Summary of Contents for Vivitar ViviCam F332
-
Page 1: User Manual
ViviCam F332 Digital Camera User Manual © 2010 Sakar International, Inc. All rights reserved. Windows and the Windows logo are registered trademarks of Microsoft Corporation. All other trademarks are the property of their respective companies. -
Page 2: Table Of Contents
Contents Introduction ... 2 What‟s Included ... 2 Parts of the Camera ... 3 Initial Camera Setup ... 4 Main Camera Modes ... 7 Camera Technical Specifications ... 8 Computer System Requirements – WINDOWS OS ... 9 Computer System Requirements – MAC OS ... 9 Powering ON/OFF Your Digital Camera ... -
Page 3: Introduction
Thank you for purchasing this camera. Everything you need to take quality digital photos and videos is included with your camera. Vivitar makes capturing those special moments as easy as possible. Please read this manual carefully first in order to get the most out of your digital camera. -
Page 4: Parts Of The Camera
Parts of the Camera 1. Power Button 2. Shutter Button 3. LCD Screen 4. LED 5. Zoom In 6. Zoom Out 7. MODE button 8. SET button 9. Scene / Left Button 10. Flash / Up / Slide Show 11. Delete / Right Button 12. -
Page 5: Initial Camera Setup
Initial Camera Setup Installing the Batteries Insert 3 X AAA (1.5V) batteries. Alkaline batteries recommended. Turning On the Camera Installing the Memory Card Insert SD Memory card (up to 32GB) before use. Using the Camera... - Page 6 When powering the camera ON for the first time the camera will take you through the initial camera setup. Powering the Camera ON Make sure the batteries have been inserted properly into your digital camera. Use 3x AAA (1.5v) batteries. Alkaline batteries are recommended. Make sure an SD card has been properly inserted into your camera (until a click sound is heard).
- Page 7 Set the Date and Time as Desired and press the SET button to confirm the selection and move to the next part of the camera setup. Setting the ViviLink Default Option Once the Date and Time have been set, you will be asked to set the default ViviLink destination for photos and videos taken with your camera.
-
Page 8: Main Camera Modes
Main Camera Modes Your camera has different modes for the various camera functions. You can switch modes by pressing the MODE button on your camera after the camera has been powered ON. Photo Capture Mode Use this mode to capture pictures with your camera. This is the default mode when the camera is powered ON. -
Page 9: Camera Technical Specifications
Camera Technical Specifications Image Sensor Image Resolution Video Resolution File Format Internal Memory External Memory LCD Display Lens Zoom Exposure White Balance Scene Flash Print Photos Self-Timer Anti-Shake Face Detect Smile Capture Macro Interface System Requirements Battery Working Temperature CMOS Sensor (14M) 4416 x 3312, (12M) 4000 x 3000, (10M) 3648 X 2736 pixels, (8M) 3264 X 2448 pixels, (7M HD) 3648X2048 pixels, (5M) 2592x1944 pixels, (3M) 2048x1536 pixels,... -
Page 10: Computer System Requirements - Windows Os
Computer System Requirements – WINDOWS OS To be able to download photos and videos to your PC, you will need the following minimum configuration: Pentium 4 processor or above with Windows XP service pack 2, Windows Vista or Windows 7 ... -
Page 11: Powering On/Off Your Digital Camera
Powering ON/OFF Your Digital Camera Make sure the batteries have been inserted properly into your digital camera. If your camera comes with a rechargeable lithium battery, make sure it is fully charged before the first use. Make sure an SD card has been inserted into your camera. (SD card up to 32GB - SD Card not included) Powering the camera ON Press the... -
Page 12: Navigating The Menus
To change the active camera mode, make sure the camera is powered ON and press the MODE button on the back of the camera. When in Photo Capture Mode, this icon will display on the top-left corner of the LCD display When in Video Capture Mode, this icon will display on the top-left corner of the LCD display When in Playback Mode, this icon will display on the top-left corner of the LCD display Navigating the Menus... -
Page 13: Photo Capture Mode
Photo Capture Mode The Photo Capture mode allows you to capture pictures with your digital camera. Taking a Picture While in Photo Capture mode, use the LCD display on the back of the camera to direct the camera at the scene you would like to capture. Click the T/Zoom In and W/Zoom Out buttons to zoom in/out if desired. - Page 14 Photo Capture Mode Quick Function Buttons Your digital camera has a four-directional pad that functions as Quick Function buttons: Button Function Scene Selection – Opens the Scene menu Left Flash Options – Toggles the Flash options appearing on the LCD Delete –...
- Page 15 Flash Options There are several Flash options available on your camera. The options appear on the Photo Capture Mode LCD screen in the sequence. To change the Flash mode, press the UP Quick Function button until you arrive at your desired settings.
- Page 16 Photo Capture Mode Menus The following are the menus that appear in your camera‟s Photo Capture Mode:...
- Page 17 Scene Menu The Scene Menu allows you to choose scene settings that allow your camera to adapt properly to your current environment. NOTE: When selecting the HIGH SENSITIVITY Option, by default the camera switches off the FLASH automatically (if it‟s ON) to optimize the picture quality. If however, you would like to override it and manually turn ON the Flash –...
- Page 18 Press the MODE button to exit the menu and return to your previous mode. An icon reflecting your selection will display on the LCD screen. Remember that this setting will be saved by your camera until you manually change the setting or restore the camera‟s default factory settings.
- Page 19 Press the SET button to select and save the desired option. selected option icon will appear on the selected item. Press the LEFT or RIGHT button to select the next menu item. Press the MODE button to exit the menu and return to your previous mode. An icon reflecting your selection will display on the LCD screen.
- Page 20 Face Detect Menu The Face Detect feature when set to „On‟ allows the camera to use a subject‟s face as the basis for balancing the other colors and focus in the camera‟s display. This feature is meant to ensure that the color and focus of your pictures will be consistently sharp and high-quality. Note: To properly use the Face Detect option, please ensure the following: ...
- Page 21 Smile Capture Menu The Smile Capture feature when set to „On‟ allows the camera to automatically take a picture when it detects that a subject in the picture is smiling. Note: To properly use the Smile Capture feature, please ensure the following: ...
- Page 22 Macro Menu With the Macro feature you can capture images at close range (30 ~ 45 cm). To enable the Macro „On‟. The flower icon mode, select mode is ON. To return to the normal mode and disable the Macro mode, select will appear on the LCD.
- Page 23 Press the UP or DOWN direction control buttons to scroll through the menu options. Press the SET button to select and save the desired option. selected option icon will appear on the selected item. Press the LEFT or RIGHT button to select the next menu item. Press the MODE button to exit the menu and return to your previous mode.
- Page 24 Press the UP or DOWN direction control buttons to scroll through the menu options. Press the SET button to select and save the desired option. selected option icon will appear on the selected item. Press the LEFT or RIGHT button to select the next menu item. Press the MODE button to exit the menu and return to your previous mode.
- Page 25 Light Exposure Menu The Light Exposure setting helps you control the amount of light that enters your camera‟s lens. This setting should be adjusted when the environment is lighter or darker than normal. When the environment has more light than is needed, reduce the exposure setting (by using the negative - count) to reduce the amount of light allowed into the lens by your camera.
- Page 26 selected option icon will appear on the selected item. Press the LEFT or RIGHT button to select the next menu item. Press the MODE button to exit the menu and return to your previous mode. An icon reflecting your selection will display on the LCD screen Remember that this setting will be saved by your camera until you manually change the setting or restore the camera‟s default factory settings.
- Page 27 Language Menu You can select your camera‟s language setting by selecting the desired language from the Language menu. Press the SET button to open the menus for the current mode. Press the LEFT or RIGHT direction control buttons to scroll and select the Language menu. Press the UP or DOWN direction control buttons to scroll through the menu options.
- Page 28 To Set the Date and Time: Press the SET button to open the menus for the current mode. Press the LEFT or RIGHT direction control buttons to scroll and select the Date/Time menu. Press the UP or DOWN direction control buttons to highlight the “Date Setup” menu option then press the SET button to select the option.
- Page 29 Auto Power Off Menu You can use the Auto Power Off feature in order to conserve you camera‟s battery life. The designated time represents when your camera will automatically power off. When the camera sits idle for the designated period of time, the camera will shut off completely and will need to be powered on again with the power button before the next use.
- Page 30 Press the MODE button to exit the menu and return to your previous mode. Remember that this setting will be saved by your camera until you manually change the setting or restore the camera‟s default factory settings. Format Memory Card Menu You can use the Format Memory Card menu to delete all of the content that is currently on your camera‟s memory card.
- Page 31 If you would like to proceed with the reset, select „Yes‟ and press the SET button to confirm. The settings will be reset. You will automatically exit the menu and return to the previous mode with the digital camera settings set to the Factory Default Settings. If you would like to exit the format, select „No‟...
-
Page 32: Photo Playback Mode
Photo Playback Mode When you first turn on the camera, the camera will be in Photo Capture mode by default. Press the MODE button twice to open the Playback Mode. The playback mode will allow you to review and edit photos and videos that you‟ve already taken with you camera. Viewing Photos on Your Camera Select your Photo: ... - Page 33 Photo Playback Mode Quick Function Buttons Your digital camera has a four-directional pad that functions as Quick Function buttons. Quick Function Button Left Right Down Other W/Zoom out Photo Playback Mode Menus The following are the menus that appear in your camera‟s Photo Playback Mode: Action Displays the PREVIOUS image Views all the Photos as a Slide Show with 3, 5 or 10 second...
- Page 34 Delete Menu While in the Playback Mode, you can delete pictures from your camera using the Delete menu. View the photo you would like to delete. Press the SET button to open the menus for the current mode. Press the LEFT or RIGHT direction control buttons to scroll and select the Delete menu. Press the UP or DOWN direction control buttons to scroll through the menu options.
- Page 35 ViviLink Menu The ViviLink technology allows you to quickly and easily upload your camera‟s photos and videos to the social networks of your choice with the accompanying Vivitar Experience Image Manager application. Press the SET button to open the menus for the current mode.
- Page 36 Crop Image Menu You can crop any picture on your camera with the Crop feature. Press the SET button to open the menus for the current mode. Press the LEFT or RIGHT direction control buttons to scroll and select the Crop Image menu.
- Page 37 Print This Photo Menu You can use the Print Photos menu to print the photos that are on your camera directly to a Pictbridge compatible printer. Scroll through your pictures and find the one you would like to print. Press the SET button to open the menus for the current mode. Press the LEFT or RIGHT direction control buttons to scroll and select the Print This Photo menu.
-
Page 38: Video Capture Mode
Video Capture Mode The Video Capture Mode allows you to capture videos with your digital camera. When the camera is first powered ON, the camera will be in Photo Capture Mode. Press the MODE button once to access the Video Capture Mode. Taking a Video While in Video Capture Mode use the LCD display on the back of the camera to direct the camera at the scene you would like to capture. - Page 39 Video Capture Mode Quick Function Buttons Your digital camera has a four-directional pad that functions as Quick Function buttons. Quick Function Button Left Right Down Other Shutter MODE Hide/Show the LCD Icons The display of the icons on the LCD screen can be hidden or visible as desired. Hold the MODE button for 2 seconds to hide the display of the icons on the screen.
- Page 40 Video Capture Mode Menus The following are the menus that appear in your camera‟s Video Capture Mode:...
- Page 41 Scene Menu The Scene Menu allows you to choose scene settings that allow your camera to adapt properly to your current environment. Press the SET button to open the menus for the current mode. Press the LEFT or RIGHT direction control buttons to scroll and select the Scene menu. Press the UP or DOWN direction control buttons to scroll through the menu options.
- Page 42 Image Quality Menu The Image Quality menu allows you to select the desired quality level of the images taken by your camera. Keep in mind that images with a higher image quality level will also take up more memory on your camera. Press the SET button to open the menus for the current mode.
- Page 43 3) Press the UP or DOWN direction control buttons to scroll through the menu options. 4) Press the SET button to select and save the desired option. 5) A selected option icon will appear on the selected item. 6) Press the LEFT or RIGHT button to select the next menu item. 7) Press the MODE button to exit the menu and return to your previous mode.
- Page 44 Color Effect Menu You can choose to add a color effect to the images taken with your camera. Press the SET button to open the menus for the current mode. Press the LEFT or RIGHT direction control buttons to scroll and select the Color Effect menu.
- Page 45 Light Exposure Menu The Light Exposure setting helps you control the amount of light that enters your camera‟s lens. This setting should be adjusted when the environment is lighter or darker than normal. When the environment has more light than is needed, reduce the exposure setting (by using the negative - count) to reduce the amount of light allowed into the lens by your camera.
- Page 46 Press the UP or DOWN direction control buttons to scroll through the menu options. Press the SET button to select and save the desired option. selected option icon will appear on the selected item. Press the LEFT or RIGHT button to select the next menu item. Press the MODE button to exit the menu and return to your previous mode.
- Page 47 Language Menu You can select your camera‟s language setting by selecting the desired language from the Language menu. Press the SET button to open the menus for the current mode. Press the LEFT or RIGHT direction control buttons to scroll and select the Language menu. Press the UP or DOWN direction control buttons to scroll through the menu options.
- Page 48 setting or restore the camera‟s default factory settings. To Set the Date and Time: Press the SET button to open the menus for the current mode. Press the LEFT or RIGHT direction control buttons to scroll and select the Date/Time menu. Press the UP or DOWN direction control buttons to highlight the “Date Setup”...
- Page 49 Frequency Menu The options in the Frequency menu represent the frequency of the electrical current in fluorescent lighting sources in your locale. If your camera is set to a frequency that does not match your country‟s electric current, you may see flickering or waves on the images taken by your camera.
- Page 50 To proceed with the format, select “Yes” and press the SET button. You will be asked to confirm the formatting of the memory card. Select “No” to exit without formatting. Select “Yes” and press the SET button to begin. The memory card will be completely formatted.
-
Page 51: Video Playback Mode
Video Playback Mode When you first turn on the camera, the camera will be in Photo Capture mode by default. Press the MODE button twice to open the Playback Mode. The Playback Mode will allow you to review and edit photos and videos that you‟ve already taken with you camera. Playing Videos on Your Camera Select your Video: ... - Page 52 Video Playback Mode Quick Function Buttons Your digital camera has a four-directional pad that functions as Quick Function buttons. Quick Function Button Action Displays the PREVIOUS image Left STOPS a playing video Displays the NEXT image Right Down Other PLAYS and PAUSES a playing video Shutter Opens Thumbnail View ...
- Page 53 ViviLink Menu The ViviLink technology allows you to quickly and easily upload your camera‟s photos and videos to the social networks of your choice with the accompanying Vivitar Experience Image Manager application. Press the SET button to open the menus for the current mode.
- Page 54 Protect/Lock Menu Pictures and Videos taken with your camera can be protected or “locked” to prevent any deletion or alteration being made to the files. Press the SET button to open the menus for the current mode. Press the LEFT or RIGHT direction control buttons to scroll and select the Protect/Lock menu.
-
Page 55: Installing The Software
Installing the Software You must be connected to the internet to install and run the Vivitar Experience Image Manager software. Insert the installation CD into your CD-ROM drive. The installation screen should automatically open. On PC: The Vivitar Experience Image Manager Installer window appears. If the window does not appear, open the application‟s CD/DVD drive and click on “Setup.exe”... -
Page 56: Connecting The Camera To The Computer
On PC and Macintosh: Click the “I accept the terms of this license agreement” and then click “Next” to continue. 10) On PC only: Let the “Vivitar Experience Image Manager” installer create the folder to where the program will be installed, and then click “Install”. -
Page 57: Getting Photos And Videos From Your Camera To Your Computer
Getting Photos and Videos from your Camera to Your Computer An SD card needs to be inserted. Do not disconnect the cable during transfer. Doing so will cancel the transfer of any files on their way to your computer. Select the “Get Images” button from the Main menu. The “Get Images from device”... -
Page 58: Get Started
Edit images using automatic and manual tools Use automatic “Geotagging” with built in Google Maps For more details on how to use the Vivitar Experience Image Manager open the Help file or click the “Take the Tour” button on the application`s Home page. -
Page 59: Transfer Media From My Camera To My Computer Manually (Using Macintosh)
Transfer media from my camera to my computer manually (Using Macintosh) Use the USB cable that came with your camera to connect your camera to your computer. MSDC appears on the LCD. The camera‟s device icon appears on the desktop. Click on the device icon and open the DCIM folder and the folder inside to view the media files. -
Page 60: Sakar Warranty Card
Sakar Warranty Card This warranty covers for the original consumer purchaser only and is not transferable. Products that fail to function properly UNDER NORMAL USAGE, due to defects in material or workmanship will be repaired at no charge for parts or labor for a period of one year from the time of purchase. -
Page 61: Technical Support
Technical Support For technical support issues please visit our website at www.vivitar.com. You can find manuals, software and FAQ‟s at the website. Can‟t find what you are looking for? E-mail us at support@vivitar.com and one of our technical support team members will answer your questions.
