Canon HDD Mirroring Kit Reference Manual

The HDD Mirroring Kit enables you to store the same data on two hard disks that are set to
the machine. When one of the hard disks malfunctions, the machine automatically accesses
the other hard disk, enabling you to prevent data loss. If you are using the HDD Data
Encryption & Mirroring Kit, you can encrypt the data stored in the hard disks and increase
the security.
NOTE
To enable this function, the HDD Mirroring Kit and the additional hard disks must be set
to the machine. For information on setting the HDD Mirroring Kit and the hard disks,
contact your local authorized Canon dealer.

Status Indicators

The status indicators indicate the status of the hard disks that are set to the
machine. There are two types of status indicators, as shown below.
Access Status Indicator (Green)
•
Indicates the access status of the hard disks.
Error Indicator (Red)
•
Indicates the error status of the hard disks.
Normal State
Accessing HDD1
Accessing HDD2
HDD1 Failed
HDD2 Failed
Copying Data to HDD1
Copying Data to HDD2
IMPORTANT
If the red status indicator of the hard disk is lit, the hard disk may have failed. Contact
your local authorized Canon dealer.
NOTE
The location of the status indicator may differ, depending on the model you are using.
HDD Mirroring Kit
Reference Guide
Status
HDD1 Green
Off/Lights
Off/Lights
Status of the Status Indicators
HDD1 Red
Off Off
Lights Off
Off Off
Off Lights
Off Off
Flashes
Off
HDD2 Green HDD2 Red
Off
Off
Lights
Off
Off Lights
Off/Lights
Off/Lights Flashes
Off
Off
Off
Off
Off
