Q-Light S80SOL Operating Manual

S80SOL / S100SOL / S125SOL
OPERATING MANUAL
Solar Cell LED Flashing Light
Thank you for purchasing Q.Light product. Please read this
manual carefully before installing this product for safe and long
use.
▪ High brightness LED flashing product of solar cell type which
needs neither power supply nor wiring.
▪ Apply a system which automatically detects the darkness of
environment.
▪ Excellent in diffusing signal light by employing unique
direct-diffusion system.
▪ Transparent water-proof cover is additionally installed on
solar cell in order to protect the solar cell perfectly from dust
, moisture and so on. It raise the effectness of battery charge
and extend the self-life.
▪ Material : Lens-AS, Body-ABS
▪ Flashes : 60-80/Min.
▪ Protection Class : IP54
1) S80SOL
General Specification
▪
Battery Battery
Model
Voltage current
2.4V 0.700Ah
S80SOL
▪ External View Drawing
2) S100SOL
General Specification
▪
Operating
Weight Color
Time
RED-R
30H 0.27Kg
AMBER-A
S80SOL
Battery Battery
Model
Voltage current
2.4V 0.700Ah
S100SOL
▪ External View Drawing
S100SOL
3) S125SOL
General Specification
▪
Battery Battery
Model
Voltage current
2.4V 0.700Ah
S125SOL
▪ External View Drawing
S125SOL
Operating
Weight Color
Time
RED-R
40H 0.41Kg
AMBER-A
Operating
Weight Color
Time
RED-R
50H 0.51Kg
AMBER-
A
