Panasonic TC-L32U3 Service Hints
Chassis: la14 & la15
Hide thumbs
Also See for TC-L32U3:
- Owner's manual (138 pages) ,
- Service manual (67 pages) ,
- Owner's manual (48 pages)
Advertisement
Quick Links
Subject : Caution for screw to secure bracket to pedestal base & bracket to TV set.
Please use this service hint together with the manual Model No. TH-L32 SERIES.
Except for the parts listed in table below, all parts are same.
TABLE OF CONTENTS
1 Service Hints ------------------------------------------------------------------------------------------------------------------------------------------------ 2
TC-L32U3
Model No.
TC-L32C3
TC-32LX34
TC-L3232C
TC-L32X30
Chassis:
LA14 & LA15
© Panasonic Corporation 2011. Unauthorized
copying and distribution is a violation of law
ORDER NO. MTV1104005BE
LCD TV
PAGE
Advertisement
Related Manuals for Panasonic TC-L32U3
Summary of Contents for Panasonic TC-L32U3
- Page 1 Please use this service hint together with the manual Model No. TH-L32 SERIES. Except for the parts listed in table below, all parts are same. TABLE OF CONTENTS PAGE 1 Service Hints ------------------------------------------------------------------------------------------------------------------------------------------------ 2 © Panasonic Corporation 2011. Unauthorized copying and distribution is a violation of law...
-
Page 2: Service Hints
1 Service Hints SYMPTOM: Remote receiver not functioning. DEFECT SAMPLE: Remote receiver board (TNPA5378) damaged with screw marking. (as shown) CAUSE: KA Board (TNPA5378) damaged due to wrong TYPE A screw applied instead of TYPE B screw usage. CAUTION POINT: a) Only use attached screw TYPE A to bracket for fixing to pedestal base. - Page 3 b) Only use attached screw TYPE B to fanbag for fixing bracket to TV set. ACTION: Change remote receiver board (TNPA5378) if found damage. *NOTE : If wrongly used screw TYPE A to secure bracket to TV set, it will damage the remote receiver board (TNPA5378).
