Tripp Lite B003-HC2-DOCK1 Owner's Manual

2-port usb-c kvm docking station
Hide thumbs Also See for B003-HC2-DOCK1:
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
2-Port USB-C KVM
Docking Station
4K @ 30 Hz, USB 3.2 Gen 1
Model: B003-HC2-DOCK1
Este manual esta disponible en español en la página
deTripp Lite: tripplite.com/support
Ce manuel est disponible en français sur le site Web
deTripp Lite : tripplite.com/support
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Tripp Lite по адресу: tripplite.com/support
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum
1

Advertisement

Table of Contents
loading

Related Manuals for Tripp Lite B003-HC2-DOCK1

Summary of Contents for Tripp Lite B003-HC2-DOCK1

  • Page 1 ISOBAR ® surge protector in our monthly drawing! tripplite.com/warranty 1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support Copyright © 2020 Tripp Lite. All rights reserved. USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum...
  • Page 2 Package Contents • 2-Port USB-C KVM Docking Station • (x2) USB-C to USB-C Cables (M/M), 3.3 ft. (1 m) • Remote Port Selector • Owner’s Manual Optional Accessories • P569-XXX-CERT Series High-Speed HDMI Cables • M100-Series USB-A to Lightning Sync/Charge Cables •...

  • Page 3: System Requirements

    System Requirements • Windows 10 and above, computer with USB-C port and ® USB-C DisplayPort Alternate Mode Note: With Intel 7th-gen Core Processor (Kaby-Lake) and above. More info about CPU generation, please reference https://www.intel. com/content/www/us/en/processors/processor-numbers.html • Mac OS X 10.12 and above, computer with USB-C port ®...

  • Page 4: Product Features

    Product Features • Allows a USB-C laptop and a USB-C smartphone* to share one monitor, keyboard and mouse, as well as USB peripherals.** • HDMI port supports crystal-clear 4K resolutions up to 3840 x 2160 @ 30 Hz. • Provides USB PD 3.0 for laptop/computer charging up to 85W at power profiles of 5/9/15/20V.

  • Page 5: Feature Identification

    B003-HC2-DOCK1 Feature Identification Front Panel REM OTE USB 3.2 Gen 1 Type-A Ports: Connects to USB-A peripherals, such as a keyboard, mouse or thumb drive.
  • Page 6 Feature Identification Rear Panel REM OTE HDM I OUT USB PD HOST USB-C DC-In Port*: Connects a USB-C power source. USB-C 3.2 Gen 1 Type-C Port 1 (Laptop)**: Connects a computer with the included USB-C cable. If you need PD laptop charging, connect your computer to this port.
  • Page 7 65W is recommended. The minimum system power requirement for basic USB functions and video output should be at least 5V 3A. The first 15W will supply the B003-HC2-DOCK1. The next 10W will supply the USB-C device connected to the Android port.
  • Page 8 Feature Identification Top Panel B003-HC2-DOCK1 Console Indicator LED (Port 1): Illuminates white when the corresponding console is in use. Console Indicator LED (Port 2): Illuminates white when the corresponding console is in use.
  • Page 9 Installation and Operation -HC2-DOCK1 Smartphone Laptop Power Adapter Remote Monitor REM OTE HDM I OUT USB PD HOST B003-HC2-DOCK1 B003-HC2-DOCK1 REM OTE HDM I OUT REM OTE HDM I OUT Mouse Keyboard...
  • Page 10 Note: This port supports up to 100W (20V 5A) maximum input. A USB-C PD power adapter over 65W is recommended. The first 15W will supply the B003-HC2-DOCK1 itself. The next 10W will supply the USB-C device connected to Port 2. The balance of power will supply the USB-C device connected to Port 1.

  • Page 11: Port Selection

    Port Selection Press the button on the Remote Port Selector to switch between the two connected source devices. The Console Indicator LED will illuminate to show which console port is currently in use. Note: If the LED begins flashing, please check the power consumption of your connected USB peripheral.

  • Page 12: Firmware Upgrade

    Connect the Remote Port Selector cable to the unit. Press and hold the remote button, then power on the B003-HC2-DOCK1. The LED will blink and unit will enter the firmware upgrade mode. Run the Upgrade.bat file and follow the instructions.

  • Page 13: Specifications

    Specifications Model B003-HC2-DOCK1 Device Connection Connectors Upstream Computer (x1) USB 3.2 Gen 1 Type-C (Female) Smartphone (x1) USB 3.2 Gen 1 Type-C (Female) Downstream USB (x2) USB 3.2 Gen 1 Type-C (Female) HDMI (x1) HDMI (Female) Source Selection (x1) 2.5 mm...

  • Page 14: Warranty And Product Registration

    Warranty and Product Registration 3-Year Limited Warranty Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of 3 years from the date of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the product, at its sole discretion.
  • Page 15 Warranty and Product Registration Product Registration Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* *No purchase necessary. Void where prohibited. Some restrictions apply See website for details.
  • Page 16 1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support 20-07-163 • 93-3C9D_RevB...
