Grizzly H8094 Quick Start Manual

Failure to follow these instructions could
result in serious personal injury or death:
1. DO NOT overload this jack beyond its
rated capacity. Overloading can cause
the jack to collapse and drop the load.
2. ALWAYS support the vehicle with appro-
priately rated support stands before
working under it.
3. DO NOT attempt to move the vehicle
while the jack is in use.
4. Use only on hard level surfaces like
concrete or asphalt. Other surfaces are
potentially unstable.
5. Center the load on the jack to maintain
proper balance and stability.
6. DO NOT use jack if it begins leaking
fluid or if it sinks when placed under
load. These are indications that the jack
needs to be immediately serviced.
Specifications
Maximum Lifting Capacity ................... 5000 Lbs.
Lifting Range .......................................5
Weight ..................................................... 62 Lbs.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
⁄ "–19
1
4
COPYRIGHT © DECEMBER, 2006 BY GRIZZLY INDUSTRIAL, INC.
#TR8825 PRINTED IN CHINA
Model H8094
Garage Jack
Operation
Pump Handle (Figure 1): To raise the jack, rotate
the pump handle clockwise completely, then move
the pump handle up and down. To lower the jack,
slowly rotate the pump handle counterclockwise.
⁄ "
1
2
If you need help with the Model H8094, call our
Technical Support line at: (570) 546-9663.
2 ⁄ Ton
1
2
Pump
Handle
Figure 1. Jack controls.
