Tripp Lite T100-001 Quick Start Manual

RJ11/RJ12/RJ45 Crimping Tool with Cable Stripper
Package Includes
• T100-001
Optional Accessories
• N020-Series Cat5e Stranded Conductor Bulk
Cable – 1,000 ft.
• N022-01K-GY Cat5e Solid Conductor Bulk
Cable, Gray – 1,000 ft.
• N024-01K Cat5e Solid Conductor
Plenum-Rated Bulk Cable, Gray – 1,000 ft.
• N028-01K-GY Cat5e Solid Conductor
Outdoor-Rated Bulk Cable, Gray – 1,000 ft.
• N030-010 Cat5e RJ45 Plugs for Solid /
Stranded Conductor Cable – 10 Pack
• N030-100 Cat5e RJ45 Plugs for Solid /
Stranded Conductor Cable – 100 Pack
Opening / Closing the Tool
To open the tool handles, simply squeeze them
together and release. To lock the handles in
place, squeeze them together slightly (one or two
clicks only) and release. You can also release
the handles by turning the knob in-between the
handles counterclockwise.
15-09-328-9334FE.indd 1
Quick Start Guide
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2015 Tripp Lite. All rights reserved.
Model: T100-001
• Quick Start Guide
• N030-100-FL Cat5e RJ45 Plugs for Solid /
Stranded Conductor Flat Cable – 100 Pack
• N031-050 Cat5e RJ45 Plugs for Stranded
Conductor Cable – 100 Pack
• N222-Series Cat6 Solid Conductor
Bulk Cable – 1,000 ft.
• N224-01K-GY Cat6 Solid Conductor
Plenum-Rated Bulk Cable, Gray – 1,000 ft.
• N230-100 Cat6 RJ45 Plugs for Solid /
Stranded Conductor Cable – 100 Pack
Cutting Cable
On one side of the tool is a single blade for cutting
cable. Insert the cable to the desired length into
the slot underneath the blade. Then cut the cable
by squeezing the handles together until the cable
cleanly separates.
