- Page 1 Vigor2620PVn series Router Quick Start Guide Version: 1.0 Firmware Version: V3.8.9_RC5 (For future update, please visit DrayTek web site) Date: September 21, 2018...
- Page 2 Intellectual Property Rights (IPR) Information © All rights reserved. This publication contains information that is protected Copyrights by copyright. No part may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language without written permission from the copyright holders. The following trademarks are used in this document: Trademarks ...
- Page 3 Declaration of Conformity Hereby, DrayTek Corporation declares that the radio equipment type Vigor2620 is in compliance with Directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following internet address: http://www.draytek.com.tw/ftp/Vigor2620/Document/CE/ Manufacturer: DrayTek Corp. Address: No.
- Page 4 The antenna/transmitter should be kept at least 20 cm away from human body. DrayTek Vigor2620PVn series VDSL2/ADSL2+ routers are compliant with 47 C.F.R. Part More update, please visit www.draytek.com. Frequency Information for FCC: 2.4G WLAN...
- Page 5 Web registration is preferred. You can register your Vigor router via http://www.draytek.com. Firmware & Tools Updates Due to the continuous evolution of DrayTek technology, all routers will be regularly upgraded. Please consult the DrayTek web site for more information on newest firmware, tools and...
-
Page 6: Table Of Contents
Table of Contents 1. Introduction ......................1 2. Package Content ....................2 3. Panel Explanation ....................3 3.1 Vigor2620 ........................... 3 3.2 Vigor2620n ................................5 4. Hardware Installation ....................7 4.1 Network Connection via DSL ..................... 8 4.2 Wall-Mounted Installation ......................9 5. -
Page 7: Introduction
1. Introduction Vigor2620 series is a VDSL2 router with multi-subnet for secure and efficient workgroup management. It integrates IP layer QoS, NAT session/bandwidth management to help users control works well with large bandwidth. By adopting hardware-based VPN platform and hardware encryption of AES/DES/3DES, and hardware key hash of SHA-1/MD5, the router increases the performance of VPN greatly and offers several protocols (such as IPSec/PPTP/L2TP). -
Page 8: Package Content
2. Package Content Take a look at the package content. If there is anything missed or damaged, please contact DrayTek or dealer immediately. Vigor Router RJ-45 to RJ-45 Cable (Annex B) - Page 9 RJ-11 to RJ- (Annex B) RJ-11 to RJ-11 Cable 45 Cable (Annex A) Quick Start Guide The type of the power adapter depends on the country that the router will be installed. UK-type Power Adapter EU-type Power Adapter USA/Taiwan-type Power Adapter AU/NZ-type Power Adapter...
-
Page 10: Panel Explanation
3. Panel Explanation Vigor2620 Status Explanation The router is powered off. Blinking The router is powered on and running normally. The router is ready to access Internet. The router is not ready to access Internet. Blinking Slowly: The DSL connection is ready. - Page 11 Interface Description Factory Reset Restore the default settings. Usage: Turn on the router (ACT LED is blinking). Press the hole and keep for more than 5 seconds. When you see the ACT LED begins to blink rapidly than usual, release the button. Then the router will restart with the factory default configuration.
-
Page 12: Vigor2620N
Vigor2620n Status Explanation The router is powered off. Blinking The router is powered on and running normally. The router is ready to access Internet. The router is not ready to access Internet. Blinking Slowly: The DSL connection is ready. Quickly: Physical line has been connected. - Page 13 Interface Description Wireless LAN Press the button and release it within 2 seconds. ON/OFF/WPS When the wireless function is ready, the green LED will be on. Press the button and release it within 2 seconds to turn off the WLAN function. When the wireless function is not ready, the LED will be off.
-
Page 14: Hardware Installation
4. Hardware Installation This section will guide you to install the router through hardware connection and configure the router’s settings through web browser. Before starting to configure the router, you have to connect your devices correctly. -
Page 15: Network Connection Via Dsl
Network Connection via DSL Connect the DSL interface to the external ADSL splitter with an ADSL line cable. Connect one port of 4-port switch to your computer with a RJ-45 cable. This device allows you to connect 4 PCs directly. Connect one end of the power cord to the power port of this device. -
Page 16: Wall-Mounted Installation
4.2 Wall-Mounted Installation Vigor router has keyhole type mounting slots on the underside. A template is provided on the Vigor router packaging box to enable you to space the screws correctly on the wall. Place the template on the wall and drill the holes according to the recommended instruction. -
Page 17: Software Configuration
5. Software Configuration To access Internet, please finish basic configuration after completing the hardware installation. 5.1 Quick Start Wizard for Network Connection The Quick Start Wizard is designed for you to easily set up your router for Internet access. You can directly access the Quick Start Wizard via Web User Interface. - Page 18 Now, the Main Screen will pop up. Click Wizards>>Quick Start Wizard. Note The home page will change slightly in accordance with the router you have. If your router can be under an environment with high speed NAT, the configuration provide here can help you to deploy and use the router quickly. The first screen of Quick Start Wizard is entering login password.
- Page 19 Click Next to go to the following page.
-
Page 20: Customer Service
Now, you can enjoy surfing on the Internet. 6. Customer Service If the router cannot work correctly after trying many efforts, please contact your dealer for further help right away. For any questions, please feel free to send e-mail to support@draytek.com.
