- Page 1 CabLite ECO Installation Manual REV : 4.1 DATE: 1/17/2018 MANUAL NUMBER : 32 ELECTRONIC CONTROLS, INC. | 7073 NORTH ATLANTIC AVE CAPE CANAVERAL, FL 32920 WWW.ECIAMERICA.COM 800-633-9788...
- Page 2 Cablite ECO Installation Manual Rev 4.0 DATE DESCRIPTION 10/28/2013 Initial release 3/7/2014 Updated the manual 7/8/20014 Added Dimming/Emergency board wiring 3/8/2017 New Manual format re-write 1/17/2018 Added new logo and drawings with 10k pot and service loops Electronic Controls, Inc. 7073 North Atlantic Ave.
-
Page 3: Table Of Contents
Cablite ECO Installation Manual Rev 4.0 Table of Contents Introduction ............................4 Warning and Disclaimer ........................4 Trademarks ............................4 Conventions Used ..........................4 Safety Information ..........................5 System Overview ..........................6 Downlights ............................ 6 6.1.1 ECO Downlight Specifications ..................... 6 CabLite ECO .......................... -
Page 4: Introduction
2 Warning and Disclaimer Thank you for purchasing equipment from ECI America, INC. We want your new equipment to operate safely. Anyone who installs or uses this equipment should read this publication (and any other relevant publications) before installing or operating the equipment. -
Page 5: Safety Information
Cablite ECO Installation Manual Rev 4.0 When you see the “notepad” icon in the left-hand margin, the paragraph to its immediate right will be a special note. Notes represent information that may make your work quicker and more efficient. The word NOTE: in boldface will mark the beginning of the text. -
Page 6: System Overview
Cablite ECO Installation Manual Rev 4.0 6 System Overview CabLite® ECO is a general downlighting system for use in passenger, residential and freight elevator cabs operating from one to twelve downlight. CabLite® ECO high output, long life low voltage LED downlights provide general interior lighting that meets or exceeds ASME A17.1, local, state and federal codes. -
Page 7: Cablite Eco With Dimming Option
Cablite ECO Installation Manual Rev 4.0 • Installation Manual 6.3 CabLite ECO with Dimming Option • 1 to 12 downlights • Dimmer board (factory wired and mounted in gang box) • 24VDC power supply (factory wired and mounted in gang box) •... -
Page 8: Cablite Eco With Dimming And Emergency Lighting Option
Cablite ECO Installation Manual Rev 4.0 Figure 2 - Dimmer Board 6.4 CabLite ECO with Dimming and Emergency Lighting Option This option allows for brightness control and emergency lighting. Included with this option: • 1 to 12 downlights • Emergency Light board (factory wired and mounted in gang box) •... -
Page 9: Cablite Emergency Board Leds
Cablite ECO Installation Manual Rev 4.0 Figure 3 - CabLite ECO Emergency Board 6.4.2 CabLite Emergency Board LEDs • CHARGE – the charge LED blinks when the battery is charging and remains solid when battery is fully charged. • FAULT – The fault LED lights when there is a problem with the battery. Wrong voltage or not charging. -
Page 10: Flat Bezel Downlight Dimensions
Cablite ECO Installation Manual Rev 4.0 7.1 Flat Bezel Downlight Dimensions Figure 4 - Flat Bezel Downlight Dimensions 7.2 Raised Bezel Downlight Dimensions Figure 5 - Raised Bezel Downlight Dimensions Figure 6 - Installation example Electronic Controls, Inc. 7073 North Atlantic Ave. Cape Canaveral, FL 32920 800-633-9788 www.eciamerica.com P a g e... -
Page 11: Cablite Eco Wiring Diagram
Cablite ECO Installation Manual Rev 4.0 7.3 CabLite ECO Wiring Diagram Figure 7 - CabLite ECO Wiring Diagram Wire power supply as shown in Figure 7 - CabLite ECO Wiring Diagram. • AC IN line – Brown wire on power supply •... -
Page 12: Cablite Eco W/ Dimming & Emergency Wiring
Cablite ECO Installation Manual Rev 4.0 As previously mentioned the CabLite system power supply and dimming board are pre-wired from the factory. Route AC power through one of the punch outs of the gang box and secure cable to box with appropriate hardware. - Page 13 Cablite ECO Installation Manual Rev 4.0 The EMERGENCY lights are connected through a second 8’ cable as shown in Figure 9. There should be two and only two downlights connected for emergency. Connecting more than two will shorten the emergency lighting time. With all downlights connected, remove the plastic cover from the POS terminal of the battery and connect RED wire from control board to battery POS terminal.
-
Page 14: Trouble Shooting
Cablite ECO Installation Manual Rev 4.0 8 Trouble Shooting 8.1 One Light Does Not Turn On 1) Swap downlight with another light in string. a) If light still does not operate replace downlight. b) If downlight lights, then check original connection to downlight. i) Replaced cable if necessary 8.2 Lights Do Not turn On (CabLite ECO) 1) Check connection between power supply and first downlight.
