FINAL FURLONG 2
CONVERSION INSTRUCTIONS

Advertisement

loading

Related Manuals for NAMCO Final Furlong 2

Summary of Contents for NAMCO Final Furlong 2

  • Page 1 FINAL FURLONG 2 CONVERSION INSTRUCTIONS...
  • Page 2 It is most important that the game is tested and any problems rectified before any conversion work is started. Please make a note of all setting values so that the new Game PCB can be set accordingly. Warning: Ensure that the game is switched off and disconnected from the mains supply before any conversion work is started.
  • Page 3 PRELIMINARY Removing the Ride Assembly 1. Raise the twelve adjustable feet, (4 on the monitor cabinet and 4 on each ride base assy), (Slacken the lock nuts with a spanner first.) 2. Remove 8off security screws (M5x12) and remove both Base Front Cover Plates. 3.
  • Page 4 4. Pull the ride assembly away from the monitor cabinet only sufficient to reach the connectors. ( Take care not to stretch the wiring harness.) 5. Disconnect the connectors and move the ride assembly completely away from the monitor cabinet. Removing the Header Assembly The header assembly is high and has a forward centre of gravity, so it is important that at least two people are used to remove or fit the Header Assembly.
  • Page 5 3. Remove 2off pozi head screws (M5x16), with flat and spring washers. 4. Slide the header assembly forward so that it disengages with the retaining bracket. 5. Remove the Header Assembly...
  • Page 6 RIDE ASSEMBLY DECALS 1. Remove the Horse Rear Decals (both sides of the horse). 2. Fit the new Horse Rear Decals (both sides of the horse). 3. Fit the new decals to the rear of the Ride Base. Replace (Both sides) New Decals...

  • Page 7: Header Assembly

    HEADER ASSEMBLY 1. Remove the ten security screws (M5x16) and remove the header acrylic. (This part is no longer required). 2. Remove 2off pozi head screw (M4x12) and remove the Top Bracket. (This part is no longer required). Pozihead screw (M4x12)
  • Page 8 3. Fit the new top brackets with 4off torx security screws (M5x12 black), supplied. Torx security screw (M5x12 black) 4. Fit the new Header Acrylic with 10off torx security screw (M5x16 chrome), supplied. Torx security screw (M5x16 chrome) Torx security screw (M5x16 chrome) Torx security screw (M5x16 chrome)
  • Page 9 MONITOR CABINET Replacing the Decals 1. Remove all the old decals, except the Monitor Middle Lower Decal. DO NOT REMOVE Remove Remove (both sides) Remove Remove 2. Fit the new decals as shown below. (both sides)
  • Page 10 Fitting the New Front Vac-Form 1. Fit the new Vac-Form Bracket with 2off torx security screw (M5x16 black), supplied. Torx security screw (M5x16 black) 2. Fit the new Vac-Form with 4off Torx security screw (M5x16 black), supplied. Torx security screw (M5x16 black)
  • Page 11 Replacing the Game PCB 1. Disconnect all the connectors on the Game PCB including the fan connectors. Note: Some of the cables will be replaced with new cables (see illustration below) These cables will not be used on the new game PCB 2.
  • Page 12 3. Place the old and new game PCBs next to each other. 4. Remove 8off pozi head screws (M4x50) and remove the fans from the old Game PCB. (4 screws on each fan). Pozi head screw (M6x25) 5. Fit the fans to the new Game PCB in exactly the same way up using 4off pozi head screws (M4x50).
  • Page 13 6. Refit the new Game PCB and fully tighten the 4off pozi head screws (Mx25). 7. Connect the new cables linking the I/O boards to the Front Cover Boards, and the new HSB cable linking the two front cover boards. 8.
  • Page 14 Refit the existing connectors to the I/O Boards and Front Cover Boards. D Sub #1 D Sub #2 Note: When refitting the D Sub connectors to the Front Boards ensure that connector 2 is fitted to the board nearest the rear of the cabinet, and the connector retaining screws are fully tightened.
  • Page 15 Replacing the Repeater (Link) PCB 1. Remove 1off pozi head screw (M5x12) and remove the Link Cover Bracket. Link cover Pozi head screw (M5x12 2. Remove 2off Pozi head screws (M4x12) and remove the Link PCB complete with mounting bracket. 3.
  • Page 16 4. Refit the new Link PCB complete with mounting bracket using the 2off pozi head screws (M4x12). Pozi head screw (M4x12) 5. Fit the new Communication cable.
  • Page 17 RE-ASSEMBLY AND TEST 1. Reasemble the Ride Assemblies to the Monitor Cabinet, taking care not to trap any wires. 2. Reconnect the Mains-In and switch ON. 3. Reinitialize both players. (see section 6-8 page 58 of the Operators Manual). 4. Reset all game settings to the required levels. (see section 6-7 ‘Test Mode’ page 47 of the Operators Manual).
  • Page 18 NEW PART NUMBERS t i n t i n...
  • Page 19 (Opposite side 2)
