The AC adaptor is designed for supplying power to the Pana-
sonic computer series. Before using the AC adaptor, read this
instruction manual and the relevant portions of the computer's
instruction manual, as well as the instruction manual of the AC
Cord, carefully.
Information on Disposal for Users of Waste Electrical &
Electronic Equipment (private households)
This symbol on the products and/or accompanying
documents means that used electrical and elec-
tronic products should not be mixed with general
household waste.
Please dispose of this item only in designated na-
tional waste electronic collection schemes, and not
in the ordinary dust bin.
For business users in the European Union
For business users in the European Union If you wish to discard
electrical and electronic equipment, please contact your dealer
or supplier for further information.
Information on Disposal in other Countries outside the Eu-
ropean Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local au-
thorities or dealer and ask for the correct method of disposal.
India Only
For the purpose of recycling to facilitate effective
utilization of resources, please return this product
to a nearby authorized collection center, registered
dismantler or recycler, or Panasonic service center
when disposing of this product.
Please see the Panasonic website for further infor-
mation on collection centers, etc.
http://www.panasonic.co.in/wps/portal/home
Precautions
If a Malfunction Occurs, Immediately Unplug the AC Plug
• This product is damaged
• Foreign object inside this product
• Smoke emitted
• Unusual smell emitted
• Unusually hot
Continuing to use this product while any of the above conditions
re present may result in fire or electric shock.
• If a malfunction occurs, immediately unplug the AC lug. Then,
contact your technical support office.
Do Not Touch this Product and Cable When It Starts Thun-
dering
Electric shock may result.
ENGLISH
Do Not Connect the AC Adaptor to a Power Source Other
tan a Standard Household AC Outlet
Otherwise, a fire due to overheating may result. Connecting to
DC/AC converter (inverter) may damage the AC adaptor. On n
airplane, only connect the AC adaptor/charger to an AC outlet
pecifically approved for such use.
Do Not Do Anything That May Damage the AC Adaptor
Do not damage or modify the cord, place it near hot tools, end,
twist, or pull it forcefully, place heavy objects on it, or undle it
tightly.
Continuing to use a damaged cord may result in fire, short cir-
cuit, or electric shock.
• Refer to "Carrying cautions".
Do Not Move This Product While the AC Plug Is Connected
The AC cord may be damaged, resulting in fire or electric shock.
• If the AC cord is damaged, unplug the AC plug immediately.
Do Not Subject the AC Adaptor To Any Strong Impact
Using the AC adaptor after a strong impact such as being
dropped may result in electric shock, short circuit, or fire.
Be Absolutely Sure to Use the AC Adaptor With the Speci-
fied Product.
Use with any other product may result in a fire.
*1
For information about the products for which the AC adaptor can
be used, refer to the Operating Instructions of your product or
36-E-1
various sources.
Specifi cations
Voltage
Dimensions
(W x D x H)
Weight
(Except AC Cord)
68-M-1
*2
Use only the supplied AC cord for this AC adaptor.
The AC cord for North America is compatible up to 125V.
• <When using with 115 V AC>
Even when the AC adaptor is not connected to the computer,
power is consumed (Max. 0.2 W) simply by having the AC adap-
tor plugged into an AC outlet.
<When using with 240 V AC>
Even when the AC adaptor is not connected to the computer,
power is consumed (Max. 0.4 W) simply by having the AC adap-
tor plugged into an AC outlet.
Use the following combinations of AC Adaptors and AC
Cords.
AC Adaptors
(Model number for order)
CF-AA6503AS
*1
Input
100 V - 240 V AC
Output
16.0 V DC, 5.0 A
Approx. 134 mm x 47.5 mm x
31.5 mm
{5.3" x 1.9" x 1.2"}
Approx. 290 g
{Approx. 0.64 lb.}
Available AC Cords
(Model number for order)
CF-ACC23T
CF-ACC25T
*2
