Pioneer 2MT700 Installation

PIONEER INDUSTRIES, INC.
3325 S. Garfield Ave
Commerce, CA 90040
(800) 338-9468
www.pioneerind.com
Model Number: 2MT700, 2AM700
Warnings and Notes:
Check with local plumbing code requirements before installation.
This product should be installed by a local listed plumber.
Do not use plumbers putty on threads.
Installation Steps:
Deck Mount Pot-Filler
(1) Shut off water supply. Remove old faucet.
Clean mounting surface in preparation for new
faucet.
(2) Do not remove plastic arm bracket before
finish installation to prevent damage on swivel
arms. Be sure to place gasket underneath of
faucet to form watertight seal.
(3) Guide the faucet through mounting hole.
Slide the washer from beneath the mounting
surface. Install the locknut with the help of
mounting tool
(4) Use faucet inlet supply hose to connect
to supply stop. You may need adapter(not
included) if supply stop outlet size is not 3/8"
compression.
(6) Remove the aerator from the spout by
turning counter-clockwise. Turn on supply
stop. Check of any leaks. Make sure all the
connection are secure. Open both handles.
Flush and allow water to run at full flow for at
least one minute. Turn off water. Replace the
aerator.
Tools:
Adjustable Wrench
INSTALLATION
Teflon Tape Rags
