Projection Television

Operating Instructions

Model No.
(Puerto Rico)
PT-52DL10
DLP
TM
A TEXAS INSTRUMENTS TECHNOLOGY
(USA)
TQBC0215-1

Advertisement

Table of Contents
loading

Related Manuals for Panasonic PT-52DL10

Summary of Contents for Panasonic PT-52DL10

  • Page 1: Operating Instructions

    HDTV SPATIALIZRT 3-D STEREO COMPATIBLE 1080 i / 720p For assistance, please call : 1-888-VIEW PTV(843-9788) or send e-mail to : consumerproducts@panasonic.com or visit us at www.panasonic.com For assistance, please call : 787-750-4300 or visit us at www.panasonic.com Projection Television...

  • Page 2: Important Safety Instructions

    Important Safety Instructions WARNING: To reduce the risk of electric shock do not remove cover or back. No user-serviceable parts inside. Refer servicing to qualified service personnel. The lightning flash with arrow-head within a triangle is intended to tell the user that parts inside the product are a risk of electric shock to persons.
  • Page 3 12. Do not overload wall outlets and extension cords as this can result in fire or electric shock. 13. Never push objects of any kind into this projection TV through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the projection TV. 14.
  • Page 4 Dear Panasonic Customer Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment from your new projection television set. To obtain maximum benefit from your set, please read these Instructions before making any adjustments, and retain them for future reference.

  • Page 5: Table Of Contents

    Table of Contents Important Safety Instructions ... 2 Installation ... 6 Receiver Location ... 6 Optional External Equipment ... 6 AC Power Supply Cord ... 6 Safety Precaution ... 6 Remote Control Battery Installation ... 7 Connecting the Antenna Cable to the RF In Terminal ... 8 Antenna / Cable Connection ...

  • Page 6: Installation

    Installation Receiver Location This unit is intended to be used with an optional stand or entertainment center. Consult your dealer for available options. Locate for comfortable viewing. Avoid placing where sunlight or other bright light (including reflections) will fall on the screen.

  • Page 7: Remote Control Battery Installation

    Remote Control Battery Installation Requires two AA batteries (supplied). 1. Turn the Transmitter face down. Remove top cover by pressing down on marking and sliding cover off in the direction indicated. Helpful Hint: For frequent remote control users, replace old batteries with Alkaline batteries for longer life.

  • Page 8: Connecting The Antenna Cable To The Rf In Terminal

    Installation Connecting the Antenna Cable to the RF In Terminal Antenna Connection - For proper reception of VHF / UHF channels, an external antenna is required. For best reception an outdoor antenna is recommended. Antenna Mode must be set to projection TV. VHF Antenna UHF Antenna Mixer...
  • Page 9 Antenna Connection (Cable Box, no VCR) Use this configuration when connecting the projection TV to a cable TV system using a Cable Box. VIDEO AUDIO COMPONENT VIDEO INPUT S-VIDEO VIDEO ANT1 SPLIT ANT2 AUDIO AUDIO PROG INPUT Connect the cable from the antenna or cable system to the ANT1 terminal on the back of the projection TV.
  • Page 10 Installation Antenna Connection (Cable Box, and VCR) Use this configuration when connecting the projection TV to a cable TV system using a Cable Box and VCR. VIDEO AUDIO COMPONENT VIDEO INPUT S-VIDEO VIDEO AUDIO ANT1 SPLIT ANT2 AUDIO PROG INPUT Connect the cable from the antenna or cable system to the ANT1 terminal on the back of the...

  • Page 11: How To Connect The "1, 2, 3, 4" Input Terminals

    How to connect the “1, 2, 3, 4” Input Terminals Connects VCRs and other peripheral equipment (Super-VHS VCR) Audio Video S-Video Similar connections are available at the INPUT 1, 2, 4 input terminals. (VHS VCR) Audio Video VIDEO AUDIO Similar connections are available at the INPUT 1, 2, 3, 4 input terminals. Notes: •...

  • Page 12: How To Connect The Component Video Input Terminals

    Installation How to connect the COMPONENT VIDEO Input Terminals DVD Player Audio DVD(Y/P ) OUT Note: Similar connections are available at the COMPONENT VIDEO Input 1, 2, 3 Terminals. DVD(Y/P VIDEO AUDIO AUDIO COMPONENT VIDEO INPUT...

  • Page 13: How To Connect The Av Prog. Out Terminals

    How to connect the AV Pro The “Prog. Out” Terminals output the same signals as the main picture on the projection TV screen and sound from the speaker at that time, e.g. TV programs or signals from INPUT 1, 2, 3, 4 terminals. Recording Equipment (VHS VCR) S-Video...

  • Page 14: How To Connect The Pc Input Terminals

    Installation How to connect the PC Input Terminals COMPUTER Signal Names for D-SUB 15P Connector 15 14 13 12 11 Pin Layout for PC Input Terminal Notes: (1) The PC input terminals are DDC1/2B-compatible. If the computer being connected is not DDC1/2B-compatible, you will need to make setting changes at the computer at the time of connection.

  • Page 15: Analog Rgb Signals That Can Be Input

    Analog RGB signals that can be input The table below lists the different types of analog RGB signals that can be input. If a signal which differs greatly from any of the types listed below is input, the picture image may not be displayed correctly, or black background may displayed.

  • Page 16: Location Of Controls

    Location of Controls Illuminated Remote Control Power button Press to turn the projection TV ON or OFF. (See page 21) Note: The TV’s power cord must first be plugged into the wall outlet and then turned on at the POWER switch (standby mode). MUTE button Push this button to mute the sound.
  • Page 17 ASPECT button Change of screen size. (See page 28) NORMAL FULL LIGHT POWER ASPECT MUTE TV/VIDEO ACTION MENU INFO/RECALL AV-ADJ NORMAL GAME RH-SPLIT EXIT VCR REC GUIDE SEARCH SPLIT PLAY STOP FREEZE SWAP TV/VCR VCR/DBS CHANNEL PAUSE OPEN/CLOSE SLOW STILL R-TUNE PROG PROG...

  • Page 18: Controls And Terminals On The Projection Tv

    Location of Controls Controls and Terminals on the projection TV < FRONT > POWER INDICATOR R-STAND BY G-POWER ON (see page 20, 21) POWER SWITCH (see page 20) POWER R-STANDBY LAMP G-POWER ON Lamp unit (see page 62) Input mode selection buttons (see page 33) PC Input terminal LAMP This indicator lights up when there is a malfunction with the...
  • Page 19 < REAR > VIDEO AUDIO COMPONENT VIDEO INPUT S-VIDEO VIDEO ANT1 SPLIT ANT2 AUDIO AUDIO PROG INPUT VIDEO AUDIO S-VIDEO COMPONENT VIDEO INPUT VIDEO Component signal input (see page 12) Monitor out terminals (see page 13) Input1 terminals (see page 11) Input2 terminals (see page 13) Input3 terminals...

  • Page 20: Power On / Off

    Power ON / OFF Connecting the Plug to the Wall Outlet Turnin the Power ON and OFF Always be sure to follow the procedure given below to turn the projection TV power ON and OFF. • The lamp cooling fan will continue to operate for approximately 90 seconds after the power is turned off by the remote control. At the same time, the power indicator will blink Orange.
  • Page 21 Power (ON / OFF) button LIGHT POWER ASPECT MUTE TV/VIDEO POWER R-STANDBY G-POWER ON Remote Control Sensor Note: Even when the main power switch (FUNCTION SWITCH) is turned off, and the POWER indicator is not lit, the projection TV is not completely cut off from the power if the power cable is still plugged in. Push the Power button to turn the projection TV ON, POWER from Stand-by mode.

  • Page 22: Flow Chart Of Main Menu

    Flow Chart of Main menu If the MENU button is pressed, the MENU screen will be displayed. If the MENU button is pressed once more while the menu screen is displayed, the MENU screen will be cleared. The MENU button on the main body can also be pressed to display the MENU screen.

  • Page 23: Search Screen

    MENU ACTION TV/VIDEO ACTION The CHANNEL button on the main body can also be pressed to select items in the MENU screen. TO PICTURE TO POSITION/ ADJUST menu SIZE PICTURE ADJ. POSITION/SIZE NORMAL NORMAL PICTURE MENU DYNAMIC SIZE — PICTURE —...

  • Page 24: Tuning Channels (Automatic Channel Programming)

    Tuning channels Automatically searches and adds receivable channels to memory. Channel tuning cannot be performed when the MAIN picture is not receiving a TV broadcast (tuning is not possible). LIGHT POWER ASPECT MUTE TV/VIDEO ACTION MENU INFO/RECALL AV-ADJ NORMAL GAME RH-SPLIT EXIT VCR REC...
  • Page 25 Tuning channels (Automatic channel programming) Press to select YES. ACTION Press to run AUTO PROGRAM. Channels will automatically advance until all channels have been scanned. Channel numbers with a video signal present will turn blue which indicates stored in the Channel Scan Memory.

  • Page 26: Tuning Channels (Manual Channel Programming)

    Tuning channels Use this setting when changing setting of receiving channels or changing the channel display. Turn the projection TV on and select the broadcast channel. Follow the steps on the previous page to display the PROGRAM CHANNEL screen. LIGHT POWER ASPECT MUTE...
  • Page 27 Tuning channels (Manual channel programming) Adding or deleting channels ACTION ACTION Repeat steps 4 and 5 to continue adding or deleting channels. MENU Notes: • PROGRAM CHANNELS are valid only during TV mode. • Some channels with very weak signals may be locked into memory. It desired, these channels can be deleted manually using the Manual Program feature.

  • Page 28: Aspect Controls

    ASPECT Controls The color monitor will allow you to enjoy viewing the picture at its maximum size, including wide screen cinema format picture. LIGHT POWER ASPECT MUTE TV/VIDEO ACTION MENU INFO/RECALL AV-ADJ NORMAL GAME RH-SPLIT EXIT VCR REC GUIDE SEARCH SPLIT PLAY STOP...
  • Page 29 Picture Mode NORMAL NORMAL ZOOM FULL JUST Notes: • The S-VIDEO terminal on this set can detect specially encoded signals that are compatible with a wide screen monitor. When a full image from the S-VIDEO terminal of specially encoded video is detected by the set, the screen size is automatically set to FULL mode.

  • Page 30: Vhf, Uhf And Catv

    VHF, UHF and CATV Power switch Remote control sensor LIGHT POWER ASPECT MUTE TV/VIDEO ACTION MENU INFO/RECALL AV-ADJ NORMAL GAME RH-SPLIT EXIT VCR REC GUIDE SEARCH SPLIT PLAY STOP FREEZE SWAP TV/VCR PAUSE VCR/DBS CHANNEL OPEN/CLOSE SLOW STILL R-TUNE PROG MENU ACTION MENU ACTION...

  • Page 31: Cable Tv

    POWER towards the cable TV tuner. Note: The remote control code number is set for Panasonic products. When peripheral equipment do not operate, reset code (see page 63, 64). Operate the cable TV tuner and select the desired volume level.

  • Page 32: Searching For The Desired Channel (Channel Search)

    Searching for the desired channel LIGHT POWER ASPECT MUTE TV/VIDEO ACTION ACTION MENU INFO/RECALL AV-ADJ NORMAL GAME RH-SPLIT EXIT VCR REC GUIDE SEARCH SPLIT PLAY STOP FREEZE SWAP TV/VCR VCR/DBS CHANNEL PAUSE OPEN/CLOSE SLOW STILL R-TUNE PROG Notes: • To end channel search, press •...

  • Page 33: Playing A Vcr Or Other Peripheral Equipment

    Playing a VCR or other peripheral equipment INPUT 4 PC INPUT S-VIDEO VIDEO L-AUDIO-R Confirm that the projection TV is in standby mode. INPUT 4 PC INPUT S-VIDEO VIDEO L-AUDIO-R LIGHT POWER ASPECT MUTE TV/VIDEO ACTION MENU INFO/RECALL AV-ADJ NORMAL GAME RH-SPLIT EXIT...

  • Page 34: Playing Games In Game Mode

    Playing games in game mode INPUT 4 PC INPUT S-VIDEO VIDEO L-AUDIO-R Confirm that the projection TV is in standby mode. INPUT 4 PC INPUT S-VIDEO VIDEO L-AUDIO-R LIGHT POWER ASPECT MUTE TV/VIDEO ACTION MENU INFO/RECALL AV-ADJ NORMAL GAME RH-SPLIT EXIT VCR REC GUIDE...

  • Page 35: Recall / Mute

    Recall / Mute LIGHT POWER ASPECT MUTE TV/VIDEO ACTION MENU INFO/RECALL AV-ADJ NORMAL GAME RH-SPLIT EXIT VCR REC GUIDE SEARCH SPLIT PLAY STOP FREEZE SWAP TV/VCR VCR/DBS CHANNEL PAUSE OPEN/CLOSE SLOW STILL R-TUNE PROG Recall (On-screen display) INFO/RECALL Press this button to display channel number, off-timer remaining time, screen modes, and other settings.

  • Page 36: Split Screen

    Split screen Split screen enables you to search other channels on the right screen or check video recording status. Splitting the screen SPLIT Press to split (The previously selected screen appears on the left.) CH10 Example: Two screen mode set to NORMAL aspect.
  • Page 37 Changing the channel of the right screen during SPLIT SCREEN FULL, SPLIT SCREEN NORMAL, and PoutP. RH-SPLIT Press to operate right screen. CH10 CH10 While is displayed on the screen, press to switch modes. CH10 Viewing videos TV/VIDEO While is displayed on the screen, press to switch modes.

  • Page 38: Adjusting Screen Position And Size

    Adjusting screen position and size LIGHT POWER ASPECT MUTE TV/VIDEO ACTION MENU INFO/RECALL AV-ADJ NORMAL GAME RH-SPLIT EXIT VCR REC GUIDE SEARCH SPLIT PLAY STOP FREEZE SWAP TV/VCR VCR/DBS CHANNEL PAUSE OPEN/CLOSE SLOW STILL R-TUNE PROG Notes: • This projection TV is equipped with various screen modes. If a screen mode with a different aspect as the broadcast program is selected, image will appear differently.
  • Page 39 Switching screen width During NORMAL mode, if noise appears on the ends of the image in SIZE 1, switch to SIZE 2. Press to narrow (SIZE 2). ACTION Press to widen (SIZE 1). During JUST mode, if noise appears on the ends of the image in SIZE 1, switch to SIZE 2. Press to enlarge image horizontally (SIZE 2).

  • Page 40: Audio Adjustments

    Audio Adjustments Press the MENU button to display the MENU screen and select ADJUST. Select AUDIO ADJUST of ADJUST from the MENU screen. ACTION ACTION BASS Adjusts low sounds TREBLE Adjusts high sounds BALANCE Adjust left and right volumes SPATIALIZER To enjoy a concert hall effect, turn SPATIALIZER to ON.
  • Page 41 Turning the speaker sound ON and OFF SPEAKERS OFF Turns off the speaker sound. SPEAKERS ON Speaker sound is normal. MENU • To end adjustments Notes: • Sound signals are output from the rear AUDIO OUT terminal. • When volume is adjusted or the mute button is pressed from the remote control, a message will displayed. SPEAKERS SPEAKERS Press MENU button.

  • Page 42: Picture Adjustments

    Picture Adjustments Press the MENU button to display the MENU screen and select ADJUST. ACTION NORMAL is displayed at default. When setting are altered, changes to NORMALIZE. ACTION PICTURE ADJ. NORMAL PICTURE MENU DYNAMIC — PICTURE — BRIGHTNESS — COLOR TINT —...
  • Page 43 PICTURE Selects proper brightness and density for the room. BRIGHTNESS Adjusts for easier viewing of dark pictures such as night scenes and hair. COLOR Adjusts slightly to a lighter color. TINT Adjust for proper skin color. SHARPNESS Displays a sharp image. COLOR TEMP (Color Temperature) classifying white light.
  • Page 44 Picture Adjustments By pressing the AV-ADJ button on the remote control, PICTURE ADJUST and AUDIO ADJUST can be directly adjusted instead of starting from the MAIN menu. AV-ADJ The selected menu will change each time the AV-ADJ button is pressed (press till the desired menu is displayed).

  • Page 45: Playing Special Video Software

    Playing special video software When playing special images such as three dimensional video disks on video disk players or game software on video game players, use GAME mode. Use TV mode for normal viewing. Selecting VIDEO menu Press the MENU button to display the MENU screen and select SETUP. Press to select VIDEO.

  • Page 46: Closed Captions

    Closed Captions This receiver has a built in decoder that provides a visual depiction of the audio portion of a television program in the form of written words across the screen (white or colored letters on a black background). It allows the viewer to read the dialogue of a television program or other information.
  • Page 47 CC MODE Activates the On-Screen Closed Caption feature. When activated this feature will remain on until OFF is selected in this menu. Press to select CC MODE. Press to select from the following: ACTION • CAPTION OFF - Recommended mode when Closed Caption is not being used. •...

  • Page 48: Lock Feature

    Lock Feature In the United States, the V-CHIP consists of two rating systems, one for motion pictures and one for TV programs. Their function is to block programs by the rating data in the XDS data packets sent from broadcasting stations. The user can select which rating programs should be blocked by the LOCK MENU options.
  • Page 49 Press to select rating to lock. ACTION Press to select YES or NO. Rating (turns red when on) ACTION PG-13: Parental guidance needed under 13 years old NC17 : No one under 17 is admitted EXIT Press to return to LOCK screen. Setting MOTION PICT.
  • Page 50 Lock Feature TV PARENTAL STATUS Press to select TV PARENTAL STATUS. Press to select ON or OFF. ACTION Changing setting Press to select CHANGE SETTING. ACTION Press to display the TV PARENTAL GUIDE screen. Setting the TV PARENTAL PROGRAMS screen VIEW NR PROGRAMS? NO : Cannot view programs with NR signals.

  • Page 51: Customizing The Video Input Labels

    Customizing the VIDEO INPUT labels Display for each VIDEO INPUT can be changed to match with the connected device (VCR, video games). Press the MENU button to display the MENU screen and select SETUP. Press to select VIDEO. ACTION Press to display the VIDEO screen. Press to select VIDEO INPUT LABEL.
  • Page 52 Customizing the VIDEO INPUT labels ACTION ACTION ACTION ACTION MENU Note: When DVD or DTV is selected for the change, images are adjusted to match each input signal. Press to select VIDEO INPUT to change. Press to change. By pressing this button, display changes as follows: VIDEO 3 BLANK HD VCR...

  • Page 53: Selecting Stereo / Sap / Mono

    Selecting STEREO / SAP / MONO Mode - Stereo / SAP / Mono When Audio is broadcast in Stereo or SAP an ON Screen display will appear on initial “Turn On” and “Channel Change”. The available choices will be indicated in Green. Press the MENU button to display the MENU screen and select CUSTOM .

  • Page 54: Using The Off-Timer

    Using the off-timer Press the MENU button to display the menu screen and select CUSTOM. ACTION ACTION MENU Notes: • When power to the projection TV set is turned off due to a power outage or similar problem, after power is restored, the off-timer will be deactivated.

  • Page 55: Video Game Player To Video Input

    Video game player to VIDEO INPUT Press the MENU button to display the MENU screen and select SETUP. Press to select VIDEO. ACTION Press to display the VIDEO screen. Press to select GAME. Changing the video game player input terminal. ACTION Press to select from the following.

  • Page 56: Optimizing Display For Dvc Recording Mode (Dvc Playback Mode)

    Optimizing display for DVC recording mode When playing back recordings made by a DVC in FRAME mode, images will have higher resolution. Press the MENU button to display the MENU screen and select SETUP. ACTION ACTION ACTION MENU Notes: • Switches only during VIDEO INPUT 1-4 or GAME modes.

  • Page 57: Turning Off Digital Comb Filter

    Turning OFF digital comb filter Press the MENU button to display the MENU screen and select SETUP. Press to select VIDEO. ACTION Press to display the VIDEO screen. Press to select 3D Y/C FILTER. ACTION Press to turn OFF. ACTION MENU Press to exit menu.

  • Page 58: Automatically Changing Screen Size For Video Input Modes

    Automatically changing screen size for VIDEO INPUT modes If the received signal contains screen size specifications in VIDEO INPUT (1-4) or COMPONENT VIDEO INPUT (1 – 3), the screen size is automatically changed. Press the MENU button to display the MENU screen and select SETUP. ACTION ACTION ACTION...

  • Page 59: Setting When 480P Signals (Sequential Scan) Are Input Through Component Video Input

    Setting when 480p signals (sequential scan) are input through COMPONENT VIDEO INPUT Adjust 480p signals to achieve a natural color from digital equipment connected to COMPONENT VIDEO INPUT (Y, P Press the MENU button to display the MENU screen and select SETUP. Press to select VIDEO.

  • Page 60: Clock

    CLOCK CLOCK is valid only during PC mode. When an RGB signal is projected, minor adjustments of the dot clock frequency and adjustments of the phase can be made. Adjusting the clock When the set is connected to the PC, CLOCK can be adjust. 1 Connect a computer to the projection TV.

  • Page 61: Switching Languages For Display

    Switching languages for display Press the MENU button to display the MENU screen and select SETUP. Press to select LANGUAGE. ACTION Press to display the LANGUAGE screen. Press to select preferred language. ACTION MENU Press to exit menu. MENU ADJUST CUSTOM SET UP LANGUAGE...

  • Page 62: Replacing The Lamp Unit

    Replacing the lamp unit The lamp unit is sold separately. To purchase a replacement, call the Panasonic accessory department, toll free at: 1-800-332-5368. Lamp unit Part No. : TY-LA2000 Lamp unit replacement period The lamp unit for the projection TV should be replaced after approximately 5,000 hours of use in the normal usage mode.

  • Page 63: Operating Peripheral Equipment Using The Remote Control

    If the correct code is entered, the mode key will blink twice and then go out. Now your remote is set for this code. Device Operate TV (Only Panasonic) VCR (Preset) Cable Boxes (Preset) DBS Boxes (Preset) RCVR RCVR (Preset) Cassette Players, V CR2 (Preset) DVD &...
  • Page 64 Operating peripheral equipment using the remote control LIGHT POWER ASPECT MUTE TV/VIDEO ACTION MENU INFO/RECALL AV-ADJ NORMAL GAME RH-SPLIT EXIT VCR REC GUIDE SEARCH SPLIT PLAY STOP FREEZE SWAP TV/VCR VCR/DBS CHANNEL PAUSE OPEN/CLOSE SLOW STILL R-TUNE PROG Infrared Remote Codes for Specific Components Helpful Hint: Write down the code numbers for your components in the space provided below.
  • Page 65 HITACHI INSTANT REPLAY JENSEN KENWOOD MAGNAVOX MARANTZ MARTA MEMOREX MINOLTA MITSUBISHI MULTITECH OLYMPIC OPTIMUS ORION PANASONIC PENNEY Maker List (VCR) Set Up No. Maker PENTAX 137, 160 PHILCO 142, 014, 015, 016 240, 011 PHILIPS 005, 013 PIONEER 081, 136...
  • Page 66 Maker ARCHER CABLEVIEW CITIZEN CURTIS DIAMOND EAGLE EASTERN GCBRAND GEMINI GENERAL INSTRUMENT / JERROLD HAMLIN HITACHI MACOM MEMOREX MOVIETIME PANASONIC PHILIPS PIONEER DVD, CD, LD Maker Player DENON FERGUSON NORDMENDE MITSUBISHI PANASONIC PIONEER Maker CARVER DENON FISHER HARMAN / KARON...
  • Page 67 Operating peripheral equipment using the remote control CASSETTE PLAYERS, RECEIVERS, AMPLIFIERS, and DBS Infrared Codes Index Cassette Maker Players PANASONIC Receiver Maker Amplifiers ADMIRAL AIWA DENON FISHER GARRARD HARMAN KARDON JENSEN KENWOOD MEGNAVOX MARANTZ MCNTOSH NAKAMICHI ONKYO OPTIMUS Maker ECHOSTAR G.E.

  • Page 68: Remote Control

    Operating peripheral equipment using the remote control Quick Reference Functional Key Control TV, DTV, VCR AUX (VCR2) CABLE, DBS RCVR (Receiver / Amplifier) DVD (DVD, CD, LD) TV/VIDEO ALL COMPONENTS POWER TV, VCR, DBS, DTV CABLE MUTE RCVR (Receiver / Amplifier) AUX (Cassette) CABLE Receiver / Amplifier...
  • Page 69 Operating peripheral equipment using the remote control Quick Reference Functional Key Control MODE CABLE DVD (DVD) R-TUNE DVD (CD) DVD (LD) AUX (Tape Cassette Player) CABLE ACTION TV, CBL INFO/RECALL DVD (DVD) DVD (CD) DVD (LD) DVD (DVD, LD) DVD (CD) RCVR AUX (Tape Cassette Player) SPLIT...
  • Page 70 Operating peripheral equipment using the remote control Quick Reference Functional Key Control FREEZE TV/VCR DVD (DVD, CD, LD) OPEN/CLOSE AUX (Tape Cassette Player) ASPECT DTV (STB) CABLE CHANNEL DVD (DVD) DVD (CD) DVD (LD) RCVR CABLE VCR/DBS DVD (DVD) DVD (CD) DVD (LD) RCVR AV-ADJ...

  • Page 71: Troubleshooting

    Troubleshooting Before you call for service, determine the symptoms and make a few simple checks as shown below. Symptoms • Power does not turn ON • • • The power turns OFF • (the Power LED blinks Orange and the TEMP LED and LAMP LED lights up Red).

  • Page 72: Cleaning

    Cleaning To ensure continued excellent performance by this product, periodic cleaning is recommended. The unit contains many plastic parts. For this reason DO NOT use benzine, thinner or other chemicals to clean the unit. DO NOT bring into contact with insecticide or other volatile substances.

  • Page 73: Specifications

    Specifications Power Source AC 120 V, 60 Hz Average use : Maximum Current 3.8 A Power Consumption Stand-by condition : 0.74 W (when cooling fan is stopped) Display 52-inch, 16 : 9 aspect ratio 45.31 ″ (1151 mm) (W) × 25.49 ″ (647.5 mm) (H) × 52 ″ (1321 mm) (diagonal) Screen Size Speaker 4 Speakers...
  • Page 74 MEMO...
  • Page 75 MEMO...
  • Page 76 Warranty Service purposes. Model Number PT-52DL10 Panasonic Consumer Electronics Company, Division of Matsushita Electric Corporation of America One Panasonic way Secaucus New Jersey 07094 Serial Number Panasonic Sales Company, Division of Matsushita Electric of Puerto Rico Inc. (“PSC”) Ave.
