- Page 1 LX710 LX710 DIGITAL SURROUND RECEIVER SYSTEM 001-021-LX710-22-Eng 3/30/04, 1:46 PM...
- Page 2 See Copyright Act 1956 and The Performer’s Protection Acts 1958 to 1972. 001-021-LX710-22-Eng Italia DICHIARAZIONE DI CONFORMITA’ Si dichiara che l’apparecchio LX710 PHILIPS risponde alle prescrizioni dell’art. 2 comma 1 del D.M. 28 Agosto 1995 n. 548. Fatto a Eindhoven Philips Consumer Electronics...
- Page 3 This product complies with the radio interference requirements of the European Community. Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under license from Digital Theater Systems, Inc. U.S. Pat. Noís.
-
Page 4: Table Of Contents
Contents General Information Supplied accessories ... 5 Care and safety information ... 5 Connections Step 1: Set up the speakers ... 6 Step 2: Placing the speakers and subwoofer .. 6 Step 3: Connecting speakers and subwoofer . 7 Step 4: Connecting FM/MW antennas ... 8 Step 5: Connecting the power cord ... -
Page 5: General Information
– Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasives. (5x) 3/30/04, 1:47 PM 10 cm (4 inches) PHILIPS 10 cm (4 inches) DVD Home Cinema System 8239 300 30602... -
Page 6: Connections
Connections Step 1: Set up the speakers You can attach the speakers directly to their bases if you want to place them on a flat surface. You can choose to hang the speakers on the wall. Attach the supplied bracket firmly to the rear of speakers using the supplied screws. -
Page 7: Step 3: Connecting Speakers And Subwoofer
Step 3: Connecting speakers and subwoofer Front Left Front Right AC MAINS AC220-240V ~ 50Hz FRONT FRONT RIGHT LEFT Rear Right Rear Left Connect the supplied speaker systems by matching the colours of the jacks and speaker cables. Fully insert the stripped portion of the speaker wire into the jacks. -
Page 8: Step 4: Connecting Fm/Mw Antennas
Connections Step 4: Connecting FM/MW antennas fix the claw into the slot DVD / SACD IN FRONT REAR FRONT LEFT LEFT CENTER FRONT REAR REAR SUB- OPTICAL RIGHT RIGHT CENTER WOOFER DIGITAL IN 7 CHANNEL IN Connect the supplied MW loop antenna to the MW jack. -
Page 9: Optional Connections - Playback
Optional Connections - Playback IMPORTANT! – You can connect other audio and audio/visual equipment to this AV receiver in order to use the Home Cinema Audio System’s surround sound capabilities. – For connection to additional components, the audio/video cables are not supplied. -
Page 10: Connecting To A Dvd/Sacd Player
Optional Connections - Playback Connecting to a DVD/SACD player DVD/SACD player AC MAINS AC220-240V ~ 50Hz FRONT FRONT RIGHT LEFT You only need to make one connection to your DVD/SACD player from the following options, depending on the capabilities of your DVD/SACD player. Option 1: Using 7 Channel In jacks If your DVD/SACD player has a built-in multichannel decoder (e.g. -
Page 11: Optional Connections - Recording
Connecting to a recording device COAXIAL IN DIGITAL IN Digital Recording device FRONT FRONT FRONT REAR REAR RIGHT LEFT CENTER RIGHT LEFT SPEAKERS (4 ) Connect the AV receiver’s COAXIAL OUT jack to the DIGITAL (COAXIAL) IN jack on a digital recording device (DTS-Digital Theatre System compatible, with a Dolby Digital decoder, for example). -
Page 12: Functional Overview
Functional Overview Main unit and remote control DIGITAL A/V SURROUND RECEIVER STANDBY- ON STANDBY ON (B) – Switches to standby mode or turns on the system. Speaker display panel SURROUND – Selects multichannel surround or stereo mode. System display panel PROGRAM –... -
Page 13: Control Buttons Available On The Remote Only
– Adjusts rear speakers’ sound level. CENTER +- – Adjusts centre speaker’s sound level. TV VOL +- – Adjusts TV volume (Philips TV only). SLEEP – Sets the sleep timer function. – Selects different levels of brightness for display panel. -
Page 14: Getting Started
Getting Started Step 1: Inserting batteries into the remote control Open the battery compartment. Insert two batteries type R06 or AA, following the indications (+-) inside the compartment. Close the cover. Using the remote control to operate the system Aim the remote control directly at the remote sensor (iR) on the front panel. -
Page 15: Adjusting The Speaker Output Levels
CENTER DELAY – Select this to set the delay time in relation to the listening position/distance for the centre speaker : 5ms, 3ms, 2ms, 1ms or OFF (default setting). REAR DELAY – Select this to set the delay time in relation to the listening position/distance for rear speakers : 15ms, 12ms, 9ms, 6ms, 3ms or OFF (default setting). -
Page 16: Sound Controls
Sound Controls IMPORTANT! For proper surround sound, make sure the speakers and subwoofer are connected (see page 7). Selecting surround sound In DISC COAX or DISC OPTI mode If receiving Dolby Digital EX and Dolby Digital 5.1 audio signal, press SURROUND button will cyclic through: DOLBY EX ™... -
Page 17: Volume Controls And Other Features
"VOL MIN" is the minimum volume level and “VOL MAX” is the maximum volume level. For Philips TVs only Press TV VOL +/- on the remote control to adjust the TV’s volume level. To listen through the headphones... -
Page 18: Tuner Operations
Tuner Operations IMPORTANT! Make sure the FM and MW antennas are connected. Tuning to radio stations Press TUNER on the remote to select “FM” or “MW”. Press and hold S / T on the remote until the frequency indication starts to change, then release. "FM SEARCH"... -
Page 19: Troubleshooting
Do not open the system as there is a risk of electric shock. If a fault occurs, first check the points listed below before taking the system for repair. If you are unable to remedy a problem by following these hints, consult your dealer or Philips for help. Problem No power. -
Page 20: Specifications
Specifications AMPLIFIER SECTION Output power - Front 75 W RMS / channel - Rear 75 W RMS / channel - Centre 75 W RMS / channel Frequency Response 200 Hz – 20 kHz - Subwoofer 150 W RMS Frequency Response 40 Hz –... -
Page 21: Glossary
Analogue: Sound that has not been turned into numbers. Analogue sound varies, while digital sound has specific numerical values. These jacks send audio through two channels, the left and right. AUDIO OUT Jacks: Jacks on the back of the DVD System that send audio to another system (TV, Stereo, etc.). -
Page 22: Connecting To A Tv
LX710 LX710 Front Speaker (right) AC MAINS AC220-240V ~ 50Hz Rear Speaker (right) Connecting to a TV TV/AV DISC TUNER DISC DVD MENU SYSTEM STOP PLAY/PAUSE RESUME SURROUND SOUND NIGHT MUTE REPEAT REPEAT SLEEP SUBW REAR CENTER TV VOL DVD / SACD IN DIGITAL OUT AUDIO FRONT... - Page 23 Connecting to a VCR DISC TUNER DISC DVD MENU SYSTEM STOP PLAY/PAUSE RESUME SURROUND SOUND NIGHT MUTE REPEAT REPEAT SLEEP SUBW REAR CENTER TV VOL AC MAINS AC220-240V ~ 50Hz Connecting to a DVD player DISC COAX DISC TV/AV DISC DISC DVD MENU SYSTEM...
