To examine the battery and the

battery charger

1. Examine the battery for damages, for example
cracks.
2. Examine the battery charger for damages, for
example cracks.
3. Make sure that the connection cord of the battery
charger is not damaged and that there are no cracks
in it.
To clean the product, the battery and
the battery charger
1. Clean the product with a dry cloth after use.
2. Clean the battery and battery charger with a dry
cloth. Keep the battery guide tracks clean.
3. Make sure that the terminals on the battery and the
battery charger are clean before the battery is put in
the battery charger or the product.
To do a check of the trimmer line
Only use the recommended trimmer line. See the
illustration on the last pages of the manual.
1. Put the cord into the hole on the cover of the product
to make sure it follows the recommendation.
To replace the trimmer head
Note: To increase the life of the cord it can be soaked in
water for a couple of days before it is assembled. This
will make the cord tougher.
1. Press the snap-in clips on the trimmer head and
remove the trimmer head and trimmer line.
28
2. Pull out the line chute assembly.
3. Remove the nut that holds the trimmer head and the
drive disc.
4. Replace the trimmer head.
5. Install the nut.
6. Install the line chute assembly.
7. Install the trimmer head.
To sharpen the grass knife and
grass blade
WARNING: Stop the product. Use protective
gloves.
WARNING: Always discard a blade that is
damaged. Do not try to make a bent or
twisted blade straight and use it again.
• To sharpen the grass knife or grass blade correctly,
refer to the instructions that come with the cutting
attachment.
• Sharpen all edges equally to keep the balance.
• Use a single-cut flat file.
