3J USB-W1D User Manual

Wireless skype phone
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
1 Instruction
1.1 Summary
The 3J-W1D is a wireless Skype phone which is composed of
one base and one handset. The base is a high quality speaker
phone, ideal for conference calls. The handset has blue back-
lighted graphic LCD. Both base and handset ring for incoming
calls. You can make/receive a call via the handset without the
limitation of USB cable, just like using a mobile phone.
1.2 Features
1. USB Wireless Phone for Skype
2. 2.4GHz ISM Band, suit for Europe, USA, Japan etc
3. Handfree with digital echo cancellation
4. Large graphic LCD with blue backlight
5. Review Skype contacts and call list on handset LCD
6. Both base and handset ring for all incoming calls
7. Multi-language caller ID display feature
8. Auto-select RF channel to improve the quality of voice
1.3 Technical Data
Standby time: More than 100 hours
Talk time: More than 10 hours
Radio range: 10 meters (32 ft)
Battery: 250mAh (Li-battery)
1

Advertisement

Table of Contents
loading

Related Manuals for 3J USB-W1D

Summary of Contents for 3J USB-W1D

  • Page 1 1 Instruction 1.1 Summary The 3J-W1D is a wireless Skype phone which is composed of one base and one handset. The base is a high quality speaker phone, ideal for conference calls. The handset has blue back- lighted graphic LCD. Both base and handset ring for incoming calls.

  • Page 2: System Requirements

    1.4 System Requirements 1. Windows 2000 or XP 2. 400MHz processor and free USB1.1 or USB2.0 port 3. 128MB RAM and 15MB free disk space 4. Any broadband connection or minimum 33.6 Kbps dialup 1.5 Package Contents 1. One handset 2.

  • Page 3: Install Battery

    : Dial/Answer (1) Call out or answer a call. (2) Press to put a call on hold, release the call by pressing again. : Hang up (1) End a call or refuse an incoming call. (2) Press the key to go back to the previous menu. : Press to input “+”...

  • Page 4: Run Skypemate

    2.3.3 Register Handset to the base If the LCD shows： , that indicates the handset has not registered to the base .Please do the following steps: (1) Press and hold the “C” key on the handset (approx.3 secs.) until three beelines is displayed on the LCD. (2) Press and hold the Handfree key (approx.3 secs) until the LCD shows .

  • Page 5: Make A Call

    2.5.2 Run SkypeMate Double-click the icon on the desktop, the Skype program will pop up the window as shown below: Select the first option “Allow this program to use Skype”, click “OK” button. Note: If you selecte the wrong option, you can make another selection.

  • Page 6: Answer A Call

    (3) Input number and call out: Press digital "11" on the handset’s keypad, then press call out. 2.6.5 Call to regular phone Press "00" + "country number" + "phone number", then press Example: call someone in Beijing, China, please press 00861012345678, and then press 0086 ----------------...
  • Page 7 2.8 State Instruction (1) Ready state a. Skype online b. Skype offline (2) The icons displayed in call list a. Incoming call b. Outgoing call (3) Battery condition (4) The icons displayed in contacts a. Online b. Offline c. SkypeOut 2.9 Advanced (1) Right click the icon c.
  • Page 8 2.10 Auto-select RF channel This function is effective to improve the quality of handset’s voice. The handset will change the RF channel automatically when the voice is not so good. (1) Right click the icon on the taskbar and select Advance (2) The window is shown as below: Select Auto selection RF Channe to enable this function.
  • Page 9 3 FAQ Problem 1 There is no ring can be heard or the ring tone is too low. Solution (1) Go to Skype, run “Tools-> Options->Sounds”, select “Play sound”. Shown as below: (2) Click “Import Sounds”. Go to the Skypemate folder, for example: C:\\program\skypemate.
  • Page 10 Problem 4 The voice is played from the PC’s sound card instead of the USB Wireless Phone when I make/answer a call? Solution Execute “Tools->Options->Sound Devices” to open the window as below: Set “Audio In” and “Audio Out” to “USB Audio Device”. Problem 5 Skype is running, but the icon of SkypeMate still show as (the phone is green and the outside is grey)?

  • Page 11: Ce Mark Warning

    CE Mark Warning: This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. FCC Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including...
  • Page 12 All batteries should be fully discharged before they are returned for disposal. 3J Communications, Inc. 1387 E Canyon Creek Dr Gilbert, AZ 85296 URL: http://www.3j-communications.com...
