Hach Ultra ORBISPHERE 510 Operator's Manual
  1. Manuals
  2. Brands
  3. Hach Ultra Manuals
  4. Measuring Instruments
  5. ORBISPHERE 510
  6. Operator's manual

Hach Ultra ORBISPHERE 510 Operator's Manual

Hide thumbs Also See for ORBISPHERE 510:
Table of Contents

Advertisement

Quick Links

ORBISPHERE 510/511/512
Revision G - 05/11/2008

Advertisement

Table of Contents
loading

Related Manuals for Hach Ultra ORBISPHERE 510

Summary of Contents for Hach Ultra ORBISPHERE 510

  • Page 1 Operator Manual ORBISPHERE 510/511/512 Revision G - 05/11/2008...
  • Page 3 Orbisphere 510/511/512 Analyzers - Important Information Product Recycling Information ENGLISH Electrical equipment marked with this symbol may not be disposed of in European public disposal systems after 12 August 2005. In conformity with European local and national regulations (EU Directive 2002/96/EC), European electrical equipment users must now return old or end-of-life equipment to the manufacturer for disposal at no charge to the user.
  • Page 4 Important Information - Orbisphere 510/511/512 Analyzers SVENSKA Elektronikutrustning som är märkt med denna symbol kanske inte kan lämnas in på europeiska offentliga sopstationer efter 2005-08-12. Enligt europeiska lokala och nationella föreskrifter (EU-direktiv 2002/96/ EC) måste användare av elektronikutrustning i Europa nu återlämna gammal eller utrangerad utrustning till tillverkaren för kassering utan kostnad för användaren.
  • Page 5 Hach Ultra. Hach Ultra will then be responsible for the disposal of this equipment. In addition, Hach Ultra will offer to take back (at cost to the customer) any old, unserviceable or redundant analyzers and systems which do not carry the above symbol, but which were originally supplied by Hach Ultra.
  • Page 6 Currently, monitoring and control instruments do not fall within the scope of the RoHS Directive, however Hach Ultra has taken the decision to adopt the recommendations in the Directive as the target for all future product design and component purchasing.

  • Page 7: Table Of Contents

    Orbisphere 510/511/512 Analyzers - Table of Contents 1 of 138 Table of Contents Installation Unpacking..................11 Installation Check List................11 Wall Mount and Pipe Mount Instruments...........12 1.3.1 Instrument Dimensions............12 1.3.2 Wall Mounting..............13 1.3.3 Pipe Mounting..............13 1.3.4 Connection Panel (bottom of instrument) ......14 Panel Mount Instrument ..............16...
  • Page 8 2 of 138 Table of Contents - Orbisphere 510/511/512 Analyzers 2.2.7 Warning Windows ..............35 Main Menu Structure .................36 View Menu Selection of the View Style ..............38 3.1.1 Numeric View...............38 3.1.2 Diagnostic View ..............38 3.1.3 Statistic View................38 Configuration of the View Styles ............40 3.2.1...
  • Page 9 Orbisphere 510/511/512 Analyzers - Table of Contents 3 of 138 Configure Snooze................68 View Inputs/Outputs ................68 Relays....................68 6.3.1 Relays Configuration ............69 6.3.2 Test Channel Relays ............70 6.3.3 Test System Relay ..............70 Analog Outputs..................71 6.4.1 Instrument Configuration .............72 6.4.2 Channel Configuration............73 6.4.3 Calibration of the Analog Outputs........75...
  • Page 10 4 of 138 Table of Contents - Orbisphere 510/511/512 Analyzers 10.1.1 Save...................107 10.1.2 Select .................107 11 Services Menu 11.1 Sensor Diagnostics................111 11.1.1 Calibration Timer..............111 11.1.2 Service Timer..............111 11.1.3 Null Current Measurement (EC sensor only) .....111 11.1.4 Gas/Temperature (EC sensor process) ......112 11.1.5...
  • Page 11 Orbisphere 510/511/512 Analyzers - Table of Contents 5 of 138 Appendix A: Glossary Gas Units..................131 Generic Terms and Definitions ............132 ORBISPHERE Operator Manual...
  • Page 12 6 of 138 Table of Contents - Orbisphere 510/511/512 Analyzers ORBISPHERE Operator Manual...
  • Page 13 However, Hach Ultra assumes no responsibility for any inaccuracies that may be contained in this manual. In no event will Hach Ultra be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages.
  • Page 14 None of the instrument’s components can be serviced by the user. Only personnel from Hach Ultra or its approved representative(s) is (are) authorized to attempt repairs to the system and only components formally approved by the manufacturer should be used.

  • Page 15: Precautionary Labels

    Orbisphere 510/511/512 Analyzers - Manual Overview 9 of 138 Intended Use of this Equipment This high accuracy Orbisphere instrument is designed for gas measurement using electrochemical (EC) or thermal conductivity (TC) sensors. The instrument can be used for process and laboratory analysis, in applications such as beverage, life sciences, power generation, and the electronics industry.
  • Page 16 10 of 138 Manual Overview - Orbisphere 510/511/512 Analyzers Acknowledgements • Dacron, Delrin, Tedlar, Tefzel, and Viton are registered trademarks of DuPont. • Halar is a registered trademark of Ausimont U.S.A., Inc. • Hastelloy is a registered trademark of Haynes International.

  • Page 17: Installation

    The instrument should now be ready for operation. If a problem should arise, please refer initially to “Troubleshooting” on page 117. If the difficulty cannot be overcome, please contact your Hach Ultra representative who will be happy to assist you. ORBISPHERE Operator Manual...

  • Page 18: Wall Mount And Pipe Mount Instruments

    12 of 138 Installation - Orbisphere 510/511/512 Analyzers 1.3 Wall Mount and Pipe Mount Instruments 1.3.1 Instrument Dimensions Fig 1-1: Wall/Pipe Mount Instrument Dimensions (in millimeters) ORBISPHERE Operator Manual...

  • Page 19: Wall Mounting

    Orbisphere 510/511/512 Analyzers - Installation 13 of 138 1.3.2 Wall Mounting Attach the U bracket provided to the wall with two screws (not provided). Tilt the instrument slightly backwards to align the bracket pins and the insertion slots, and slide the instrument onto the bracket as shown.

  • Page 20: Connection Panel (Bottom Of Instrument)

    14 of 138 Installation - Orbisphere 510/511/512 Analyzers 1.3.4 Connection Panel (bottom of instrument) 1.3.4.1 Cable Protection Shield The cable protection located at the bottom of the instrument (shown in place in Fig 1-4 below) must be lowered, and eventually removed, to get access to the bottom of the instrument.
  • Page 21 Orbisphere 510/511/512 Analyzers - Installation 15 of 138 Fig 1-6: Wall and Pipe Mount Connection Panel 1) Power cable. The type of 7) USB-A host connector for mass connection will vary depending on storage device the instrument specification (see 8) External pressure sensor cable “Connection to Mains Power...

  • Page 22: Panel Mount Instrument

    16 of 138 Installation - Orbisphere 510/511/512 Analyzers 1.4 Panel Mount Instrument 1.4.1 Instrument Dimensions Fig 1-7: Panel Mount Instrument Dimensions (in millimeters) ORBISPHERE Operator Manual...

  • Page 23: Mounting

    Orbisphere 510/511/512 Analyzers - Installation 17 of 138 1.4.2 Mounting 1) Cut an opening in the panel to accommodate the bracket frame provided (this is the same size as previous generations of Orbisphere type 3600 instruments). Fig 1-9: Opening Dimensions...

  • Page 24: Connection Panel (Bottom Of Instrument)

    18 of 138 Installation - Orbisphere 510/511/512 Analyzers Alternative Instrument Mounting Procedure When it is not convenient to work from the back of the panel, the instrument can be connected before fitting in the panel. 1) Install the panel support frame in the panel opening...

  • Page 25: Portable Table Instrument

    Orbisphere 510/511/512 Analyzers - Installation 19 of 138 1.5 Portable Table Instrument 1.5.1 Instrument Dimensions Fig 1-11: Portable Instrument Dimensions (in millimeters) ORBISPHERE Operator Manual...

  • Page 26: Mounting

    20 of 138 Installation - Orbisphere 510/511/512 Analyzers 1.5.2 Mounting Install the instrument on a laboratory table. Place it on a clean flat surface in a safe area. Locate the instrument convenient to the power source connectors, supplies and the PC.

  • Page 27: Connectors Assembly Instructions

    Orbisphere 510/511/512 Analyzers - Installation 21 of 138 1.6 Connectors Assembly Instructions 1.6.1 Cable Gland Wiring Instructions A waterproof cable gland is provided each time a cable must be connected inside the instrument. The nickel-plated brass cable glands are EMC-types, designed so that the cable shields attach directly to the instrument housing as a ground.

  • Page 28: Ethernet Connector (Table Version)

    22 of 138 Installation - Orbisphere 510/511/512 Analyzers 1.6.2 Ethernet Connector (table version) The Harting RJ Industrial® IP 67 Push Pull connector can be locked and unlocked using one hand and minimal force. Only a few steps are necessary in order to quickly and reliably attach an Industrial Ethernet cable to the Harting RJ Industrial®...

  • Page 29: Usb-B Client Adapter Cable

    Orbisphere 510/511/512 Analyzers - Installation 23 of 138 PROFInet® Color Code Signal Function Wire color RJ 45 pin N° Transmission Data + Yellow TD - Transmission Data - Orange Receiver Data + White RD - Receiver Data - Blue 1.6.3 USB-B Client Adapter Cable This supplied cable is needed to connect the instrument to a PC.

  • Page 30: Connection To Mains Power Supply

    24 of 138 Installation - Orbisphere 510/511/512 Analyzers 1.7 Connection to Mains Power Supply 1.7.1 Power Supply Unit (portable instrument) For portable instruments, an external power supply unit is supplied as standard. Connect the power supply unit to the table instrument with the FIXCON®...

  • Page 31: Power Supply Connection (High Voltage Instruments)

    Orbisphere 510/511/512 Analyzers - Installation 25 of 138 1.7.3 Power Supply Connection (high voltage instruments) High voltage instruments (100-240 VAC) are pre-wired internally for mains connection with a male BINDER connector. A female connector is supplied attached to the male connector as illustrated below.

  • Page 32: Connections To Electronic Boards

    26 of 138 Installation - Orbisphere 510/511/512 Analyzers 4) Slide the cable clamp (3) back onto the connector (4) and secure the cable. 5) Screw the two parts (4) and (2) back together. 6) Secure the power cable by screwing the end plug (1) back in place.

  • Page 33: Main Board Connections

    Orbisphere 510/511/512 Analyzers - Installation 27 of 138 1.8.3 Main Board Connections Fig 1-17: Connector P8 Fig 1-16: Main Board Fig 1-18: Connector P3 Connector P8 1) RS-485 (signal A) 8) Not used 2) RS-485 (signal B) 9) Not used...

  • Page 34: Measurement Board

    28 of 138 Installation - Orbisphere 510/511/512 Analyzers 1.8.4 Measurement Board The different measurement boards for the EC and TC sensors are illustrated in Fig 1-19 Fig 1-20 below. The type of board is easily identified by the color of the J8 connector.
  • Page 35 Orbisphere 510/511/512 Analyzers - Installation 29 of 138 Connector J7 (inputs & outputs) Measurement alarms relays Analog current (or voltage) outputs 1) Common 5) GND 2) Output relay 1 6) Output 1 3) Output relay 2 7) Output 2 4) Output relay 3...

  • Page 36: Set Measurement Alarm Relays

    30 of 138 Installation - Orbisphere 510/511/512 Analyzers 1.9 Set Measurement Alarm Relays The three output relays are located on the measurement board. When the instrument is delivered, all three of these relays are set to NO by default. They can be individually configured to Normally Open (NO) or to Normally Closed (NC) by physically moving the jumper on each relay.

  • Page 37: User Interface

    Orbisphere 510/511/512 Analyzers - User Interface 31 of 138 User Interface 2.1 Instrument The instrument front panel provides these user interfaces: • A touch screen acting as display, touch pad and keyboard. Contrast can be adjusted. • A LED, showing when the instrument is on.

  • Page 38: Function Keys On The Header Bar

    32 of 138 User Interface - Orbisphere 510/511/512 Analyzers 2.2.1 Function Keys on the Header Bar Shortcut to the user login window. Pressing this button for more than 2 seconds calls the ID and password window (see “Identification and Authorization Level” on page 34).

  • Page 39: Special Function Keys On Portable Instruments

    Orbisphere 510/511/512 Analyzers - User Interface 33 of 138 2.2.2 Special Function Keys on Portable Instruments The green sample mode start/stop button starts the measurement process when in sample mode. Pressing the button again manually interrupts the process and an “aborted”...

  • Page 40: Rolling List

    34 of 138 User Interface - Orbisphere 510/511/512 Analyzers 2.2.4 Rolling List For convenience, selection through a possible large list of items has been designed with a rolling list, like in this example. Use the up and down arrow to navigate, or select directly one item and press OK.

  • Page 41: Warning Windows

    Orbisphere 510/511/512 Analyzers - User Interface 35 of 138 2.2.7 Warning Windows At various stages, a warning message may be displayed to request confirmation from the operator that his last action(s) must really be saved or cleared, or that there is a problem that did not enable the requested action, such as during instrument calibration (example shown left).

  • Page 42: Main Menu Structure

    36 of 138 User Interface - Orbisphere 510/511/512 Analyzers 2.3 Main Menu Structure This is the structure of the main menu which is used to control every functionality of the instrument. These submenus are detailed in the following sections of this Operator Manual.

  • Page 43: View Menu

    Orbisphere 510/511/512 Analyzers - View Menu 37 of 138 View Menu Fig 3-1: View Menu ORBISPHERE Operator Manual...

  • Page 44: Selection Of The View Style

    38 of 138 View Menu - Orbisphere 510/511/512 Analyzers 3.1 Selection of the View Style 3.1.1 Numeric View This is the default view: Display shows the numeric measurement value identified for each gas measurement channel available, a graphic showing measurement value evolution during the set time frame, and sample temperature.
  • Page 45 Orbisphere 510/511/512 Analyzers - View Menu 39 of 138 Cpk process variability Cpk takes into account the center of the data relative to the specifications, as well as the variation in the process. • A Cpk value of one indicates that the tail of the distribution and the specification are an equal distance from the overall average.

  • Page 46: Configuration Of The View Styles

    40 of 138 View Menu - Orbisphere 510/511/512 Analyzers 3.2 Configuration of the View Styles 3.2.1 Numeric View Configuration List of parameters that can be adjusted to customize the numeric view display: Display temperature: no, channel x, Display channel 1, 2, 3: yes/no ⌧...

  • Page 47: Statistic View Configuration

    Orbisphere 510/511/512 Analyzers - View Menu 41 of 138 3.2.2 Statistic View Configuration On the left side of the screen, select the channel to be displayed in the statistic window, and press OK. To configure the statistic view for a channel, select the channel number in the right side of the window, to take you directly to the configuration window.
  • Page 48 42 of 138 View Menu - Orbisphere 510/511/512 Analyzers ORBISPHERE Operator Manual...

  • Page 49: Measurement Menu

    Orbisphere 510/511/512 Analyzers - Measurement Menu 43 of 138 Measurement Menu Fig 4-1: Measurement Menu ORBISPHERE Operator Manual...

  • Page 50: Instrument Configuration

    44 of 138 Measurement Menu - Orbisphere 510/511/512 Analyzers 4.1 Instrument Configuration 4.1.1 TPO or TPA Calculation (portable instrument) The TPO (Total Package Oxygen) and TPA (Total Package Air) features are available on the portable instrument for an EC sensor measuring oxygen (refer also to the table in “Generic Terms and Definitions”...

  • Page 51: Sample Mode Measurements (Portable Instrument)

    Orbisphere 510/511/512 Analyzers - Measurement Menu 45 of 138 4.1.4 Sample Mode Measurements (portable instrument) When the numeric view is selected, the normal measurement window is displayed. Press the function key (on the header bar) to initiate the sample measurement.

  • Page 52: Stop Criteria Configuration (Portable Instrument)

    46 of 138 Measurement Menu - Orbisphere 510/511/512 Analyzers TPO and TPA Parameters (portable instrument) The screen illustrated left is for TPO calculation, but the parameters required for TPA calculation are the same. Overflow volume: Total package size Net content volume: Volume of liquid in the package Press the “Compute”...

  • Page 53: Measurement Configuration

    Orbisphere 510/511/512 Analyzers - Measurement Menu 47 of 138 4.2 Measurement Configuration 4.2.1 EC Sensor Sensor’s membrane number selection Medium: Liquid or gas phase. Gas unit type: Partial, Fraction, Dissolved. Gas unit *: The list of available units depends on unit type selected above.

  • Page 54: Measurement Alarms Configuration

    48 of 138 Measurement Menu - Orbisphere 510/511/512 Analyzers 4.2.3 Measurement Alarms Configuration Set the thresholds for the low/high concentration levels, according to the application. Each alarm type can be individually enabled or disabled without losing its settings. These events can activate the relays and can be displayed.

  • Page 55: Measurement Filter Configuration

    Orbisphere 510/511/512 Analyzers - Measurement Menu 49 of 138 4.2.4 Measurement Filter Configuration The filters are aimed at “flattening” the measurement curve in situations where the process shows atypical peak values that could otherwise hamper the interpretation of measurement readings. The filter is applied on the last set of measurements each time a measurement is taken.

  • Page 56: Advanced Configuration

    Liquid to gas factor: Enable correction as appropriate. ⌧ If checked, the percentage correction factor must be entered. This value cannot be negative. Note: If you believe you need to enable these corrections, it is advisable to contact a Hach Ultra Service Representative first. ORBISPHERE Operator Manual...

  • Page 57: Interferences Configuration

    In the petroleum industry, the detection of oxygen is sometimes hampered by significant concentrations of hydrogen sulfide in the sample. Hach Ultra recommends using the H interference option if the hydrogen sulfide concentration exceeds 0.15% in gas phase, or 5 ppm in dissolved phase.
  • Page 58 52 of 138 Measurement Menu - Orbisphere 510/511/512 Analyzers 4.2.6.2 Interferences in Hydrogen Measurement The presence of oxygen in the sample can have an effect on the hydrogen sensor to varying degrees, depending on the membrane being used. The oxygen correction option enables the instrument to correct for this condition.

  • Page 59: Measured Data Storage

    Orbisphere 510/511/512 Analyzers - Measurement Menu 53 of 138 Temperature compensation: As descibed above ⌧ Interfering H2O: As descibed above ⌧ Interfering H2: If the sample is known to contain ⌧ hydrogen, check this box. 4.3 Measured Data Storage There is one measurement file per channel which contains the data generated by the measurement cycle.
  • Page 60 54 of 138 Measurement Menu - Orbisphere 510/511/512 Analyzers RAM time (volatile memory): Delay in seconds Note: Data stored in volatile between two recordings of measured data. memory are lost when FLASH time (non-volatile memory): Delay in seconds instrument is off, non-...

  • Page 61: Calibration Menu

    Orbisphere 510/511/512 Analyzers - Calibration Menu 55 of 138 Calibration Menu Fig 5-1: Calibration Menu Note: The amplifiers calibration option is reserved for Hach Ultra service technicians only, and is therefore not explained in this manual. ORBISPHERE Operator Manual...
  • Page 62 56 of 138 Calibration Menu - Orbisphere 510/511/512 Analyzers Fig 5-2: Sensor Calibration Menu (cont. from previous page) ORBISPHERE Operator Manual...

  • Page 63: Definitions

    Orbisphere 510/511/512 Analyzers - Calibration Menu 57 of 138 5.1 Definitions We define 2 types of calibration: • the calibration of the gas to measure (e.g. O for an O sensor) • the calibration of interferences (e.g. H O for a CO...
  • Page 64 58 of 138 Calibration Menu - Orbisphere 510/511/512 Analyzers Modify Calibration Parameters Calibration mode: 2 types available, depending on the gas being measured: - Direct value: Any gas - In Air: For or O (default) Medium: Select liquid or gas (direct calibration only)

  • Page 65: O 2 Sensor Calibration

    Orbisphere 510/511/512 Analyzers - Calibration Menu 59 of 138 The value “% last calibration” shows the ratio between the current measurement and the previous sensor calibration. The value “% variation” indicates the variation during the last 3 measurements, which is the stability of the measurements.

  • Page 66: O 3 Sensor Calibration

    Make sure the H concentration used for calibration is within the acceptable range for the membrane. Hach Ultra recommends the following calibration gas/inert gas combinations for calibrating with the following membranes. See the Sensor Maintenance Manual for further details on membrane specifications:...

  • Page 67: Tc Gas Sensor Calibration

    Orbisphere 510/511/512 Analyzers - Calibration Menu 61 of 138 5.3 TC Gas Sensor Calibration 5.3.1 Calibration of the Measured Gas Start Before initiating a calibration process, the calibration parameters must be set by pressing on the Modify button. The last calibration parameters are memorized, so this step can be ignored if the correct parameters are already set.
  • Page 68 62 of 138 Calibration Menu - Orbisphere 510/511/512 Analyzers Calibration Results A calibration screen will be displayed showing current measurement data which is continually refreshed. The value “% ideal slope” is a percentage of the slope against the ideal slope. If this percentage is not within the...

  • Page 69: Calibration Errors (Ec And Tc Sensors)

    Orbisphere 510/511/512 Analyzers - Calibration Menu 63 of 138 5.4 Calibration Errors (EC and TC sensors) Calibration is not possible in the following circumstances: • When the "ratio ideal current" is greater than 170% or smaller than 30% • When the sensor cannot measure (thermal cut off, sensor out, etc.) •...

  • Page 70: Interference Calibration (Tc Sensor)

    64 of 138 Calibration Menu - Orbisphere 510/511/512 Analyzers 5.6 Interference Calibration (TC sensor) This calibration is available for TC sensors and is required when one of the interferences has been enabled (See “Interferences Configuration” on page 51). The lower part of the screen displays the actual measurement.

  • Page 71: External Pressure Calibration (Optional Sensor)

    Orbisphere 510/511/512 Analyzers - Calibration Menu 65 of 138 5.8 External Pressure Calibration (optional sensor) Two calibration methods for the external pressure sensor can be selected: • Two point calibration (recommended) • One point calibration By default the two point calibration is selected...

  • Page 72: Calibration Reports

    66 of 138 Calibration Menu - Orbisphere 510/511/512 Analyzers 5.9 Calibration Reports Once a calibration is completed (for a gas or pressure sensor), the calibration report is updated with the new details. The calibration report contains data for the last 50 calibrations.

  • Page 73: Inputs/Outputs Menu

    Orbisphere 510/511/512 Analyzers - Inputs/Outputs Menu 67 of 138 Inputs/Outputs Menu Fig 6-1: Inputs/Outputs Menu ORBISPHERE Operator Manual...

  • Page 74: Configure Snooze

    68 of 138 Inputs/Outputs Menu - Orbisphere 510/511/512 Analyzers 6.1 Configure Snooze In the event of an alarm, the “snooze” button stops the instrument buzzer and returns all the relays in the instrument to their normal state during a "snooze time".

  • Page 75: Relays Configuration

    Orbisphere 510/511/512 Analyzers - Inputs/Outputs Menu 69 of 138 6.3.1 Relays Configuration The three relays (per channel) can be triggered by several standard events, or a combination of events (custom). The relays output can be used to turn on a beacon, horn or PLC (see “Connections to Electronic Boards”...

  • Page 76: Test Channel Relays

    70 of 138 Inputs/Outputs Menu - Orbisphere 510/511/512 Analyzers 6.3.2 Test Channel Relays The three measurement alarm relays can be manually activated for testing purposes: Select Relay On, Off or Not under test. See note regarding the relays below. “Not under test”...

  • Page 77: Analog Outputs

    Orbisphere 510/511/512 Analyzers - Inputs/Outputs Menu 71 of 138 6.4 Analog Outputs There are 3 analog outputs per channel. These outputs are configurable in terms of function, content and behavior through the instrument menus. Analog outputs are used to output a voltage or a current which is a function (e.g a linear characteristic) of a measurement: AOut = f (M).

  • Page 78: Instrument Configuration

    72 of 138 Inputs/Outputs Menu - Orbisphere 510/511/512 Analyzers 6.4.1 Instrument Configuration Select the analog output range of current: 4-20 mA or 0-20 mA The 4-20 mA range (recommended) allows for an extended event indication mode that can be selected...

  • Page 79: Channel Configuration

    Orbisphere 510/511/512 Analyzers - Inputs/Outputs Menu 73 of 138 6.4.2 Channel Configuration For each of the 3 analog output channels, set the type of measurement that will be transmitted through this channel, and the output characteristics. Meas. type: Select the type of measurement available from the rolling list.
  • Page 80 74 of 138 Inputs/Outputs Menu - Orbisphere 510/511/512 Analyzers The following table lists the default configuration. The first three events on the list are pre-set and only the priority can be changed: Table 6-2: Extended Event Table Priority Event I [mA] Sensor out 0.25...

  • Page 81: Calibration Of The Analog Outputs

    Orbisphere 510/511/512 Analyzers - Inputs/Outputs Menu 75 of 138 6.4.3 Calibration of the Analog Outputs The calibration of the analog output is aimed at aligning the internally calculated current to the real current output. This was performed at factory, but could become necessary again because of electronic tolerances.

  • Page 82: Direct Test

    76 of 138 Inputs/Outputs Menu - Orbisphere 510/511/512 Analyzers 6.4.4 Direct Test Test to check the calibration of the analog outputs. A precision ammeter connected at the corresponding analog output connection point is required. Select a value (4, 12, 20 mA available) and compare this value (+ 0.02 mA) with that which the ammeter...

  • Page 83: Analog Output Characteristics

    Orbisphere 510/511/512 Analyzers - Inputs/Outputs Menu 77 of 138 6.5 Analog Output Characteristics The analog output characteristics can be set to either Mono Linear, Tri Linear or None. 6.5.1 “Mono Linear” Analog Output The "Mono Linear" output is the default setting for each analog output. It is illustrated in Fig 6-3 below (4-20 mA output is shown, 0-20 mA or 0-5 V settings are similar).

  • Page 84: Tri Linear" Analog Output

    78 of 138 Inputs/Outputs Menu - Orbisphere 510/511/512 Analyzers 6.5.2 “Tri Linear” Analog Output The "Tri-linear" output brings benefits over the “Linear output” discussed before. It is illustrated in Fig 6-4 below (4-20 mA output is shown, 0-20 mA or 0-5 V settings are similar).

  • Page 85: None" Analog Output

    Orbisphere 510/511/512 Analyzers - Inputs/Outputs Menu 79 of 138 These points should be set keeping in balance the following conditions (see Fig 6-4 on page 78): • The smaller is Range 2, the better is the analog signal resolution within the expected range of measure.
  • Page 86 80 of 138 Inputs/Outputs Menu - Orbisphere 510/511/512 Analyzers ORBISPHERE Operator Manual...

  • Page 87: Communication Menu

    Orbisphere 510/511/512 Analyzers - Communication Menu 81 of 138 Communication Menu Fig 7-1: Communication Menu The external RS-485 port of the main board is directly connected to a RS-485 bus (single twisted pair). Optionally it can be connected to a fieldbus module (gateway).

  • Page 88: Simple Mode Configuration

    82 of 138 Communication Menu - Orbisphere 510/511/512 Analyzers 7.1 RS-485 Simple Mode Configuration This protocol allows the instrument to output data to an external device (PLC, SCADA, PC, etc.). The communication is unidirectional. The data are output on the RS-485 link as simple ASCII text.

  • Page 89: Data Available

    Orbisphere 510/511/512 Analyzers - Communication Menu 83 of 138 7.1.1 Data Available All individual data are separated by at least one tabulation character (ASCII code=0x09). For the cyclic measurements, the data format is detailed. For the files, only one example for each file is given to explain the data format.
  • Page 90 84 of 138 Communication Menu - Orbisphere 510/511/512 Analyzers EC Gas Sensor Calibration Report Example Calibration report nb 1 Type..... Sensor calibrated on this instrument Date (yy.mm.dd - hh:mm) .
  • Page 91 Orbisphere 510/511/512 Analyzers - Communication Menu 85 of 138 Barometric Sensor Calibration Report Example Calibration report nb 1 Date (yy.mm.dd - hh:mm) ..05.02.16 - 20:38 Operator ....jp Operator ID .
  • Page 92 86 of 138 Communication Menu - Orbisphere 510/511/512 Analyzers Configuration Report Example The "Configuration" below is given for a one channel instrument. INSTRUMENT CONFIGURATION Measurement mode..Continuous mode Pressure unit ....[bar] Temperature unit .

  • Page 93: Example Of Use

    Orbisphere 510/511/512 Analyzers - Communication Menu 87 of 138 7.1.2 Example of Use In this example we use: • One PC with a RS232 port. • One "RS-485<->RS232 converter" Procedure: 1) Connect both RS-485 wires of the instrument to the "RS-485<->RS232 converter".

  • Page 94: Profibus-Dp Communication (Optional)

    88 of 138 Communication Menu - Orbisphere 510/511/512 Analyzers 7.2 PROFIBUS-DP Communication (optional) 7.2.1 Installation On the Orbisphere CD, there is an “Orbi2079.gsd” and an “Orbi2079.bmp” file available in the “Profibus DP” folder to help configure the PROFIBUS-DP. The GSD file contains the following elements: •...

  • Page 95: Input/Output Data

    Orbisphere 510/511/512 Analyzers - Communication Menu 89 of 138 2) Select the menu "Configuration/RS-485" and choose "PROFIBUS-DP" as protocol. 3) Select the menu "Configuration/PROFIBUS-DP", choose the slave address and restart the instrument. 7.2.2 Input/Output Data The main board: • Writes the latest measurement data to the Profibus Input Buffer.
  • Page 96 90 of 138 Communication Menu - Orbisphere 510/511/512 Analyzers Name Type Size Offset Channel 3 gas concentration Input float 32 bits Channel 3 gas unit Input byte 8 bits Channel 3 temperature Input float 32 bits Channel 3 temperature unit...
  • Page 97 Orbisphere 510/511/512 Analyzers - Communication Menu 91 of 138 The gas, temperature and barometric pressure unit values are coded as defined in the following tables: Gas Unit Value Temperature Value Barometric Value Unit Pressure Unit mbar °C mbar °F psia atm.
  • Page 98 92 of 138 Communication Menu - Orbisphere 510/511/512 Analyzers 7.2.2.2 Commands The “Command Output Buffer” is formatted as follows: Name Type Size Offset Output command toggle (OCT) Output byte 8 bits Output command ID (OCI) Output byte 8 bits Output command data byte 1 (OCD1)
  • Page 99 Orbisphere 510/511/512 Analyzers - Communication Menu 93 of 138 Change Product Command - Input Name Value Comment 0 = OK 1 = Unknown command ID 2 = Invalid parameter (e.g. invalid channel no or product number) 3 = Execution failure...

  • Page 100: Usb-A Port (Host)

    94 of 138 Communication Menu - Orbisphere 510/511/512 Analyzers 7.3 USB-A Port (host) This option allows the export or import of data from an external mass storage device. The device must first be connected to the instrument through the USB-A port.

  • Page 101: Pc Interface

    Orbisphere 510/511/512 Analyzers - Communication Menu 95 of 138 7.4.2 PC Interface Once the server has been enabled and the interface information set up, access the information by launching an internet browser and typing “http://” followed by the server name that has been assigned to the instrument, in the address box as illustrated below:...
  • Page 102 96 of 138 Communication Menu - Orbisphere 510/511/512 Analyzers Click on any of these options and the data will be displayed on the PC screen. The following shows an example of the screen when selecting the Current Measurement option: ORBISPHERE...

  • Page 103: Data File Transfer Through The Usb Port

    Orbisphere 510/511/512 Analyzers - Communication Menu 97 of 138 7.5 Data File Transfer Through the USB Port The USB port allows you to copy data files from the instrument to a PC using the Microsoft ActiveSync® software. The files in the instrument are coded in a binary format, so they must be converted to a readable format on your PC to make them suitable for viewing.

  • Page 104: Microsoft Activesync® Configuration

    PC. See “Upload Report Files” on page Orbisphere Install is an installation software used by the Hach Ultra after sales technicians to upload new software versions. To avoid an accidental software modification, a key is required. 7.5.2 Microsoft ActiveSync® Configuration The latest version of ActiveSync®...

  • Page 105: Upload Report Files

    Orbisphere 510/511/512 Analyzers - Communication Menu 99 of 138 7.5.3 Upload Report Files Double click on the Orbisphere USB upload icon on the PC desktop (created during the process described previously in “PC Software Installation” ) to start the upload and convert process.
  • Page 106 100 of 138 Communication Menu - Orbisphere 510/511/512 Analyzers Uploaded Files There are a number of files that are uploaded to the PC during this process. However, only the text files (with a .txt file extension) are in a readable format on the PC. Most document editors (Word, Notepad, etc.) can be used to open these files, as well as...

  • Page 107: Security Menu

    Orbisphere 510/511/512 Analyzers - Security Menu 101 of 138 Security Menu Fig 8-1: Security Menu Note: When the instrument is started for the very first time, security is disabled by default. It is highly recommended that each user be entered into the system and given appropriate access rights as soon as possible to avoid any unauthorized access.

  • Page 108: Access Rights Management

    102 of 138 Security Menu - Orbisphere 510/511/512 Analyzers 8.1 Access Rights Management Each user has a unique ID and user password. The ID and password is used by the software to: • Allow or deny a user to perform specific actions.

  • Page 109: User Management

    Orbisphere 510/511/512 Analyzers - Security Menu 103 of 138 8.3 User Management This window shows the list of registered users for the instrument. They are listed by name, ID, password and access level. Note: The "User password" must be at least 4 characters long.
  • Page 110 104 of 138 Security Menu - Orbisphere 510/511/512 Analyzers ORBISPHERE Operator Manual...

  • Page 111: Products Menu

    Orbisphere 510/511/512 Analyzers - Products Menu 105 of 138 Products Menu Fig 9-1: Products Menu 9.1 Overview This option allows users to save and/or use previously saved, product configurations. A maximum of 100 different product configurations can be stored in the instrument. The basic measurement configuration (gas to analyze, gas unit, alarm limits, analog outputs, etc.) can be set up for a product and will be automatically used by the machine when that...

  • Page 112: Select Product

    106 of 138 Products Menu - Orbisphere 510/511/512 Analyzers 9.1.1 Select Product Note: If the PROFIBUS-DP communications protocol has been enabled, products can be selected for analysis using that facility (see “Input/Output Data” on page 89 specifically “Change Product Command - Output” on page 92 for details).

  • Page 113: Global Configuration Menu

    Orbisphere 510/511/512 Analyzers - Global Configuration Menu 107 of 138 10 Global Configuration Menu Fig 10-1: Global Configuration Menu 10.1 Overview The global configuration option allows users to save, and use previously saved, instrument configurations. A maximum of 10 configurations can be saved, with configuration 0 (zero) the instrument default.
  • Page 114 108 of 138 Global Configuration Menu - Orbisphere 510/511/512 Analyzers ORBISPHERE Operator Manual...

  • Page 115: Services Menu

    Orbisphere 510/511/512 Analyzers - Services Menu 109 of 138 11 Services Menu Fig 11-1: Services Menu - Part 1 ORBISPHERE Operator Manual...
  • Page 116 110 of 138 Services Menu - Orbisphere 510/511/512 Analyzers Fig 11-2: Services Menu - Part 2 ORBISPHERE Operator Manual...

  • Page 117: Sensor Diagnostics

    11.1.3 Null Current Measurement (EC sensor only) This is a diagnostic tool for Hach Ultra technicians. This feature will allow checking the ability of the EC measurement board to measure a null current. This ability is very important to measure traces of gas.

  • Page 118: Gas/Temperature (Ec Sensor Process)

    112 of 138 Services Menu - Orbisphere 510/511/512 Analyzers 11.1.4 Gas/Temperature (EC sensor process) This feature allows you to check the ability of the EC measurement board to measure a range of currents and temperatures. To use this feature an EC sensor simulator (Part N°...

  • Page 119: Language Selection

    Orbisphere 510/511/512 Analyzers - Services Menu 113 of 138 11.2 Language Selection Check the language as required and restart the instrument to apply the change. The instrument will restart in the language selected Note: Level 3 or 4 is required to change the display language.

  • Page 120: Buzzer

    114 of 138 Services Menu - Orbisphere 510/511/512 Analyzers 11.5 Buzzer Adjust the sounds available on the instrument: When “screen tap” is enabled, a click sound is heard each time the screen is touched. The volume is adjustable. The instrument alarm sound can be enabled or disabled to suit the application.

  • Page 121: Sensor Parameters

    Orbisphere 510/511/512 Analyzers - Services Menu 115 of 138 Pressing the amplifiers correction button displays the value of the actual correction factor on the amplifiers. The display illustrated left is for an EC sensor. The display for a TC sensor is slightly different, and is shown below.

  • Page 122: Batteries

    11.8 Software Download For Hach Ultra technician use only. Used when reloading the software for new versions. Note: This ends the application. User must stop and restart the instrument to restart the program.

  • Page 123: Maintenance And Troubleshooting

    117 of 138 12 Maintenance and Troubleshooting 12.1 Instrument Maintenance Any instrument maintenance should be carried out by a qualified Hach Ultra Service Technician. Please contact your local representative should you feel any maintenance or instrument adjustments are required 12.2 Troubleshooting...

  • Page 124: List Of Events And Alarms

    118 of 138 Maintenance and Troubleshooting - Orbisphere 510/511/512 Analyzers 12.3 List of Events and Alarms Table 12-1: List of Events Event Name Description Bit mask type value (32 bits long) 0x00000000 Measure Normal measurement mode. 0x00000001 Filter enabled The gas measurements are filtered.
  • Page 125 Orbisphere 510/511/512 Analyzers - Maintenance and Troubleshooting 119 of 138 0x00000400 Channel disabled The channel has been disabled. 0x00000800 The measurement board has been disconnected (or Channel out does not answer). 0x00001000 Sensor out The sensor has been disconnected. 0x00002000 Ext.

  • Page 126: Storage, Handling And Transportation

    120 of 138 Maintenance and Troubleshooting - Orbisphere 510/511/512 Analyzers 12.4 Storage, Handling and Transportation Protect the instrument against the elements: rain, splashing, direct sunlight, etc. A properly packaged instrument can be stored and transported at a temperature -20°C to +70°C and relative humidity up to 80%. Best practice for packing the instrument for transportation is to reuse the original packaging in which the instrument was first delivered.

  • Page 127: Specifications

    Orbisphere 510/511/512 Analyzers - Specifications 121 of 138 13 Specifications 13.1 Hardware Description The instrument hardware is made of one main board, up to 3 measurement boards - one for each measurement channel (= one per sensor), a power supply and a battery pack as options.
  • Page 128 122 of 138 Specifications - Orbisphere 510/511/512 Analyzers 511 Model Number Matrix A A A Oxygen EC 5 1 1 D D D Carbon Dioxide TC (Max 2 channels) E E E Nitrogen TC (Max 2 channels) F F F Hydrogen TC (Max 2 channels)
  • Page 129 Orbisphere 510/511/512 Analyzers - Specifications 123 of 138 Example 1: 510 / ACD / W1C00 000 • Analyzer model 510 multi channel • One oxygen EC sensor, one ozone EC sensor and one carbon dioxide TC sensor • Wall mounted •...

  • Page 130: Operating Conditions

    124 of 138 Specifications - Orbisphere 510/511/512 Analyzers 13.3 Operating Conditions -5°C to +50°C - 1 channel instrument Operating temperature -5°C to +45°C - 2 channel instrument limits -5°C to +40°C - 3 channel instrument Storage temperature -20°C to +70°C...

  • Page 131: Size And Weight

    Orbisphere 510/511/512 Analyzers - Specifications 125 of 138 13.7 Size and Weight Instrument version Height [mm] Depth [mm] Width [mm] Weight (kg) inches inches inches pounds 236.5 Wall or pipe mount 9.31” 6.30” 9.84” 8.38 lbs 156 (123) 220 (214) Panel mount: Face (housing) 6.14”...

  • Page 132: Security Level Table

    126 of 138 Specifications - Orbisphere 510/511/512 Analyzers 13.9 Security Level Table A cross means that the user who has this user security level can access this function or setting (See “User Management” on page 103). Note: When not shown, the sub-levels carry the same security level as the level above.

  • Page 133: Default Parameters

    Orbisphere 510/511/512 Analyzers - Specifications 127 of 138 13.10 Default Parameters The table below indicates the factory default configurations. The instrument has these settings when started for the first time. Parameter Default Settings Customer Settings Disabled Security Measurement • Measurement mode Continuous •...
  • Page 134 128 of 138 Specifications - Orbisphere 510/511/512 Analyzers ORBISPHERE Operator Manual...

  • Page 135: Part Lists

    Orbisphere 510/511/512 Analyzers - Part Lists 129 of 138 14 Part Lists 14.1 Accessories Part N° Description 29089 Purge gas pressure regulator kit for TC sensors 10 wire cable to connect 31xxx sensors to Orbisphere 410/51x wall and 32501.03 panel instrument, length 3m...

  • Page 136: Spare Parts

    130 of 138 Part Lists - Orbisphere 510/511/512 Analyzers Part N° Description Longer 10 wire cable to connect 31xxx sensors to Orbisphere 410/51x wall 32501.MM and panel instrument, total length = MM, price added per meter of length greater than 3 m.

  • Page 137: Gas Units

    Orbisphere 510/511/512 Analyzers - Glossary 131 of 138 Appendix A: Glossary A.1 Gas Units Table A-1: Gas Units Unit Meaning percentage, by weight. A concentration of 100% air corresponds to liquid saturated with air at current pressure and temperature. The equivalent...

  • Page 138: Generic Terms And Definitions

    132 of 138 Glossary - Orbisphere 510/511/512 Analyzers A.2 Generic Terms and Definitions Table A-2: Generic Terms and Definitions Terms Meaning This is the total pressure in a system Absolute pressure (i.e. relative pressure, plus atmospheric pressure) A voltage or current signal that is a continuous function of the Analog output measured parameter.

  • Page 139: Operator Manual

    Orbisphere 510/511/512 Analyzers - Glossary 133 of 138 Table A-2: Generic Terms and Definitions RS-232 is a serial communication standard providing asynchronous communication capabilities with hardware flow control, software flow RS-232 control, and parity check. Maximum transmission distance is up to 15 meters at a max.
  • Page 140 134 of 138 Glossary - Orbisphere 510/511/512 Analyzers ORBISPHERE Operator Manual...

  • Page 141: Operator Manual

    Orbisphere 510/511/512 Analyzers - Annex 135 of 138 Annex Tables and Illustrations Fig. 1-1 Wall/Pipe Mount Instrument Dimensions (in millimeters) ....12 Fig. 1-2 Wall Mount Bracket ................13 Fig. 1-3 Pipe Mount Diagram................13 Fig. 1-4 Cable Protection Shield in Place and Front Door Closed....14 Fig.
  • Page 142 136 of 138 Annex - Orbisphere 510/511/512 Analyzers Fig. 7-1 Communication Menu................81 Fig. 8-1 Security Menu..................101 Table 8-1 Access Levels..................102 Fig. 9-1 Products Menu.................105 Fig. 10-1 Global Configuration Menu ..............107 Fig. 11-1 Services Menu - Part 1 ..............109 Fig. 11-2 Services Menu - Part 2 ..............110...

  • Page 143: Operator Manual

    Orbisphere 510/511/512 Analyzers - User Notes 137 of 138 User Notes ORBISPHERE Operator Manual...

This manual is also suitable for:

Orbisphere 511Orbisphere 512

Table of Contents
