Tripp Lite B112-002-R Specification Sheet

Model #: P500-100-P
100-ft. Plenum Rated SVGA/VGA Monitor Extension Cable, (HD15 M/F)
Description
Tripp Lite's Plenum Rated SVGA Extension cable is ideal in Educational or Commercial installations where local fire codes call for a CMP rated cable
to run through walls, ceilings, and plenum air chambers. 100ft distance is achieved through high quality construction: 75ohm Coaxial conductors for
Red, Green, and Blue (RGB) signals, each protected by a 93% tinned copper braid shield. An overall shiled of Mylar foil and 85% Copper Braid
shield ensures maximum signal integrity.
Applications
Educational or Commercial locations where Fire Codes dictate the use of Plenum Rated cables. Ideal for schools with suspended ceiling
mount projectors, or retail locations with Plasma screen displays.
System Requirements
Monitor with HD15 cable
Package Includes
100-ft. Plenum Rated XVGA/SVGA/VGA Monitor Extension Cable HD15M to HD15F Gold Connectors w/ RGB Coax
Features
Superior molded cables with foil and braid shielding for maximum EMI/RFI protection
UL Listed, CMP Rated Cable Jacket
Constructed from mini-coax (RGB) and paired video wire construction for superior signal quality
Resolution supported for VGA, SVGA, XGA, SXGA, UXGA, QXGA
Gold plated connectors and gold plated copper contacts ensure excellent conductivity
HD15 male to HD15 female molded connectors

Specifications

OVERVIEW
Intended Application
Display Style
Highlights
Connecting Peripherals
Direct Connect
UL Listed, CMP rated cable
Superior molded cables with foil and braid shielding for maximum EMI/RFI
protection
Constructed from 75ohm mini-coax (RGB) and paired video wire construction
for superior signal quality
Gold plated connectors and gold plated copper contacts
