USE, INSTALLATION AND MAINTENANCE
INSTRUCTIONS FOR ELECTRICAL
Dear User,
we are sincerely grateful to you for purchasing one of our products.
We are sure that the appliance modern, functional and easy to use, built with the finest materials
and components will satisfy all your needs.
We would ask that you read the instructions within this booklet very carefully so as to enable you
to obtain quality results from the outsets.
The appliance must be installed only by a qualified electrician in compliance with the
instructions provided. The manufacturer declines all responsability for improper installation.
Model: PB1328
The manufacturer is not responsible for any transcription errors or misprints contained in this handbook and,
furthermore, reserves the right to make any modification on the products, which might be deemed
necessary or usefull, this being in the user's interest, without altering their basic operating or safety
features. This cook top was designed to be used exclusively as a cooking appliance: any other use
(such as heating rooms) is to be considered improper and dangerous.
BUILT-IN HOT PLATES
COD. 04043DN - 03.04.20514
