π
H-738, H-814
deluxe pusHer
tensioner
Tools Needed
Single Notch Sealer
sTrap specificaTioNs
Model
#
WIDTH
H-738
3/8 to 3/4"
.015 to .023"
H-814
3/4 to 1¼"
.025 to .035"
iMporTaNT: read all operating instructions.
EyE INjUry HAzArD
Always wear safety glasses with side shields that
conform to ANSI Standard z87.1.
Pawl
PAGE 1 OF 2
1-800-295-5510
uline.com
GAUGE
GeNeral safeTY
STrAP brEAkAGE HAzArD
Place the strap correctly around a properly positioned
load. Improper strapping or unstable or shifted loads
may result in a sudden loss of strap tension during
tensioning, causing you to lose your balance and fall.
Use edge protectors if the load corners are sharp.
Position yourself to one side of the strap and keep all
bystanders away. Do not position yourself in line with the
strap during tensioning and sealing. Severe personal
injury from flying strap or tool can result.
refereNce
Tension Handle
Lift Arm
0714 IH-738
Advertisement
Related Manuals for U-Line H-738
Summary of Contents for U-Line H-738
- Page 1 π H-738, H-814 1-800-295-5510 uline.com deluxe pusHer tensioner Tools Needed Single Notch Sealer sTrap specificaTioNs Model WIDTH GAUGE H-738 3/8 to 3/4" .015 to .023" H-814 3/4 to 1¼" .025 to .035" GeNeral safeTY STrAP brEAkAGE HAzArD iMporTaNT: read all operating instructions.
- Page 2 operaTioN 1. Thread the strap through the seal and around the 4. When desired tension is reached, push the drive bundle. Thread the strap through the seal again. pawl forward and lower the tension handle until it bend the lower strap sharply to hook the lower lip of contacts the lift arm.
