MODELS
PRECAUTIONS TO BE OBSERVED BEFORE BEFORE SERVICING ......................... INSIDE FRONT COVER
WARNING TO SERVICE PERSONNEL .............................................................................................................. 1
FOREWORD AND WARNING ............................................................................................................................. 1
PRODUCT SPECIFICATIONS ............................................................................................................................ 2
WIRE HARNESS DRAWING ............................................................................................................................... 3
COMPONENT REPLACEMENT .......................................................................................................................... 4
PARTS LIST ........................................................................................................................................................ 6
SHARP CORPORATION
SERVICE MANUAL
INSIGHT RANGE HOOD
KB-0333KS
KB-0333KK
KB-0333KW
TABLE OF CONTENTS
This document has been published to be used for after
sales service only.
The contents are subject to change without notice.
1
KB-0333KS
KB-0333KK
KB-0333KW
S65H253KB033K
Page
Advertisement
Table of Contents
Related Manuals for Sharp KB-0333KS
Summary of Contents for Sharp KB-0333KS
- Page 1 KB-0333KS KB-0333KK KB-0333KW SERVICE MANUAL S65H253KB033K INSIGHT RANGE HOOD KB-0333KS KB-0333KK MODELS KB-0333KW TABLE OF CONTENTS Page PRECAUTIONS TO BE OBSERVED BEFORE BEFORE SERVICING ......INSIDE FRONT COVER WARNING TO SERVICE PERSONNEL ......................1 FOREWORD AND WARNING ..........................1 PRODUCT SPECIFICATIONS ..........................2 WIRE HARNESS DRAWING ..........................
-
Page 2: Before Servicing
ING SERVICING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY. 1. Use this unit only in the manner intended by the manufacturer. If you have questions, contact Sharp at the address or telephone number listed on page 2 of this manual. -
Page 3: Product Description
COMPONENT REPLACEMENT KB-0333KW FOREWORD PARTS LIST This Manual has been prepared to provide Sharp Electronics Corp. Service Personnel with Operation and Service Information for the SHARP INSIGHT RANGE HOODS, KB-0333KS, KB-0333KK, KB- 0333KW. It is recommended that service personnel carefully study the entire text of this manual so that they will be qualified to render satisfactory customer service. -
Page 4: Product Specification
KB-0333KS KB-0333KK KB-0333KW PRODUCT SPECIFICATION ITEM DESCRIPTION Power Requirements 120 Volts, 60 Amps 60 Hertz Case Dimensions Width 30" Height 7 1/4" Depth 20" Hood lamps (3 Levels) 2 bulbs (not included) 40W x 2 (Incandescent light bulbs) or 50W x 2 (Halogen bulbs) Hood fan (4 Speeds) Approx. -
Page 5: Schematic Diagram
KB-0333KS KB-0333KK FUSE AND SCHEMATIC DIAGRAM KB-0333KW FUSE To replace the fuse: The hood control contains a fuse to protect it from power 1. Disconnect power at service entrance. surges. If the fuse has opened (blown), the green fan- 2. Remove filters, bottom panel, light wire harness and air level indicators will operate properly when the fan chute. -
Page 6: Component Replacement And Adjustment Procedure
KB-0333KS KB-0333KK KB-0333KW COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE WARNING : Before servicing or cleaning unit, switch power OFF at service panel and lock the service disconnect to prevent power from being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel. - Page 7 KB-0333KS KB-0333KK KB-0333KW CONTROL ASSEMBLY and CONTROL PANEL SERVICING 1. Switch OFF power at service panel, to prevent accidental electrical shock, or damage to components. 2. Remove FILTERS and set aside. 3. Remove two #8 screws (A) attaching BOTTOM COVER (B) to HOOD, tip BOTTOM COVER down and remove.
-
Page 8: Parts List
ELECTRIC PARTS PDUC-B153MRP0 7" Round duct plate FFTA-B006MRK0 Damper/Duct connector LX-BZB021MRE0 Screw RC-QZB025MRE0 Motor capacitor RTRN-B089MRE0 Isolation transfomer PSHEPB197MRR0 Key unit (KB-0333KS/KK) PSHEPB198MRR0 Key unit (KB-0333KW) HPNLCB215MRF0 Control panel (KB-0333KS/KK) HPNLCB216MRF0 Control panel (KB-0333KW) LX-BZB022MRE0 Screw LX-BZB023MRE0 Screw LX-CZB036MRE0 Ground screw... - Page 9 KB-0333KS KB-0333KK KB-0333KW HOOD PARTS Actual wire harness may be different from illustration.
- Page 10 KB-0333KS KB-0333KK KB-0333KW NOTES:...
- Page 11 KB-0333KS KB-0333KK KB-0333KW NOTES:...
- Page 12 KB-0333KS KB-0333KK KB-0333KW COPYRIGHT © 2005 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in retrieval systems, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without...
