Owner's Manual
Single-Display Sit-Stand
Desk-Mount Workstation
Model: WWSS1332C
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY
(17.6 lb. / 8 kg). SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR!
Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com
Русскоязычная версия настоящего руководства представлена на веб-сайте компании
Tripp Lite по адресу: www.tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar:
www.tripplite.com
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
1
17-09-134-933777-EN.indd 1
10/23/2017 10:19:41 AM

Advertisement

loading

Related Manuals for Tripp Lite WorkWise WWSS1332C

Summary of Contents for Tripp Lite WorkWise WWSS1332C

  • Page 1 Owner’s Manual Single-Display Sit-Stand Desk-Mount Workstation Model: WWSS1332C CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY (17.6 lb. / 8 kg). SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com Русскоязычная...

  • Page 2: Component Checklist

    Component Checklist IMPORTANT: Ensure all parts according to the component checklist have been received prior to installation. If any parts are missing or faulty, visit www.tripplite.com/support for service. Bracket Arm Support Mast Keyboard Shelf Clamp Top Clamp Bottom Cable Clamp Grommet Pressure Plate M8 x 105...
  • Page 3 The WWSS1332C Single-Display Sit-Stand Workstation offers two different mounting methods: by desk clamp or by grommet mount. For easy and convenient installation and removal, use the desk clamp mounting option. For a permanent mounting solution, use the grommet mounting option. Desk Clamp Assembly –...
  • Page 4 Desk Clamp Assembly Option 1a-3 1a-4 To proceed with step 2 of assembly, go to page 6. 17-09-134-933777-EN.indd 4 10/23/2017 10:19:41 AM...
  • Page 5 Grommet Mount Assembly Option Note: For instructions on Clamp Assembly, go to page 3. 1b-1 1b-2 3/8 to 3” (10 to 80 mm) To proceed with step 2 of assembly, go to page 6. 17-09-134-933777-EN.indd 5 10/23/2017 10:19:41 AM...
  • Page 6 Desk Clamp/Grommet Mount Assembly Remove VESA Plate from Support Mast Attach Keyboard Shelf to Support Mast 17-09-134-933777-EN.indd 6 10/23/2017 10:19:41 AM...
  • Page 7 Desk Clamp/Grommet Mount Assembly Attach Keyboard Shelf and Support Mast Assembly to Bracket Arm 3/16” (5 mm) Attach VESA plate to back of display Note: Firmly secure the VESA plate to the display using the appropriate screws, washers and spacers (if necessary). Do not over-tighten screws.
  • Page 8 Desk Clamp/Grommet Mount Assembly Slide VESA plate and Display on to the Support Mast Using an assistant or mechanical lifting equipment, lift the display with attached VESA plate. Slide the VESA plate over the Support Mast bracket. Reattach the top knob to secure the VESA mount (removed in step 1).
  • Page 9 Desk Clamp/Grommet Mount Assembly Adjust to the desired location or tilt +15° -15° To correct the tilting angle, tighten the adjustment screws using the provided Hex Keys (or tighten the knob). Maintenance • Check that the bracket is secure and safe to use at regular intervals (at least every three months).

  • Page 10: Warranty And Product Registration

    Warranty and Product Registration 5-Year Limited Warranty Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of 5 years from the date of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the product, in its sole discretion.
