Summary of Contents for Husqvarna 587932801
- Page 1 Operator′s manual Weed Brush Please read the operator’s manual carefully and make sure you E E E E n n n n g g g g l l l l i i i i s s s s h h h h understand the instructions before using the machine.
-
Page 2: Table Of Contents
ENGLISH Contents Safety instructions ..........................7 General ............................7 Proper use ............................ 7 General safety and accident prevention regulations ..............7 Pictograms used ........................10 Description ............................11 General description of weed brush .................... 11 Mounting on carrier vehicle ......................11 Installation............................ - Page 3 ENGLISH...
- Page 4 ENGLISH...
- Page 5 ENGLISH...
- Page 6 ENGLISH...
-
Page 7: Safety Instructions
1.2 Proper use • The weed brush is intended for use with a Husqvarna P 520D or P 525D. • The machine is designed for clearing weeds in standard applications and work in agriculture and forestry, e.g. - Page 8 ENGLISH • Exercise caution around rotating and oscillating tools - maintain a safe distance. • Exercise caution with trailing machine parts. Before working on these, wait until they have completely stopped. • There are crushing and shearing points on driven parts. •...
- Page 9 ENGLISH 1.3.4 During operation • If any persons or vehicles approach the danger area (10 m radius), stop the attachment immediately. • Never leave the operator console while moving. • Only leave the operator console when the tools on the attachment have come to a standstill. •...
-
Page 10: Pictograms Used
ENGLISH 1.4 Pictograms used The following pictograms are located on the unit to inform the operator that care and attention is required when using and maintaining the unit. Explanation of pictograms used: Read and observe the operating manual and the safety instructions before starting up. -
Page 11: Description
ENGLISH Description 2.1 General description of weed brush The weed brush consists of a steel construction with an angular gear, on which the tool holder - also known as the brush plate (1:B) - is mounted. The brush plate can be fitted with a tufted brush edging (1:C) or with braided wire rope. -
Page 12: Connecting Hydraulic Hoses
ENGLISH 3.3 Connecting hydraulic hoses • Before connecting the hydraulic hoses, make sure that the carrier vehicle hydraulic system is not pressurized. • Before connecting, make sure all connections are clean. Impurities in the hydraulic fluid can cause severe damage to the hydraulic system. •... -
Page 13: Adjusting The Splash Guard
ENGLISH 5.2.2 Adjusting the brush plate inclination • The brush plate inclination angle is adjusted using the hydraulic cylinders (1:I and 1:H). The cylinder (1:I) pivots the brush plate laterally to the direction of travel. The cylinder (1:H) pivots the brush plate forwards and backwards relative to the direction of travel. •... -
Page 14: Maintenance After 50 Operating Hours Or Long Stoppages
ENGLISH 6.3 Maintenance after 50 operating hours or long stoppages • The moving parts must be greased or oiled at regular intervals, and at the beginning and end of every season. • Check hydraulic fittings and hoses for leaks and damage, and replace if necessary. Refer to the legal requirements for the maximum usage period. -
Page 15: Technical Data
ENGLISH Technical data Technical data Drive Mechanical 81.5 dB(A) at operator ear Sound level L pA,eq Measurement based on DIN EN 12733:2009 Max. power take-off speed 1,600 rpm Max. brush plate speed 300 rpm Brush plate Ø 50 cm Tufted brush edging 20 units Weight 195 kg... -
Page 16: Eg - Konformitätserklärung
EG - Konformitätserklärung CE Déclaration de conformité EC Declaration of Conformity EG conformiteitsverklaring Nous Kersten Arealmaschinen GmbH Empeler Straße 95 D- 46459 Rees erklären, dass das déclarons que le produit herewith declare that verklaren dat het produkt Produkt the product Wildkrautbürste Brosse déherbante Weed brush... - Page 17 Original instructions Order number: B00062 From machine no.: 55010 Revision: R00 As of: 01.01.2015 2015-02-19...
