E. Monitoring wireless HART network join status:
1. From the main DD screen, select Service Tools... (In Simatic PDM, select Service Tools...
from the Device menu at the top of the screen).
2. Select Communications... Wireless Status...
3. Monitor the progress of the wireless HART join. If Join Failed under Join Status becomes
set, check the Network ID and Join Key that were used to see that they are correct.
At this point, the VECTOR V1100 is ready to be installed and commissioned in the field. For
installation information and wiring drawings proceed to "Installation" on page 39.
