ViewSonic
PJD7383/ PJD7383i
PJD7583w/PJD7583wi
DLP Projector
IMPORTANT: Please read this User Guide to obtain important
information on installing and using your product in a safe
manner, as well as registering your product for future service.
Warranty information contained in this User Guide will describe
your limited coverage from ViewSonic Corporation, which is
also found on our web site at http://www.viewsonic.com in
English, or in specific languages using the Regional selection
box in the upper right corner of our website.
"Antes de operar su equipo lea cuidadosamente las
instrucciones en este manual"
®
- User Guide
- Guide de l'utilisateur
- Bedienungsanleitung
- Guía del usuario
- Guida dell'utente
- Guia do usuário
- Användarhandbok
- Käyttöopas
- Podręcznik użytkownika
- Pyководство пользователя
- Kullanιcι kιlavuzu
- 使用手冊(繁中)
- 使用手册 (简体)
- 사용자 안내서
Model No. : VS13339
VS13340

Advertisement

Table of Contents
loading

Related Manuals for ViewSonic PJD7383

Summary of Contents for ViewSonic PJD7383

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.

  • Page 2: Compliance Information

    Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this unit near water. Clean with a soft, dry cloth. Do not block any ventilation openings. Install the unit in accordance with the manufacturer’s instructions.

  • Page 4: Declaration Of Rohs Compliance

    Declaration of RoHS Compliance This product has been designed and manufactured in compliance with Directive 2002/95/EC of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Substance...

  • Page 5: Copyright Information

    Please use care and dispose of in accordance with local, state or federal laws. ViewSonic respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic website to learn more.

  • Page 6: Table Of Contents

    Table of contents Important safety instructions ...3 Introduction...5 Projector features ... 5 Shipping contents... 6 Projector exterior view... 7 Controls and functions ... 8 Positioning your projector...12 Choosing a location... 12 Projection dimensions ... 13 Connection ...15 Connecting a computer or monitor ... 16 Connecting Video source devices ...

  • Page 7: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before you operate your projector.
  • Page 8 Do not block the ventilation holes. If the ventilation holes are seriously obstructed, overheating inside the projector may result in a fire. - Do not place this projector on a blanket, bedding or any other soft surface. - Do not cover this projector with a cloth or any other item. - Do not place inflammables near the projector.

  • Page 9: Introduction

    Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features. • Short throw lens to create larger images with less distance between the projector and the screen •...

  • Page 10: Shipping Contents

    Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated.

  • Page 11: Projector Exterior View

    Projector exterior view Front/upper side Rear/lower side 14 15 11 12 Warning • THIS APPARATUS MUST BE EARTHED. • When installing the unit, incorporate a readily accessible disconnect device in the fixed wiring, or connect the power plug to an easily accessible socket-outlet near the unit. If a fault should occur during operation of the unit, operate the disconnect device to switch the power supply off, or disconnect the power plug.

  • Page 12: Controls And Functions

    Controls and functions Projector Introduction Focus ring Adjusts the focus of the projected image. TEMPerature indicator light Lights up red if the projector's temperature becomes too high. POWER indicator light Lights up or flashes when the projector is under operation. POWER Toggles the projector between standby mode and on.

  • Page 13: Remote Control

    Remote control To use the remote mouse control keys (Page Up, Page Down, ), see "Using the remote mouse control" on page 10 Toggles the projector between standby mode and on. Source selection keys (VGA 1/VGA 2/Video) Selects an input source for display. Source Displays the source selection bar.

  • Page 14: Using The Remote Mouse Control

    Laser Emits visible laser pointer light for presentation purposes. Page Up/Page Down Operates your display software program (on a connected PC) which responds to page up/down commands (like Microsoft PowerPoint) when the mouse mode is activated. AUTO Automatically determines the best picture timings for the displayed image.

  • Page 15: Remote Control Effective Range

    Remote control effective range Infra-Red (IR) remote control sensors are located on the front and the back of the projector. The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensors to function correctly. The distance between the remote control and the sensors should not exceed 8 meters (~ 26 feet).

  • Page 16: Positioning Your Projector

    Positioning your projector Choosing a location Your room layout or personal preference will dictate which installation location you select. Take into consideration the size and position of your screen, the location of a suitable power outlet, as well as the location and distance between the projector and the rest of your equipment.

  • Page 17: Projection Dimensions

    Projection dimensions Refer to "Dimensions" on page 77 calculating the appropriate position. PJD7383/PJD7383i • 4:3 image on a 4:3 screen • 16:9 image on a 4:3 screen (e): Screen (f): Center of lens 4:3 image (a) Screen (b) Projection Size...
  • Page 18 PJD7583w/PJD7583wi • 16:10 image on a 16:10 screen • 16:10 image on a 4:3 screen (e): Screen (f): Center of lens (a) 16:10 Screen Size Projection [inch (m)] distance [m (inch)] (0.8) 0.32 (12) (1.0) 0.42 (17) (1.3) 0.53 (21) (1.5) 0.63 (25) (1.8) 0.74 (29) (2.0) 0.84 (33)

  • Page 19: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. • In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...

  • Page 20: Connecting A Computer Or Monitor

    Connecting a computer or monitor Connecting a computer The projector provides two VGA input sockets that allow you to connect them to both IBM® compatibles and Macintosh® computers. A Mac adapter is needed if you are connecting legacy version Macintosh computers. To connect the projector to a notebook or desktop computer: •...

  • Page 21: Connecting Video Source Devices

    Connecting Video source devices You can connect your projector to various Video source devices that provide any one of the following output sockets: • Component Video • S-Video • Video (composite) You need only connect the projector to a Video source device using just one of the above connecting methods, however each provides a different level of video quality.

  • Page 22: Connecting A Component Video Source Device

    Video source device is turned on and operating correctly. Also check that the signal cables have been connected correctly. VGA-Component adapter • (ViewSonic P/N: CB-00008906) Connecting an S-Video source device Examine your Video source device to determine if it has an unused S-Video output socket available: •...

  • Page 23: Playing Sound Through The Projector

    Connecting a composite Video source device Examine your Video source device to determine if it has a set of unused composite Video output sockets available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to a composite Video source device: Take a Video cable and connect one end to the composite Video output socket of the Video source device.
  • Page 24 ensure a quality use of the wireless microphone, it is recommended that your microphone conforms to the specifications listed in the table below. Signal Microphone • There are two ways to adjust microphone volumes. • Directly set microphone volume levels in the SYSTEM SETUP: Advanced > Audio Settings >...

  • Page 25: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted). Check that the POWER indicator light on the projector flashes blue after power has been applied. Remove the lens cap.
  • Page 26 The projector will start to search for input signals. The current input signal being scanned appears in the upper left corner of the screen. If the projector doesn't detect a valid signal, the message 'No Signal' will continue to be displayed until an input signal is found.

  • Page 27: Using The Menus

    3D Sync 3D Sync Invert Color Management Analog RGB Auto Disable MENU Exit English Front Table Disable Disable ViewSonic MENU Exit : SYSTEM SETUP: Basic : SYSTEM SETUP: Advanced : INFORMATION Auto Status ENTER Go to the previous page Disable or to exit.

  • Page 28: Utilizing The Password Function

    Utilizing the password function For security purposes and to help prevent unauthorized use, the projector includes an option for setting up password security. The password can be set through the On-Screen Display (OSD) menu. For details of the OSD menu operation, please refer to page You will be inconvenienced if you activate the password functionality and subsequently forget the password.

  • Page 29: Entering The Password Recall Procedure

    If the password is incorrect, the password error message is displayed lasting for three seconds, and the message 'INPUT PASSWORD' is displayed for your RECALL PASSWORD Please write down the recall code, and contact ViewSonic Customer Center. Recall code: 0 2 1 2...

  • Page 30: Switching Input Signal

    retry. You can press MENU/EXIT on the projector or Exit on the remote control to cancel the change or try another password. Though the password function is disabled, you need to keep the old password in hand should you ever need to re-activate the password function by entering the old password. Switching input signal The projector can be connected to multiple devices at the same time.

  • Page 31: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projection angle The projector is equipped with 1 quick-release adjuster foot and 2 rear adjuster feet. These adjusters change the image height and projection angle. To adjust the projector: Press the quick-release button and lift the front of the projector.

  • Page 32: Correcting Keystone

    Fine-tuning the image clarity Sharpen the image by rotating the focus ring. Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. To correct this, besides adjusting the height of the projector, you will need to manually correct it following one of these steps.

  • Page 33: Magnifying And Searching For Details

    Magnifying and searching for details If you need to find the details on the projected picture, magnify the picture. Use the direction arrow keys for navigating the picture. • Using the remote control Press Magnify +/- to display the Zoom bar. Press Magnify + to magnify the center of the picture.
  • Page 34 Press to select an aspect ratio to suit the format of the video signal and your display requirements. About the aspect ratio In the pictures below, the black portions are inactive areas and the white portions are active areas. OSD menus can be displayed on those unused black areas. Auto: Scales an image proportionally to fit the projector's native resolution in its horizontal width.

  • Page 35: Optimizing The Image

    Optimizing the image Selecting a picture mode The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal picture type. To select an operation mode that suits your need, you can follow one of the following steps.

  • Page 36: Adjusting Brightness

    Setting the User 1/User 2 mode There are two user-definable modes if the current available picture modes are not suitable for your need. You can use one of the picture modes (except the User 1/User 2) as a starting point and customize the settings. Press MENU/EXIT on the projector or Menu on the remote control to open the On- Screen Display (OSD) menu.

  • Page 37: Adjusting Color

    Adjusting Color Highlight the PICTURE > Color menu and press Lower setting produces less saturated colors. If the setting is too high, colors on the image will be overpowering, which makes the image unrealistic. Adjusting Tint Highlight the PICTURE > Tint menu and press The higher the value, the more reddish the picture becomes.

  • Page 38: Color Management

    Color Management Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered. Color management provides fine color control adjustment to allow for more accurate color reproduction, should you require it. If you have purchased a test disc which contains various color test patterns and can be used to test the color presentation on monitors, TVs, projectors, etc., you can project any image from the disc on the screen and enter the Color Management menu to make adjustments.

  • Page 39: Hiding The Image

    Hiding the image In order to draw the audience's full attention to the presenter, you can use on the remote control to hide the screen image. Press any key on the projector or remote control to restore the image. The word 'BLANK' appears at the lower right corner of the screen while the image is hidden.

  • Page 40: Freezing The Image

    Freezing the image Press Freeze on the remote control to freeze the image. The word 'FREEZE' will be displayed in the upper left corner of the screen. To release the function, press any key on the projector or remote control. Even if an image is frozen on the screen, the pictures are running on the video or other device.

  • Page 41: Creating Your Own Startup Screen

    Creating your own startup screen In addition to selecting the projector preset startup screen from among ViewSonic logo, Black or Blue screen, you can make your own startup screen that is a picture projected from your computer or video source.

  • Page 42: Setting The Presentation Timer

    Setting the presentation timer Presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Follow these steps to utilize this function: Press Timer on the remote control to access the Presentation Timer menu, or go to the SYSTEM SETUP: Advanced >...

  • Page 43: Controlling The Projector Through A Lan Environment

    Controlling the projector through a LAN environment You can manage and control the projector from one or more remote computers when they are properly connected to the same local area network. Wired LAN connection If you are in a DHCP environment: Take a RJ45 cable and connect one end to the RJ45 LAN input jack of the projector and the other end to the RJ45 port on your Ethernet or router.

  • Page 44: Wireless Lan Connection

    Wireless LAN connection To connect to the projector wirelessly, you have to plug a ViewSonic wireless dongle (optional) to the USB Type A connector on the projector, and then only a few OSD configuration steps are required.

  • Page 45: Resetting The Network Settings

    If you need more information about AP and Infrastructure modes, please refer to user documentations for Wireless Routers which are usually available on 3C stores. Resetting the network settings If you encounter a malfunctiom of network connection and need to reset the network settings, you can go into the SYSTEM SETUP: Basic >...
  • Page 46 To have access to the Administrator page, you need to enter a password. The default password is “0000”. • System Status: Displays the system information. • General Setup: Allows you to turn on/off the projector, switch the input signal for the projector, and change the password for the Administrator page. •...
  • Page 47 i. These buttons function the same as the ones on the OSD menus or remote control. See page 8 for details. ii. To switch between input signals, click on your desired signal. iii. The software is available in multiple languages. •...
  • Page 48 Please pay attention to the limitation of input length (including space and other punctuation keys) in the list blow: Category Item Crestron Control Projector Network Configuration User Password Admin Password The info page displays the information and status of this projector. After pressing the button “Contact IT Help”, the HELP DESK window will appear in the upper right corner of the screen.
  • Page 49 For more information, visit http://www.crestron.com & www.crestron.com/getroomview. **Crestron RoomView On the “Edit Room” page, enter the IP Address (or hostname) as shown on the projector’s on-screen display (OSD) menu, and “02” for IPID, “41794” for the reserved Crestron control port. About Crestron RoomView setting and command method, please access below website to get RoomView User Guide and more information: http://www.crestron.com/features/roomview_connected_embedded_projectors_devices/...

  • Page 50: Displaying Images Through Vspresenter

    Displaying images through vsPresenter Downloading and installing vsPresenter The vsPresenter is an application running on the host PC. It helps connect your computer to an available network projector and transfer the desktop content to the network projector via local network connection. Enter the main page of Network Control.
  • Page 51 If you want to project your computer screen after connection, click Directly. If you want to connect to the projector via Network Control system, click Connect to webpage. The main page of Network Control will be displayed after connection. iii. Click Connect.
  • Page 52 The Basic Setting page allows you to configure vsPresenter. • To allow notification messages to appear, click Yes. Click Apply. • The Software Information is available on this page. The Advanced Setting page allows you to configure vsPresenter. • To adjust the image quality, click the down arrow to reveal a drop-down list and select a desired quality level.
  • Page 53 You can manage the connected projectors listed under Device Management. • Under a conference mode: 1. Only the administrator can take control. 2. A projector can display up to 4 computer screens. • You can set the name of your computer under vsPresenter Management. •...

  • Page 54: Displaying Pictures With A Usb Storage Device

    Displaying pictures with a USB storage device The projector is built-in an application which can display packaged images on a USB storage device. It can eliminate the need for a computer source. The projector supports the following image formats: File format JPEG GIF/TIFF/PNG/BMP •...
  • Page 55 • Next: Selects the next folder/image. • Previous: Selects the previous folder/image. • Thumbnail/Full Screen/SlideShow: Displays the selected image in thumbnail/ Full Screen/SlideShow mode. • NameOrder/ExtendOrder/SizeOrder/TimeOrder: Sets the images to be displayed in the order of filenames, filename extension, file sizes, or time the photos were taken.
  • Page 56 • Rotate + 90: Rotates the image 90 degrees clockwise. • Rotate -90: Rotates the image 90 degrees counterclockwise. • USB 2.0 compliant USB storage media (Mass Storage Class) is supported. • It is strongly recommended to use an AC power adaptor with the USB hard disk. •...

  • Page 57: Using The Pointblank Pen (Pjd7383I/Pjd7583Wi Only)

    Using the PointBlank pen (PJD7383i/PJD7583wi only) The PointBlank pen can work in place of your regular computer mouse. Just hold the pen in your hand, and point it at the projected image to point, click, and drag. It gives you more flexibility to operate your computer without standing next to it.

  • Page 58: Using The Quick Menu

    If there are multiple projectors, you can set a channel with the Link Channel menu to differentiate between projectors and communicate with the pen. To meet the needs of left-handers and right-handers, you can set your handwriting mode on the Handwriting Mode menu. When selecting User for the mode, you need to further adjust the pointer’s Horizontal and Vertical positions.
  • Page 59 Take a USB cable, and connect the smaller end to the pen and the larger end to a computer. Make sure the computer is powered on. The battery light stays amber while the battery is charging. When charging is finished, the battery lights off.
  • Page 60 • Make sure the projector is displaying the same image as the computer’s main or built-in monitor (don’t extend your desktop into multiple monitors.) If the battery light does not turn on when the pen is being charged, try one of the following: •...

  • Page 61: Using The Projector In Standby Mode

    Using the projector in standby mode Some of the projector functions are available in standby mode (plugged in but not turned on). To use these functions, be sure you have turned on the corresponding menus under SYSTEM SETUP: Basic > Standby Settings, and the cable connections are correctly made.

  • Page 62: Shutting Down The Projector

    Shutting down the projector Press POWER and a confirmation message is displayed prompting you. If you don't respond in a few seconds, the message will disappear. Press POWER a second time. Disconnect the power cord from the wall socket if the projector will not be used in an extended period of time.

  • Page 63: Menu Operation

    • • TI 3D DLP Link/Off Disable/Invert Primary Color R/G/B/C/M/Y Saturation Gain PC source: Brightest/PC/ViewMatch/Cinema/User 1/User 2 Video source: Brightest/Gaming/ViewMatch/ Cinema/User 1/User 2 PC source: Brightest/PC/ViewMatch/Cinema Video source: Brightest/Gaming/ViewMatch/ Cinema On/Off T1/T2/T3/T4 Options Auto/4:3/16:9 (PJD7383/PJD7383i only) Auto/4:3/16:9/16:10 (PJD7583w/PJD7583wi only) Operation...
  • Page 64 Main menu Quick Auto Search PointBlank 3. SOURCE (PJD7383i/ PJD7583wi only) Operation Sub-menu On/Off Enabled Yes/No Click Speed Fast/Medium/Slow Link Channel Auto/1/2/3/.../28 Handwriting Lefthand 1/Lefthand 2/ Mode Righthand 1/Righthand 2/User Horizontal Vertical Normal/Draw Alt-Tab Alt-Esc Command-Tab Left Mouse M Button Right Mouse Middle Mouse Double Click...
  • Page 65 Standby Settings Sub-menu Front Table/Rear Table/Rear Ceiling/Front Ceiling Disable/5 min/10 min/20 min/ 30 min/40 min/50 min/60 min Disable/5 min/10 min/15 min/ 20 min/25 min/30 min On/Off Black/Blue/ViewSonic/Screen Capture/Off On/Off Status DHCP IP Address Wired LAN Subnet Mask Default Gateway Apply...
  • Page 66 Main menu High Altitude Mode Audio Settings Menu Settings Closed Caption SYSTEM Lamp Settings SETUP: Advanced Presentation Timer Security Settings Reset All Settings Current System Status INFORMATION Operation Sub-menu On/Off On/Off Mute On/Off Volume Microphone Volume Menu Display 5 sec/10 sec/15 sec/20 sec/25 Time sec/30 sec Center/Top-Left/Top-Right/...

  • Page 67: Description Of Each Menu

    Description of each menu Function Screen Color Aspect Ratio Keystone Position Phase H. Size Zoom 3D Sync 3D Sync Invert Color Management Description Corrects the projected picture’s color when the projection surface is not white. See "Using Screen Color" on page 32 There are three options to set the image's aspect ratio depending on your input signal source.

  • Page 68: Function Description

    Function Color Mode Reference Mode Brightness Contrast Color Tint Sharpness Brilliant Color Color Temperature Save Settings Quick Auto Search PointBlank Operation Description Pre-defined picture modes are provided so you can optimize your projector image set-up to suit your program type. See "Selecting a picture mode"...
  • Page 69 Function Sets the language for the On-Screen Display (OSD) menus. See Language "Using the menus" on page 23 The projector can be installed on a ceiling or behind a screen, or Projector with one or more mirrors. See Position for details. Allows the projector to turn off automatically if no input signal Auto Power is detected after a set period of time.
  • Page 70 Function Audio Settings Menu Settings Closed Caption Operation Description The sound adjustments made as below will have an effect on the projector speaker. Be sure you have made a correct connection to the projector audio input/output jacks. See "Playing sound through the projector" on page 19 more details.

  • Page 71: Reset All

    Function Lamp Mode "Setting Lamp Mode as Economic" on page 69 Reset Lamp Timer Lamp "Resetting the lamp timer" on page 73 Settings Equivalent Lamp Hour "Getting to know the lamp hour" on page 69 how the total lamp hour is calculated. Presentation "Setting the presentation timer"...

  • Page 72: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.

  • Page 73: Lamp Information

    Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. To obtain the lamp hour information: Press MENU/EXIT on the projector or Menu on the remote control and then press until the SYSTEM SETUP: Advanced menu is highlighted.

  • Page 74: Timing Of Replacing The Lamp

    Timing of replacing the lamp When the Lamp indicator lights up red or a message appears suggesting it is time to replace the lamp, please install a new lamp or consult your dealer. An old lamp may cause a malfunction in the projector and in some instances the lamp may explode. CAUTION The Lamp indicator light and Temperature warning light will light up if the lamp becomes too hot.

  • Page 75: Replacing The Lamp

    Be careful of sharp edges in the lamp compartment. Wash hands after lamp replacement. • Only ViewSonic certified lamps are tested with this projector. Use of other lamps may cause electrical shock and fire. Turn the power off and disconnect the projector from the wall socket.
  • Page 76 Lift the handle so that it stands up. Use the handle to slowly pull the lamp out of the projector. CAUTION • Pulling it too quickly may cause the lamp to break and scatter broken glass in the projector. • Do not place the lamp in locations where water might splash on it, children can reach it, or near flammable materials.

  • Page 77: Resetting The Lamp Timer

    Tighten the screws that secure the lamp cover. CAUTION • Loose screw may cause a bad connection, which could result in malfunction. • Do not over tighten the screws. Restart the projector. CAUTION Do not turn the power on with the lamp cover removed. Resetting the lamp timer After the startup logo, open the On-Screen Display (OSD) menu.
  • Page 78 Indicators Light Power Temp Blue Flashing Blue Blue Purple Flashing Blue Blue Purple Purple Green Maintenance Status & Description Lamp Power events Stand-by mode Powering up Normal operation Lamp events The projector has shut down automatically. If you try to re- start the projector, it will shut down again.

  • Page 79: Troubleshooting

    Troubleshooting The projector does not turn on. Cause There is no power from the power cord. Attempting to turn the projector on again during the cooling process. No picture Cause The video source is not turned on or connected correctly. The projector is not correctly connected to the input signal device.

  • Page 80: Specifications

    IR receiver x 2 Environmental Requirements Operating temperature Operating relative humidity Operating altitude Specifications PJD7383/PJD7383i 1024 x 768 XGA 1-CHIP DMD F = 2.6, f = 6.9 mm 210 W lamp AC100–240V, 3.29 A, 50/60 Hz (Automatic) 329 W (Max); < 1 W (Standby) 3.5 Kg (7.7 lbs)

  • Page 81: Dimensions

    Dimensions 290 mm (W) x 126 mm (H) x 254 mm (D) Ceiling mount installation 14.04 Timing chart Supported timing for PC input Horizontal Resolution Frequency 720 x 400 640 x 480 800 x 600 Vertical Frequency (kHz) (Hz) 31.469 70.087 31.469 59.94...
  • Page 82 1024 x 768 1280 x 800 1280 x 960 1440 x 900 1400 x 1050 1600 x 1200 640 x 480@67Hz 832 x 624@75Hz 1024 x 768@75Hz 1152 x 870@75Hz Supported timing for Component-YP Signal Format 480i(525i)@60Hz 480p(525p)@60Hz 576i(625i)@50Hz 576p(625p)@50Hz 720p(750p)@60Hz 720p(750p)@50Hz 1080i(1125i)@60Hz...

  • Page 83: Copyright And Regulation Information

    Copyright 2010. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of ViewSonic Corporation. Disclaimer...

  • Page 84: Appendix

    Appendix IR control table Power Freeze Down Left Right/Key Lock Color Mode Volume+ Volume- Auto/Page Down Source/Page Up Blank Menu/Mouse L key Magnify + Magnify - Enter Exit/Mouse R key Mute VGA1 VGA2 Video Keystone + Keystone - Mouse Timer RS232 command table <Pin assignment for this two end>...
  • Page 85 Turn on Write Turn off Power Power Read status (on/off) Reset Execute Splash Screen Black Splash Screen Blue Splash Screen Write ViewSonic Splash Splash Screen Screen Screen Capture Splash Screen Off Splash Read Screen status High Altitude Mode Off Write High...
  • Page 86 Write Message Read Write Projector Position Read Write 3D Sync Read Write 3D Sync Invert Read Write Contrast Read Write Brightness Read Write Aspect ratio Read Auto Adjust Execute Write Horizontal position Read Appendix Message 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x27 0x00 0x84 Message 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x27 0x01 0x85 Message...
  • Page 87 Vertical position shift up Write Vertical Vertical position position shift down read Read Vertical position color temperature color temperature Write color Color temperature temperature color temperature color Read temperature status Blank on Write Blank Blank off Read Blank status 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x12 0x09 0x68 Decrease Write Keystone-...
  • Page 88 Write Read Write Saturation Read Write Gain Read Write Freeze Read Write Source input Read Write Quick Auto Search Read Write Mute Read Write Volume Read Appendix 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x11 0x00 0x6F decrease 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x11 0x01 0x70 increase 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x12 0x11 0x70 Saturation...
  • Page 89 Write Language Read Language Reset Lamp Write usage hour Lamp Time Lamp Read usage hour Read error Error status Read status Disable PointBlank Write Enable PointBlank PointBlank PointBlank Read status 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x00 0x61 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x01 0x62 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x02 0x63 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x03 0x64...

  • Page 90: Customer Support

    (Mexico) Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: 01.222.891.55.77 CON 10 LINEAS Electroser, Av Reforma No. 403Gx39 y 41, 97000 Mérida, Yucatán. Tel: 01.999.925.19.16 Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico Latin America (Peru) www.viewsonic.com/la/ Macau www.hk.viewsonic.com...

  • Page 91: Limited Warranty

    If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
  • Page 92 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon inconvenience,...

  • Page 93: Mexico Limited Warranty

    ViewSonic warrants its products to be free from defects in material and workmanship, under normal use, during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
  • Page 94 E-Mail: rrrb@sureste.com Tijuana: Av Ferrocarril Sonora #3780 L-C Col 20 de Noviembre Tijuana, Mexico 4.3: ViewSonic Mexico Limited Warranty Villahermosa: Compumantenimietnos Garantizados, S.A. de C.V. AV. GREGORIO MENDEZ #1504 COL, FLORIDA C.P. 86040 Tel: 01 (993) 3 52 00 47 / 3522074 / 3 52 20 09 E-Mail: compumantenimientos@prodigy.net.mx...
