Grizzly T10435 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
To reduce the risk of serious personal
injury, death, or property damage:
Only use these chock/locks on tandem-
•
axle trailers rated at Class 4 or less.
• Only use the chock/locks as a pair when
the trailer can be parked on a hard,
level ground. Never use the chock/locks
alone as a parking brake—although they
help with braking, additional chocks or
wedges must be used.
• Even if the chock/locks are in use,
never place your body between the
tandem wheels or in the rolling path of
the trailer.
• Never allow children to play with the
chock/locks, especially while in use.
• Inspect the chock/locks for cracked
welds, worn pivots, stripped threads, or
any other damage. Never drill, weld, or
modify the chock/locks in any way, and
never use them if they are damaged.
• Make sure the trailer landing gear is
correctly supporting the trailer, and all
tires are inflated correctly to the trailer
manufacturer's specifications.
• Never attempt to use the chock/locks
as jacks. Never use a cheater pipe to
tighten the lock levers or overload the
chock/locks. Doing so can damage the
chock/locks and tires.
WARNINg: NO pORTION OF THIS MANUAL MAy bE REpRODUCED IN ANy SHApE
OR FORM WITHOUT THE WRITTEN AppROvAL OF gRIzzLy INDUSTRIAL, INC.
COPyRiGHT © JUNE, 2011 By GRiZZLy iNDUSTRiAL, iNC.
#CR14166 PRiNTED iN CHiNA
MODEL T10435
TANDEM CHOCK/LOCKS
INSTRUCTIONS
Figure 1. Model T10435.
Introduction
The Model T10435 Tandem Chock/Locks stop
an RV or boat trailer from rocking back and forth
when climbing onto or when moving around
inside. Often wheel chocks by themselves do not
offer enough stability. When installed in between
the tandem axles on both sides of the trailer, the
chock/locks provide the required stability. When
a padlock is used to secure the lock lever, the
chock/locks also serve as an additional means
to prevent trailer theft. The scissor design and
single-action levers make installation and removal
fast and easy.
Specifications
Maximum Trailer GVWR ..... 10,000 lbs (Class 4)
Adjustment Range Between Tires . ...........1
Collapsed Size (Each) . .............. 1 6
Construction ................................................ Steel
Holes for Optional Padlocks . ....................
Anti-Corrosion Finish . .......................Zinc-Coated
Weight .............................. 11 lbs. (5.5 lbs. Each)
⁄ "–6"
1
2
⁄ " x 4 ⁄ " x 3"
1 1
2 2
⁄ " Dia.
3
8
