U S E R M A N U A L

Advertisement

Table of Contents
loading

Related Manuals for Smeg 899 Series

Summary of Contents for Smeg 899 Series

  • Page 1 U S E R M A N U A L...
  • Page 3 Index Important directions for safety and the environment Page For your safety Caring for the environment Cleaning, sanitization and maintenance of the ice and/or water dispenser (if present) Installation Installation Connection to the electrical power supply Connection to the water system Before starting Know your appliance Main features...

  • Page 4: Important Directions For Safety And The Environment

    Styrofoam. Warning Indications for avoiding injury Any repairs must be performed by a qualified Smeg Service tech- to people nician. This appliance is not intended for use by persons (including children)

  • Page 5: Caring For The Environment

    Important directions for safety and the environment Caring for the environment Pay special attention to correct disposal procedure for all the pack- aging materials. The appliance must not be disposed of with urban waste. Contact lo- cal waste disposal centers for on how to dispose of recyclable waste. Prior to disposal, cut the power supply cord and make it impossible to close the door.

  • Page 6: Installation

    Installation Installation Make sure that installation is performed correctly, adhering to all direc- tions in the specific installation manual provided with the appliance. Connection to the electrical power supply The appliance is equipped with a Schuko type 16A plug and must be connected to the electrical power supply through a corresponding Schuko socket.

  • Page 7: Connection To The Water System

    Installation Connection to the water system The models provided with Ice Maker require a connection to the do- mestic water supply system. This can be executed through the pro- vided water hose with 3/4” threading. The system pressure must be between 0.05 MPa and 0.5 MPa (between 0.5 Bar and 5 Bar).

  • Page 8: Before Starting

    Should you require further information, please check our website www.smeg.com Main features The Smeg Multizone refrigeration system and the efficient separation of internal compartments ensures maximum Stainless steel surface both inside and outside, with fine freshness and offers excellent conservation of foods in the aluminum trim three compartments: refrigerator, Multizone.

  • Page 9: Main Components

    Before starting Main components Single drawer Fridge 2 Control panel with Menu 3 Water Filter 4 Patented shelf positioning system 7 Drawer with controlled humidity 8 Automatic icemaker 9 Double refrigeration system 10 Temperature display 11 Sound signals 12 Holiday function 13 Spacious door shelves 14 Innovative lighting 15 Automatic door and...

  • Page 10: Electronic Control

    Before starting Electronic Control Componenti principali The electronic control system maintains constant temperature on the two compartments and visualizes it on the control panel display. It also allows user interaction making it possible to personalize settings of the various functions and to receive sound and/ or visual messages should occur any malfunction in the appliance.

  • Page 11: Appliance Switching On And Off

    Appliance switching on and off Switching on and off First startup When the appliance is connected to the electrical power supply but has not yet been switched on, the display shows the message Tis is a safety message to warn that the appliance is connected to the mains, and all the panel buttons are off.

  • Page 12: How To Adjust The Temperature For Different Requirements

    Appliance switching on and off How to adjust the temperature for different requirements Each model has been carefully tested before leaving the factory and is adjusted in such a way to ensure high performance and low con- sumption. Usually, it is not necessary to modify the settings. Nevertheless, according to special needs, it is possible to modify the set temperatures as follows: Refrigeration Compartment...

  • Page 13: Settings And Special Functions

    Settings and Special Functions Customization and language settings It is possible to customized the functions of your Smeg to adapt it to diverse usage needs, resetting the main parameters (Settings) or acti- vating special functions (Functions). To prevent an inadvertent change to the settings...
  • Page 14 Settings and Special Functions Holiday fridge Holiday Fridge This function (recommended in case of prolonged absences since it al- lows considerable energy savings) brings the refrigerator compartment temperature to +14°C (57.2°F). It is possible to program the duration, or it can be manually deactivated upon re-entry after a period of absence.
  • Page 15 Settings and Special Functions Holiday Multizone This function (recommended in case of prolonged absences since it allows considerable energy savings) brings the Multizone compart- ment temperature to - 18°C (46.4°F). It is possible to program the duration, or it can be manually deacti- vated upon re-entry after a period of absence.
  • Page 16 Settings and Special Functions Sabbath Mode (Optional) The function makes it possible to comply to certain religious observ- ances requiring that the operation of the appliance is not affected by the opening or closing of the doors (the thermostatic control, the inner lighting and the ice maker are deactivated).
  • Page 17 Settings and Special Functions Basic settings of the Menu Select the Menu button and used the Up/Down button to select Multizone Options The freezer compartment can, if required, be converted to the re- frigeration o 0°C operating mode. Settings Multizone Options How to set the Fridge function Fridge Enter to confirm...
  • Page 18 Internal Layout Set 12/24 This function selects the display at 12 or 24 h. Settings Time Set View How to set the display to 12 h Set: 12 Settings Time Set View How to set the display to 24 h Set: 24 Show Time Through this function it is possible to activate/deactivate the constant...

  • Page 19: Internal Layout

    Internal Layout Multizone Drawer The upper Multizone can be removed using the same method used for the 0°C drawer to remove the inner Multizone drawer unscrew the thumbscrews. When replacing the drawers, make certain the back of the drawers engage under the clips on the slide guides. Ice Tray Located in the upper drawer of the freezer compartment after removal, make sure to reposition it correctly.

  • Page 20: Activation And Use Of The Ice Maker

    Activation and use of the Ice Maker Activation and use of the Ice Maker If the ice is not used frequently is advisable to To activate the Ice Maker after installation of the appliance, press the empty the ice bin once every 8-10 days. Icemaker button It is normal that some ice cubes stick to one Please note that 12 to 24 hours are necessary before ice production...

  • Page 21: Water Filter

    Filter Replacement Prior to changing the filter, switch off the Ice Maker by pressing the Ice- Maker button. Then enter the Smeg Access Menu and set “Manual Clean” function. At the end of the cleaning cycle remove the water from the ice tray and wipe it dry.
  • Page 22 LED lights directly illumi- nate different areas of the refrigerator compartment and the freezer drawer. In case of malfunction and/or wearing out of the lighting system, the repair should be carried out by a qualified Smeg Service technician.

  • Page 23: Food Preservation

    Food Preservation Recommendations for preserving fresh food Vegetables Wash vegetables in cold water and dry well. Place vegetables in vacuum packed containers, plastic containers or vegetable bags in a 0°C Drawer. Fruit Wash and dry fresh fruit. Pack very aromatic fruit in plastic bags. Fruit should be placed in the high humidity 0°C compartment.

  • Page 24: Recommended Times For Food Preservation

    Recommended times for Food Preservation Fresh foods Preservation area Time Raw meats Large cuts 0°C Compartment 4 days Beef steaks, poultry and wild game 0°C Compartment 3 days Ground meat 0°C Compartment 1-2 days Carpaccio 0°C Compartment Immediately Cooked meat Boiled meat and roasted meat Refrigerator Compartment 2 days...

  • Page 25: Care And Cleaning

    Care and Cleaning 11.1 Care and Cleaning To clean the parts made of steel use a microfiber cloth and the sponge provided in the kit with the appliance. Always use the cloth and sponge in the direction of the steel’s satin finish. Every now and then, to polish the steel, wipe with a slightly damp micro- Scrupulously follow the detailed directions that fiber cloth.

  • Page 26: Troubleshooting Guide

    Troubleshooting Guide 12.1 Troubleshooting Guide If you notice malfunctions in your appliance, use this guide before calling for service: this guide can help you personally resolve the problem or could provide important information to be conveyed to the service technician to ensure rapid and effective repair. Malfunction message A malfunction is usually indicated by a message on the display.

  • Page 27: Malfunction Indications Appearing On The Display

    Troubleshooting Guide The Ice Maker does not work Make sure that the Ice Maker is on (Icemaker button on). To switch on the Ice Maker press the button. Make sure that the appliance is connected to the water supply. The Ice Maker does not produce On average, the Ice Maker produces approximately 10 cubes of ice sufficient amounts of ice every two and half hours.
  • Page 28 Smeg Access Menu Map 13.1 Functions Shopping Fridge Off Shopping ON/OFF Shopping Fridge On Shopping Fridge Shopping Time Set Hours: 1 Holiday Fridge Off Holiday ON/OFF Holiday Fridge On Holiday Fridge Holiday Time Set Hours: 1 Shopping Multiz Off Shopping ON/OFF...
  • Page 29 Smeg Access Menu Map 13.2 Setting Freezer Fresco Multiz Options Fridge Default Setting Enter to Confirm Set Date DATE: 01-01-2009 Date DATE: 01-01-2009 On Show Date DATE: 01-01-2009 Off Set Time TIME: 01:01 TIME: 01:01 On Time Show Time TIME: 01:01 Off...
  • Page 33 I N S T A L L A T I O N G U I D E...
  • Page 34 IMPORTANT Dimensions in parentheses are in inches. Weights in parentheses are in pounds. Temperatures in parentheses are in Fahrenheit degrees.
  • Page 35 Installation Guide Index Important Instructions Important safety instructions Page Children safety Technical requirements Appliance features and installation requirements Installation niche features: Integrated Installation niche features: Free-Standing Preparing to install Transport to installation site and unpacking Electrical and Water connection Levelling Panels mounting Decorative door and Bottom-Drawer panels layout Decorative panels layout for Fridge with one Bottom-Drawer...

  • Page 37: Children Safety

    Installation Guide Important safely instruction Note Symbols used in the Guide Tips for the correct use of the appliance Important Directions to avoid appliance damage Warning directions to prevent injury Children safety If this appliance is replacing an existing appliance which must be removed or disposed of, make sure that it does not become a dangerous trap for children by cutting its power supply cable and rendering it impossible to close the door.

  • Page 38: Appliance Features And Installation Requirements

    Appliance features and installation requirements Appliance dimensions 60 Series w: 599 mm (23 5/8”)/ h: 2050 mm (80 3/4”)/ d: 610 mm (24”) Integrated 75 Series w: 749 mm (29 1/2”)/ h: 2050 mm (80 3/4”)/ d: 610 mm (24”) 90 Series w: 899 mm (35 3/8”)/ h: 2050 mm (80 3/4”)/ d: 610 mm (24”) Appliance dimensions...
  • Page 39 Installation Guide Installation niche features: Integrated Series area to be left clear for the anti-tipping brackets Door Opening Angle area to be left clear for the power supply cable 105° and water supply hose Width Minimum Niche Height RI96: 899 mm (35 3/8”) 2064 mm (81 1/4”) RI76: 749 mm (29 1/2”) WI66: 599 mm (23 5/8”)
  • Page 40 Installation niche features: Free-Standing Series area to be left clear for the anti-tipping brackets Door Opening Angle area to be left clear for the power supply cable 105° and water supply hose Width Minimum Niche Height RF396: 886 mm (34 7/8”) 2134 mm (84”) RF376: 736 mm (29”) WF366: 586 mm (23”)

  • Page 41: Preparing The Installation

    Installation Guide Series: All Preparing the installation Transport to installation site Since this is a large and heavy appliance, before transporting the ap- and unpacking pliance, check the access to the location where it will be installed (door size, manoeuvring space in stairwells, etc.). The appliance is attached to the base of the packaging (pallet) through four bolts which can be removed using a 17 mm (3/4”) wrench.

  • Page 42: Electrical And Water Connection

    Series: All Electrical and Water connection A Schuko 16 A socket with an efficient grounding should be made available for the electrical mains connection, as well as an omnipolar switch which can easily be reached when the appliance is installed. To connect to the water supply system (for appliances equipped with ice makers) a tap with a male 3/4”...
  • Page 43 Installation Guide Series: Integrated Back of appliance Electrical connection Water connection Operate as follows: Unwind the electric cable and connect it directly to the wall socket. Make sure the appliance is in the Stand-by condition and that all lights are off; should it be not so press the Unit button to switch it off.
  • Page 44 Series:Free-Standing Back of appliance Electrical connection Water connection Front of appliance Operate as follows: Unwind the electric cable and connect it directly to the wall socket. Make sure the appliance is in the Stand-by condition and that all ights are off; should it be not so press the Unit button to switch it off.
  • Page 45 Installation Guide Series: All Levelling Adjust the appliance level by means of the front levelling feet and the rear adjustable wheels. Operate as follows: After removing the bottom plinth or grille (it is kept in position by magnets), adjust the height of the levelling feet by means of a 17 mm (3/4”) open spanner.

  • Page 46: Decorative Door And Bottom-Drawer Panels Layout

    Series: Integrated Decorative door and bottom-drawer panels layout The dimensions of the panels are indicated in the table and draw- ings on pages 18-21. Nevertheless, according to the requirements for aligning with other kitchen structures, the door panel can be higher than the upper edge of the refrigerator door, and the drawer panel can be lower than the edge of the drawer.
  • Page 47 Installation Guide Series: Integrated Position the brackets on each set of marks to make sure they are aligned , then drill holes through the panel (pay close attention to the panel’s thickness) Screw the brackets in place Drawer Panel When preparing the Drawer Panel, follow the same instructions as per the door panel, but make sure measurements are taken starting from the top edge .
  • Page 48 Series: Integrated Decorative panels layout for Fridge with one Bottom-Drawer Series 75 Series 90 ¼” �⁄�” 897 (35 747 (29 ½” ½” 418 (16 343 (13 ½” ½” 418 (16 343 (13 F / G 354.5 (14”) 279.5 (11”) Holes positions ½”...
  • Page 49 Installation Guide Series: Integrated Decorative panels layout for Fridge with glass door and one Bottom-Drawer Series 60 Hinge Left Hinge Right ½” ½” 597 (23 597 (23 �⁄�” ½” 276.5 (10 268 (10 ½” �⁄�” 268 (10 276.5 (10 F / G 203.5(8”) 203.5(8”) �⁄�”...
  • Page 50 Series: Integrated Panels Dimensions One Bottom - Drawer Panels with width ranging between 18 mm (3/4 in) and 28 mm (1 1/8 in). Door panels with weight max of 23 kg (51 lb) and drawer panels with weight max of 11kg (25 lb) Series Door/Drawer Width Door Cutout Width...
  • Page 51 Installation Guide Series: Integrated Mounting panels to the door and the drawer Once all brackets and small brackets have been applied to the pan- els, you can begin installing the bottom drawer. Operate as follows: Partially tighten the screw to the fixing Hook the bottom drawer panel starting from the fixings on the bot- It is now possible to align panels to adjacent cabinets in height using the lower alignment brackets,...
  • Page 52 Series: Integrated Hook the panel to the fixing devices starting from the top aligning bracket At this point, alignment between the panel and adjacent cabi- nets can be adjusted using the alignment bracket and small brack- Vertical alignment: tighten or loosen the screw in the brackets to raise or lower the panel Depth alignment: working from the inside of the door, after lift- ing up the magnetic seal, adjust the panel position so it is closer to...

  • Page 53: Installation

    Installation Guide Series: Integrated Installation Built-in installation single appliance For a built-in installation, to close gaps between the appliance and the adjacent cabinets, special side profiles and aluminum covering frames are provided. Operate as follows: Push the appliance into the installation niche If the unit is to be installed inside a niche or within an enclosed structure, it is necessary to design a ventilation shaft at the back of the niche to assure proper ventilation at the back of the unit.
  • Page 54 Series: Integrated Built-in installation two or more appliances Required accessories to be ordered separately: Central connection Kit Special side profiles and aluminum covering frames are provided for closing gaps between the appliance and the adjacent cabinets. Operate as follows: Position the appliances in front of the installation area, leaving enugh space to operate at their back Move at the back of the appliances to mount the joining brackets: fix on side of the top and lower brackets to one of the appliances...
  • Page 55 Installation Guide Series: Integrated Once completed the previous steps, push the units in their final posi- tion If the units are to be installed inside a niche or within an enclosed structure, it is necessary to design a ventilation shaft at the back of the niche to assure proper ventilation at the back of the unit.
  • Page 56 Series: Integrated Free-standing installation Operate as follows: two or more appliances Position the appliances in front of the installation area, leaving enough space to operate at their back. Move at the back of the appliances to mount the joining profile Place the two units side by side and join them at the front attach the bracket on top of the units as per figure and at the bottom...

  • Page 57: Anti-Tipping Safety Assembly

    Installation Guide Series: Integrated Anti-tipping safety assembly ” ) � ⁄ � 4 5 ( To prevent the appliance from tipping over an extra-long kit is vailable up on request if the appliance needs to remain distanced from the wall, it is mandatory to install two brackets on the upper part of the appliance for fixing it securely to the wall.
  • Page 58 Series:Free-Standing Anti-tipping safety assembly To avoid danger of the appliance tipping over when opening full doors and drawers, it is mandatory to install two brackets on the upper part of the appliance for fixing it securely to the wall. The brackets should be applied as illustrated using the provided screws and expansion plugs.
  • Page 59 Installation Guide Series:Free-Standing Fit the brackets and secure them to the wall , remove the ventila- Anti-tipping safety assembly: full integration tion grid and the frontal closing Make the electrical and water connection (see page 8) and push the unit Insert the brackets to the rear holes Fix brackets and reinstall the removed parts...
  • Page 60 Series: Free-Standing Mounting the handles on stainless front To mount the handles onto the door and the drawer operate as follows: Operate as follows: Insert the two handle spacers onto the supports already available on the door and the drawer Screw in the Allen screws available on the handle The screws must be tightened in by means of a 2.5 mm (1/8”) hex wrench.
  • Page 61 If the grille is partially covered by the kitchen kickplate, it is advisable to remove the grille in order to provide for a better airflow. 899 Series 749 Series 599 Series 860 (33 �⁄�”) 740 (29 �⁄�”) 560 (22”)
  • Page 62 Series:Free-Standing Ventilation Ventilation is insured by a forced air system through a grille located in the upper part of the appliance. This grille should never be covered by panels or any other devices that could reduce its efficiency. Please refer to page 5-6 to ensure correct air circulation.

  • Page 63: Post Installation Control

    Installation Guide Series: All Post installation control Check that the front levelling feet have been properly installed. Check that the connection to the water system does not have any leaks and that the closing tap is easily accessible. Check that the electrical connection is correctly installed and that the multipole switch and socket are easily accessible.
  • Page 64 Series: All Start up To start the appliance, connect the plug to the electrical mains: at this point, when opening the door, the control panel will usually visual- ize the message “Stand by”, and all the panel keys be off To turn on all the appliance compartments, press the Unit button for three seconds.
  • Page 65 Installation Guide...
