww/en/view/90529409) free of charge. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 111: Parameters
"Port Configuration Tool", or it can be copied from the old compact starter to the new compact starter with the help of the function block "IO-Link Call". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 112: Starter Available" Parameter
If you use the 10-core connecting cable, you must re-supply the auxiliary voltage V after the empty location. You can find more information on the connecting cables in " Connecting cable for IO-Link (Page 238)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 113 View ① Empty location (starter not available) ② Connecting cable 14-core, length 200 mm for compact starter ③ IO-Link ④ Auxiliary voltage V Figure 6-1 Configuration with "Starter available" parameter = nein SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 114: Type Of Starter" Parameter
If the current setting range of the compact starter is not important for configuring, the value 1 can be assigned to the starter type 3RA64 or 3RA65. The parameter cannot then be used to draw any conclusions regarding the current setting range. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 115: Parameter "Operation At Preset <> Actual Configuration
The number of configured compact starters is checked continuously, regardless of the "Operation at Preset <> Actual Configuration" parameter value. You can find more information on the data sets in " Data sets for the 3RA64/3RA65 compact starter with IO-Link (Page 279)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 116: Operation With Operator Panel
"Operator panel available" parameter Value Description Default setting Operator panel available: No — Operator panel available: Yes The "Operator panel available" parameter can only be modified via IO-Link. It cannot be adjusted at the device. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 117: Parameter "Operation At Preset <> Actual Configuration
"Operation at Preset <> is not possible. Actual Configuration = "disable" The parameter "Operation at Preset <> Actual Configuration" can only be modified via IO-Link. It cannot be adjusted at the device. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 118: Process Image
DI1.0 1: Ready (automatic) DI1.1 1: Motor ON DI1.2 1: Group fault DI1.3 1: Group warning DI1.4 1: Ready (automatic) DI1.5 1: Motor ON DI1.6 1: Group fault DI1.7 1: Group warning SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 119 Only in the case of the reversing starter. You can find information on the trip reset in "Overload protection function (Page 122)". For additional information, please refer to " Group diagnostics - data set (index) 90 (Page 283) ". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 120: Functions
READY, the machine will start up immediately. People may be injured if they stay in the danger area of the machine. Make sure that the danger area of the machine is kept clear of people. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 121 For additional information on eliminating malfunctions, please refer to "Shutdown on malfunction (Page 62)". For additional information on eliminating short circuits, please refer to "Short-circuit protection function (Page 60)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 122: Overload Protection Function
Make sure that the danger area of the machine is kept clear of people. ● "Overload trip class" selector switch: For selecting trip CLASS 10E or CLASS 20E. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 123 V , another overload trip can result since the motor will not yet have cooled sufficiently. Do not switch the compact starter on again until the motor has cooled sufficiently. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 124: Short-Circuit Protection Function
You can disable the actuator on the 3RA64/3RA65 compact starter with IO-Link in the same way as on the 3RA61/3RA62 compact starter. For additional information, please refer to " Disabling the actuator (Page 63) ". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 125: Diagnostics
Activation Motor direction 1 activated READY Control priority: Green Green IO-Link/ Green/ Manual operation Flashing yellow Motor direction 2 activated READY Control priority: Green Green IO-Link/ Green/ Manual operation Flashing yellow SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 126 2 triggered Green Green Green Limit switch 2 tripped and direction READY of rotation 2 triggered Yellow Green Limit switch 2 tripped and opposite READY direction 1 triggered Green Green Green SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 127 Check the connection between the connecting terminals (ground) of the IO-Link Master (A3, A4, A7, and A8) and the connecting terminals (ground) of the power module (A1, A4, A7, and A8). After setting the actuator to READY. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 128: Diagnostics Via Io-Link
Diagnostics via IO-Link Fault types of the 3RA64/3RA65 compact starter IO-Link errors are mapped to PROFIBUS DP errors. Mapping takes place as described in IO-Link Integration Part 1 or in accordance with vendor-specific definitions from Siemens. Table 6- 11 IO-Link event display...
Page 129: Installing/Removal
If you replace the 3RA64/3RA65 compact starter with IO-Link with a new compact starter, you must transfer the parameter data and configuration data to the new compact starter. You can find information on replacing a module in Chapter "Replacing an IO-Link device (Page 108)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 130 Connecting cable 14-core (8 mm) Figure 6-2 Connecting 3RA64/3RA65 compact starters with IO-Link You can find more information on connecting the operator panel in "Operator panel for 3RA64/3RA65 compact starter with IO-Link (Page 240)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 131 Plugging in the connecting cables Step Instructions Image Open the cover for the interface for the connecting cable. Plug the connecting cable into the interface until you hear it engage. Close the interface cover. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 132: Removing The 3Ra64/3Ra65 Compact Starter With Io-Link
Disconnecting the compact starters Table 6- 12 Removing the connecting cable Step Instructions Image Open the cover for the interface for the connecting cable. Remove the connecting cable from the interface. Close the interface cover. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 133: Connection
Connect the terminal blocks on the 3RA64/3RA65 compact starter with IO-Link in the same way as the 3RA61/3RA62 compact starter. For information, please refer to " Connecting terminal blocks (Page 78) ". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 134: Connecting The 3Ra64/3Ra65 Compact Starter With Io-Link
Conductor bridge pre-mounted at factory Note Note the current consumption of the compact starter when selecting the auxiliary power supply (A1+ / A2-). For additional information, please refer to "Technical data (Page 251)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 135 Main contacts (on the outgoing side) ① Conductor bridge pre-mounted at factory Note Before a limit switch can be connected to terminals Y1 - Y2 or Y3 - Y4, the bridge must be removed. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 136: Connecting Limit Switches
3RA64 compact starter with IO-Link (direct starter) ② 3RA65 compact starter with IO-Link (reversing starter) ③ Limit switch for direction of rotation 1 ④ Limit switch for direction of rotation 2 Figure 6-3 Connecting limit switches SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 137 When delivered, terminals Y1 - Y2 and Y3 - Y4 are bridged as standard by a conductor. For this reason, remove this conductor bridge before connecting a limit switch. You can find more information on connecting the screw terminals and spring-loaded terminals in chapter Connection via terminals (Page 74). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 138: Emergency Stop
Compact starters with their own V supply are connected with the upstream compact starter not via the 14-core connecting cable but via the 10-core connecting cable (3RA6931-0A). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 139 Auxiliary voltage V ⑦ Switch for EMERGENCY STOP Figure 6-4 Connecting the EMERGENCY STOP function You can find more information on the required connecting cables in "Connecting cable for IO-Link (Page 238)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 140: Commissioning
< 20 s (for heavy starting) You can use a slide switch to set the trip class to CLASS 10E or CLASS 20E. Figure 6-5 Setting CLASS 10E/20E on the compact starter with IO-Link SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 141 6.10 Commissioning Current setting I Set the rated operating current of the motor to be protected on the setting scale. Figure 6-6 Setting the current setting I on the compact starter with IO-Link SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 142 Figure 6-7 Setting RESET M/A on the compact starter with IO-Link For additional information on the manual and auto reset functions, please refer to "Overload protection function (Page 58)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 143: Accessories
- 2 NC contacts 3RA6912-2A - 1 NO contact + 1 NC contact 3RA6913-2A Control kit 3RA6950-0A 3RA61 3RA62 3RA64 3RA65 Adapter for screw fastening the compact starter 3RA6940-0A 3RA61 3RA62 3RA64 3RA65 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 144 Operator panel for compact starter (incl. enabling block for 3RA6935-0A 3RA64 operator panel) 3RA65 Enabling block for operator panel for compact starter 3RA6936-0A 3RA64 3RA65 Blanking cover for operator panel 3RA6936-0B 3RA64 3RA65 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 145 (for reordering an original part that has been lost) IP 20 terminal cover for screw-type infeeds 25/35 mm 3RA6880-2AB — (pack of 2) IP 20 terminal cover for screw-type infeeds 50/70 mm 3RA6880-3AB — (pack of 2) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 146 Article number Valid for Door-coupling rotary operating mechanism 3RV2926-0B 3RA61 3RA62 - 130 mm long 3RA64 3RA65 EMERGENCY OFF door-coupling rotary operating mechanism 3RV2926-0C 3RA61 3RA62 - 130 mm long 3RA64 3RA65 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 147: Adapter For Screw Fastening
The adapters for screw fastening are required for installing the 3RA61/3RA62/3RA64/3RA65 compact starter on a level surface (screw fastening). For information, please refer to " Installing the compact starter on a level surface (screw fastening) (Page 65) ". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 148: Main Circuit Terminals
Requirements DANGER Hazardous voltage! Will cause death or serious injury. Before starting work, disconnect the system and the device from the power supply. ● The main circuit terminals must have been disconnected. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 149 Instaling main circuit terminals Step Instructions Image Insert the removable main circuit terminal into the device's mechanically coded guiderail from the back. Then push the main circuit terminal forwards until you hear it engage. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 150: Control Circuit Terminals
The mechanical coding on the control circuit terminals prevents mix-ups. The terminals are marked as follows: ① A: Top/front mounting position on compact starter ② B: Bottom/rear mounting position on compact starter Figure 7-1 Coding on the control circuit terminals SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 151 Push the terminal block up and then back until you hear it engage. Make sure that you install the two terminal blocks in the correct order. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 152 Step Instructions Image Push the terminal block's release clip down. Pull the terminal block out to the front. Move the terminal block down and out from the compact starter's mechanically coded guiderail. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 153: Control Kit
Then the main contacts can be closed using the actuator and the motor will start up. Configuration View Meaning Mechanical connection point Handle SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 154: Using The Control Kit
Only use the control kit briefly for testing purposes (e.g. checking the direction of rotation or the auxiliary switch wiring). Long-term operation using the control kit is not permissible. Requirements ● The compact starter must be switched off (actuator set to OFF position). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 155 Release the latch mechanism (5a). Push the control kit backwards and then tilt it down (5b). Remove the control kit from the compact starter by pulling it down at an angle (5c). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 156: External Auxiliary Switch Block
The external auxiliary switch block is available with screw-type or spring-loaded connection technology in the following versions: ● 2 NO contacts ● 2 NC contacts ● 1 NO contact + 1 NC contact SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 157: Installing/Removal
Installing the auxiliary switch block Step Instructions Image Insert the auxiliary switch block into the location holes on the compact starter. Push the auxiliary switch block up until it engages. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 158 Release the locking latch on the lower side of the auxiliary switch block. Push the auxiliary switch block downwards. Remove the auxiliary switch block from the compact starter by pulling it forwards and off. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 159: Connection
The designations of the terminals on the external auxiliary switch block are made up of the labeling on the compact starter and on the external auxiliary switch block. ① Compact starter ② External auxiliary switch block Figure 7-2 Terminal designations external auxiliary switch block SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 160 Pin assignment Table 7- 1 Pin assignments on the auxiliary switch block for compact starter Auxiliary switch block View Meaning 2 NC contacts 1 NC contact + 1 NO contact 2 NO contacts SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 161 2 x (0.5 to 1.5) mm 2 x (0.25 to 1.5) mm 2 x (0.75 to 2.5) mm 2 x (20 to 16) 2 x (24 to 14) 2 x (18 to 14) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 162: Infeed System For 3Ra6
(for installing Type E starters in accordance with UL 508) Left infeed, 25/35 mm² screw terminal with three slots, outgoing terminals with - Screw-type connection technology 3RA6812-8AB - Spring-loaded connection 3RA6812-8AC technology Incl. PE bar SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 163 - Spring-loaded connection 3RA6823-0AC technology Incl. PE bar Left or right infeed, 25/35 mm², with 3RA6830-5AC spring-loaded connection technology PE infeed, 25/35 mm², with - Screw-type connection technology 3RA6860-6AB - Spring-loaded connection 3RA6860-5AC technology SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 164 Extension connector 3RA6890-1AB (for reordering an original part that has been lost) IP 20 terminal cover for screw-type 3RA6880-2AB infeeds 25/35 mm IP 20 terminal cover for screw-type 3RA6880-3AB infeeds 50/70 mm SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 165: Description Of The Hardware
1.20 m using extension modules. For this purpose, the infeed blocks and extension modules are arranged side by side and connected up electrically using an extension connector and an optional PE extension connector. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 166 Accessories 7.7 Infeed system for 3RA6 ① Screw-type infeed (25/35 mm ② Screw-type infeed (50/70 mm ③ Spring-loaded infeed ④ Extension block Figure 7-3 Infeed system for 3RA6 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 167 3RA6 using the 45 mm adapter for the infeed system for 3RA6 (3RA6890-0BA). For additional information on combining the equipment with other sizes, please refer to "Infeed system for 3RA6 (Page 30)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 168: Installing/Removal
Place the back of the screw-type infeed onto the upper edge of the standard mounting rail Press the lower half of the screw-type infeed against the standard mounting rail until you hear it engage. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 169 The electrical interface for the expansion module must be fitted with an extension connector or an end cover at all times when the power supply is energized. When installing/removing an extension connector or an end cover the system power supply must be switched off. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 170 Use an extension connector to establish an electrical connection between the extension module and spring-loaded infeed. Attach the end cover to the right or left of the extension module. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 171 The electrical interface for the expansion module must be fitted with an extension connector or an end cover at all times when the power supply is energized. When installing/removing an extension connector or an end cover the system power supply must be switched off. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 172 Attach the end cover to the additional extension module. Note If the infeed system is being mounted on a vertical mounting rail, a suitable stopper must be installed underneath the infeed system to keep it in place. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 173: Installing The Infeed System For 3Ra6 On A Level Surface (Screw Fastening)
Mount the screw-type infeed/extension module on the pre-assembled screws. Insert each of the remaining screws through the relevant holes in the screw- type infeed/extension module and screw the device onto the level surface. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 174: Installing The Accessories For The Infeed System For 3Ra6
, with screw-type or spring-loaded connection technology ② PE tap, 6/10 mm , with screw-type or spring-loaded connection technology ③ PE extension connector Figure 7-5 Mounting options for PE infeed and PE tap SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 175 Note If you are installing the PE infeed on a level surface (screw fastening), it will also need to be fixed to the surface using an M4 x 16 screw. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 176 Remove the end cover from the infeed system for 3RA6. Push together the infeed system for 3RA6 and the 3RV29 infeed system. Connect the infeed system with the extension connector for 3RV29. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 177 3RA6 and may cause an electric shock. Mount only 3RV2.2 circuit breakers of size S0 on the 45 mm adapter for the infeed system for 3RA6. In addition, interphase barriers must be installed. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 178 – Approximately 18 mm coverage with terminal cover 3RA6880-3AB ● For clamping points not occupied with cables, the covers can be turned over once and pushed over the clamping points, thereby covering the metal parts so they are safe-to- touch. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 179 The following representations show the mounting options for the terminal cover for screw- type infeeds 25/35 mm Figure 7-6 Top mounting of terminal cover for screw-type infeeds 25/35 mm Figure 7-7 Bottom mounting of terminal cover for screw-type infeeds 25/35 mm SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 180 The following representations show the mounting options for the terminal cover for screw- type infeeds 50/70 mm Figure 7-8 Top mounting of terminal cover for screw-type infeeds 50/70 mm Figure 7-9 Bottom mounting of terminal cover for screw-type infeeds 50/70 mm SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 181: Uninstalling The Accessories For The Infeed System For 3Ra6
PE infeed sideways. Press the clip on the PE tap backwards and then pull the PE tap down and out of the infeed or extension module. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 182: Removing The Infeed System For 3Ra6 From A Standard Mounting Rail
Pull the screw-type infeed down until it can be pulled away from the standard mounting rail. Pull the screw-type infeed away from the standard mounting rail and lift it off the rail's upper edge. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 183 Pull the spring-loaded infeed down until it can be pulled away from the standard mounting rail. Pull the spring-loaded infeed away from the standard mounting rail and lift it off the rail's upper edge. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 184 Pull the extension module down until it can be pulled away from the standard mounting rail. Pull the extension module away from the standard mounting rail and lift it off the rail's upper edge. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 185: Coding
The infeed system for 3RA6 can be locked against compact starters with the following current setting ranges: ● 3 to 12 A ● 8 to 32 A ● 3 to 12 A and 8 to 32 A SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 186 Each slot is individually coded for compact starters with a particular current setting range. ① ④ Slot 1 coding Slot 4 coding ② ⑤ Slot 2 coding Slot 5 coding ③ Slot 3 coding Figure 7-11 Coding the SIRIUS infeed system for 3RA6 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 187: Connection
PE infeed, 25/35 mm , screw-type connection 3RA6860-6AB 13 mm technology PE infeed, 25/35 mm , spring-loaded 3RA6860-5AC 23 mm connection technology PE tap 3RA6870-4AB 10 mm 3RA6870-3AC Terminal block 3RV2917-5D 12 mm SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 188 On the infeed system with spring-loaded connection technology, all terminals are equipped with special test probe openings. Openings for test probes on ① The spring-loaded infeed ② The extension blocks Figure 7-12 Test probe openings on the infeed system SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 189 10 … 50 mm Max. (2 x 35) mm 2.5 … 35 mm 2.5 … 50 mm Max. (2 x 35) mm 10 to 2/0 10 to 2/0 Max. 2 x (10 to 1/0) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 190 2 x (14 to 10) 2 x (16 to 10) 2 x (14 to 10) 2 x (14 to 10) 1 x 8 1 x 8 1 x 8 1 x 8 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 191 1 x 8 Table 7- 11 Terminal block 3RV2917-5D 8WA2 803 8WA2 804 (3.5 x 0.5 mm) 1,5 ... 6 mm 1,5 ... 6 mm 1,5 ... 4 mm 15 to 10 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 192: 3-Phase Busbar
S00 circuit breakers Cover cap for terminal lugs 3RV1915-6AB 3-phase infeed terminal, 3RV2925-5EB connection from above, with screw-type connection technology and for installing "Type E starters", UL 508 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 193: Description Of The Hardware
(see Configuration). NOTICE Material damage to the busbar and connecting terminals! Thermal overloads can damage the busbar and connecting terminals. When extending the 3-phase busbar, please remember to observe its current carrying capacity. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 194 (e.g. for reversing starters). These cover caps need to be removed before extending the busbars. Configuration Configuration involving 3RV19 3-phase busbar and infeed terminal from the top/bottom Figure 7-13 3-phase busbar and infeed terminal from the top/bottom SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 195 Accessories 7.8 3-phase busbar Configuration involving 3RV19 3-phase busbar and 3-phase infeed terminal for installing Type E starters, UL 508 Figure 7-14 3-phase busbar and 3-phase infeed terminal (Type E) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 196: Connection
(17.6 … 22 lb in) (2.5 ... 25) mm (2.5 … 25) mm (2.5 … 25) mm (2.5 … 25) mm (2.5 … 16) mm (2.5 … 16) mm 10 … 4 10 … 4 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 197: 8Us Busbar Adapter
60 mm system Note: Except for the adapter for screw fastening, fastening parts are prefitted. Device holder for side mounting on 8US1250-1AA10 busbar adapter (only if installing a 3RA62 reversing starter) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 198: Description Of The Hardware
The following accessory is available for the 8US busbar adapter: ● Device holder for lateral mounting on busbar adapter (8US1250-1AA10). You only need the device holder when installing a 3RA62 compact starter reversing starter. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 199: Installing/Removal
● 10 mm Step Instructions Image Push the 3 fastening blocks down. Adjust the fastening blocks in accordance with the busbar thickness (5 mm/10 mm). Push the fastening blocks up until they engage. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 200 Press the button on the top side of the busbar adapter to release the holder. The holder should flip out from the front of the busbar adapter. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 201 Connect the wiring from the busbar adapter to the compact starter's main circuit terminal. Mount the busbar adapter on the busbars from the top. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 202 Connect the wiring from the busbar adapter to the reversing starter's main circuit terminal. Mount the busbar adapter plus device holder on the busbars from the top. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 203: Removal
Removing the busbar adapter plus mounted device holder When removing the busbar adapter along with a mounted device holder, you will need to release both holder (A) on the busbar adapter and the one on the device holder. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 204: Terminal For A Type E Self-Protected Combination Motor Controller (Ul 508)
Supply options in accordance with UL 508 (Type E) are still available when compact starters are installed with a 3RV19 3-phase busbar and the infeed system for 3RA6. For additional information, please refer to "Infeed in accordance with UL 508 (Type E) (Page 39)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 205 7.10 Terminal for a Type E self-protected combination motor controller (UL 508) Procedure Step Instructions Image Attach the terminal to the compact starter's main circuit terminal from the top. Screw the screw terminals tight. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 206: Connection
Max. 10 + max. 25 mm (1 … 16) mm (1 … 16) mm Max. 10 + max. 10 mm Max. 6 + max. 16 mm 14 to 3 16 to 3 Max. 6 + max. 3 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 207: Door-Coupling Rotary Operating Mechanism
● Door-coupling rotary operating mechanism for EMERGENCY OFF applications (black/red actuator) (article number: 3RV2926-0C) Both versions have been designed to provide IP64 degree of protection and can be locked in OFF position using up to 3 padlocks. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 208: Installing
Accessories 7.11 Door-coupling rotary operating mechanism 7.11.3 Installing Installing the door-coupling rotary operating mechanism Remember to observe the mechanical coding of the connecting rod! Figure 7-15 Installing the door-coupling rotary operating mechanism SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 209: Commissioning
If you want to open the control cabinet door during operation, press the button to the side of the bypass finger-grip knob (step 1). To close the door during operation press the button again so that the extension shaft reengages. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 210 OFF) and turn the rotary switch of the door-coupling rotary operating mechanism to OFF. Attach the extension shaft cap to the rotary switch and then insert the extension shaft into the cap. Close the control cabinet door. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 211 In the OFF position, the rotary operating mechanism can be secured using up to 3 locks, e.g. while maintenance work is carried out on the system. Figure 7-17 Door-coupling rotary operating mechanism, securing SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 212: As-I Mounting Module For 3Ra61/3Ra62 Compact Starter
For active AS-Interface modules, • intelligent sensors and actuators In accordance with AS-Interface • Version 3.0 Including extended addressing • mode Scope of supply including • addressing line (1.5 m stereo jack) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 213: Description Of The Hardware
● AS-i mounting module with two digital inputs for manual control of the compact starter (article number: 3RA6970-3F). For additional information on connecting the AS-i mounting module, please refer to "Connecting the AS-i mounting module (Page 221)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 214 Design of the AS-i mounting module with up to 2 digital inputs and/or outputs (3RA6970-3C, -3D, -3E) View Function Connection of 24 V DC (PELV power supply unit) AS-i cable connection AS-i/Fault LED AUX Power LED Addressing socket Terminal block for connecting floating switches or resistive loads SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 215 Green: Ready/communication OK. • Red: Communication error • AUX Power LED Off: No AUX Power. • Green: AUX Power present. • You can find more information on the LED statuses in "Diagnostics (Page 237)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 216: Communication Via As-Interface
Up to 62 nodes (e.g. compact starters) can be connected to the AS-Interface line. This is possible thanks to the use of A/B technology, whereby the maximum 31 addresses are split into two completely separate sub-addresses (e.g. 1A and 1B). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 217 Certification by the AS-International association The AS-i mounting module for compact starter is tested at an accredited test laboratory in accordance with the relevant testing regulations and certified by the AS-International association. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 218: Installing/Removal
● The control circuit terminals must be removed from the compact starter (24 V) (for information on removing the control circuit terminals, please refer to "Installing/removal (Page 150)"). ● The compact starter must be switched off (actuator set to OFF position). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 219 7.12 AS-i mounting module for 3RA61/3RA62 compact starter Procedure Step Instructions Image Insert the AS-i mounting module into the mechanically coded guiderail on the device from the bottom and then push it back until you hear it engage. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 220: Removing The As-I Mounting Module
Take hold of the recessed grip on the lower side of the AS-i mounting module and pull the AS-i mounting module forwards. Move the AS-i mounting module down and out through the mechanically coded guiderail on the device. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 221: Connection
• Always place electrostatic sensitive devices on conductive bases. • Always store and transport electronic modules or components in ESD-safe conductive packaging, e.g. metallized plastic or metal containers. Leave the component in its packaging until installation. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 222 This will damage the AS-i mounting module if it is electrostatically charged. Please observe the ESD regulations when working with the AS-i mounting module. Step Instructions Image Contact the cables by applying the cover of the connector. Please note the connector pin assignment. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 223 Accessories 7.12 AS-i mounting module for 3RA61/3RA62 compact starter Insert the connector from below into the AS-i mounting module. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 224: Connecting Terminals
"direction of rotation 2" (only if mounting a reversing starter) Note If the terminals Y1-Y2 and/or Y3-Y4 are not used these must be bridged irrespective of the compact starter (direct starter or reversing starter). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 225 Table 7- 17 Terminals for an additional digital input and a digital output (3RA6970-3D) Terminals Meaning Image IN 4 Connection terminals for a digital input OUT 3 Connection terminals for a digital output SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 226 Connecting terminals for switching between automatic and manual mode for manual control of direction of rotation 1 Y3, Y4 Connecting terminals for switching between automatic and manual mode for manual control of direction of rotation 2 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 227 Table 7- 20 Conductor cross-sections of terminals Terminals 0.5 ... 0.6 Nm (4.5 to 5.3 lb·in) (0.5 x 3.0) mm DIN ISO 2380-A 0.5 ... 2.5 mm 0.5 ... 2.5 mm 20 to 12 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 228: Commissioning
To carry out the AS-i mounting module addressing, you will need the following (example): ● An AS-Interface addressing unit (3RK1904-2AB02) ● A connecting cable for connecting the AS-Interface addressing unit to the AS-i mounting module. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 229 For more detailed information on the AS-Interface and on addressing of AS-i slaves, please refer to the operating instructions "AS-Interface addressing unit V3.0" (3ZX1012-0RK10- 4BA1). Note The module address can be changed as often as required. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 230: Process Data And Process Images
- the AS-i mounting module is snapped onto a functionally ready compact starter and - AS-i communication and AUX PWR are available. The bit is only set if the output was already set before the undervoltage or overvoltage was detected. X: Bit set SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 231 - the AS-i mounting module is snapped onto a functionally ready compact starter and - AS-i communication and AUX PWR are available. The bit is only set if the output was already set before the undervoltage or overvoltage was detected. X: Bit set SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 232 - the AS-i mounting module is snapped onto a functionally ready compact starter and - AS-i communication and AUX PWR are available. The bit is only set if the output was already set before the undervoltage or overvoltage was detected. X: Bit set SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 233 - the AS-i mounting module is snapped onto a functionally ready compact starter and - AS-i communication and AUX PWR are available. The bit is only set if the output was already set before the undervoltage or overvoltage was detected. X: Bit set SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 234 - the AS-i mounting module is snapped onto a functionally ready compact starter and - AS-i communication and AUX PWR are available. The bit is only set if the output was already set before the undervoltage or overvoltage was detected. X: Bit set SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 235 - the AS-i mounting module is snapped onto a functionally ready compact starter and - AS-i communication and AUX PWR are available. The bit is only set if the output was already set before the undervoltage or overvoltage was detected. X: Bit set SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 236 AS-i mounting module from controlled 24 V - 20% approx. 24 V + 20% Compact starter the compact starter. the AS-i mounting module from controlled AS-i mounting module is deactivated. approx. 24 V + 20% SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 237: Diagnostics
- No auxiliary voltage, - Switch on 24 V DC auxiliary voltage, - Auxiliary voltage connected with - Connect properly, incorrect polarity, - Measure auxiliary voltage (approx. 24 V - Auxiliary voltage too low SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 238: Connecting Cable For Io-Link
200 mm for compact starter Connecting cable, 10-core with 14- 3RA6932-0A core connection, 8 mm long for compact starter (pack of 5) Connecting cable 10-core, length 3RA6933-0B 200 mm for compact starter SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 239: Function
7.13.3 Installing/removal Installing connecting cables Up to 4 compact starters with IO-Link are connected to form a group using the connecting cables. For information, please refer to " Installing/removal (Page 129) ". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 240: Operator Panel For 3Ra64/3Ra65 Compact Starter With Io-Link
Enabling block for operator panel 3RA6936-0A Blanking cover for operator panel 3RA6936-0B Connecting cable 10-core, length 3RA6933-0A 2 m for operator panel (connection between operator panel and 3RA6 compact starter with IO-Link) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 241: Installing
The IP54 seal and correct functional capability of the operator panel are not guaranteed if the tightening torque of the supplied screws is too high. Ensure the tightening torque of the supplied screws is not too high. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 242: Operator Control
Inserting or removing the 10-core connecting cable under voltage results in momentary failure of the internal bus connection of the compact starter 3RA64 / 3RA65. Ensure that no auxiliary voltage is applied to the compact starter before inserting or removing the connecting cable. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 243 2 (counter-clockwise). The LED lights up to confirm this. Slot for enabling block Plug the enabling block into the slot to take control priority of the compact starters. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 244 LED (1, 2, 3 or 4) lights up. 2. Check whether a general fault is present: – SF LED red: General fault present. – SF LED off: No general fault SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 245 Jog mode: The compact starter is only activated while you press the button. Activation stops as soon as you release the button. Continuous operation: If you press the button, the compact starter is activated until you press the button again. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 246 IO-Link, the compact starter switches back on immediately and the machine starts up. People may be injured if they stay in the danger area of the machine. Make sure that the danger area of the machine is kept clear of people. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 247: Service
Following a shutdown caused by a malfunction, you will need to replace the compact starter. If the SIRIUS 3RA6 compact starter shuts down following a malfunction (e.g. end of service life), you will need to replace it. In order to achieve a safe system status for the purpose of replacing the compact starter, you can continue operating the compact starter for a short time.
Page 248: Replacing The Compact Starter
Replacing the compact starter When service work becomes necessary or there is a malfunction (e.g. end of service life reached), the SIRIUS 3RA6 compact starter will need to be replaced. The permanent wiring means that the main circuit terminals will be disconnected automatically when the compact starter is removed.
Page 249 ● "Removing the compact starter from a level surface (screw fastening) (Page 70)" ● "Removing the compact starter from an infeed system for 3RA6 (Page 72)" ● "Installing/removal (Page 150)" ● "Disconnecting terminal blocks (Page 83)" SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 250 Service 8.3 Replacing the compact starter SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 251: Technical Data
Technical data in Siemens Industry Online Support Technical data sheet You can also find the technical data of the product at Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/ps/16301/td). 1. Enter the full article number of the desired device in the "Product" field, and confirm with the Enter key.
Page 252: Overview Tables
Technical data 9.2 Overview tables Overview tables Overview tables technical data You will find overview tables with technical data in the "Product information" tab in our online ordering system (https://mall.industry.siemens.com/mall/en/ww/Catalog/Products/10041648?tree=CatalogTre SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 253: Dimension Drawings
Dimension drawings 10.1 CAx data You can find the CAx data in the Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/ps/16301/td). 1. Enter the full article number of the desired device in the "Product" field, and confirm with the Enter key. 2. Click the "CAx data link.
Page 254: 3Ra6 Compact Starter
3RA6 compact starter (screw-type connection technology) Dimensions in mm ① Push-in lug for screw fastening ② Adapter for screw fastening Figure 10-1 Side view of the 3RA6 compact starter (screw-type connection technology) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 255 3RA6 compact starter (spring-loaded connection technology) Dimensions in mm ① Push-in lug for screw fastening ② Adapter for screw fastening Figure 10-2 Side view of the 3RA6 compact starter (spring-loaded connection technology) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 256: Minimum Distances From Neighboring Components (Dimensions In Mm)
Distances from neighboring components (3RA6 compact starter) Note The lateral distances are minimum distances from grounded components. The distances at the top and bottom are required in order to provide an arcing space! SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 257: Operator Panel
Dimension drawings 10.3 Operator panel 10.3 Operator panel Operator panel SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 258: Infeed System For 3Ra6
Dimension drawings 10.4 Infeed system for 3RA6 10.4 Infeed system for 3RA6 10.4.1 Dimensions (in mm) 3RA6813-8AB Figure 10-4 Dimension drawing of screw-type infeed (50/70 mm2) featuring outgoing terminals with screw-type connection technology SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 259 Dimension drawing of screw-type infeed (25/35 mm ) featuring outgoing terminals with screw-type connection technology 3RA6813-8AC Figure 10-6 Dimension drawing of screw-type infeed (50/70 mm ) featuring outgoing terminals with spring-loaded connection technology SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 260 10.4 Infeed system for 3RA6 3RA6812-8AC ① 3RA6 compact starter Figure 10-7 Dimension drawing of screw-type infeed (25/35 mm ) featuring outgoing terminals with spring-loaded connection technology 3RA6830-5AC Figure 10-8 Dimension drawing of spring-loaded infeed SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 261 3RA6823-0AC, 3RA6822-0AC Figure 10-9 Dimension drawing of extension blocks featuring outgoing terminals with spring-loaded connection technology 3RA6823-0AB, 3RA6822-0AB Figure 10-10 Dimension drawing of extension blocks featuring outgoing terminals with screw-type connection technology SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 262: Minimum Distances From Neighboring Components (Dimensions In Mm)
The distances at the top and bottom are required in order to provide an arcing space! The installation guidelines for compact starters, circuit breakers and fuseless load feeders must also be observed along with the associated clearances. SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 263: 8Us Busbar Adapter
Dimension drawings 10.5 8US busbar adapter 10.5 8US busbar adapter 10.5.1 Dimensions (in mm) 8US1211-1NS10 Figure 10-12 Dimension drawing of the 8US busbar adapter SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 264 Dimension drawings 10.5 8US busbar adapter 8US1250-1AA10 Figure 10-13 Dimension drawing of the 8US device holder SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 265: Circuit Diagrams
Circuit diagrams 11.1 CAx data You can find the CAx data in the Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/ps/16301/td). 1. Enter the full article number of the desired device in the "Product" field, and confirm with the Enter key. 2. Click the "CAx data link.
Page 266: 3Ra61/3Ra62 Compact Starter Internal Circuit Diagram
11.2 3RA61/3RA62 compact starter internal circuit diagram 11.2 3RA61/3RA62 compact starter internal circuit diagram 3RA61 compact starter (direct starter) Figure 11-1 Schematic internal circuit diagram for the 3RA61 compact starter (direct starter) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 267 Circuit diagrams 11.2 3RA61/3RA62 compact starter internal circuit diagram 3RA62 compact starter (reversing starter) Figure 11-2 Schematic internal circuit diagram for the 3RA62 compact starter (reversing starter) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 268: Internal Circuit Diagram Of 3Ra64/3Ra65 Compact Starter With Io-Link
3RA64 compact starter with IO-Link (direct starter) ① Connecting cable, 14-core, for compact starter ② IO-Link ③ Control system Figure 11-3 Schematic internal circuit diagram for the 3RA64 compact starter with IO-Link (direct starter) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 269 3RA65 compact starter with IO-Link (reversing starter) ① Connecting cable, 14-core, for compact starter ② IO-Link ③ Control system Figure 11-4 Schematic internal circuit diagram for the 3RA62 compact starter with IO-Link (reversing starter) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 270: Control Circuit Of The 3Ra61/3Ra62 Compact Starter
Control circuit of the 3RA61/3RA62 compact starter 3RA61 compact starter (direct starter) ① Pushbutton switch control ② Maintained-contact operation ③ Overload release, breaker latching mechanism Figure 11-5 Control circuit of the 3RA61 compact starter (direct starter) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 271 11.4 Control circuit of the 3RA61/3RA62 compact starter 3RA62 compact starter (reversing starter) ① Pushbutton switch control ② Maintained-contact operation ③ Overload release, breaker latching mechanism Figure 11-6 Control circuit of the 3RA62 compact starter (reversing starter) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 272: Parallel Switching Of Several 3Ra62 Compact Starters (Reversing Starters)
Parallel switching of several 3RA62 compact starters (reversing starters) ① 3RA62 compact starters (reversing starters) 1 ② 3RA62 compact starters (reversing starters) 2 Figure 11-7 Parallel switching of several 3RA62 compact starters (reversing starters) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 273: Circuit Diagram Of The As-I Mounting Module For Compact Starter
The AS-i 3RA6970-3E mounting module is only mounted on 3RA6120... (24 V). Figure 11-8 Circuit diagram of AS-i mounting module for 3RA6 compact starter (24 V) (3RA6970-3A, -3B, -3C, -3D, -3E, -3F) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 274 Open Open Open Closed Table 11- 2 Settings of the switch S3 (only in the case of the 3RA6250 reversing starter) Switch Counterclockwise rotation Clockwise rotation S3/1 Open Closed S3/2 Closed Open SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 275: Characteristic Curves
3. The instantaneous short-circuit release (electromagnetic) Figure 12-1 Schematic circuit diagram of the time-current characteristic curve for 3RA6 ① Inverse-time delayed overload release (electronic) ② Short-time delayed overcurrent release (electronic) ③ Instantaneous short-circuit release (electromagnetic) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 276 You will find further information on the settings of the compact starter in the following chapters: ● Chapter "Commissioning (Page 85)" for the 3RA61/3RA62 compact starters ● Chapter "Commissioning (Page 140)" for the 3RA64/3RA65 compact starters SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 277 IO-Link. You will find further information on the displays and messages in the following chapters: ● "Diagnostics (Page 87)" for 3RA61/3RA62 compact starters ● "Diagnostics (Page 125)" for 3RA64/3RA65 compact starters SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 278 Characteristic curves Characteristic curve reference Time-current characteristics, let-through current characteristics and I t characteristics can be obtained if required via "Technical Assistance" at the e-mail address: technical-assistance@siemens.com or at Characteristic curve reference (http://www.siemens.com/sirius/technical-assistance). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 279: Data Sets For The 3Ra64/3Ra65 Compact Starter With Io-Link
SIRIUS Compact Starter IO-Link Product ID 3RA64 / 3RA65 Product Text — Serial number — Hardware Revision Firmware Revision Application Specific Name Max. 64 Group diagnostics — Actual configuration — Target configuration — SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 280: Io-Link Communication Parameters
Device ID 1 0x09 0x0A Device ID 2 0x02 0x0B Device ID 3 0x00 0x0C Function ID 1 0x00 0x0D Function ID 2 — 0x00 0x0E Reserved — — 0x0F Reserved — — SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 281: Device-Specific Parameters
Starter version Starter 4 Type of starter 10.0...10.7 Starter version Operator panel 210: Operator panel You can find additional information on the "Type of starter" parameter in ""Type of starter" parameter (Page 114)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 282: Identification Data
Product ID 3RA64/3RA65 — 0x14 Product Text — — 0x15 Serial Number — — 0x16 Hardware Revision — 0x17 Firmware Revision — 0x18 r/rw Application Specific Name Max. 64 Direct Parameter Page SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 283: Group Diagnostics - Data Set (Index) 90
Data set (index) 90 - group diagnostics: Starter group Data set Byte.Bit Designation Index Diagnosis of the starter group 4.0...4.6 Number of starters (compact starters and operator panel) Preset <> actual configuration SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 284 15.6 Switch off - end position left 15.7 Process image error 16.0 Manual operation local 16.1 Manual operation connection aborted 16.2 Contact block cooling time active 16.3 Remaining life time (RLT 0%) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 285 24.6 Switch off - end position left 24.7 Process image error 25.0 Manual operation local 25.1 Manual operation connection aborted 25.2 Contact block cooling time active 25.3 Remaining life time (RLT 0%) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 286 33.6 Switch off - end position left 33.7 Process image error 34.0 Manual operation local 34.1 Manual operation connection aborted 34.2 Contact block cooling time active 34.3 Remaining life time (RLT 0%) SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 287 Data set (index) 90 - operator panel Data set Byte.Bit Designation Index Specific module diagnostics - operator panel 45.0..45.6 Operator panel (item number) 46.1 Operator panel available For additional information, please refer to "Process image (Page 118)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 288: Actual Configuration - Data Set (Index) 105
Fixed value 0x60 11.0 Starter OK 11.1 Starter available 12.0...12.7 Type of starter 13.0...14.7 Starter version (To differentiate between versions in the case of identical article numbers) — 15.0...15.7 Fixed value 0x07 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 289 Fixed value 0x60 32.0 Starter OK 32.1 Starter available 33.0...33.7 Type of starter 34.0...35.7 Starter version (To differentiate between versions in the case of identical article numbers) — 36.0...36.7 Fixed value 0x07 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 290 You can find additional information on the "Starter available" parameter in ""Starter available" parameter (Page 112)". You can find additional information on the "Type of starter" parameter in ""Type of starter" parameter (Page 114)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 291: Target Configuration - Data Set (Index) 130
Byte.Bit Designation Index 0.0...0.7 Fixed value 0x21 1.0...1.7 Fixed value 0x00 2.0...2.7 Fixed value 0x00 3.0...3.7 Fixed value 0x00 Diagnosis of the starter group 4.0...4.6 Fixed value 0x05 8.0...8.7 Fixed value 0x07 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 292 Data set Byte.Bit Designation Index 23.0...23.6 Starter 3 (item number) 24.0...24.7 Fixed value 0x60 25.0 Preset <> Actual configuration 25.1 Starter available 26.0...26.7 Type of starter 27.0...28.7 Starter version 29.0...29.7 Fixed value 0x07 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 293 You can find additional information on the "Starter available" parameter in ""Starter available" parameter (Page 112)". You can find additional information on the "Type of starter" parameter in ""Type of starter" parameter (Page 114)". SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 294 Data sets for the 3RA64/3RA65 compact starter with IO-Link A.7 Target configuration - data set (index) 130 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 295: References
In addition to this manual, please refer to the operating instructions and manuals for any accessories. You can download the relevant documentation from the Internet (http://www.siemens.com/sirius/manuals). Simply enter the order number of the relevant item into the search field. Operating instructions...
Page 296 References B.1 References SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 297: List Of Abbreviations
Width across flats Auxiliary power supply Rated operating current Current setting Rated operating voltage Rated frequency Rated surge voltage Rated insulation voltage Power loss vmax Diameter Acceleration Short-circuit current rating American Wire Gauge SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 298 List of abbreviations C.1 List of abbreviations SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 299: Glossary
The infeed system for 3RA6 enables several compact starters to be fed using a modular infeed system with permanent wiring. Terminals for Type E combination controller The terminals conform to the creepages and clearances stipulated by UL 508 (Type E). SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 300 Glossary SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 301: Index
Limit switch, 227 READY, 55, 120 Terminal for Type E, 206 TRIPPED, 57, 121 Configuration 3-phase busbar, 194 Siemens Industry Online Support, 14 3RA61 compact starter, 46 Approvals, 16 3RA62 compact starter, 49 Article numbers 3RA64 compact starter with IO-Link, 95...
Page 302 3RA64/3RA65 compact starter with IO-Link, 267 EPLAN macros, 13 Isolating features, 16 Features LEDs on the 3RA61 compact starter, 45 3RA61 compact starter, 89 3RA62 compact starter, 48 3RA62 compact starter, 90 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 303 Interruption of the auxiliary voltage, 123 Reset Messages via IO-Link, 123 Auto reset, 122 Operator controls, 58, 122 Manual reset, 122 RESET M/A, 86, 142 Parameter Actual configuration, 288 Safe isolation, 28 Device-specific parameters, 281 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...
Page 304 Infeed system for 3RA6, 187 Technical Assistance, 14 Terminal designation Auxiliary switch block for compact starter, 159 Test reports, 16 Tripping current, 60 UL 508, 39 Use as prescribed, 16 Used symbols, 11 SIRIUS 3RA6 compact starter System Manual, 08/2018, NEB560060102000/RS-AB/007...

This manual is also suitable for:

Sirius 3ra61 Sirius 3ra62 Sirius 3ra64 Sirius 3ra65

Siemens SIRIUS 3RA6 System Manual

1 Introduction

2 Safety Instructions

3 System Description

4 Application Planning

3 RA61/3RA62 Compact Starter

3 RA64/3RA65 Compact Starter with IO-Link

7 Accessories

8 Service

9 Technical Data

10 Dimension Drawings

11 Circuit Diagrams

12 Characteristic Curves

Quick Links

Related Manuals for Siemens SIRIUS 3RA6

Summary of Contents for Siemens SIRIUS 3RA6
