- Page 1 INSTALLATION GUIDE Remote Access Controller Model 3.5 with KIM Swipe Reader Solitaire 710-II / 710 / System 700 / Generation E-760 PK2918...
-
Page 2: Table Of Contents
Please read and follow all directions carefully. These instructions are designed for use by maintenance professionals or lock installers who are familiar with common safety practices and competent to perform the steps described. Kaba Ilco is not responsible for damage or malfunction due to incorrect installation, however arising. -
Page 3: Features
Installation Guide 1. Features The Model 3.5 Remote Access Controller System is designed to activate electrical locking or control devices where a stand-alone electronic lock is not practical. This system can control any door or access point from up to 500 feet (150 m) away. The KIM Swipe Reader Assembly can be mounted directly on door frames as narrow as 2 inches (5.1 cm). - Page 4 RAC Model 3.5 with KIM Swipe Reader 1. Shut off the electrical power to the AC line to be connected to the control panel. 2. Set AC input switch S1 on the Power Supply (C) for the electrical voltage used in your country. North American applications require 115VAC, 60Hz;...
-
Page 5: If A Wiring Extension Is Required
Installation Guide 18. If a battery is being installed, mount the battery bracket in the control panel using 2 screws provided in the battery kit. The battery should be installed with the terminals facing the controller board and positioned closer to the power supply (see Figure 1). Connect the red wire from the TB4 terminal on the Power Supply (C) to the + red terminal on the Battery (F). - Page 6 RAC Model 3.5 with KIM Swipe Reader Single Reader Access Controller Assembly - Electromagnetic Lock/Electric Strike Figure 1 Note 1: Due to Hanchett Entry Systems (HES) modifying their 7000 series electric strikes and Rutherford Controls modifying their 83xx series electromagnetic locks to include an on-board...
- Page 7 Installation Guide Dual Reader Access Controller Assembly - Electromagnetic Lock/Electric Strike Figure 2 Note 1: Due to Hanchett Entry Systems (HES) modifying their 7000 series electric strikes and Rutherford Controls modifying their 83xx series electromagnetic locks to include an on-board diode, it is no longer necessary to install the diode from the installation kit.
- Page 8 RAC Model 3.5 with KIM Swipe Reader Controller (A) to KIM Swipe Reader (B) Connections Controller KIM Swipe Reader JP3-1 JP3-2 Black JP3-3 Orange Figure 3. Access Delay Select DIP Switch Bank JP3-4 Green JP3-5 Purple JP3-6 Brown JP3-7 Blue...
-
Page 9: Settings And Operation
1 or Figure 2 for the positions of the J1 and P1 connectors. Refer to Figure 4 or Figure 5 below for an illustration. 2. For step by step programming instructions, refer to chapter 5 of the Kaba Ilco Lodging Access Control System Reference Manual, version 6.5 or higher. Note: When programming the RAC, you do not swipe the Programming keycard in the reader. -
Page 10: Hotel Id Reinitialization
RAC Model 3.5 with KIM Swipe Reader 4.2 Hotel ID Reinitialization To reinitialize the Hotel ID code: 1. Set the switches in switch bank S2 to CFG #16. 2. Swipe a new initialization keycard through the swipe reader. The red and green LEDs on the KIM Swipe Reader will flash in sequence -red once, green twice. -
Page 11: Optional Accessories
Installation Guide 5. Optional Accessories Pannex Exit Device 120 22-1 (504440) with Electromagnetic Lock (504631) NOTE 1: Due to Hanchett Entry Systems (HES) modifying their 7000 series electric strikes and Rutherford Controls modifying their 83xx series electro- magnetic locks to include an on-board diode, it is no longer necessary to install the diode from the installation kit. - Page 12 RAC Model 3.5 with KIM Swipe Reader Elevator Call Button Installation Electric Strike and REX Button with Timer NOTE 1: Due to Hanchett Entry Systems (HES) and Rutherford Controls modifying their electro-magnetic locks to include an on-board diode, it is...
-
Page 13: Drilling Templates
Installation Guide Notes: Drilling Templates for KIM Swipe Readers: SATIN CHROME BLACK Back Panel of Reader 1.3" (33 mm) Drill 0.25" hole for cable #6 x 0.5" (12.7 mm) screw (x4) 4 x 0.125" (3.175 mm) hole... - Page 14 Kaba Lodging Systems 7301 Boul. Décarie Montréal (QC) H4P 2G7 Technical Support: 1.800.906.4526 Customer Service: T: 1.877.468.3555 F: 514.735.6589 General Information: www.kabalodging.com Online Consumable Orders: www.keycard.com To access all of our easy steps, please visit our Support Website: http://connect.kabalodging.com...
