Napoleon CLEARION Series Quick Start Manual

CLEARION™ SERIES ELECTRIC APPLIANCE

Specifications

Model
NEFBD50H (120V/240V)
NEFBD50H-SS (120V/240V)
NEFBD50H-DT (120V/240V)
NEFBD50H-SS-DT (120V/240V) 5000/9000
Overview
Dimensions
EN
Product information provided is not complete and is subject to change without notice. Please consult the installation manual for
the most up to date installation information.
BTU
Actual Framing
5000/9000 50
5000/9000 50
5000/9000 50
50
FRONT VIEW
EN
EN
G
H
A
TOP VIEW
depth of
appliance
regular trim
depth of
appliance
deep trim
* F is the distance between trim edges. The deep trim reduces this dimension. See table below.
A B
NEFBD50H 50" 18 3/8"
(1270mm) (467.2mm)
50" 18 3/8"
NEFBD50H-SS
(1270mm) (467.2mm)
NEFBD50H-DT 50" 18 3/8"
(1270mm) (467.2mm)
NEFBD50H-SS-DT 50" 18 3/8"
(1270mm) (467.2mm)
24 Napoleon Road, Barrie, Ontario, Canada L4M 0G8 • 214 Bayview Drive, Barrie, Ontario, Canada L4N 4Y8
Fireplaces, Heating and Cooling: 705-721-1212 • Grills: 705 726-4278 • napoleonproducts.com
Width Height
Actual
49 17 11/16 17 15/16
49 17 11/16 17 15/16
49 17 11/16 17 15/16
49 17 11/16 17 15/16
B
standard
*
E F
*
E
F
Dimensions
C D E
9" 17 11/16" 47 9/16"
(228.6mm) (450mm) (1207.8mm)
9" 17 11/16" 47 9/16"
(228.6mm) (450mm) (1207.8mm)
9" 17 11/16" 47 9/16"
(228.6mm) (450mm) (1207.8mm)
9" 17 11/16" 47 9/16"
(228.6mm) (450mm) (1207.8mm)
Depth
Framing Actual Framing
9 8
9 8
9 4 1/2
9 4 1/2
C
C
D D
deep
trim trim
F G H
8 1/16" 12" 43 5/8"
(205.2mm) (304.8mm) (1107.6mm)
8 1/16" 12" 43 5/8"
(205.2mm) (304.8mm) (1107.6mm)
4 9/16" 12" 43 5/8"
(116.3mm) (304.8mm) (1107.6mm)
4 9/16" 12" 43 5/8"
(116.3mm) (304.8mm) (1107.6mm)
Viewing Area
12 X 43 5/8
12 X 43 5/8
12 X 43 5/8
12 X 43 5/8
04/2018
