OPERATOR'S INSTRUCTION MANUAL

MODEL: ____________________

SERIAL: _____________________

DATE OF PURCHASE: ____________

PURCHASED FROM: __________________________

WARNING:

9475 PASCAL GAGNON STREET, ST-LÉONARD, QUEBEC, CANADA

GRIZZLY

410 000

THIS PRODUCT IS DESIGNED AND MANUFACTURED TO

PROVIDE SAFE AND DEPENDABLE SERVICE IF OPERATED

ACCORDING

PROVIDES THE FOLLOWING INSTRUCTIONS FOR USE AND

CARE

THIS

PURCHASER TO SEE TO IT THAT THESE INSTRUCTIONS ARE

MADE CLEAR TO THE PERSONS WHO WILL ACTUALLY BE

USING THE EQUIPMENT. FAILURE TO DO SO COULD RESULT

IN SERIOUS INJURY OR EQUIPMENT DAMAGE.

GRIZZLY EQUIPMENT

TEL: (514) 325-1260 / 1-888-325-9953 FAX: (514) 325-9952

E-MAIL: info@alcor-inc.com Web site:

ENGINE MODEL: _______________

ENGINE SERIAL: _______________

INSTRUCTIONS.

EQUIPMENT

THE

MANUFACTURER

AND

RELIES

www.grizzlyequip.com

UPON

THE

Table of Contents

Summary of Contents for Grizzly G41

Page 1 MADE CLEAR TO THE PERSONS WHO WILL ACTUALLY BE USING THE EQUIPMENT. FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY OR EQUIPMENT DAMAGE. GRIZZLY EQUIPMENT 9475 PASCAL GAGNON STREET, ST-LÉONARD, QUEBEC, CANADA TEL: (514) 325-1260 / 1-888-325-9953 FAX: (514) 325-9952 E-MAIL: info@alcor-inc.com Web site:...
Page 2 PREPARATION ............................................4 OPERATOR;............................................4 WEAR PROPER ATTIRE ..........................................4 ROOF PREPARATION (IF G41 IS TO BE USED BY ROOFERS) ............................4 INSPECT ROOF DECK .......................................... 4 WARNING LINE SYSTEM ........................................4 HOISTING MACHINE TO ROOF ........................................ 4 CONNECTING TO LIFT RINGS ......................................4 SAFETY PRECAUTIONS ..........................................
Page 3: Introduction
Thank you for purchasing this quality product. With proper use and care, the G41 will provide many years of reliable service. For the safety of all job-site personnel it is mandatory that the instructions provided for the use and handling of the equipment be read and thoroughly understood by the operators.
Page 4: Preparation
ALWAYS CHECK DECK LOAD LIMITS WITH BUILDER, OWNER, OR ARCHITECT BEFORE DECIDING TO USE ON THE ROOF. CONNECTING TO LIFT RINGS Four hoist rings are provided on the G41 as shown in Fig. 1 and 2. WEIGHT; Model: 410000 1190 LBS...
Page 5: Safety Precautions
(Fig. 10)  Never allow the G41 to be left alone with the engine running and or with the loader arms up if the cylinder lock is not in place. (Fig. 10) ...
Page 6: Knowing The G41
(Keep from using the detent if operating an accessory with a cylinder). The G41 also provides the ability to decide how much hydraulic oil flow the operator wants to direct to the accessory by adjusting the flow control lever.
Page 7: The Controls
THE CONTROLS Fig. 3 Control lever for the left side travel motors Pushing forward on this lever turns the left wheels forward Pulling back on this lever turns the left wheels backward Control lever for the right side travel motors Pushing forward on this lever turns the right wheels forward Pulling back on this lever turns the right wheels backward Control lever for loader arms...
Page 8: Attachment Plate And Connectors
OPERATING PRECAUTIONS Start by planning your work Inspect the G41, check for leaks, broken or loose parts, check oil levels (hydraulic and engine), check and refill fuel tank. Check wheel motor woodruff keys daily to ensure that the wheel hub is solidly attached to the wheel motor.
Page 9: Operating The G41
OPERATING THE G41 START UP PROCEDURE 1) Walk around the machine to look for possible damage, leaks, loose parts, etc. If any are found, have the machine repaired immediately. 2) Check hydraulic and engine oil levels, check air filter and fill gasoline tank if necessary, check tire pressure and adjust.
Page 10: Mounting Attachments
NEVER TRAVEL OR TURN WITH A RAISED BUCKET LOUVERS  The G41 is equipped with louvers to protect the hydraulic components from falling debris.  The machine can be used without the louvers on very hot days where prolonged use may generate a lot of heat.
Page 11: Table Of Contents
MAINTENANCE WARNING; FUEL OR OIL LEAKS OR SPILLS CAN CREATE A FIRE OR EXPLOSION HAZARD. MAINTENANCE CHART Daily Daily Weekly Monthly Annually 8 hours 20 hours 50 hours 200 hours 400 hours Engine oil check Engine oil change Engine oil filter change Engine air filter check Engine air filter change Engine fuel filter check...
Page 12: Engine Oil Check
ENGINE OIL CHECK Check engine oil level daily (see engine manual for detailed instructions) Make sure machine is cold because muffler and hoses may be very hot (Fig. 11). ENGINE OIL AND FILTER CHANGE Fig. 11 Change engine oil and filter after the initial 20 hours of operation and then every 200 hours of operation. (See engine manual for detailed instructions.) ENGINE AIR FILTER Check air filter daily and replace every 200 hours, in extremely dusty conditions service the air filter several times...
Page 13: Check Battery/Terminals
The hydraulic oil level can be checked visually by looking at the level sight glass window on the right hand side of the G41 in between both wheels. Oil level should be near the top of the level sight glass window, if no oil is visible, oil should be added.
Page 14: Hydraulic Oil Change
 Remover the filler breather cap.  Place a drain pan under the drain plug on the right side of the G41 (Fig. 15), make sure the pan can hold 20 gallons of oil.  Remove the drain plug and allow the oil to completely drain out.
Page 15: Grease(Lubrication)
GREASE(LUBRICATION)  Grease all pivot points daily and immediately after washing, use good general purpose grease.  Grease the pivot pins on the top of the loader lift arms. (Fig. 16)  Grease the pivot pins on the bottom of the loader lift arms. (Fig. 17) ...
