- Page 1 ZyXEL NWD-490 802.11 b/g Wireless SDIO Adapter User’s Manual Version 1.0 January 2007...
-
Page 2: Important Note
ZyXEL NWD-490 User Manual Important Note Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 3: Software Installation
ZyXEL NWD-490 User Manual 1. Introduction Take advantage of the Wi-Fi connection when you on the go. The NWD-490 SDIO 802.11g wireless client adapter provides high-speed wireless connection to your PDA or Smart phone. If your pocket PC does not have the built-in Wi-Fi function, or the built-in 802.11b wireless module keeps you waiting when you need to get e-mail... -
Page 4: Getting Started
3. Getting Started The installation screen shots are based on Mobile 5.0 unless otherwise specified. To ensure ZyXEL NWD-490 works well in your PDA or Smart phone, we recommend you process the following steps for setting. Insert the ZyXEL SDIO Card into the SD slot of your PDA. - Page 5 ZyXEL NWD-490 User Manual Tab on Start menu -> Settings. Tap on the Connections tab.
- Page 6 ZyXEL NWD-490 User Manual Tap on Set up my proxy server on the Connection page. On the Proxy Settings page, make sure the checkbox of This network connects to the Internet is checked, the checkbox of This network uses a proxy server to connect to the Internet should not be checked and the Proxy server box should remain blank.
- Page 7 ZyXEL NWD-490 User Manual If your device has built-in 802.11b wireless, in order to improve wireless performance, you may disable the existing IEEE 802.11b signal. Return to Settings page -> Connections tab -> tap on the built-in wireless connection (In this case, it is iPAQ Wireless).
- Page 8 ZyXEL NWD-490 User Manual On Settings page -> Connections tab -> tap on the Network Cards icon. Tab on Network Adapters tab, and select the ZyXEL SDIO Wireless Adapter.
- Page 9 Access Point (AP) or Router you want to connect to. You also need to configure the security settings if the AP or Router already has one. The NWD-490 supports WEP, WPA-PSK and WPA2-PSK for wireless network security. Tap on Start -> Settings page -> Connections tab -> Network Cards icon.
- Page 10 ZyXEL NWD-490 User Manual Select the SSID you want to connect to from the list of wireless networks found. If wireless security was enabled in the network you selected, enter the appropriate Network key (case-sensitive) to match the AP or Router.
-
Page 11: Troubleshooting
ZyXEL NWD-490 User Manual 5. Troubleshooting The driver was not installed, or installed incorrectly. Make sure your PDA or Smart phone’s operating system is either PC 2003 or Mobile 4.2/5.0. If you found a previous installed drive exists, create an active connection and uninstall the existing driver in ActiveSync then re-run the software installation. -
Page 12: Customer Support
ZyXEL NWD-490 User Manual 6. Customer Support Please have the following information ready when you contact customer support. • Product model and Serial number • Warranty Information • Date that you received or purchased your device • Brief description of the problem including any steps that you have...
