ASSEMBLY INSTRUCTIONS
Camo Hood Wrap / Bed Tonneau Cover
Congratulations on the purchase of your Camo Hood Wrap! These instructions will guide you through the assembly process. Carefully read these instructions and
familiarize yourself with components before starting the assembly process.
Please call 1-800-643-7332, visit our website at americanlandmaster.com, or your local dealer, if you experience any problems with this kit or need further
assistance.
Hood Wrap
I. Hood Wrap Installation
Unfold the Camo Hood Wrap
•
Orient the wrap so that the headlight openings are aligned with the headlights
•
Pull wrap towards dash so that the edge is aligned with the top corner of the dash as shown in Fig 1.
•
At the dash, install (3) pieces of included adhesive Velcro® at each end and in the top center as shown in Fig 2.
•
Pull the wrap snug and attach to the dash mounted Velcro®
•
Attach the remaining (6) Velcro® straps as shown in Figs 3 and 4
•
Fig 1 – Camo Wrap Cover Alignment
Fig 3 – Velcro Strap Locations
II. Hood Wrap Care
Hood Wrap can be attached and removed as often as desired
•
Machine wash COLD and TUMBLE DRY on LOW heat. DO NOT use detergents with Optical Brighteners or Bleach
•
Fig 2 – Velcro Locations
Fig 4 – Typical Strap Routing
Page 1 of 2 PN 15506
