Summary of Contents for JVC DM-ND300E
- Page 1 MPEG-2 NETWORK DECODER DM-ND300E Instruction Manual This instruction book is made from 100% recycled paper. LST0166-001B...
- Page 2 SAFETY PRECAUTIONS Maintaining the unit (Please turn off Place of storage and use the power before performing main- Please avoid storing or using this unit in tenance work.) the following places: ●Extremely hot or cold places beyond the Please wipe the unit with a soft cloth. Do not wipe it with thinner or benzene lest the allowable temperature for operation (5˚C- surface melts or becomes dull.
- Page 3 SAFETY PRECAUTIONS (FOR EUROPE) POWER SYSTEM IMPORTANT (In the United Kingdom) Mains Supply (240 V AC g , 50 Hz only) Connection to the mains supply IMPORTANT This unit operates on voltage of 220 V to 240 V AC, 50 Hz/60 Hz. Do not make any connection to the Larger Terminal coded E or Green.
- Page 4 Sicherheitshinweise Betrieb und Lagerung Reinigung (Schalten Sie das Gerät Lagern und betreiben Sie das Gerät nicht unbedingt ab, bevor Sie die in Umgebungen, in denen Reinigung durchführen!) ●extrem hohe oder niedrige Temperaturen Wischen Sie das Gerät mit einem weichen (unter 5°C oder über 35°C) herrschen, ●extrem hohe oder niedrige Luftfeuchtig- Tuch ab.
- Page 5 VERSORGUNG WICHTIG (bei Betrieb in Großbritannien) NETZSPANNUNG: 240 V AC, 50 Hz Anschluss an das Stromnetz ACHTUNG! Das Gerät wird mit einer Netzs- pannung von 220 V bis 240 V AC, 50 Schließen Sie keinen Leiter an den Hz/60 Hz betrieben. Kontakt des Steckverbinders an, der mit dem Buchstaben E markiert oder GRÜN farbkodiert ist.
- Page 6 TECHNISCHE DATEN AC-Netzteil AC-Eingang 220 V bis 240 V AC, 50 Hz/60 Hz DC-Ausgang 9 V DC, 1,66 A Abmessungen 90 × 58 × 28 mm 180 ˝ Gewicht AC-Kabel ca. 1,80 m (abnehmbar) DC-Kabel ca. 1,80 m...
- Page 7 Sonstinge Vorsichtsmaßnahmen Diese Anlage steht in Übereinstimmung mit den Bestimmungen und Schutzanforderungen der anwendbaren EU-Richtlinien. Diese Anlage wurde für professionelle Videoanwendungen entwickelt und ist für den Einsatz in den folgenden Umgebungen vorgesehen: 5 Wohnbereiche (im geschlossenen Raum) 5 Handel und Leichtindustrie (z. B. Bürogebäude oder Theater) 5 innerstädtische Freiluftbereiche Für optimale Leistung und aus Gründen der elektromagnetischen Kompatibilität empfehlen wir die Verwendung von Kabeln, die folgende Längen nicht überschreiten:...
-
Page 8: Table Of Contents
Thank you for choosing JVC’s MPEG-2 network decoder DM-ND300E. Key Features ● This equipment is operated using a remote controller. ● Standard network protocols compliant. Stream control and transport are RTSP and RTP compliant. ● Receives and decompresses MPEG-2 stream up to a maximum of 10Mbps and outputs analog composite signal, YC signal as well as analog audio signals. -
Page 9: Check Of Accessories / Bundled Items
1. Check of Accessories / Bundled Items Accessories/bundled items included with the network decoder are listed as follows. Check if there is any shortage and contact the sales outlet at which the purchase is made if neces- sary. (1) Instruction Manual (4) AC Cord (Approx. -
Page 10: Names And Functions
2. Names and Functions Front Panel DM-ND300E MPEG-2 NETWORK DECODER POWER PLAY LINK 100M 6 7 8 9 0 ! @ 2 3 4 5 POWER LED (Green) 100M LED (Green) Lights up when power is turned on. Displays the connection speed of network. - Page 11 Rear Panel RIGHT LEFT VIDEO OUT1 RESET REMOTE AUDIO OUT VIDEO OUT2 DC9V REMOTE VIDEO OUT 2 Remote terminal. Y/C video signal output terminal. Not applicable to this equipment. RESET Use only in cases of emergency to reset Serial connection port (COM Port). equipment.
- Page 12 2. Names and Functions (Continued) Remote Controller (1) When system does not make use of a menu server HOME Button To play back the network encoder that has been pre-assigned. MENU Button Same function as HOME button. Number Buttons To play back the network encoder that has been pre-assigned.
- Page 13 Operating the Remote Controller To show the previous menu. 1. Send data by directing toward the ‘re- Number Buttons mote control sensor’ of DM-ND300E. To execute the corresponding item on the 2. Range between the remote controller menu. and the front face of the sensor is within 5 m.
-
Page 14: How To Operate
Press the Stop button on the remote controller to stop playing back the video/sound. PRECAUTION When the network encoder is set as Unicast, access by other DM-ND300E’s are denied during the Play Back or Pause mode. Access by other DM-ND300E’s is possible upon switching to the Stop mode. -
Page 15: Specifications
4. Specifications Design and specifications are subject to change for improvement without prior notice. DM-ND300E main unit Compression format Video ISO/IEC13818-2 (MPEG-2 VIDEO) Compression: MPEG-2 Video format: 480i Frame rate: 25 Hz Audio ISO/IEC11172-3 (MPEG-1 Layer II Audio) Compression: MPEG-1 layer II... -
Page 16: Caution For Cables
5. Caution for Cables This equipment is in conformity with the provisions and protection requirements of the corre- sponding European Directives. This equipment is designed for professional video appliances and can be used in the following environments: 5 Residential area (in houses) 5 Commercial and light industry;... -
Page 17: Saving Energy
6. Saving Energy Turn off the power when not in use to save energy. 7. Others 1. All rights are reserved with regard to a portion or the entire manual. 2. Contents of this booklet may be altered without any prior notice. 3. - Page 18 Dimension (Unit=mm) DM-ND300E MPEG-2 NETWORK DECODER POWER PLAY LINK 100M...
- Page 20 VICTOR COMPANY OF JAPAN, LIMITED ® is a registered trademark owned by VICTOR COMPANY OF JAPAN, LTD. ® is a registered trademark in Japan, the U.S.A., the U.K. and many other countries. LST0166-001B © 2003 VICTOR COMPANY OF JAPAN, LIMITED...
