Summary of Contents for A.caminetti Crystal 3D 50/60
- Page 1 Manual of use installation & operation www.acaminetti-factory.com...
- Page 2 A.caminetti – People‘s Fireplace The passion and love for the wood fire inspired us to create the unique fireplaces A.caminetti. A modern fireplace with a magnificent and cozy fire that will fill your spirit with inspiration and will relax your mind.Our philosophy is different and our vision is positive.Starting from Gladys Taber quote,a house with no fireplace...
-
Page 3: Table Of Contents
CONTENTS 1.SAFETY 1.1 Risk of burning..............Safe distance................Putting into operation............Open operation................. 1.5 Fire in the chimney..............1.6 Supply of combustion air............. 1.7 Unauthorized technical modifications........2. FUEL 2.1 Forbidden fuel................2.2 Permitted fuel ................2.3 Types of wood................ 2.4 Storage of wood fuel.............. - Page 4 7. GENERAL WARRANTY TERMS 7.1 Important information............7.2 Warranty conditions..............7.3 Warranty period............... 7.4 Common wearing..............7.5 Repair and maintenance............7.6 Making a claim................INTRODUCTION..............PRODUCTS ..................15 CHECKING THE PRODUCT ............16 CORRECT POSITIONING OF THE FIREPLACE......TRANSPORT .................17 POSITIONING THE FIREPLACE INSERT ........18 REMOVING THE TRANSPORT SECURING .......19...
-
Page 5: Safety
Carefully read these instructions for using the fireplace insert and keep the manual in a safe place. A.caminetti fireplace inserts are certifed according to European standard EN 13229 and carry the CE indication. When assembling the fireplace insert, you must comply with local regulations and instructions applicable to national and European standards. -
Page 6: Putting Into Operation
The paint is soft during burning so do not touch it. 1.5. OPEN OPERATION A.caminetti freplace inserts are not designed to be operated with an open door. The f i replace must always be closed with the exception of adding fuel so as to prevent burning wood falling out and combustion gases leaking into the room. -
Page 7: Supply Of Combustion Air
2.2. PERMITTED FUEL It is only permitted to burn only wood in natural condition with the humidity 18 % in A.caminetti fireplace inserts. 2.3. TYPES OF WOOD The volume of energy contained in one kilogram of wood is approximately the same for all types of wood. -
Page 8: Storage Of Wood Fuel
2.4. STORAGE OF WOOD FUEL it is recommended to store wood for ideally 2 to 3 years in well ventilated and dry area. optimally, wood is recommended to be stored to the southern part of the house on a grid to provide a fow of air and good ventilation of wood. we recommend to cover the top of the wood to protect against rain (fig. -
Page 9: Description Of Control Elements
4 . ceramic glass 3.2. OPTIONS FOR CLOSING THE DOOR A.caminetti f i replace inserts enable two methods of closing the door: 1 – automatic closing of the door 2 – manual closing of the door T he door is set in production for manual closing –... -
Page 10: Operation Of Freplace Inserts
4. OPERATION OF FIREPLACE INSERTS 4.1. COMMISSIONING, BURNING PHASE AND REGULATION OF AIR SUPPLY First check that there is no large quantity of ash in the burning chamber. This would cause hot particles to fall from the fireplace insert into the room when adding wood. Set the handle for regulation of the air supply for burning to the maximum This ensure a sufficient supply of air for ignition. -
Page 11: Operation In The Transient Period
If you do not want to add more fuel and the dose has burnt out, set the regulation of air to the left to the minimum (Fig. 9). This will prevent burning air getting into the chamber and will prolong the heat phase. The coal will remain hot in the chamber longer and the heat will not escape through the chimney. -
Page 12: Cleaning And Maintenance
5.1. ClEaNiNG ThE GlaSS The door of the A.caminetti fireplace insert is produced from high-quality ceramic glass and is fitted with a self-cleaning ceramic glass system. Air supplied into the combustion chamber “rinses” the glass from the inside. Correct regulation of air and by burning dry wood will result in clear glass that won’t need to be cleaned very often. -
Page 13: Regular Specialist Maintenance
5. 3 . rEGular SPECialiST MaiNTENaNCE Once a year, before starting the heating season, the fireplace insert should be inspected by an expert - fireplace technician. This maintenance should include: checking and cleaning of the burning chamber for hot-air fireplace insert: and burnt passages - checking the regulation and air supply system checking the sealing parts and mechanism for opening... -
Page 14: General Warranty Terms
7. GENERAL WARRANTY TERMS 7.1. iMPOrTaNT iNFOrMaTiON A.caminetti products are produced from high-quality materials with a long service life. The whole manufacturing process is the subject of regular inspection to prevent any defects. The installation of this product requires professional knowledge and, therefore, must only be done by qualifed companies aware of the valid legal provisions. -
Page 15: Repair And Maintenance
Wearing of surface treatment: colour change of the varnish surfaces due to thermal stressing or overheating. Wearing of sealing: decreasing the tightness due to the affection of heat, mechanical wearing and hardening of sealing. Wearing of glass: dirtying by soot or remainders of burn materials, colour or other changes by the affection of heat. -
Page 16: Products
PRODUCTS MODEL POWER OUTPUT DOSE OF CO LOAD OF WOOD EFFICIENCY (KW) (KG) CRYSTAL 3D 50/60 14 KW 0.041% 2-3 kg/h CRYSTAL 3D 50 14 KW 0.041% 2-3 kg/h CRYSTAL 3D 15 KW 0.032% 3-4 kg/h CRYSTAL 3D MAX 17 KW 0.031%... -
Page 17: Checking The Product
9. CHECKING THE PRODUCT. Immediately after receipt of the consignment, check: - that there is no visible damage that all movable parts and mechanisms are functional that the consignment is fully complete and contains: - Installation and User Manual - Warranty Certificate IMMEDIATELY NOTIFY YOUR SUPPLIER OF ANY POTENTIAL DEFECTS AND DISCREPANCIES. -
Page 18: Transport
11. TRANSPORT Handling the fireplace insert is made easier by using the transport handles which can be inserted into the on the body of the fireplace insert (Fig. 1). Before transporting, make sure that both the ejection mechanism of the doors (applicable to fireplace inserts with liftdoors) and linning of the fireplace are secured. -
Page 19: Positioning The Fireplace Insert
12 . P OSITIONING THE FIREPLACE INSERT - The fireplace insert must be positioned on a base with the respective load-bearing capacity. - The fireplace insert must be positioned on the foundation plate, not on an unstable or movable surface. The distance of the fireplace insert from the floor can be regulated by turning the legs . -
Page 20: Removing The Transport Securing
13. REMOVING THE TRANSPORT SECURINGS After positioning the fireplace insert, remove the transport securings that prevent damage to the lift-down door mechanism. After removing of the securings, check the movement of the door. If there are any defects, inform your supplier and stop the installation work. -
Page 21: Gas Outlet Variants
14. GAS OUTLET VARIANTS Extracting smoke from the fireplace depends on how the fireplace insert is combined with an -accumulating flue system. We supply the following versions: V ersion with rear smoke extraction recommended for connection to the accumulating flue system or for direct connection to the chimney. -
Page 22: Connection To The Chimney
15 . CONNECTION TO THE CHIMNEY Before connecting the freplace insert to the chimney, check the size and condition of the chimney (according to the dIn 18160 directives and standards). The correct operation of the chimney according to dIn En 13384 must be signed by legal authority. When making the chimney calculations, you must include the parameters of the freplace insert. -
Page 23: Condraweight Placement
In the moment that you have take out the cover part in the front side of the fireplace which is marked the logo ( A.caminetti) , FIG 3,chapter 13, in the same time you have to take out the condraweight covering which are galvanised metal.Raise up the coverings and pull them out. -
Page 24: Deflector
FLAT LIFTDOOR MODELS CORNE R LIFTDOOR MODELS CRYSTAL MODELS NOTE: THE DOOR OPENING IS THE SAME FOR ALL CRYSTAL MODELS. -
Page 25: Installing The Fireplace Insert
18. I nstAllInG tHe fIRePlACe InseRt - When assembling the consumer appliance, follow all local regulations and regulations related to national and European standards. - during the construction, pay special attention to regulations concerning fire safety, options for using materials and the size of the ventilation grids. - The construction must enable access for cleaning the consumer appliance, chimney flue and chimney. - Page 26 Wall 14. Protective floor made from fireproof Insulation layer (chimney flue) material Connection / chimney flue 15. Insulation layer (sides) Insulation layer (rear wall) 16. surroundings (of the room) Convection area 17. radiation area Grid for the inflow of convection air 18.
- Page 27 Insulating layers (protection of standard walls) - The forewall (22) and the wall of the building (20) must be protected by an insulating layer (4, 16) with a minimum thickness of 9 cm. - The surrounding (11) does not need to be protected by the insulating layer if the construction is protected so that the surface of the surroundings heats to a maximum of 85°C.
- Page 28 - In the forward direction, it depends on the height of the bottom of the combustion chamber from the floor, it is necessary to add to this height 20 cm; the minimum value is 30 cm. Radiation area of the fireplace insert - From the hole into the fireplace (forward, upward, downward and on the sides) a gap of at least 80 cm must be kept between the construction parts and the flammable material or a the flammable parts and the furniture.
-
Page 29: Permitted Insulating Materials
Each material in our fireplaces are strictly choosen,we are proud for our partners,Partner companies: Senotherm / Schock metall / Schott ROBAX / Culimeta / Skamol Culimeta is global leading industry supplier in the field of gaskets for fireplaces, as well as door and window seals for industrial-, stove- and heating boiler constructions. - Page 30 A.caminetti factory National road km2 Korce-Erseke, KORCE,ALBANIA . A.caminettti GmbH AM Industriegleis 6a,Ergolding / Germany. info@acaminetti-factory .com www.acaminetti-factor y.com...
