Panasonic KX-CLPF1 Service Manual

Panasonic KX-CLPF1 Service Manual

Optional paper feeder
Hide thumbs Also See for KX-CLPF1:
Table of Contents

Advertisement

Quick Links

Download this manual
CONTENTS
KX-CLPF1
Page
3
3
4
5
5
8
8
9
© 2003 Panasonic Communications Co., Ltd.
All rights reserved. Unauthorized copying and
distribution is a violation of law.
ORDER No.KM60305628C0
Optional Paper Feeder
G0
Page
10
12
13
13
14
17
19

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-CLPF1

Summary of Contents for Panasonic KX-CLPF1

  • Page 1: Table Of Contents

    2.2. Feeder Board 3.2. General Descriptions 2.3. Paper Size Switch 3.3. Schematic Diagram 2.4. Sensor Board, Motor and Pickup Solenoid 4 Troubleshooting © 2003 Panasonic Communications Co., Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law.
  • Page 2 KX-CLPF1 5 Replacement Parts List with Lubrication Guide 5.4. Packing Material 5.1. Covers 5.5. Feeder Board 5.2. Chassis 5.6. Paper Empty/Jam Sensor Board 5.3. Cassette 6 Schematic Diagram for printing A4 size...

  • Page 3: About Lead Free Solder

    KX-CLPF1 1 About Lead Free Solder 1.1. Suggested PbF Solder...

  • Page 4: How To Recognize That Pbf Free Solder Is Used

    KX-CLPF1 1.2. How to recognize that PbF Free solder is used 1.2.1. Feeder Board 1.2.2. Paper Empty/Jam Sensor Board...

  • Page 5: Removal And Replacement Procedures

    KX-CLPF1 2 Removal and Replacement Procedures 2.1. Front, Right, Left and Rear Covers Note: Reinstalling of Covers When reinstalling the covers, install rear cover next to right cover, left cover and front cover in that order on paper feeder mechanical unit.
  • Page 6 KX-CLPF1 2.1.2. Front Cover Before performing the following steps, remove the left cover (see above section 2.1.1). 1. Remove the screw. 2. Release the hook (A). 3. Insert a flat-blade screw driver through the opening (B) as shown in the Figure-1.
  • Page 7 KX-CLPF1 2.1.3. Rear Cover Before performing the following steps, remove the left cover (see above section 2.1.1). If necessary, remove the front cover (see above section 2.1.2). 1. Remove the screw. 2. Release the 2 hook (A). 3. Remove the Rear Cover while releasing the 2 hook (B) and hook (C).

  • Page 8: Feeder Board

    KX-CLPF1 2.2. Feeder Board Before handling, remove the Left Cover (see Section 1.1). Disconnect the 5 connectors from the Feeder Board. Remove the 3 screws (A). Remove the Feeder Board with shield cover. Remove the screw (B). Remove the Feeder Board.

  • Page 9: Sensor Board, Motor And Pickup Solenoid

    KX-CLPF1 2.4. Sensor Board, Motor and Pickup Solenoid Before handling, remove the Left Cover (see Section 1.1). Remove the Sensor Board [2 screws (A)]. Disconnect the connector CN3201 from the Sensor Board. Remove the Motor [screws (B)]. Disconnect the connector CN4 from the Feeder Board.

  • Page 10: Jam Sensor Arm, Paper Empty Sensor Arm, Pickup, Paper Feed Roller And Pinch Rollers

    KX-CLPF1 2.5. Jam Sensor Arm, Paper Empty Sensor Arm, Pickup, Paper Feed Roller and Pinch Rollers Before handling, remove the Left Cover (see Section 1.1). 2.5.1. Jam Sensor Arm and Paper Empty Sensor Arm Remove the Motor Bracket Unit with the Sensor Board (2 screws).
  • Page 11 KX-CLPF1 2.5.2. Pickup Roller and Paper Feed Roller Remove the 2 Pickup Roller Assemblies from the Pickup Roller Shaft by sliding it in the arrow direction while unlatching the hook from the grove of pickup roller shaft. Remove the Pickup Gear while unlatching the gear hook.

  • Page 12: Paper Cassette

    KX-CLPF1 2.6. Paper Cassette Remove the paper size detector or move it to “Legal Position”. Remove the paper size detector with support plate. Move the corner separator in the arrow direction (2) while pushing the hook in the direction (1), then remove the left ant right corner separators in the arrow direction (3) as shown Figure-1.

  • Page 13: Electronic Circuit Description And Diagrams

    KX-CLPF1 3 Electronic Circuit Description and Diagrams 3.1. Block Diagram Printer Engine another Optional Paper Feeder Optional Paper Feeder Board Buffer (HCT244) To another Optional Paper Feeder I/O Expander Motor Solenoid Driver Drive Paper Size Pickup Solenoid Switch Paper Feed...

  • Page 14: General Descriptions

    KX-CLPF1 3.2. General Descriptions Following is a brief description of the optional paper feeder board and major electrical component. 3.2.1. General I/O Circuit The optional paper feeder has the IC2 (16bit I/O Expander) that is controlled by printer engine. The communication protocol of the printer engine and IC2 is 4-wired serial method.
  • Page 15 KX-CLPF1 3.2.2. Motor Drive Circuit The motor (stepping motor) is driven by IC3 (bipolar constant current driver). The motor rotates in sync with the clock (PHASE1, PHASE2) that is generated by IC4 based on ACF1_SMNA and ACF1_SMNB. When the both IA1 and IA2 are low level, the motor rotates with maximum current.
  • Page 16 KX-CLPF1 3.2.3. Pickup Solenoid Drive Circuit The pickup solenoid is driven by the transistor (Q1). When the signal nSOL_ON is low, the paper is fed from the tray. Timing Chart...

  • Page 17: Schematic Diagram

    KX-CLPF1 3.3. Schematic Diagram Not Mount FROM I/O PCB or ACF1 SGND SIO_CS1 SIO_CLK 1 DO SIO_CS2 2 DI SGND 3 CLK SIO_DO 4 CS SIO_DI Paper Empty/Jam PGND Sensor Board 5 VCC ACFJAM ACFPNON 7 GND1 5VGND +24VACF 12 GND2...
  • Page 18 KX-CLPF1...

  • Page 19: Troubleshooting

    KX-CLPF1 4 Troubleshooting...

  • Page 20: Replacement Parts List With Lubrication Guide

    KX-CLPF1 5 Replacement Parts List with Lubrication Guide 5.1. Covers Ref. No. Part No. Part Name & Description PJKEB0042Y-1 Front Cover PJKEB0041Y-1 Light Cover PJKEB0040Y-1 Left Cover PJYKCLPF1M Rear Cover PJKEB0056Y-2 Cassette Cover Assembly PJKEB0054Y-1 Connector Cover XTW3+6L Screw 3 x 6mm...

  • Page 21: Chassis

    KX-CLPF1 5.2. Chassis...

  • Page 22: Feeder Board

    KX-CLPF1 Ref. No. Part No. Part Name & Description Remarks PJHRB0200Z Pinch Roller Base PJDFB0127Z Pinch Roller Shaft PJDSB0181Z Pinch Roller Spring PJDRB0048Z Pinch Roller PJNWB0004Z Plastic Ring PJDJB0019Z Bushing PJDRB0041Z Paper Feed Roller PJDJ05011CZ Bushing PJDGB0152Z Feed Gear PJHG353Z...
  • Page 23 KX-CLPF1 5.3. Cassette Ref. No. Part No. Part Name & Description PJHRB0225Z-1 Paper Chute PJZE1CLPF1M Cassette Base Plate PJDSB0094Z Lift Large Spring PJUSB0049Z Side Pressure Spring PJMDB0130Z Corner Separator (L) PJZEGCL500M Paper Side Guide (L) Assembly PJDSB0088Z Lift Small Spring...

  • Page 24: Packing Material

    KX-CLPF1 5.4. Packing Material Ref. No. Part No. Part Name & Description PJPGB0098Y Carton Box PJPNB0095Z Cushion (Front) PJPNB0096Z Cushion (Rear) PJQMB0065Z Operating Instructions PJPNB0100Z Cassette Base Plate Pad...
  • Page 25 KX-CLPF1 5.5. Feeder Board...
  • Page 26 KX-CLPF1 Integrated Circuits Ref. No. Part No. Part Name & Description C0JBAZ001885 C0ZBZ0000301 16-Bit I/O Expander C0GBF0000014 C0JBAF000178 C0JBAF000178 Diodes and Transistors Ref. No. Part No. Part Name & Description B0BC4R600016 Diode B0JCDD000001 Diode PJVDD1FL20UT Diode PJVDD1FL20UT Diode PJVDD1FL20UT Diode...
  • Page 27 KX-CLPF1 Ref. No. Part No. Part Name & Description ERJ3GEYJ103 10K / 1/10W / Chip Resistor ERJ3GEYJ103 10K / 1/10W / Chip Resistor ERJ3GEYJ103 10K / 1/10W / Chip Resistor ERJ3GEYJ330 33 / 1/10W / Chip Resistor ERJ3GEYJ103 10K / 1/10W / Chip Resistor...

  • Page 28: Paper Empty/Jam Sensor Board

    KX-CLPF1 5.6. Paper Empty/Jam Sensor Board Ref. No. Part No. Part Name & Description CN3201 175489-4 Connector Q3201 0N1024SLKU Photo Interrupter Q3202 0N1024SLKU Photo Interrupter R3201 ERDS2TJ181T 180 / 1/4W / Carbon R3202 ERDS2TJ181T 180 / 1/4W / Carbon PJUPB0016Z...
