e-Manual
Philips LCD Monitor Electronic User's Manual
file:///D|/My%20Documents/dfu/A9/english/190p6/index.htm2005-06-09 8:34:44 AM

Advertisement

Table of Contents
loading

Related Manuals for Philips 190p6

Summary of Contents for Philips 190p6

  • Page 1 Philips LCD Monitor Electronic User’s Manual file:///D|/My%20Documents/dfu/A9/english/190p6/index.htm2005-06-09 8:34:44 AM...

  • Page 2: Safety And Troubleshooting Information

    In order to maintain the best performance of your monitor and use it for a longer lifetime, please use the monitor in a location that falls within the following temperature and humidity ranges. file:///D|/My%20Documents/dfu/A9/english/190p6/safety/safety.htm (1 of 2)2005-06-09 8:34:47 AM Temperature: 5-40°C 41-104°F...
  • Page 3 Consult a service technician if the monitor does not operate normally, or you are not sure what procedure to take when the operating instructions given in this manual have been followed. file:///D|/My%20Documents/dfu/A9/english/190p6/safety/safety.htm (2 of 2)2005-06-09 8:34:47 AM Humidity: 20-80% RH RETURN TO TOP OF THE PAGE...

  • Page 4: About This Manual

    Throughout this guide, blocks of text may be accompanied by an icon and printed in bold or italic type. These blocks contain notes, cautions or warnings. They are used as follows: file:///D|/My%20Documents/dfu/A9/english/190p6/about/about.htm (1 of 2)2005-06-09 8:34:48 AM provides tips and solutions for common problems...
  • Page 5 All rights reserved. Reproduction, copying, use, modification, hiring, renting, public performance, transmission and/or broadcasting in whole or in part is prohibited without written consent of Philips Electronics NV file:///D|/My%20Documents/dfu/A9/english/190p6/about/about.htm (2 of 2)2005-06-09 8:34:48 AM RETURN TO TOP OF THE PAGE...
  • Page 6 • Screen size • Pixel Pitch • LCD Panel type • Effective viewing area • Display Colors file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (1 of 13)2005-06-09 8:34:53 AM RETURN TO TOP OF THE PAGE TFT LCD 19" / 48.26 cm diagonal 0.294 x 0.294 mm 1280 x 1024 pixels R.G.B.
  • Page 7 • Peak contrast angle • White Chromaticity • Viewing Angle (C/R>5) • Response time * This data is subject to change without notice. file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (2 of 13)2005-06-09 8:34:53 AM 56 Hz-76 Hz 30k Hz-83 kHz 140 MHz 75 ohm 2.2K ohm 0.7 Vpp...
  • Page 8 DR feature enriches your photo and video experience with preset modes ideal for your favorite DR only works with latest Philips LCD Monitor which is sepcially built to use this DR can only work on 170X5,190X5 or 170P6/190P6 or later version LCD monitor. DR feature in your monitor, you'll want install the LightFrame DR, place the CD in your CD-ROM drive.
  • Page 9 Your cursor becomes a blue light bulb when it passes over an active LightFrame LightFrame DR in the selected window. file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (4 of 13)2005-06-09 8:34:53 AM DR enhanced window or area. Clicking DR enhancement. DR in the selected window. To activate...
  • Page 10 Exit icon 3. Optimizing LightFrame Here's how to optimize LightFrame Select your desired mode from the mode Menu. Click to open the mode. file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (5 of 13)2005-06-09 8:34:53 AM Turns LightFrame DR on and off. When LightFrame DR icon selected window, the icon changes from blue to yellow.
  • Page 11 Product Information The settings menu Change settings by pulling the color bar or pressing the plus (+) or minus (-) button to move incrementally to the desired levels. file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (6 of 13)2005-06-09 8:34:53 AM...
  • Page 12 LightFrame you can abort or continue the installation; however, if you continue the installation, LightFrame file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (7 of 13)2005-06-09 8:34:53 AM Hot Key, an OSD window opens. Touch the button continually to scroll among DR Hot Key for three seconds to enter the LightFrame DR, Dutch, French, German, Italian, Portuguese, Spanish, DR only works with monitors specially built to use this software.
  • Page 13 Note: Do not block the sensor file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (8 of 13)2005-06-09 8:34:53 AM DR shortcut icon appears on your screen whenever the computer is started. Digital Reality, please refer to the help information, which is available after DR is compatible with:...
  • Page 14 If an input from a keyboard, mouse or other input device is detected, the monitor will 'wake up' automatically. The following table shows the power consumption and signaling of this automatic power saving feature: VESA Mode Active Sleep file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (9 of 13)2005-06-09 8:34:53 AM Resolution 640*350 720*400 640*480 640*480...
  • Page 15 Signal Assignment T.M.D.S. Data2- T.M.D.S. Data2+ T.M.D.S. Data2/4 Shield No connect No connect file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (10 of 13)2005-06-09 8:34:53 AM ® compliant. s an NERGY ® NERGY guidelines for energy efficiency. RETURN TO TOP OF THE PAGE 425 x 432 x 210 mm 7.3 kg...
  • Page 16 Green video ground Blue video ground Product Views Follow the links to see various views of the monitor and its components. Front View Product Description file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (11 of 13)2005-06-09 8:34:53 AM T.M.D.S. Clock 14 +5V Power Shield 15 Ground (for +5V) 23 T.M.D.S.
  • Page 17 Product Information Physical Function Tilt Swivel file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (12 of 13)2005-06-09 8:34:53 AM...
  • Page 18 Product Information Height adjustment RETURN TO TOP OF THE PAGE file:///D|/My%20Documents/dfu/A9/english/190p6/product/product.htm (13 of 13)2005-06-09 8:34:53 AM...

  • Page 19: Installing Your Lcd Monitor

    Optimizing • Performance VOLUME file:///D|/My%20Documents/dfu/A9/english/190p6/install/install.htm (1 of 3)2005-06-09 8:34:57 AM UP and DOWN buttons are used when adjusting the OSD of your monitor. LEFT and RIGHT buttons, like the UP and DOWN buttons, are also used in adjusting the OSD of your monitor.
  • Page 20 Installing Your LCD Monitor Rear View Optimizing Performance file:///D|/My%20Documents/dfu/A9/english/190p6/install/install.htm (2 of 3)2005-06-09 8:34:57 AM LightFrame hotkey for mode-switching between full-screen mode and multi-window mode USB Hub for versatile peripheral connections. RETURN TO TOP OF THE PAGE 1 Earphone jack 2 PC audio input...
  • Page 21 Click on the link to know more about this program. More about file:///D|/My%20Documents/dfu/A9/english/190p6/install/install.htm (3 of 3)2005-06-09 8:34:57 AM You can check the current display settings by pressing the 'OK' button Flat Panel Adjust (FP Adjust) FP_setup04.exe...

  • Page 22: On-Screen Display

    Below is an overall view of the structure of the On-Screen Display. You can use this as a reference when you want to work your way around the different adjustments later on. file:///D|/My%20Documents/dfu/A9/english/190p6/osd/osddesc.htm (1 of 3)2005-06-09 8:35:01 AM buttons at the front bezel of the monitor to move to adjust/select the change.
  • Page 23 On-Screen Display Note: sRGB is a standard for ensuring correct exchange of colors between different devices (e.g. digital cameras, monitors, printers, scanners, etc.) file:///D|/My%20Documents/dfu/A9/english/190p6/osd/osddesc.htm (2 of 3)2005-06-09 8:35:01 AM...
  • Page 24 After this, please do not change the brightness or contrast setting of your monitor. If you change either of these, the monitor will exit the sRGB mode and go to a color temperature setting of 6500K. file:///D|/My%20Documents/dfu/A9/english/190p6/osd/osddesc.htm (3 of 3)2005-06-09 8:35:01 AM RETURN TO TOP OF THE PAGE...

  • Page 25: Customer Care And Warranty

    Customer Care & Warranty Customer Care & Warranty PLEASE SELECT YOUR COUNTRY/AREA TO REVIEW DETAILS OF YOUR WARRANTY COVERAGE WESTERN EUROPE: Austria Finland • Ireland • Italy Switzerland • Spain • United Kingdom EASTERN EUROPE: Czech Republic Turkey LATIN AMERICA: Antilles Peru •...
  • Page 26 The dimension of color that is referred to an achromatic scale, ranging from black to white, also called lightness or luminous reflectance. Because of confusion with saturation, the use of this term should be discouraged. file:///D|/My%20Documents/dfu/A9/english/190p6/glossary/glossary.htm (1 of 9)2005-06-09 8:35:07 AM R S T U V W X Y Z...
  • Page 27 Contrast The luminance variation between light and dark areas in an image. Contrast ratio The ratio of luminance between the brightest white pattern and the darkest black pattern. file:///D|/My%20Documents/dfu/A9/english/190p6/glossary/glossary.htm (2 of 9)2005-06-09 8:35:07 AM RETURN TO TOP OF THE PAGE...
  • Page 28 Companies joining this program, must be willing to commit themselves to manufacture one or more products capable of going into a low -power state (< 30 W) either after a period of inactivity, or after a predetermined time selected by the user. file:///D|/My%20Documents/dfu/A9/english/190p6/glossary/glossary.htm (3 of 9)2005-06-09 8:35:07 AM RETURN TO TOP OF THE PAGE...
  • Page 29 A technique of improving the viewing angle of an LCD where the liquid crystal molecules are switched in the plane of the LCD layer rather than vertical to it. file:///D|/My%20Documents/dfu/A9/english/190p6/glossary/glossary.htm (4 of 9)2005-06-09 8:35:07 AM RETURN TO TOP OF THE PAGE...
  • Page 30 A unit of luminance equal to 1 cd/m2 or 0.292 ftL. Pixel PICture Element; the smallest element on a computerized CRT or LCD image, and hence a display. Polarizer file:///D|/My%20Documents/dfu/A9/english/190p6/glossary/glossary.htm (5 of 9)2005-06-09 8:35:07 AM RETURN TO TOP OF THE PAGE...
  • Page 31 6500K. Other: USB plug: An upstream and a downstream USB plug is provide for user's convenience. file:///D|/My%20Documents/dfu/A9/english/190p6/glossary/glossary.htm (6 of 9)2005-06-09 8:35:07 AM...
  • Page 32 The hub isolates low speed ports from full speed signaling. A hub consists of two portions: the Hub Controller and Hub Repeater. The repeater is a protocol- file:///D|/My%20Documents/dfu/A9/english/190p6/glossary/glossary.htm (7 of 9)2005-06-09 8:35:07 AM USB automatically determines resources (like driver software and...
  • Page 33 The direction of data flow towards the host. An upstream port is the port on a device electrically closest to the host that generates upstream data traffic from the hub. Upstream ports receive downstream data traffic. file:///D|/My%20Documents/dfu/A9/english/190p6/glossary/glossary.htm (8 of 9)2005-06-09 8:35:07 AM...
  • Page 34 Glossary Vertical refresh rate Expressed in Hz, it is the number of frames (complete pictures) written to the screen every second. file:///D|/My%20Documents/dfu/A9/english/190p6/glossary/glossary.htm (9 of 9)2005-06-09 8:35:07 AM RETURN TO TOP OF THE PAGE RETURN TO TOP OF THE PAGE...

  • Page 35: Download And Print

    2. From the menu that appears, choose 'Save Link As...', 'Save Target As...' or 'Download Link to Disk'. 3. Choose where you would like to save the file; click 'Save' (if prompted to save as either 'text' or 'source', choose 'source'). file:///D|/My%20Documents/dfu/A9/english/download/download.htm (1 of 3)2005-06-09 8:35:09 AM Adobe® Acrobat Reader for 190B6.pdf 190P6.pdf 190S6.pdf Mac.
  • Page 36 Download and Print Printing instructions: To print the manual: 1. With the manual file open, follow your printer's instructions and print the pages you need. Installing FPadjust Program The FP Adjust program generates alignment patterns which will help you adjust monitor settings such as CONTRAST, BRIGHTNESS, HORIZONTAL &...
  • Page 37 Download and Print RETURN TO TOP OF THE PAGE file:///D|/My%20Documents/dfu/A9/english/download/download.htm (3 of 3)2005-06-09 8:35:09 AM...

  • Page 38: Faqs (Frequently Asked Questions)

    You have 10 minutes to complete the operation; if you do not complete within 10 minutes, power off and re-power on monitor to enter changes. What does 'refresh rate' mean in connection with an LCD monitor? file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_faq.htm (1 of 8)2005-06-09 8:35:13 AM...
  • Page 39 Make sure the AC power cord is connected to the Monitor. Will the LCD monitor accept an interlaced signal under PC models? No. If an Interlace signal is used, the screen displays both odd and even horizontal file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_faq.htm (2 of 8)2005-06-09 8:35:13 AM...
  • Page 40 ARM or accessories. Touch panels are being developed for future applications. Check with your Philips sales representative for more information. Screen Adjustments What is the FPadjust program on the CD-ROM? file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_faq.htm (3 of 8)2005-06-09 8:35:13 AM RETURN TO TOP OF THE PAGE...
  • Page 41 Please contact your dealer/retailer for more information. Are Philips LCD monitors Plug-and-Play? Yes, the monitors are Plug-and-Play compatible with Windows® 95, 98, 2000 and What is USB (Universal Serial Bus)? file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_faq.htm (4 of 8)2005-06-09 8:35:13 AM RETURN TO TOP OF THE PAGE...
  • Page 42 This combination is sometimes called 'glass' or 'cell.' The LCD cell is assembled into a 'module' by adding the backlight, driver electronics and frame. file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_faq.htm (5 of 8)2005-06-09 8:35:13 AM RETURN TO TOP OF THE PAGE...
  • Page 43 A TFT LCD has several advantages over a CRT, since it can be very thin and no flickering occurs because it does not use the scanning file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_faq.htm (6 of 8)2005-06-09 8:35:13 AM...
  • Page 44 Unlike a CRT, an LCD monitor does not have key parts that generate Electro Magnetic Interference, especially magnetic fields. Also, since an LCD display utilizes relatively low power, its power supply is extremely quiet. Ergonomics, Ecology and Safety Standards file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_faq.htm (7 of 8)2005-06-09 8:35:13 AM RETURN TO TOP OF THE PAGE...
  • Page 45 The specification page provides detailed data on safety standards. More information is provided in the file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_faq.htm (8 of 8)2005-06-09 8:35:13 AM Regulatory Information section. RETURN TO TOP OF THE PAGE...

  • Page 46: Troubleshooting

    (Power LED not lit) No Picture (Power LED is amber or yellow) Screen says Screen says file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_troub.htm (1 of 3)2005-06-09 8:35:14 AM Check these items Make sure the power cord is plugged into the power outlet and into the back of the monitor.
  • Page 47 Image vibrates on the screen Vertical flicker appears Horizontal flicker appears The screen is too bright or too dark file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_troub.htm (2 of 3)2005-06-09 8:35:14 AM The Auto Function is designed for use on standard Macintosh or IBM-compatible PCs running Microsoft Windows.
  • Page 48 Green, red, blue, dark, and white dots remains For further assistance, refer to the Philips distributor. file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_troub.htm (3 of 3)2005-06-09 8:35:14 AM If an image remains on the screen for an extended period of time, it may be imprinted in the screen and leave an after- image.

  • Page 49: Regulatory Information

    Labeled products must meet strict environmental demands, for example, in respect of the reduction (Taiwan Only) of electric and magnetic fields, physical and visual ergonomics and good usability. file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (1 of 13)2005-07-20 6:30:27 PM Congratulations! You have just purchased a TCO '99 approved and labeled product! Your choice has provided you with a product developed for professional use.
  • Page 50 The relevant TCO'99 requirement states that batteries may not contain any mercury. It also demands that mercury is not present in any of the electrical or electronics components associated with the labeled unit. CFCs (freons) file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (2 of 13)2005-07-20 6:30:27 PM http://www.tco-info.com/ RETURN TO TOP OF THE PAGE...
  • Page 51 Energy Energy-saving mode after a certain time-beneficial both for the user and the environment Electrical safety file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (3 of 13)2005-07-20 6:30:27 PM RETURN TO TOP OF THE PAGE Congratulations! The display you have just purchased carries the TCO'03 Displays label.
  • Page 52 For help and service, please contact Information Center Mr. Job Chiu - Environment manager file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (4 of 13)2005-07-20 6:30:27 PM chlorinated and brominated flame retardants and polymers heavy metals such as cadmium, mercury and lead. For more information, please visit www.tcodevelopment.com...
  • Page 53 - 93/68/EEC (Amendment of EMC and Low Voltage Directive) and is produced by a manufacturing organization on ISO9000 level. file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (5 of 13)2005-07-20 6:30:27 PM RETURN TO TOP OF THE PAGE This marking on the product or on its packaging illustrates that, under European...
  • Page 54 One step We recommend you switch off the monitor when it is not in use for quite a long time. Federal Communications Commission (FCC) Notice (U.S. Only) file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (6 of 13)2005-07-20 6:30:27 PM RETURN TO TOP OF THE PAGE PHILIPS...
  • Page 55 Augmenter la distance entre l'équipement et le récepteur. Brancher l'équipement sur un autre circuit que celui utilisé par le récepteur. Demander l'aide du marchand ou d'un technicien chevronné en radio/télévision. file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (7 of 13)2005-07-20 6:30:27 PM RETURN TO TOP OF THE PAGE...
  • Page 56 Interference. Install and use the equipment according to the instruction manual. Class B ITE file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (8 of 13)2005-07-20 6:30:27 PM RETURN TO TOP OF THE PAGE RETURN TO TOP OF THE PAGE...
  • Page 57 A protection mark "B" confirms that the equipment is in compliance with the protection usage requirements of standards PN-93/T-42107 and PN-89/E-06251. file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (9 of 13)2005-07-20 6:30:27 PM RETURN TO TOP OF THE PAGE...
  • Page 58 FÖRSÄKRA DIG OM ATT HUVUDBRYTARE OCH UTTAG ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING PÅPLATS. Placering/Ventilation ADVARSEL: SØRG VED PLACERINGEN FOR, AT NETLEDNINGENS STIK OG STIKKONTAKT ER NEMT TILGÆNGELIGE. file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (10 of 13)2005-07-20 6:30:27 PM RETURN TO TOP OF THE PAGE...
  • Page 59 Damit Ihr Monitor immer den in der Zulassung geforderten Werten entspricht, ist darauf zu achten, daß Reparaturen nur durch Fachpersonal durchgeführt werden. nur original-Ersatzteile verwendet werden. bei Ersatz der Bildröhre nur eine bauartgleiche eingebaut wird. file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (11 of 13)2005-07-20 6:30:27 PM RETURN TO TOP OF THE PAGE RETURN TO TOP OF THE PAGE...
  • Page 60 This product may contain lead and/or mercury. Dispose of in accordance to local-state and federal regulations. For additional information on recycling contact Information for UK only file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (12 of 13)2005-07-20 6:30:27 PM RETURN TO TOP OF THE PAGE www.eia.org (Consumer Education Initiative)
  • Page 61 Regulatory Information file:///D|/My%20Documents/dfu/A9/china/190p6/safety/regs/regulat.htm (13 of 13)2005-07-20 6:30:27 PM pin plug fitted in its place. If the mains plug contains a fuse, this should have a value of 5A. If a plug without a fuse is used, the fuse at the distribution board should not be greater than 5A.

  • Page 62: Other Related Information

    Use a Cord Set consisting of a minimum 18 AWG cord and grounding type attachment plug rated 15 A, 250 V. The Cord Set should have the appropriate safety approvals for the country in which the equipment will be installed and / or be marked HAR. file:///D|/My%20Documents/dfu/A9/english/190p6/safety/saf_other.htm2005-06-09 8:35:17 AM RETURN TO TOP OF THE PAGE...
  • Page 63 For more information of Philips SmartManage, please contact with Philips sales representatives in your country. SmartManage is a software dedicated to business environments. Personal users normally do not need to use SmartManage. Philips SmartControl file:///D|/My%20Documents/dfu/A9/english/190p6/product/smart.htm (1 of 5)2005-06-09 8:35:25 AM...
  • Page 64 By moving the sliding bar toward left or right, users will be able to adjust brightness, contrast, audio volume (if applicable), video noise (not applicable when using DVI-D input), and color temperatures. file:///D|/My%20Documents/dfu/A9/english/190p6/product/smart.htm (2 of 5)2005-06-09 8:35:25 AM http:// www.philips.com...
  • Page 65 Users can adjust the horizontal and vertical position of the screen by moving the sliding bar left and right. This function is disabled when using DVI-D (digit) input. Product Information Click Product Information in the left pane to view the product information stored in the monitor's memory. file:///D|/My%20Documents/dfu/A9/english/190p6/product/smart.htm (3 of 5)2005-06-09 8:35:25 AM...
  • Page 66 SmartControl is a control panel extension, which helps users to adjust monitor performances and settings by a software interface, instead of the hardware buttons at the front bezel of the monitors. file:///D|/My%20Documents/dfu/A9/english/190p6/product/smart.htm (4 of 5)2005-06-09 8:35:25 AM...
  • Page 67 In a monitor with the LightFrame feature, when LightFrame is enabled, sRGB adjustment in SmartControl is not responding, why? When LightFrame is enabled, the sRGB adjustment is disabled automatically. To use sRGB, you need to disable LightFrame first. file:///D|/My%20Documents/dfu/A9/english/190p6/product/smart.htm (5 of 5)2005-06-09 8:35:25 AM RETURN TO TOP OF THE PAGE...

  • Page 68: Philips Pixel Defect Policy

    There are the types of bright dot defects: file:///D|/My%20Documents/dfu/A9/english/190p6/product/pixel.htm (1 of 4)2005-06-09 8:35:26 AM Bright dot defects appear as pixels or sub pixels that are always lit or 'on'. That...
  • Page 69 LCD panel in a Philips flat panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the following tables. file:///D|/My%20Documents/dfu/A9/english/190p6/product/pixel.htm (2 of 4)2005-06-09 8:35:26 AM Two adjacent lit sub pixels: - Red + Blue = Purple...
  • Page 70 Total bright or black dot defects of all types Note: * 1 or 2 adjacent sub pixel defects = 1 dot defect All Philips monitors are ISO13406-2 Compliant file:///D|/My%20Documents/dfu/A9/english/190p6/product/pixel.htm (3 of 4)2005-06-09 8:35:26 AM ACCEPTABLE LEVEL 190P6 190B6 ACCEPTABLE LEVEL...
  • Page 71 Philips Pixel Defect Policy file:///D|/My%20Documents/dfu/A9/english/190p6/product/pixel.htm (4 of 4)2005-06-09 8:35:26 AM...
  • Page 72 Note: Philips worldwide service centers have the right to return to you any monitor turned-in for repair or exchange if Views they are found to be defect-free under the Philips Perfect Panel Warranty policy. file:///D|/My%20Documents/dfu/A9/english/190p6/product/perfect.htm2005-06-09 8:35:27 AM . Philips Perfect Panel™ warranty coverage begins from RETURN TO TOP OF THE PAGE...

  • Page 73: Rotating The Monitor

    Before rotating the monitor, remove the lock on the back of the base and raise the monitor to a higher vertical height adjustment to avoid hitting the bottom edge of the monitor when rotating. file:///D|/My%20Documents/dfu/A9/english/190p6/product/rotate.htm (1 of 3)2005-06-09 8:35:27 AM...
  • Page 74 Select the Settings tab and click Advanced. then find your graphic card. For ATI graphics cards: Select the Rotation tab and set the preferred rotation. For nVidia graphics cards: Click the nVidia tab; in the left-hand column select NVRotate and then select the preferred rotation. file:///D|/My%20Documents/dfu/A9/english/190p6/product/rotate.htm (2 of 3)2005-06-09 8:35:27 AM...
  • Page 75 If you do not find the rotation option or if you have problems when following the steps listed above, you need to go to your computer graphics card manufacturer's website or your computer manufacturer's website for information on rotating your operating system. file:///D|/My%20Documents/dfu/A9/english/190p6/product/rotate.htm (3 of 3)2005-06-09 8:35:27 AM RETURN TO TOP OF THE PAGE...

  • Page 76: Connecting To Your Pc

    • Getting Started • Optimizing Performance • The Base Connecting to Your PC file:///D|/My%20Documents/dfu/A9/english/190p6/install/connect.htm (1 of 3)2005-06-09 8:35:34 AM Description Power Cord (socket may differ for different countries) Macintosh Adapter (optional) VGA Signal Cable E-DFU package with Quick Setup Guide and CD-ROM.
  • Page 77 Connecting to Your PC file:///D|/My%20Documents/dfu/A9/english/190p6/install/connect.htm (2 of 3)2005-06-09 8:35:34 AM Plug in the cables into connectors. Note: If you use an Apple Macintosh, you need to connect the special Mac adapter to one end of the monitor signal cable...
  • Page 78 Plug the power cord of your computer and your monitor into a nearby outlet. Turn on your computer and monitor. If the monitor displays an image, installation is complete. file:///D|/My%20Documents/dfu/A9/english/190p6/install/connect.htm (3 of 3)2005-06-09 8:35:34 AM RETURN TO TOP OF THE PAGE...
  • Page 79 Adjust the monitor attitude for your preference. to your PC • Getting Started • Optimizing Performance • Unlock the Base • Remove the Base Remove the Base Remove the 4 screws. file:///D|/My%20Documents/dfu/A9/english/190p6/install/base.htm (1 of 2)2005-06-09 8:35:35 AM RETURN TO TOP OF THE PAGE...
  • Page 80 The Base RETURN TO TOP OF THE PAGE file:///D|/My%20Documents/dfu/A9/english/190p6/install/base.htm (2 of 2)2005-06-09 8:35:35 AM...

  • Page 81: Getting Started

    Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'. Double click on the 'Display' icon. Select the 'Settings' tab then click on 'Advanced...'. Select the 'Monitor' button, then click on 'Change...' button. file:///D|/My%20Documents/dfu/A9/english/190p6/install/gt_start.htm (1 of 3)2005-06-09 8:35:35 AM...
  • Page 82 Windows® XP' message, please click on the 'Continue Anyway' button. Click on the 'Finish' button then the 'Close' button. Click on the 'OK' button and then the 'OK' button again to close the Display_Properties file:///D|/My%20Documents/dfu/A9/english/190p6/install/gt_start.htm (2 of 3)2005-06-09 8:35:35 AM...
  • Page 83 Getting Started dialog box. If your Windows® 95/98/2000/Me/XP version is different or you need more detailed installation information, please refer to Windows® 95/98/2000/Me/XP user's manual. file:///D|/My%20Documents/dfu/A9/english/190p6/install/gt_start.htm (3 of 3)2005-06-09 8:35:35 AM RETURN TO TOP OF THE PAGE...

  • Page 84: Your Philips F1Rst Choice Warranty

    Your Philips F1rst Choice Warranty Your Philips F1rst Choice Warranty Thank you for purchasing this Philips monitor. All Philips monitors are designed and manufactured to high standards and deliver high-quality performance, ease of use and ease of installation. Should you encounter any difficulties while installing or using this product, please contact the Philips helpdesk directly to benefit from your Philips F1rst Choice Warranty.
  • Page 85 Your Philips F1rst Choice Warranty Reception problems caused by signal conditions or cable or antenna systems outside the unit; Defects caused by abuse or misuse of the monitor; Product requires modification or adaptation to enable it to comply with local or national technical standards, which apply in countries for which the product was not originally designed, manufactured, approved and/or authorized.
  • Page 86 Your Philips F1rst Choice Warranty file:///D|/My%20Documents/dfu/A9/english/warranty/war_1st.htm (3 of 3)2005-06-09 8:35:40 AM...

  • Page 87: Your Guarantee In Central And Eastern Europe

    Your Guarantee in Central and Eastern Europe Your Guarantee in Central and Eastern Europe Dear Customer, Thank you for purchasing this Philips product, which has been designed and manufactured to the highest quality standards. If, unfortunately, something should go wrong with this product Philips guarantees free of charge labor and replacement parts during a period of 36 months from date of purchase.
  • Page 88 Your Guarantee in Central and Eastern Europe Therefore always check whether a product can be used in a specific country. Just a click away In case of any problems, we advise you to read the operating instructions carefully or go to the philips.com/support website for additional support.

  • Page 89: Your International Guarantee

    International Guarantee Your International Guarantee Dear Customer, Thank you for purchasing this Philips product which has been designed and manufactured to the highest quality standards. If, unfortunately, something should go wrong with this product Philips guarantees free of charge labor and replacement parts irrespective of the country where it is repaired during a period of 12 months from date of purchase.
  • Page 90 International Guarantee file:///D|/My%20Documents/dfu/A9/english/warranty/war_intl.htm (2 of 2)2005-06-09 8:35:41 AM...

  • Page 91: Who Is Covered

    United States Guarantee Your Philips F1rst Choice Warranty(Canada/USA) Thank you for purchasing this Philips monitor. All Philips monitors are designed and manufactured to high standards and deliver high-quality performance, ease of use and ease of installation. Should you encounter any difficulties while installing or using this product, please contact Philips directly to benefit from your Philips F1rst Choice Warranty.

  • Page 92: Where Can I Get More Information

    United States Guarantee Your warranty does not cover: labor charges for installation or setup of the product, adjustment of customer controls on the product, and installation or repair of antenna systems outside of the product. product repair and/or part replacement because of misuse, accident, unauthorized repair or other cause not within the control of Philips Consumer Electronics.
  • Page 93 United States Guarantee (877) 835-1838 or (919) 573-7855 (In U.S.A., Puerto Rico and U.S. Virgin Islands, all implied warranties, including implied warranties of merchantability and fitness for a particular purpose, are limited in duration to the duration of this express warranty. But, because some states do not allow limitations on how long an implied warranty may last, this limitation may not apply to you.) TO GET WARRANTY SERVICE IN CANADA...
  • Page 94 United States Guarantee Other cards installed Having the following information available will also help speed up the process: Your proof of purchase indicating: date of purchase, dealer name, model and product serial number. The full address to which the swap model should be delivered. Just a phone call away Philips’...

  • Page 95: F1Rst Choice Contact Information

    F1rst Choice Contact Information F1rst Choice Contact Information Country Austria Belgium Cyprus Denmark Finland France Germany Greece Ireland Italy Luxembourg The Netherlands Norway Portugal Spain Sweden Switzerland United Kingdom file:///D|/My%20Documents/dfu/A9/english/warranty/warfirst.htm2005-06-09 8:35:48 AM Telephone number Tariff 0820 901115 070 253 010 800 92256 Free of Charge 3525 8761...

  • Page 96: Consumer Information Centers

    Consumer Information Centers Consumer Information Centers Antilles • Argentina • Australia Belarus • Bulgaria • Croatia India • Indonesia • Korea • Pakistan • Paraguay • Montenegro • Singapore Ukraine • Uruguay • Venezuela Eastern Europe BELARUS Technical Center of JV IBA M.
  • Page 97 Consumer Information Centers ESTONIA FUJITSU SERVICES OU Akadeemia tee 21G EE-12618 Tallinn Tel: +372 6519900 www.ee.invia.fujitsu.com HUNGARY Serware Szerviz Vizimolnár u. 2-4 HU - 1031 Budapest Tel: +36 1 2426331 Email: inbox@serware.hu www.serware.hu LATVIA ServiceNet LV Jelgavas iela 36 LV - 1055 Riga, Tel: +371 7460399 Email: serviss@servicenet.lv LITHUANIA...
  • Page 98 Consumer Information Centers SLOVAKIA Datalan Servisne Stredisko Puchovska 8 SK - 831 06 Bratislava Tel: +421 2 49207155 Email: servis@datalan.sk SLOVENIA PC HAND Brezovce 10 SI - 1236 Trzin Tel: +386 1 530 08 24 Email: servis@pchand.si POLAND Zolter ul.Zytnia 1 PL - 05-500 Piaseczno Tel: +48 22 7501766 Email: servmonitor@zolter.com.pl...
  • Page 99 Consumer Information Centers UKRAINE Comel Shevchenko street 32 UA - 49030 Dnepropetrovsk Tel: +380 562320045 www.csp-comel.com Latin America ANTILLES Philips Antillana N.V. Kaminda A.J.E. Kusters 4 Zeelandia, P.O. box 3523-3051 Willemstad, Curacao Phone: (09)-4612799 Fax : (09)-4612772 ARGENTINA Philips Antillana N.V. Vedia 3892 Capital Federal CP: 1430 Buenos Aires Phone/Fax: (011)-4544 2047...
  • Page 100 Consumer Information Centers COLOMBIA Industrias Philips de Colombia S.A.-Division de Servicio CARRERA 15 Nr. 104-33 Bogota, Colombia Phone:(01)-8000 111001 (toll free) Fax : (01)-619-4300/619-4104 MEXICO Consumer Information Centre Norte 45 No.669 Col. Industrial Vallejo C.P.02300, -Mexico, D.F. Phone: (05)-3687788 / 9180050462 Fax : (05)-7284272 PARAGUAY Av.
  • Page 101 Consumer Information Centers URUGUAY Rambla O'Higgins 5303 Montevideo Uruguay Phone: (598) 619 66 66 Fax: (598) 619 77 77 Customer Desk: Phone: 0004054176 VENEZUELA Industrias Venezolanas Philips S.A. Apartado Postal 1167 Caracas 1010-A Phone: (02) 2377575 Fax : (02) 2376420 Canada CANADA Philips Electronics Ltd.
  • Page 102 Consumer Information Centers NEW ZEALAND Philips New Zealand Ltd. Consumer Help Desk 2 Wagener Place, Mt.Albert P.O. box 1041 Auckland Phone: 0800 477 999 (toll free) Fax : 0800 288 588 Asia BANGLADESH Philips Service Centre 100 Kazi Nazrul Islam Avenue Kawran Bazar C/A Dhaka-1215 Phone: (02)-812909...
  • Page 103 Consumer Information Centers INDIA Phone: 91-20-712 2048 ext: 2765 Fax: 91-20-712 1558 BOMBAY Philips India Customer Relation Centre Bandbox House 254-D Dr. A Besant Road, Worli Bombay 400 025 CALCUTTA Customer Relation Centre 7 justice Chandra Madhab Road Calcutta 700 020 MADRAS Customer Relation Centre 3, Haddows Road...
  • Page 104 Consumer Information Centers KOREA Philips Korea Ltd. Philips House C.P.O. box 3680 260-199, Itaewon-Dong. Yongsan-Ku, Seoul 140-202 Phone: 080 600 6600 (toll free) Fax : (02) 709 1210 MALAYSIA After Market Solutions Sdn Bhd, Philips Authorised Service Center, Lot 6, Jalan 225, Section 51A, 46100 Petaling Jaya, Selangor Darul Ehsan, Malaysia.
  • Page 105 Consumer Information Centers SINGAPORE Accord Customer Care Solutions Ltd Authorized Philips Service Center Consumer Service 620A Lorong 1 Toa Rayoh Singapore 319762 Tel: +65 6882 3999 Fax: +65 6250 8037 TAIWAN Philips Taiwan Ltd. Consumer Information Centre 13F, No. 3-1 Yuan Qu St., Nan Gang Dist., Taipei 115, Taiwan Phone: 0800-231-099 Fax : (02)-3789-2641...
  • Page 106 Consumer Information Centers SOUTH AFRICA PHILIPS SA (PTY) LTD Customer Care Center 195 Main Road Martindale, Johannesburg P.O. box 58088 Newville 2114 Telephone: +27 (0) 11 471 5194 Fax: +27 (0) 11 471 5123 E-mail: phonecare.za@philips.com Middle East DUBAI Philips Middle East B.V. Consumer Information Centre P.O.Box 7785 DUBAI...
