XtendLan MCDVR-480G User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MCDVR-480G
USERS MANUAL
1

Advertisement

Table of Contents
loading

Summary of Contents for XtendLan MCDVR-480G

  • Page 1 MCDVR-480G USERS MANUAL...

  • Page 2: Table Of Contents

    List of contents 1. Notice for safety........................3 2. Package contents......................... 4 3. Name and function of each part ..................4 4. Menu setup.......................... 6 4.1 Time Setup ........................6 4.2 Record Setup......................... 7 4.3 Camera Setup ........................ 8 4.4 SD card information....................10 4.5 Etc setup........................

  • Page 3: Notice For Safety

    Security 1. Notice for safety 1) Do not use water or volatile chemicals when cleaning the inside of the car or the product.This may increases the risk of product damage, file, and electric shock. 2）Avoid causing the product severe impact and immersing it in a foreign substance. 3) If the user is in a tunnel or is driving at night, video recording cannot work properly.

  • Page 4: Package Contents

    2. Package contents Check the objects in the packing box before using the product, if there is missing, please contact the dealer. Purchase on selection: 1* External camera 1* SD card 1* SD card reader 3. Name and function of each part The back 1 In 2 Out 3 Reset 4 Power 5 LED 6 Mic 7 Up 8 Enter 9 Down...
  • Page 5 (8)button swith the video output (press once，switch to the picture of the other camera.) (9)button enmergency record （press one second）, enter into main menu( press three seconds) (10)SD Card slot Before use,please insert SD CARD Disconnect the power cable or turn off the engine before Inserting or removing the SD card. The user should format the SD card before when using a SD card not supplied by the manufacturer.

  • Page 6: Menu Setup

    4. Menu setup Press (9) button for 3 seconds, enter into main menu as the picture below（When enter into the interface, you can hear deng’s sound three times, after entering into main menu interface, (7) button upward, （8）button confirm/exit (9) button downward ) Main Menu 1.

  • Page 7: Record Setup

    4.2 Record Setup Select the Record Setup at the main menu interface，enter into record setup interface 2. Record Setup 1. Record Time 2. Record Quality 3. Record Resolution Record Setup 4. Record Volume 5. Exit Menu Number Record hold time setup: 1 min，5 min，10 min； 2.1 Set Record Time 1.

  • Page 8: Camera Setup

    Record Volume Setup 2.4 Set Record Volume 1. Volume Up Level 2 2. Volume Up Level 1 3. Normal 4. Volume Down Level 1 5. Volume Down Level 2 6. Exit Menu Number: 4.3 Camera Setup Select the Record Setup at the main menu interface，enter into camera setup interface 3.
  • Page 9 Camera Mirror Setup 3.3 Set Mirror 1. Mirror Off 2. Mirror On 3. Exit Menu Number Camera Frame Rate Setup（1，fixed frame rate；2，variable frame rate） 3.4 Set Frame Rate 1. Fix Frame Rate 2. Frame Rate Variable 3. Exit Menu Number: Power frequency setup 3.5 Set Power Frequency 1.

  • Page 10: Sd Card Information

    4.4 SD card information Select the SD Card Info at the main menu interface，enter into SD card information interface 4. SD Card Information 1. Total Size 2. Free Size 3. Format 4. Exit Manu Number: Check total size of SD card 4.1 Total Size SD Card Total Size is 1883 MB Press any key to return...

  • Page 11: Etc Setup

    4.5 Etc setup Select the Etc setup at the main menu interface，enter into setuo interface 5. Etc Setup 1. Set Acceler Trigger Level 2. Set UTC Time 3. Get Firmware Version 4. Update Firmware 5. Exit Menu Number: Sensitive of accel trigger setup 5.1 Trigger Level 1.

  • Page 12: Installing Instructions

    Update Firmware Can used to upgrade functions of the product (need manufacturer provide upgrade file, for free) Update Instructions Copy the update program to the SD card, then insert the card into the product. Enter into the main menu, select 5.ETC Setup, and then select 4.Update Firmware, product can automatic updates. Note: Do not remove the power cable and do not turn off the engine，power off during the update process may cause fatal error.
  • Page 13 • Detailed description for installation  fix the mount with the body as the image mounted on holder like a drawing to the body. （tear off the clear film at the bottom before using, or it can not attracted to the glasses) ...

  • Page 14: Operation Instruction

    6. Operation instruction Before operation Before operating, please follow the sketch to let each part come together and mount this vehicle recorder to the most suitable place. Insert SD Card, and this product will start working simultaneously when the cigarette lighter connected and the car started.

  • Page 15: Specification

    8. Specification Item Specification Double camera WDR CMOS Sensor(Angle:140) Video 640*480 @ 30fps(1Ch.)/15fps(2Ch.) 320*240 @ 30fps(1Ch.)/15fps(2Ch.) Audio Inernal Mic. Inernal GPS Module Event G-sensor(3-Axis).EMR Button Memory SD Card Memory (1/2/4/8/16GB) H.264 Compressed Format Interfaces Power (DC 12-36V)/SD Card slot/TV-in/TV-out Power Power DC12V-DC36V Backup...
